DRAPP 2016

Project Update

Presented by:

Ashley Summers

August 25, 2016

Click to edit Master title style Click to edit Master title style

Agenda

• Status of Image Processing
• Pilot Review Committee Results
• Interim and Final WMS
• Order Updates
• Planimetric Updates
• Timeline
• Next Steps
• Questions/Discussion

Click to edit Master title style Click to edit Master title style

Final Image Processing

Target Dates for DAT:

• Area 1: Late Oct
• Area 1a: Mid Oct
• Area 2: Aug 15 
• Area 3: Late Oct
• Area 4: Late Oct
• Area 4a: Early Sept

Click to edit Master title style Click to edit Master title style

Pilot Review Committee Results

• Area 1, 1a, 2, 4, and 4a were reviewed in person by a

committee on July 7th. Area 3 was reviewed in mid-August by interested partners on their own and comments were sent via email.

• Regarding the color, balance, contrast, level of snow, and

sharpness: reviewers felt that the imagery was acceptable and approved Sanborn to continue with final image processing.

• The committee highlighted the importance of:
• Not losing detail in the shadows, including in areas with steep

terrain

• Minimizing haze
• Minimizing radiometric differences between flight lines, including

areas that were captured on different dates

• Minimizing building lean

Click to edit Master title style Click to edit Master title style

Sample Imagery

Click to edit Master title style Click to edit Master title style

Sample Imagery

• Identify assets in shadows!

Click to edit Master title style Click to edit Master title style

Sample Imagery

• Identify

assets on roofs!

Click to edit Master title style Click to edit Master title style

Sample Imagery

• Roads unobscured by building lean!

Click to edit Master title style Click to edit Master title style

Interim & Final WMS

• Sanborn
• Google-hosted WMS/WMTS
• Imagery year - 2016
• Interim –As of this week, it’s seamless!
• Final (piecemeal) – available October 2016-January 2017
• Final (seamless) – available in January 2017
• Harris MapMart
• Imagery year(s) – 2002 to 2016 (final only)
• 2002 to 2014 - available now
• 2016 – available in winter/spring 2017

Click to edit Master title style Click to edit Master title style

Order Updates

• Clarifications on SIDs:
• Large orders (e.g. the entire project area) to be delivered in

the same tile grid as in 2014

• Small orders (e.g. just your city limits) to be delivered as

seamless mosaics

• A few exceptions…
• Order confirmations:
• Watch your email for order confirmations from Sanborn. You

will be asked to review and confirm:

• Extent(s)
• Format(s)
• Projections(s)
• Mailing Address

Click to edit Master title style Click to edit Master title style

Planimetric Update Project – Progress!

• What: updating the 2014 planimetric datasets using the

2016 imagery

• When: Q1 & Q2 of 2017; pick a vendor this fall
• Who: 25 potential partners, looking for more!
• Why: To leverage the data we’ve already captured, keep

data current and useful (remember: updates are MUCH cheaper than new collections from scratch)

• If your organization is interested, please reach out to me at

asummers@drcog.org or 303-480-6746.

Click to edit Master title style Click to edit Master title style Timeline

• Release DAT RFP– Aug



• Board approval of imagery vendor – Sept



• Board approval of DAT vendor – Oct



• Quotes and Letters of Intent – Nov



• Write vendor contracts – Nov/Dec



• Project officially starts – Jan/Feb



• Color Survey – Dec



• Custom Orders – Jan/Feb



• Flights- Mar/Apr



• First invoice



Click to edit Master title style Click to edit Master title style Timeline

• Area 3 flights – Jun



• Pilot Review Committee - Jul



• Interim imagery in WMS – Jun to Aug



• Final image processing – Jun to Oct
• Deliveries to partners – Dec/Jan
• Final invoice – Dec/Jan
• Final WMS – Jan/Feb

Click to edit Master title style Click to edit Master title style

Next Steps

• DRCOG/Sanborn/Harris
• Developing, reviewing the final imagery
• Partners
• Review the order confirmation email
• Use Sanborn’s 2016 interim WMS
• Contact Ashley about planimetric project participation (if

interested and haven’t made contact already)

Click to edit Master title style Click to edit Master title style

Discussion Questions

• How do we feel about extending the flight window for

future projects?

• Currently March 1 – April 15 for metro & plains, June for

moutains

• Consider October 1 – April 15 to maximize time in leaf-off

conditions

• Consider July/August for mountains to ensure snow free
• How do we feel about collecting some areas every other

project (rural eastern plains)?

Click to edit Master title style Click to edit Master title style

QU QUESTIONS IONS/COMM /COMMENT ENTS?
