slide-1
SLIDE 1

Demand Response Availability Data System (DADS):

Phase I and II

John Moura NERC Staff

slide-2
SLIDE 2

Presentation Goals

Introduce the Demand Response Availability System (DADS) to industry stakeholders and provide instruction on how to complete the required data forms for the Phase I pilot program Solicit feedback from workshop participants and answer program or

  • rganization-specific questions. Additionally, encourage continued feedback,

comments, and suggestions throughout the Phase I pilot program Provide an overview of the on-going efforts at NERC to collect historical performance data on demand response

slide-3
SLIDE 3

NERC & Demand Response

slide-4
SLIDE 4

About NERC

  • Develop & enforce reliability standards
  • Analyze system outages and near-misses

& recommend improved practices

  • Assess current and future reliability

International regulatory authority for electric reliability in North America

slide-5
SLIDE 5

NERC & Demand Response

  • Demand Response is an important component in the
  • verall portfolio of resources required to reliably meet the

increasing demands for electricity in North America.

  • In order for NERC to carry out its responsibility to ensure

the reliability of the North American bulk power system, NERC must be able to:

  • Evaluate and understand the benefits of Demand

Response and its impact on reliability.

  • Quantify the performance of demand-side resources
  • Assess the overall characteristics of Demand

Response as it relates to bulk power system planning and operations

slide-6
SLIDE 6

NERC & Demand Response

  • Recommendations and Conclusions in the 2008 and

2009 Long-Term Reliability Assessment

  • Additional demand-side resources could be an effective
  • ption to preserve system reliability over the next ten
  • years. In addition, they may facilitate the integration of

renewable and variable resources.

  • Potential reliability impacts of broad-scale use of Demand

Response resources must be better understood by industry and regulators.

  • Better measurement and verification techniques will be

needed to measure and track actual availability of Demand Response under various system conditions.

slide-7
SLIDE 7

NERC & Demand Response

  • NERC acts on these responsibilities through

several activities:

  • Long-term assessment of Demand Response projections
  • Long-Term Reliability Assessment
  • Short-term assessment of Demand Response projections
  • Seasonal (Summer/Winter) Reliability Assessments
  • Other assessments or evaluations of Demand Response
  • Demand-Side Management Task Force (completed)
  • Integration of Variable Generation Task Force
  • Reliability Impacts of Climate Change Initiatives
  • Demand Response Data Task Force
  • NERC Special Reliability Assessments
slide-8
SLIDE 8

NERC & Demand Response

  • Current Issue
  • No feedback loop
  • Only projections are assessed
  • Potential concerns of resource

availability

  • Measure and validate

projections

  • Current activities
  • Demand Response Availability

Data System

  • Post-Seasonal Reliability

Assessment

Dem and Response Data

Projections Historic

Market Participation Event

Dem and Response Availability Data System

Seasonal Long-Term

NERC Reliability Assessm ents Program Types Program Types

Capacity Energy Reserves Regulation Capacity Supports EIA- 411 submission

Current and Future Demand Response Data Collection Mechanisms

Future Current

slide-9
SLIDE 9

2010 Long-Term Reliability Assessment

Impacts of Resource Mix Changes to System Stability and Frequency Response Changing Resource Mix Transmission Operations with Vital Transmission Out-of-Service During Upgrades Diminishing Frequency Response Uncertainty of Sustained Participation in Demand Response Consistent Modeling of Remote Resources

Likelihood

High Low

Consequence

High Low

Preliminary Results—Not for Citation

slide-10
SLIDE 10

Demand Response Availability Data System (DADS) Overview

slide-11
SLIDE 11

What is DADS?

DADS = Demand Response Availability Data System

DADS is a system that is aimed to collect demand response event and market participation information to measure the ongoing influence of demand response on reliability. The DADS will enable NERC to receive, manage, assess and disseminate data on Demand Response Programs, products and services administered by retail and wholesale entities throughout North America. DADS will serve as a resource to the industry for information about Demand Response participation and performance.

slide-12
SLIDE 12

DADS Phase I & II Report

  • The Demand Response Availability Data System

Phase I and II report was approved by the NERC Planning Committee in September 2009.

  • The report outlines the functional requirements of the

Phase I and II system

  • Provides a framework for a mandatory data request

to be issued by NERC

  • Identifies the required reporting parties, as well as the

data to be collected by the system

slide-13
SLIDE 13

DADS Phase I & II

DADS Phase I & II Phase Implementation Year Responsible Entities Reporting Requirement Demand Response Type(s) Reporting Frequency System Design

I 2010 BA, LSE, DP, PSE Voluntary Dispatchable, Controllable Semi - Annual In-house / Excel Workbooks II 2011 BA, LSE, DP, PSE Mandatory Dispatchable, Controllable Semi - Annual Third Party Software Developer/ Web App

  • Phase I & II will focus on reliability or event related

Demand Response which is both dispatchable and controllable.

  • Phase I is a voluntary pilot program.
  • Phase II is a mandatory reporting system
slide-14
SLIDE 14

DADS Annual Reporting Cycle

Phase I & II DADS Data Collection & Deliverable Schedule Date Action April 1st – September 30th Summer DADS reporting period December 15th Summer DADS data due to NERC October 1st – March 31st Winter DADS reporting period June 15th Winter DADS data due to NERC

NERC has restructured the reporting timeframe and deliverable dates.

  • Semi-annual reporting will be implemented

(versus the previously structured quarterly reports). The reporting periods are designed around summer and winter seasons—the summer reporting period will occur from April 1st to September 30th and the winter reporting period will occur from October 1st to March 31st. Data will be due to NERC approximately 2 1/2 months after the close of the reporting period.

slide-15
SLIDE 15

DADS Annual Reporting Cycle

DADS Responsible Entities Demand Response Data Task Force

Jan Feb Mar Apr Jun Jul Aug Sep Oct Nov May Dec

Reporting Period for Q1 Reporting Period for Q2 Reporting Period for Q3 Reporting Period for Q4 Data Gathering for Q1 Data Gathering for Q2 Data Gathering for Q3 Q1 DADS data due Q2 DADS data due Q3 DADS data due Q1 Summary Report Published

Quarter 1 (Q1) Quarter 2 (Q2) Quarter 3 (Q3) Quarter 4 (Q4)

Q2 Summary Report Published Receive Q1 DADS data Receive Q1 DADS data Receive Q1 DADS data

DADS Annual Reporting Schedule

Q1 Data Processing Q2 Data Processing Q3 Data Processing

DADS Responsible Entities Demand Response Data Task Force

Jan Feb Mar Apr Jun Jul Aug Sep Oct Nov May Dec

Reporting Period for Q1 Reporting Period for Q2 Reporting Period for Q3 Reporting Period for Q4 Data Gathering for Q1 Data Gathering for Q2 Data Gathering for Q3 Q1 DADS data due Q2 DADS data due Q3 DADS data due Q1 Summary Report Published

Quarter 1 (Q1) Quarter 2 (Q2) Quarter 3 (Q3) Quarter 4 (Q4)

Q2 Summary Report Published Receive Q1 DADS data Receive Q1 DADS data Receive Q1 DADS data

DADS Annual Reporting Schedule

Q1 Data Processing Q2 Data Processing Q3 Data Processing

DADS Responsible Entities Demand Response Data Task Force

April May Jun July Sep Oct Nov Dec Jan Feb Aug Mar

Reporting Period for Summer Reporting Period for Winter Data Gathering Summer Summer DADS data due Summer Report Published

Summer Winter

Receive Summer DADS data Receive Winter DADS data

DADS Annual Reporting Schedule

Summer Data Processing Winter Data Processing Winter DADS data due Data Gathering Winter Winter Report Published

slide-16
SLIDE 16

Responsible Reporting Entities

  • Responsible Entities will be required to maintain Demand

Response data in DADS. A Responsible Entity is defined as a NERC Registered Entity that either dispatches a Demand Response Resource and/or administers a Demand Response Program, product or service. Responsible Entities for DADS data submittals are limited to:

NERC Responsible Entities for DADS Data Function Name Responsible Entity Balancing Balancing Authority Distribution Distribution Provider Load-Serving Load-Serving Entity Purchasing-Selling Purchasing-Selling Entity

slide-17
SLIDE 17

Why the “Duplicative” Reporting?

  • External Relationships
  • A single Demand Response resource can be used in multiple

programs for different Reporting Entities

Balancing Authority

  • Reports 50 MW Capacity

Program

LSE

  • Reports 10 MW

Capacity Program

Submitted Data

BA - 50 MW LSE -10 MW Total Enrolled DR: 60 MW

  • 5 MW are used

in BA program

Total Enrolled DR: 55 MW

slide-18
SLIDE 18

Why the “Duplicative” Reporting?

  • Internal Relationships
  • A single Demand Response resource can be used in multiple

programs within the same entity

Balancing Authority

  • Reports 50 MW

Capacity Program

  • Reports 40 MW

Energy Program

Submitted Data

50 MW Capacity 40 MW Energy Total Enrolled DR: 90 MW Total Enrolled DR: 50 MW

Energy Program Participants are also enrolled in the Capacity Program

slide-19
SLIDE 19

Overview of Data to be Collected

  • Demand Response Program Criteria
  • DADS requires data for all Demand Response Programs

currently in effect. However, Responsible Entities are only required to register and submit data on Demand Response Programs if: 1) The Demand Response Program has been commercially in- service for more than 12 months; or 2) The Demand Response Program has enrolled 10 MW or more of combined Demand Response Resources.

  • Serves to not discourage small scale Demand Response

deployment and to encourage the development of pilot Demand Response.

slide-20
SLIDE 20

Overview of Data to be Collected

  • Program Registration and Enrollment Data
  • Identification of the Demand Response Program
  • Zone Information
  • Product Type
  • Energy, Capacity, Reserve, Regulation
  • Service Type (i.e. Capacity – Direct Load Control)
  • Program Start/End Dates
  • Registered/Enrolled Number of Resources
  • Registered/Enrolled Capacity
  • Program Relationships

Demand-Side Management

Demand Response Energy Efficiency Dispatchable Non-Dispatchable Reliability Economic

Capacity Regulation Energy - Voluntary Reserves

Direct Control Load Management Interruptible Load Critical Peak Pricing (CPP) with control Load as a Capacity Resource Emergency Spinning Reserves Non -Spinning Reserves

Energy - Price

Demand Bidding & Buy -Back

Time-Sensitive Pricing

Time-of-Use (TOU) Critical Peak Pricing (CPP) Real -Time Pricing (RTP) System Peak Response Transmission Tariff (4CP Response)

Demand-Side Management

Demand Response Energy Efficiency Dispatchable Non-Dispatchable Reliability Economic

Capacity Regulation Energy - Voluntary Reserves

Direct Control Load Management Interruptible Load Critical Peak Pricing (CPP) with control Load as a Capacity Resource Emergency Spinning Reserves Non -Spinning Reserves

Energy - Price

Demand Bidding & Buy -Back

Time-Sensitive Pricing

Time-of-Use (TOU) Critical Peak Pricing (CPP) Real -Time Pricing (RTP) System Peak Response Transmission Tariff (4CP Response)

Demand-Side Management

Demand Response Energy Efficiency Dispatchable Non-Dispatchable Reliability Economic

Capacity Regulation Energy - Voluntary Reserves

Direct Control Load Management Interruptible Load Critical Peak Pricing (CPP) with control Load as a Capacity Resource Emergency Spinning Reserves Non -Spinning Reserves

Energy - Price

Demand Bidding & Buy -Back

Time-Sensitive Pricing

Time-of-Use (TOU) Critical Peak Pricing (CPP) Real -Time Pricing (RTP) System Peak Response Transmission Tariff (4CP Response)

slide-21
SLIDE 21

Overview of Data to be Collected

  • Demand Response Reliability Event Data
  • Advance Notification Date/Time
  • Deployment Date/Time
  • Reduction Deadline
  • Release/Recall Date/Time
  • Committed MW
  • Contracted/Registered
  • Number of Committed Resources
  • Dispatched MW
  • Hourly Estimated Realized Demand Reduction (MW)
  • Hourly Estimated Realized Energy Reduction (MWh)

DEPLOYMENT PERIOD RECOVERY PERIOD

REDUCTION DEADLINE DEPLOYMENT

RAMP PERIOD SUSTAINED RESPONSE PERIOD

RELEASE/RECALL NORMAL OPERATIONS

DEMAND RESPONSE EVENT

ADVANCE NOTIFICATION(S)

slide-22
SLIDE 22

Overview of Data to be Collected

  • Market Participation Data (Monthly)
  • Total Offer and Self Scheduled Hours
  • Scheduled/Cleared Hours
  • Offered or Self Scheduled Energy Reduction (MW/h)
  • Estimated Realized Energy Reduction (MW/h)
  • Offered Scheduled Demand Reduction (MW)
  • Estimated Realized Demand Reduction (MW)
slide-23
SLIDE 23

Overview of Data to be Collected

  • Ancillary Services Product Data (Monthly)
  • Registered & Qualified Resources (MW)
  • Total Offered and self-Scheduled Hours
  • Total Committed Hours
  • Offered or Self Scheduled Capacity (MW)
  • Total Committed Capacity (MW x Hours)
  • Average Hourly Committed Capacity (MW)
  • Deployment Hours (Regulation Only)
  • Total Deployments
slide-24
SLIDE 24

Overview of Data to be Collected

  • Confidentiality of Submitted Data
  • Any data submitted that is classified as confidential shall be managed in

accordance with NERC’s treatment of confidential information as described in Section 1500 of the Rules of Procedure. Confidential data will not be accessible by others except the Responsible Entity that submitted that data and NERC staff, who will be responsible for its analysis; however, aggregate data may be used for metrics and presented to third parties as necessary or appropriate.

  • DADS data may be classified as:
  • Confidential Business and Market Information
  • Critical Energy Infrastructure Information
  • Non-Confidential
  • The following data will be classified as confidential when deemed so by a

Responsible Entity.

  • Enrollment Data (Number of Registered Resources and Registered MWs)
  • All Reliability Event/Market Participation/Ancillary Product Data

DADS is intended to serve as a valuable tool, not only for reliability and resource adequacy analysis, but for research outside of NERC.

slide-25
SLIDE 25

Other Important Notes

  • All data is aggregated
  • No single demand resource identified
  • NERC is working on developing a procedure to minimize

reporting burden

  • If the entity does not have qualifying demand response programs
  • If the entity’s entire portfolio of resources are included in another

entity’s program

  • Phase I voluntary submission dates are flexible!
  • The goal is to learn and understand the reporting procedure,

which programs should/should not be reported, and develop enhancements for Phase II

slide-26
SLIDE 26

DADS Status & Next Steps

  • Status:
  • PHASE I in progress (Voluntary Data)
  • Letter to industry participants confirming

restructured data submission requirements

  • Next Steps
  • Coordinate mandatory requirements
  • First mandatory data submittal aimed for

December 15th, 2011

slide-27
SLIDE 27

Question & Answer

Contact: John Moura Technical Analyst, Reliability Assessments & Performance Analysis john.moura@nerc.net 609.524.7047 References:

DADS Website: http://www.nerc.com/page.php?cid=4|357 DRDTF Website: http://www.nerc.com/filez/drdtf.html DADS Phase I Technical Conference: http://www.nerc.com/filez/DADS/index.htm
