` Discovery of Green Fluorescent Protein, GFP Osamu Shimomura Ruins of the Medical College of Nagasaki, 1945 Shigeo Hayashi, 1945 Prof. Shungo Yasunaga (1911-1959) Nagasaki University Prof. Yoshimasa Hirata (1915-2000) Nagoya University

slide-1
SLIDE 1

Discovery of Green Fluorescent Protein, GFP

Osamu Shimomura

`

slide-2
SLIDE 2

Ruins of the Medical College of Nagasaki, 1945

Shigeo Hayashi, 1945

slide-3
SLIDE 3
  • Prof. Shungo Yasunaga (1911-1959)

Nagasaki University

slide-4
SLIDE 4
  • Prof. Yoshimasa Hirata (1915-2000)

Nagoya University

slide-5
SLIDE 5

Cypridina hilgendorfii

Luciferase

1 mm

Cypridina hilgendorfii

slide-6
SLIDE 6

Extraction of Cypridina luciferin

500g dried Cypridina powder Vacuu m pump

H2 gas

Red-heated Cu-fragments

slide-7
SLIDE 7

Crystals of Cypridina luciferin (1956)

slide-8
SLIDE 8

Luminescence Reaction of Cypridina Luciferin

Cypridina luciferin Oxyluciferin Light Luciferase and O2 Kishi et al., 1966

slide-9
SLIDE 9

Hikawa-Maru leaving Yokohama, Aug. 1960

slide-10
SLIDE 10

Hikawa-Maru leaving Yokohama, Aug. 1960

slide-11
SLIDE 11
  • Prof. Frank H. Johnson (1908-1990)

Princeton University

slide-12
SLIDE 12

Friday Harbor, 1961

slide-13
SLIDE 13

Aequorea aequorea

5

5 cm

slide-14
SLIDE 14
  • Univ. of Washington, Friday Harbor Laboratories, 1961
slide-15
SLIDE 15

Aequorea aequorea

In Daylight Luminescence in Dark

slide-16
SLIDE 16

Basic Strategy for the Extraction

  • f Bioluminescent Substances

A bioluminescent substance in light organs must be solubilized and extracted under a condition that reversibly inhibits the emission of light.

slide-17
SLIDE 17

Extracti

  • n of

Aequori n

Tissue of light organ (rings) Weak light pH 4 buffer Filtration Cell-free extract (pH 4) No light NaHCO3 Cell-free extract (neutral pH) Weak light Ca2+ or sea water Bright light

slide-18
SLIDE 18

Extraction of Aequorin and GFP

Rings of jellyfish (tissue of light organs) Shake in saturated (NH4)2SO4 Squeeze through gauze Filtration Granular light organs Shake in EDTA solution Filtration Crude aequorin solution Purification Aequorin and GFP

slide-19
SLIDE 19

Blue-fluorescent compound AF-350 To obtain 1 mg of AF-350, about 150 mg of aequorin is needed, requiring to collect and process 50,000 jellyfish (2.5 tons) in one summer (2,000-3,000 jellyfish per day). Urea Aequorin AF-350

2-mercaptoethanol

slide-20
SLIDE 20

Jellyfish Collectors (1974)

slide-21
SLIDE 21
  • Dr. Johnson collecting jellyfish
slide-22
SLIDE 22

. My family collecting jellyfish

slide-23
SLIDE 23

Cutter

Jellyfish Ring-cutter (made by Frank Johnson)

slide-24
SLIDE 24

Test-run of ring-cutters by Johnsons,1968

slide-25
SLIDE 25

Cutting rings

slide-26
SLIDE 26

Extraction of aequorin

slide-27
SLIDE 27

Structure Elucidation of Coelenterazine

AF-350 (Coelentramine) Coelenteramide Coelenterazine Cypridina oxyluciferin Cypridina luciferin

slide-28
SLIDE 28

Luminescence and Regeneration of Aequorin

LIGHT

465 nm

slide-29
SLIDE 29

Aequorin Luminescence with GFP

509 nm

Green Light

slide-30
SLIDE 30

GFP Crystals

Photo by Dr. Shinya Inoue

slide-31
SLIDE 31

Isolation of GFP Chromophore GFP (100 mg)

Denature at 90 °C Digest with papain Extraction with butanol at pH 1 TLC purification

Isolated chromophore (0.1 mg)

FEBS Lett. 104, 220-2 (1979)

slide-32
SLIDE 32

Chromophore of GFP

NH2 COOH G

GFP

chromophore

Ordinary Fluorescent Proteins GFP

Shimomura, 1979 Cody rt al, 1993 Amino acid residue

slide-33
SLIDE 33

Acknowledgments

I thank the many collaborators and colleagues who helped our study of aequorin and GFP, and the NSF and NIH for financial support

.
