Distributed Training

Khoa Le & Somin Wadhwa

Background

The Problem?

Goto Solution: Distribute Machine Learning Applications to Multiple Processors/Nodes

Traditional Machine Learning Task

Distributed Machine Learning Task

Obvious solution:

• Utilize Tensorflow’s native support for Distributed Training.

Issues:

• New concepts….but not a lot of documentation!
• Simply didn’t scale well.. :(

Data Parallel Approach:

Updating gradients: Parameter Server Approach

• What should be the right ratio of workers/parameter servers?
• Increased complexity leads to increase in the amount of information being

passed on...

Better way to update gradients: Ring-AllReduce

Horovod:

• Created a standalone package based on Baidu’s Ring-Allreduce algorithm,

fully integrated with Tensorflow.

• Replace the actual Ring-Allreduce algorithm with NVIDIA’s native NCCL (i.e

Ring-Allreduce across multiple machines.

• Added support for models that fit inside a single server, potentially on multiple

GPUs, whereas the original version only supported models that fit on a single

• GPU. (How??)
• API improvements.

Benchmarking:

Motivation for CROSSBOW

• To reduce training time, systems

exploit data parallelism across many GPUs to speed up training.

• How: parallel synchronous SGD.

Motivation for CROSSBOW

• To utilise many GPUs effectively, a

large batch size is needed.

• Why: communication overhead to

move data to and from the GPU dominates if batch size is too small

Motivation for CROSSBOW

• However, large batch sizes reduce

statistical efficiency.

• Why: small batches ensure faster

training and are more likely to find solutions with better accuracy

• Typical solutions: dynamically adjusting batch sizes, or other hyper-

parameters such as learning rate, momentum

• Not always work well because of time consuming model-specific methodology
• Need a DL system that can effectively trains with small batch sizes (2-32),

while still scaling to many GPUs => CROSSBOW: single-server, multi-GPU DL system that improve statistical efficiency when increasing the number of GPUs, irrespective of the batch size.

Motivation for CROSSBOW

Key contributions of CROSSBOW

• Synchronous model averaging
• Auto-tuning the number of learners
• Concurrent task engine

SMA with Learners (Important Concepts)

• Learner: an entity that trains a

single model replica independently with a given batch size

• In contrast with parallel S-SGD,

model replicas with learners evolve independently because they are not reset to a single global model after each batch

Parallel Synchronous SGD VS SMA with learners

SMA with Learners (Important Concepts)

• Synchronize local model of learners

by maintaining a Central Average Model

• Prevent learners from diverging by

applying a Correction to the model

• Use momentum to make the central

model converge faster than the learners

SMA with Learners (Important Concepts)

• Input/output
• Initialization
• Iterative Learning process
• Update to central average model

SMA with Learners (Algorithm)

• To achieve high hardware utilisation,

we can execute multiple learners per GPU

• Local Reference Model VS Central

Average Model

SMA with Learners (Expansion)

CROSSBOW System Design

• Must share GPU efficiently
• Decide on # of learners/GPU at runtime
• Global SMA synchronization needs to

be efficient

• Data pre-processors: prepares

training dataset into batches

• Task manager: controls the pools of

model replicas, input batches and learner streams

• Task scheduler: assigns learning

tasks to GPUs based on the available resources

• Auto-tuner

SMA with Learners (Crossbow Implementation)

SMA with Learners (Crossbow Implementation)

• Learner Streams: hold a learning task

and a corresponding local synchronization task

• Synchronization Streams: holds a

global synchronization task

• Overlaps the synchronisation tasks

from one iteration with the learning tasks of the next

SMA with Learners (Crossbow Implementation)

• Concurrency!
• Use All-reduce (hello Horovod!) for

inter-GPU operations: evenly distributes the computation of the update for the average model among the GPUs.

• Schedule new learning tasks on a first-

come-first-serve basis

SMA with Learners (Crossbow Implementation)

Choosing the number of learners

• Too few, a GPU is under-utilised, wasting

resources

• Too many, the execution of otherwise

independent learners is partially sequentialized on a GPU, leading to a slow-down => Tune the number of learners per GPU based on the training throughput at runtime

Tuning Learners (CROSSBOW Implementation)

• Auto-tuner: measures the training

throughput by considering the rate at which learning tasks complete, as recorded by the task manager

• Server with homogeneous GPUs,

measure only the throughput of a single GPU to adapt the number of learners for all GPUs

• Adding a learner to a GPU requires

allocating a new model replica and a corresponding learner stream

• Places temporarily a global execution

barrier between two successive iterations

• Also locks the resources pools,

preventing access by the task scheduler or manager during resizing

Tuning Learners (CROSSBOW Implementation)

Memory MGMT (CROSSBOW Implementation)

• CROSSBOW uses double buffering to create a pipeline between data pre-

processors and the task scheduler

• Offline memory plan to reuse the output buffers of operators using reference

counters, which reduces the memory footprint of a learner by up to 50%

• For multiple learners/GPU, enables the sharing of some of the output buffers

among learners on the same GPU using an online memory plan to avoid

• ver-allocate memory

Scalability Results

Statistical Efficiency VS Hardware Efficiency

Selecting number of learners

SMA vs other

Synchronization efficiency

• Pros:
• It introduces an alternative synchronization strategy (SMA), which allows training

with small batch size to achieve better hardware efficiency

• System design provides efficient concurrent execution of learning and

synchronisation tasks on GPUs

• Cons:
• It lacks automatic differentiation and other more advanced user primitives when

compared to TensorFlow

• It’s only tested for a single multi-GPU server. Distribution of CROSSBOW across

cluster would see more challenges, such as heterogeneous resources.

Imperative Programming:

• Caffe
• TensorFlow (sort of….mixture of both)

Declarative Programming:

• NumPy
• Matlab

MXNet (mix-net) Programming Interface:

• Symbol: Used to generate compute graph (compositions of symbol range

from simple operators to complex ConvLayers).

• Supports auto-diff, in addition to load, save, visualize etc.

MXNet (mix-net) Programming Interface:

• NDArray: Computations work seamlessly with the Symbol.
• Fills the gap between declarative symbolic expression & the host language.
• Complex symbolic expressions are often evaluated efficiently because MXNet

also uses lazy execution of NDarray. (So?)

MXNet (mix-net) Programming Interface:

• K-V Store: Distributed key-value store for data-sync over multiple nodes.
• Weight updating function is registered to the KVStore.
• Each worker repeatedly pulls the newest weight from the store.
• Pushes out the locally computed gradient.

MXNet Implementation:

• Graph Computation: Suggest straightforward implementations like at

inference time, only forward pass is needed, to extract features we can simply skip the last layers, multiple operators can be grouped into one etc.

• Memory Allocation: Simple idea, reuse non-intersecting variables. To reduce

complexity in determining such an allocation, use of a heuristic is proposed.

Discussions
