Development and deployment of integrated attribute based access control for collaboration

kjk@internet2.edu

Collaborations and Virtual Organizations

• IdM is a critical dimension of collaboration, crossing many

applications and user communities

• Virtual organizations represent critical communities of

researchers sharing domain resources and applications as well as general collaboration tools. Providing a unified identity management platform for collaboration is essential in a multi-domain, multi-tool world.

• Lots of activities in domesticating applications to work in a

federated world, moving from tool-based identity to collaboration-centric identity.

kjk@internet2.edu

Collaboration Platform

• Integrated set of collaboration apps (wikis, listprocs, CVS,

file share, calendaring, etc)

• Integration of at least identity and access control via group

memberships

• Integration with domain science apps
• Integration of content and meta-data is harder
• Repackages successful approaches for a collaborative/

project/VO setting

• Federated identity, group management, directories, and security

token services (aka credential convertors)

kjk@internet2.edu

Collaboration Infrastructure (COIN)

• Dutch National Collaboration Infrastructure
• Domesticated tools -Adobe Connect; Alfresco; Foodle;

Filesender; Confluence; WSO2 mashup server; OpenFire; Drupal; KnowledgeTree, Sympa and Limesurvey

• Domesticated services -Google Apps; MyExperiment.org;

Twitter; PubMed

• Integration across VO, institution and third-party domains
• Workflow
• Grid integration

kjk@internet2.edu

Domestication of applications

• The work of re-factoring applications to use the emergent

identity services infrastructure

• Begins with federated identity and authentication, use of

directories; gains a lot from group management for access control, etc

• Needs a fine grain set of authorization tools down the road
• Domesticated apps can receive IdM attributes via LDAP,

SAML, X.509, SQL, Kerberos PAC, and maybe all of the above

kjk@internet2.edu

Typical activities in collaboration management

• Add or remove people from groups
• Create new subgroups, identify overlapping memberships,

etc.

• Permit or deny access control to wiki pages, calendars,

computing resources, version control systems, etc

• Add people to mailing lists, wikis, etc
• Create and delete/archive users, accounts, keys
• Identify group membership on a given date

kjk@internet2.edu

COManage Elements

Dashboard Shib SP Grouper STS Shib IdP LdapPC Including provisioning

Applications

Data Store

kjk@internet2.edu

What’s in a COmanage data store

Enterprise Attributes Project/VO attributes Federated Id PI groups Enrolled classes Wiki editing permissions Display name Instrument permissions Citizenship VO certificates Enterprise affiliation …

kjk@internet2.edu

Grouper

• A general purpose, extensible, open-source group

management tool

• In production at many institutions in the US and overseas
• Core national infrastructure service in several countries
• Manages groups of things – people, devices, processes
• Has GUI, people picker, group math, inheritance,

delegation, provisioning and deprovisioning, etc.

• Stores values in LDAP directory
• Aimed at spectrum from power user to collabmin,

sysadmin and enterprise IdM.

kjk@internet2.edu

Security Token Service

• Converts the form of an existing credential or packs a set
• f attributes into a new credential
• Presents external security information to an application or

service in the lingua of the app/service

• Conversions – SAML into X.509, SAML into Kerberos,

SAML to LDAP, etc.

• Mythical in a single comprehensive package; legion in

individual instances

kjk@internet2.edu

What forms does COmanage take?

• Usually as an assembled set of services
• A dashboard, directory product, Shibboleth IdP and SP,

Grouper, and a set of applications provisioned on other servers

• On an enterprise level to serve its collaborations and

VO’s, within a large VO, or at a federation level to serve a national community

• Can also be a VM, a VM in the cloud, or a service with the

applications in the cloud.

• Can be embedded in a science portal or gateway

kjk@internet2.edu

Flows of attributes - 1

Enterprise

Data Store

Project comanage

Relying Party

Enterprise

kjk@internet2.edu

Use cases it enables

• A student adds a class and is immediately enabled to use

the VO wiki; a student drops the class and is immediately disabled from using the VO instruments

• A resource prohibited from use by foreign nationals is

protected

• International privacy laws are adhered to
• Anonymous access is enabled but limited to those

authorized to participate

• Security is commensurate with the risks
