Dolphin Pro HD+ Certification Location of equipment aboard ship ClimaticTests Climatic Setup Cyclic damp heat test Applicable standard: ......................... IEC 60068-2-30 test Db var.2 Number of cycles: ............................. 2

SLIDE 1

Dolphin Pro HD+ Certification

SLIDE 2

Location of equipment aboard ship

SLIDE 3

ClimaticTests

Climatic Setup

SLIDE 4

Cyclic damp heat test Applicable standard: ......................... IEC 60068-2-30 test Db var.2 Number of cycles: ............................. 2 Cycle duration: .................................. 24 hours

SLIDE 5

Cold test Applicable standard: .......................... IEC 60068-2-1 test Ab Temperature step: .............................. - 25°C ± 2°C Duration: ............................................. thermal stabilisation + 2 hours

SLIDE 6

Salt Mist test Applicable standard: .................................. IEC 60068-2-52 test Kb Number of spraying:: ................................. 4 Storage period in damp chamber:............... 7 days after each spraying, 28 days total Spray duration: ........................................... 2 hours Storage temperature: .................................. 40°C ± 2°C Storage Humidity : ..................................... 93% +2%/-3%

SLIDE 7

Vibration Tests

Wide Band Random Test Applicable standard: .......................... IEC 60068-2-64 test Fh Frequency bandwidth: ........................ from 3 to 100 Hz Overall level: ...................................... 1 grms Duration: ............................................. 2.5 hours per axis Sine survey test Applicable standard: .......................... IEC 60068-2-6 test Fc Frequency bandwidth: ........................ from 2 to 100 Hz Sweep rate:.......................................... 1 oct/min Number of sweeps: ............................. 2 (initial and final)

SLIDE 8

Wide Band RandomTest

SLIDE 9

Wide Band RandomTest

SLIDE 10

Sine Survey Test

SLIDE 11

EMC Tests

SLIDE 12

Radiated emission setup Conducted emission setup

SLIDE 13

Conducted Emission Results Radiated Emission Results

SLIDE 14

Radiated Immunity test setup

SLIDE 15

ESD test setup Conducted low frequency test setup Surge test setup FastTransient test setup

SLIDE 16

Low Voltage directive 72/23/EEC
Standard of test EN 60335-1 and EN 60335-2-29
DNV specification :
Insulation Resistance Test
High voltage Test
IP 22

SafetyTests

SLIDE 17

Directives : « Marine Equipment Directive (MES) » - 96/98/EC « Electromagnetic Compatibility Directive (EMC) » - 89/336/EEC « Low Voltage Directive (LVD) » - 72/23/EEC Standards specified in the DNV – Standard for certification 2.4 – April 2006 : Climatic : IEC 60068-2-30 test Db & IEC 60068-2-1 test Ab et Ad & IEC 60068-2-52 test Kb Vibration : IEC 60068-2-6 test Fc & IEC 60068-2-64 IP : test IEC publication N°60529 EMC : EN 55016-2-1:2009, EN 55016-2-1/A1:2011, CISPR 16-2-1 am2:2013 EN 55016-2-3:2010 + EN 55016-2-3/A1:2010 IEC 61000-4-3:2006 + A1:2007 + A2:2010 IEC 61000-4-2:2008 IEC 61000-4-6:2013 IEC 61000-4-5:2005 IEC 61000-4-4:2012 DNV standard complementary tests: DNV § 3.4 Power supply failure DNV § 3.5 Power supply variation DNV § 3.14.4 Conducted Low Frequency Immunity Test

Products Compliant with the DNV Standard
