Demo Presentation O N E F I T S A L L Basic Parts of TAU System - - PowerPoint PPT Presentation

O N E F I T S A L L

Demo Presentation

O N E F I T S A L L

Basic Parts of TAU System

FIRMWARE

Is the software running inside the inverter Is programmed once at production time One covers many possible applications One manages all available inverters

CONFIGURATION

Inverter actions depend

• n the configuration

setup Is stored inside the inverter Done by the customer

INVERTER

Can drive one or two AC motors Available in different ratings (voltage and currents)

GUI

PC application for configuration change Friendly setup of a new application Easy troubleshooting

O N E F I T S A L L

O N E F I T S A L

Main Feature

TAU GENERATION TECHNOLOGY

Thought for maintenance Powerful Friendly & Easy Flexible

O N E F I T S A L L

Tau System Flexibility

Flexible assignment and configuration of all Inputs and of all Outputs (relays, fans, negative brake,..) in relation to the control variable (input pins, temperature of motors

• r inverters, working conditions)

The connector mapping is visible in the GUI for easy troubleshooting Graphical setup of throttle’s transfer characteristics of almost all types in the market Auto-set of motor control parameter for easy and quick motor tuning based on IEEE Standard AC Motor Mode Capability of building complex distributed control systems over CANopen data bus

O N E F I T S A L L

Friendly and Easy to use

Smoothly operable by not skilled people Significant reduction of time-to-system startup Significant reduction of time-to-market of your application Powerful logging of all sensible working variables System is fully configurable simply through the supplied GUI. The inverter behaviour is safe in every allowed configuration and the parameter change process is made friendly and easy to understand.

GUI

O N E F I T S A L L

THOUGHT for MAINTENANCE

GUI designed for EASY APPLICATION SUPPORT Friendly system setup

Easy fault finding and solving Clear fault description Powerful and configurable data logger Complete product tracking of factory’s data and inverter’s life

GUI

O N E F I T S A L L

Powerful Control Systems

State-of-the-art Motor Control Features Support for CAN OPEN and J1939 networks and for BMS applications Advanced Torque Control and Speed Control simply selectable via GUI Accurate differential control of Twin Drive Motors, quickly set via GUI Precise battery current estimation for Advanced State Of Charge (SOC) algoritm

O N E F I T S A L L

Cleaning Cleaning Machines Air Platform Scissor and Aerial Lifts Electric vehicle Electric Scooter and Karts Golf and Small City Cars Generic Electric Vehicle and UTV Lawn mower Lawn Mower Machines Ground support equipment Tractors Single Drive and Twin Drive Tow Tractors with advanced differential control of drive Hybrid system Traction and/or Generator Hybrid System Hydraulic pump Hydraulic Pump Systems Fans drive Air Compressors Fans Drive Systems Material handling Counterbalanced Single and Twin Drive Lift Trucks with advanced differential control of drive Order Picking Trucks

Applications covered by standard products

O N E F I T S A L L

Applications covered by standard products

For any not covered application (STANDALONE, MASTER or NOT GENERIC SLAVE) SME engineers are at disposal for developing a custom product.

Roadmap to the future Generic Slave AC

Control of all kinds of PM Motors and its integration in the TAU SYSTEM

Inverter driving AC motor/s, acting as Slave in a CAN network with PC/PLC as Master

On Request

Non Standard Applications
