Stephen E. Brock, Ph.D., NCSP EDS 250 Descriptive Statistics 1

1

Descriptive Statistics

Stephen E. Brock, Ph.D., NCSP California State University, Sacramento

2

Descriptive Statistics

Describes (or summarizes) data. Describes quantitatively (with numbers or graphs) how a particular characteristic is distributed among one or more groups of people. No generalizations beyond the sample represented by the data are made by descriptive statistics.

 However, if your data reflects an entire population, then the

data are considered to be population parameters.

 On the other hand, if your data represents a population

sample, then the data is considered a statistic that describes a

• sample. Inferential statistics are required to determine if the

samples statistics can be generalized back to the population.

3

Group Activity: Prepare to teach the following concepts.

What is the “mean” of a data set? What is the “standard deviation” of a data set? What are derived or “standard scores?” What is the “bell shaped curve?”

Stephen E. Brock, Ph.D., NCSP EDS 250 Descriptive Statistics 2

4

Preface: Preparing Data for Analysis

Scoring standardized test.

 Follow manual instructions  Have someone else double check 25% of the

protocols

Scoring self-developed measures.

 Establish reliability 5

Preface: Conducting Data for Analysis

Be careful and take your time. Work with a partner who can check your work. Break-up data entry sessions to make sure you avoid the errors caused by fatigue.

 Don’t try to get it all done in one sitting  Double check the work of others (e.g., research

assistants).

 Assuming, accurate data entry, there is no such a

thing as “bad data.”

Develop a coding system and set up a database. The structure of the database will depend upon the type of data being used.

6

Preface: Identify Scale of Measurement

Scale Properties E.G.

Nominal (to name) Data represents qualitative or equivalent categories (not numerical). Eye color, Gender, Race or ethnicity (could be a word in database, but…). Mode Ordinal (to order) Numerically ranked, but has no implication about how far apart ranks are. Grades (always a number in the database). Mode, Median Interval (equal) Numerical value indicates rank and meaningfully reflects relative distance between points on a scale Temperature (always a number in the database). Mode, Median, Mean Ratio (equal) Has all the properties of an interval scale, and in addition has a true zero point. Length, Weight (always a number in the database). Mode, Median, Mean

Determines what descriptive statistic will be used

Stephen E. Brock, Ph.D., NCSP EDS 250 Descriptive Statistics 3

7

Preface: Data Entry

Give each participant a subject # Data is generally placed in columns Codes for categorical and nominal data are determined.

 Including group membership (usually

coded as a group number).

8

Preface Coding Descriptive Data

Develop a way to code each of the following

• variables. Remember only nominal data can be

coded with words or letters, all other data must be quantified.

 Eye color  Grades  IQ scores  Weight  Gender  Art skill level  Temperature  Length  Ethnicity  Race results

9

A Sample Data Base

S# EC Gd IQ Wt Sx Art Eth RR 1 Bn 4 100 97 1 10 1 1 2 Bn 3 105 65 1 3 1 2 3 Bn 4 130 200 2 5 3 3 4 Bl 4 111 99 2 7 4 4 5 H 1 90 43 1 9 2 5 6 Bn 65 55 1 2 5 6 7 G 2 117 67 1 4 6 7 8 H 2 100 87 2 6 7 8 9 Bl 2 89 96 1 8 3 9 10 Bn 4 85 45 2 1 3 10

Stephen E. Brock, Ph.D., NCSP EDS 250 Descriptive Statistics 4

10

Preface: Coding Experimental Data

Develop a way to code each of the following

• variables. Remember only nominal data can

be coded with words or letters, all other data must be quantified.

 Group membership (ADHD Int, v ADHD Hyp v Bipolar Type 1)  Hyperactivity

11

A Sample Data Base

S# Group T-Score 1 1 60 2 1 50 3 1 55 4 2 71 5 2 78 6 1 65 7 2 88 8 2 70 9 2 89 10 2 85 S# Group T-Score 11 1 50 12 1 55 13 2 79 14 2 65 15 1 50 16 1 61 17 1 58 18 2 65 19 2 88 20 1 50 S# Group T-Score 21 3 79 22 3 65 23 3 80 24 3 71 25 3 78 26 3 65 27 3 88 28 3 70 29 3 61 30 3 90

12

Types of Descriptive Statistics

Univariate (single variable data set summaries)

 Measures of Central Tendency (location)  Measures of Variability (dispersion)  Measures of Shape (symmetry of the normal curve)  Measures of Relative Position (rank, standard score)

Bivariate (two data sets)

 Measures of Relationship

Stephen E. Brock, Ph.D., NCSP EDS 250 Descriptive Statistics 5

13

Measures of Central Tendency

Mode

 Determined by looking at a set of scores and seeing

which occurs most frequently.

 Not typically used, however, it is the only appropriate

statistic for nominal data.

14

Measures of Central Tendency

Median

 The point above and below which 50% of the scores

are found.

 Unlike the mode, may not be one of the obtained

results.

 e.g., if there are an even number of scores the median is the point halfway between the two middle scores  i.e., in “13, 25, 27, 45” the median = 26

 When an extreme score is a part of the data set the

median will not be the best estimate of the group’s performance.

 Appropriate for use when the data is ordinal. 15

Group Activity: Prepared to teach the following concepts.

What is the “mean” of a data set?

Stephen E. Brock, Ph.D., NCSP EDS 250 Descriptive Statistics 6

16

Measures of Central Tendency

Mean

 Most frequently used measure of central tendency  The arithmetic average of the scores  Appropriate for use when the data is interval or ratio. 17

Measures of Central Tendency

For example…

 Compute measures of central tendency for the

following data set of math standard scores

 96, 96, 97, 99, 100, 101, 102, 104, 195

 Mode = 96  Median = 100  Mean = 110.6

 What does each measure of central tendency tell you

about the data set?

 Mode = most frequently obtained score  Median = middle point of obtained range of scores  Mean = when a data set includes one or more extreme scores the mean will reflect the average performance of the group as a whole, but not the most typical result.

18

Measures of Variability

Range

 The difference between the highest and the lowest

score.

 A quick estimate of variability.

Stephen E. Brock, Ph.D., NCSP EDS 250 Descriptive Statistics 7

19

Measures of Variability

Variance

 The amount of spread among the scores  In a data set (35, 25, 30, 40, 30) with a mean of 32

the variance is obtained by doing the following:

 35-32 = 3  25-32 = -7  30-32 = -2  40-32 = 8  30-32 = -2  Because the sum of these scores is 0, to estimate the variance each number is squared (9+49+4+64+4 = 130)  130/5 (the number of cases) = 26  Mathematically, to say the variance is 26 is not a problem, but do we typically deal with squared units (do we ask a clerk if 100 squared $ is enough)?

20

Group Activity: Prepared to teach the following concepts.

What is the “standard deviation” of a data set?

21

Measures of Variability

Standard Deviation (SD)

 The square root of the variance returns the

variance to the metric of the obtained score.

 The most practical estimate of variability.  Small SD indicates the scores are close together

(little variability)

 What will this distribution “look” like?

 Large SD indicates the scores are far apart (large

variability)

 What will this distribution “look” like?

 If the distribution is normal, over 99% of the

• btained scores will fall with in + or – 3 standard

deviations from the mean.

Stephen E. Brock, Ph.D., NCSP EDS 250 Descriptive Statistics 8

22

Once upon a time . . .

One sunny Saturday morning, down by the banks, of the Hankie Pankie. A group

• f Woodchucks congregated with the

intent of competing in the international Woodchuck, wood-chucking competition. These are the results of the pounds of wood-chucked in one 24 hour period.

23

Compute Mean, Median, Mode, Range, Variance, Standard Deviation

Larry - 95 lbs Charles - 100lbs Vic - 125 lbs Bertha - 85 lbs Bunny - 90 lbs Chauncy - 95 lbs

24

Measures of Central Tendency and Variability

Mode: Most frequently occurring Median: Point above/below which 50% of scores occur Mean: The average of the scores Range: The difference between the highest and lowest scores Variance: Amount of spread among the scores. Standard Deviation: Measure of Variability of a distribution of test scores.

Stephen E. Brock, Ph.D., NCSP EDS 250 Descriptive Statistics 9

25

Group Activity: Prepared to teach the following concepts.

What is the “bell shaped curve?”

26

Measures of Shape

When population or sample scores on a particular characteristic are graphed, the shape of the “normal curve” resembles a bell. The majority of scores fall in the middle (near the mean), and a few scores fall at the extreme ends of the curve. The height of a “normal curve” will be determined by the variability of the scores.

27

Measures of Shape

The Normal (or bell shaped) Curve If a variable is normally distributed it falls in a normal or bell shaped curve. Characteristics

 50% of scores are above/below the

mean

 Mean, median, mode have the same

value (a reason for looking at all three)

 Most scores are near the mean. Fewer

scores are away from the mean.

 The same number of scores are found +

and - a standard deviation from the mean.

Stephen E. Brock, Ph.D., NCSP EDS 250 Descriptive Statistics 10

28

The Bell-Shaped Curve

29

Measures of Shape

Skewed Distributions Assumptions that form the basis for parametric inferential statistical analyses require a normal (or near normal) distributions.

 Non-parametric statistics are used when the

distribution is not “normal.”

Skewed distributions are asymmetrical (either positively or negatively). Examination of the mean, median, and mode will tell you if a distribution is skewed or not.

30

Symmetrical and Asymmetrical Distributions

Negatively Skewed Distribution Positively Skewed Distribution

A distribution with no skew (e.g. a normal distribution) is symmetrical A negatively skewed distribution has a longer tail to the left A positively skewed distribution has a longer tail to the right

Stephen E. Brock, Ph.D., NCSP EDS 250 Descriptive Statistics 11

31

Activity

Interpret these descriptive statistics Assuming these data are normally distributed, what do you think their respective bell shaped curves might look like?

Group N Mean Hyp. T-score Median T-Score SD Range ADHD Hyp 10 72 70 14.17 69 to 90 ADHD Int 10 55 50 22.79 45 to 61 Bipolar Typ 1 10 77 71 14.98 70 to 99

32

Group Activity: Prepared to teach the following concepts.

What are derived or “standard scores?”

33

Measures of Relative Position

Percentile Rank

 Percent of scores that fall at or below a given score  Appropriate for ordinal data, typically computed for

interval data.

 Ranks are much closer together at the center of the

distribution.

Standard Scores

 A derived score that reflects how far a score is from a

reference point (typically the mean)

 Z-Scores, # of SDs from the mean.  T Scores, a z score that has been transformed in some

way

 Difference between all scores are equal regardless of

location on distribution.

Stephen E. Brock, Ph.D., NCSP EDS 250 Descriptive Statistics 12

34

Measures of Relative Position

35

Measures of Relationship

Correlation

 Determine whether and to what degree a

relationship exists between two or more quantifiable variables

 Degree of relationship is expressed via the

correlation coefficient.

36

Measures of Relationship

Scatter Plots

Stephen E. Brock, Ph.D., NCSP EDS 250 Descriptive Statistics 13

37

Activity

Teaching Descriptive Statistics



Mean



Standard Deviation



Standard Score



Bell Shaped Curve

38

April 23

Data Analysis: Inferential Statistics



Read Educational Research Chapter 19.



Portfolio Element #10 Due: Identify resources that will assist you in analyzing data. These resources do not necessarily need to be CSUS resources. Portfolio entries could include student descriptions of the data analysis resources

• identified. Alternatively, any descriptive

handout(s) describing how to locate/use a given resource may be included.
