SLIDE 1
Photo credits: Brook Moyers, Hoekstra lab, Whitehead + Crawford 2006
Detecting adaptive differentiation in structured populations with - - PowerPoint PPT Presentation
Detecting adaptive differentiation in structured populations with - - PowerPoint PPT Presentation
Detecting adaptive differentiation in structured populations with genomic data and common gardens Emily Josephs @emjosephs Photo credits: Brook Moyers, Hoekstra lab, Whitehead + Crawford 2006 Detecting local adaptation requires knowing about
SLIDE 2
SLIDE 3
Lowland maize Highland maize Rice varieties
Detecting local adaptation requires knowing about (1) genetic variation in traits
Photo credits: IRRI, Childs et al., Poland et al Northern leaf blight in maize
- Pop. A
- Pop. B
Common garden
SLIDE 4
Lowland maize Highland maize Rice varieties
Detecting local adaptation requires knowing about (1) genetic variation in traits (VA)
Photo credits: IRRI, Childs et al., Poland et al Northern leaf blight in maize
- Pop. A
- Pop. B
Common garden Crosses to get
VA
SLIDE 5
Lowland maize Highland maize Rice varieties
Detecting local adaptation requires knowing about (1) genetic variation and (2) relatedness
Photo credits: IRRI, Childs et al., Poland et al Northern leaf blight in maize
- Pop. A
- Pop. B
Divergence time
SLIDE 6
Lowland maize Highland maize Rice varieties Photo credits: IRRI, Childs et al., Poland et al Northern leaf blight in maize
- Pop. A
- Pop. B
Detecting local adaptation requires knowing about (1) genetic variation and (2) relatedness
SLIDE 7
Qst- Fst comparisons test for excess trait divergence
Prout and Barker 1993, Spitze 1993, Whitlock 1999
btw-pop genetic var. for trait total genetic var. for trait
Qst
btw-pop neutral genetic var. total neutral genetic var.
Fst
vs.
SLIDE 8
Qst- Fst comparisons test for excess trait divergence
Prout and Barker 1993, Spitze 1993, Whitlock 1999
btw-pop genetic var. for trait total genetic var. for trait
Qst
btw-pop neutral genetic var. total neutral genetic var.
Fst =
SLIDE 9
Qst- Fst comparisons test for excess trait divergence
Prout and Barker 1993, Spitze 1993, Whitlock 1999
btw-pop genetic var. for trait total genetic var. for trait
Qst
btw-pop neutral genetic var. total neutral genetic var.
Fst >
SLIDE 10
Lots of datasets that have genomes + phenotypes from diversity panels
SLIDE 11
How can we systematically detect local adaptation... In quantitative traits? In gene expression? For GxE?
SLIDE 12
Relatedness between populations can be summarized with a kinship matrix.
A1 A2 B1 B2 A1 A2 B1 B2
Lighter colors = more related
SLIDE 13
The eigenvectors of the kinship matrix (PCs) summarize relatedness
SLIDE 14
Size
How do PCs relate to traits?
SLIDE 15
Size
A correlation btw PC & trait can be consistent with drift
SLIDE 16
Size
A correlation btw PC & trait can be consistent with drift
SLIDE 17
Modelling the slope expected due to drift
Slope of trait against PC m
Size
SLIDE 18
Modelling the slope expected due to drift
Slope of trait against PC m Mean slope
Size
SLIDE 19
Amount of relatedness explained by PC m
Modelling the slope expected due to drift
Slope of trait against PC m Mean slope
Size
SLIDE 20
Amount of relatedness explained by PC m
Modelling the slope expected due to drift
Can estimate VA from a subset of PCs
Slope of trait against PC m Mean slope
Size
SLIDE 21
Selection can increase trait divergence
Size
Amount of relatedness explained by PC m
Can estimate VA from a subset of PCs
Slope of trait against PC m Mean slope
SLIDE 22
Selection can increase trait divergence
Size
Amount of relatedness explained by PC m
Can estimate VA from a subset of PCs
Slope of trait against PC m Mean slope
SLIDE 23
Size
Slope of trait against PC m Mean slope Amount of relatedness explained by PC m
Testing for diversifying selection
Can estimate VA from a subset of PCs
Number of PCs used to estimate VA
SLIDE 24
How can we systematically detect local adaptation... In quantitative traits? In gene expression? For GxE?
SLIDE 25
Detecting local adaptation in maize
Wikipedia
SLIDE 26
Detecting local adaptation in maize
240 domesticated inbred maize lines (Flint-Garcia et al. 2005). Whole genome sequence data (Panzea). 22 traits measured in common garden.
SLIDE 27
The kinship matrix of 240 maize lines
Lighter colors = more related Individuals Individuals
SLIDE 28
The kinship matrix of 240 maize lines
Lighter colors = more related Individuals Individuals
PC 2 PC 1
SLIDE 29
Neutral expectations of relationship between PC and trait
Kernel number
SLIDE 30
Divergence along PC1 consistent with drift
Kernel number
SLIDE 31
Flowering time
Neutral expectations of relationship between PC and trait
SLIDE 32
Adaptive divergence in flowering time along PC 1
FDR < 0.05
Flowering time
SLIDE 33
Signatures of adaptation across traits
Josephs et al. 2018 Genetics
p = White circles mean FDR < 0.05
SLIDE 34
How can we systematically detect local adaptation... In quantitative traits? In gene expression? For GxE?
SLIDE 35
Testing for selection on gene expression
Gene expression data (RNAseq) for 208 maize lines in 7 tissues
Kremling et al. 2018 Jennifer Blanc
SLIDE 36
How many genes show evidence of selection on expression?
Kernel
Jennifer Blanc
SLIDE 37
Which tissues show strongest evidence of adaptation?
Kernel Leaf (day) Leaf (night)
Jennifer Blanc
SLIDE 38
Evidence of local adaptation for gene expression
Jennifer Blanc Blanc et al. in prep
Leaf night (day 8) Leaf night (day 26) Leaf day (day 8) Leaf day (day 26) 3rd leaf tip 3rd leaf base Kernel Seedling shoot Seedling root
Number of genes that show evidence of selection on expression
SLIDE 39
How can we systematically detect local adaptation... In quantitative traits? In gene expression? For GxE?
SLIDE 40
The environment shapes traits
Clausen, Keck, and Heisey
SLIDE 41
Genetic variation for plasticity (‘GxE’)
Clausen, Keck, and Heisey
SLIDE 42
- A. thaliana flowering time as a model for GxE
1001 Genomes Consortium, Kathleen Donohue
SLIDE 43
Flowering time at 16oC is locally adapted
p = 0.0002 Bonferoni p = 0.0015
SLIDE 44
Flowering time at 10oC is also locally adapted
p = 0.006 Bonferoni p = 0.03
SLIDE 45
Using the reaction norm to measure plasticity
Temperature Days to flower
SLIDE 46
Using the reaction norm to measure plasticity
Temperature Days to flower
SLIDE 47
Variation in reaction norm consistent with drift
p = 0.03 Bonferoni p = 0.16 Later flowering at 16oC than 10oC Earlier flowering at 16oC than 10oC Reaction norm
SLIDE 48
How to deal with trait correlations?
SLIDE 49
How to deal with trait correlations?
SLIDE 50
We can use PC + trait relationships to detect adaptation
SLIDE 51
We can use PC + trait relationships to detect adaptation
Local adaptation shapes trait divergence
Flowering time
SLIDE 52
We can use PC + trait relationships to detect adaptation
Local adaptation shapes trait divergence These methods can be used in additional systems!!!
https://github.com/emjosephs/quaint
SLIDE 53
Thanks!
Jeremy Berg Jennifer Blanc Karl Kremling Ed Buckler Cinta Romay Kate Crosby Coop Lab Ross-Ibarra Lab Graham Coop Jeff Ross-Ibarra
SLIDE 54
The Josephs lab at Contact me! Josep993@msu.edu, http://JosephsLab.github.io/
SLIDE 55
We can use PC + trait relationships to detect adaptation
Local adaptation shapes trait divergence These methods can be used in additional systems!!!
https://github.com/emjosephs/quaint
SLIDE 56
Adaptive divergence along additional PCs
FDR < 0.05
Flowering time
SLIDE 57
What about detecting adaptation in genotypes that haven’t been phenotyped?
SLIDE 58
Testing for adaptation with polygenic scores
Polygenic score
Allele frequency Effect size At all GWAS loci Berg and Coop 2014
SLIDE 59
Evidence for polygenic adaptation in European maize
Josephs et al. 2018 Biorxiv
