DEM Project: Kenyan Solar Solution

Created by: Brian Brosnan, Jason Ochs, Tomas Quinteros Amat, Rachel Wiggins

Mission Statement

To provide the poverty-stricken rural population of Kenya with an affordable means of charging personal electronics to a full charge through renewable resources and without the need for significant travel.

Background:

• Target: Rural Nakuru, Central Kenya
• Secondary Market: larger scale, urban areas
• 82% of Kenyans use cell phones
• Climate: arid, drought-stricken

○ Monsoon winds/storms in some parts of country

• Rural Poverty: $0.68/Day
• Design: adjustable, affordable, solar powered
• Goal: fixed yet durable and adaptable product for individual use

Decision Matrix

Prototype 1

***Following final concept selection**** Design for the case, not the mount

Tests:

• Water Resistance
• Debris
• Stress
• Drop Sensitivity
• Weight
• Smash

Prototype 1 Test Results:

Water Resistance Test: waterproof except for one corner Debris Test: mud, dirt, and food residue rinse right off Stress Test: strongest vertically and diagonally with compression Drop Test: no damage until drop from 6ft Weight Test: acrylic can survive compression of 110+ pounds Smash Test: acrylic cannot withstand impact and shatters

Water Resistance Test

• When the case was under running water, water entered

through one corner in drops

• When submerged, bubbles were seen in the same corner

Debris Test

Debris Amount of Debris Visual Observations Hard to Clean? Scale (1- 5) Dirt Cover Acrylic cleans off completely very easy, run under water 5 Mud Cover Acrylic cleans off completely very easy, run under water 5 Coffee Grounds Cover Acrylic Cleans off completely very easy, run under water 5

Stress Test

Position

• f Product

# Turns of Crank Visual Observations Scale (1-5) Horizontal 1 ¼ wood starts to break apart on edge, cracking sound 3 Vertical 3 Glass separating, little bending, hard to turn, warping, cracking sound 4 Diagonal 2 ¾ Warped Acrylic, warped corners, acrylic and wood frame separates on side 2

Drop Test

Height (ft) Visual Observations Scale (1-5) 1 No damage seen 5 2 No damage seen 5 3 No damage seen 5 4 Small Chip breaks off from the bottom 4 5 No damage seen 5 6 Acrylic breaks apart from 3 out of the 4 sides 2

After 6 foot drop

Weight Test

Weight (lbs) Visual Observations Scale (1-5) 25 No changes/ damages 5 50 No changes/ damages 5 75 Starts to depress, dips, no damages 4 100 Dips/ depresses, no damage 3 105.3 Dips/ depresses, no damages 3 110.1 Dips/ depresses, no damages 3

105.3 lbs

Smash Test

After one hit with a hammer

Improvements for Prototype 2

• Adjustment for new solar panel
• Angled Mount
• Polycarbonate Covering (25x+ stronger)
• Waterproofing
• Stronger bond for clear cover

Prototype 2

• Wooden blocks for optimal angles
• Affixed to roof
• 5V 240mAh Panel
• Circuitry: panel, rectifier, USB port,

and voltage regulator

• Screwed-on polycarbonate

Prototype 2 Testing

Pending parts arrival and assembly

Prototype 3

• Plastic material
• Versatility to connect to other power sources
• Rubber waterproofing

How Design Will Benefit the Customer

Frugal - Stays w/in the $10 budget Estimated Cost Breakdown: $9.92

• Rectifier Diodes: 4x $0.50
• Voltage Regulator: $0.58
• USB Port: $0.72
• Solar Panel (5V, 240 mA, 1.2W,

110x 69 mm) : $2.52

• Polycarbonate sheet: $4.10
• Building supplies: FREE
• Simple installation, simple

maintenance

• Easy to shift for optimal power
• Weather tested for tropical climate
• Small Size, Worked into daily lives
• f consumer
• Based on Samsung b310 Piton, a

phone available in Kenya, would charge in ~4 hours of direct sunlight
