CPAIOR 2019 Deep Inverse Optimization Yingcong Tan 1 , Andrew Delong 2 , Daria Terekhov 1 1 Department of Mechanical, Industrial and Aerospace Engineering Concordia University 2 Department of Computer Science and Software Engineering Concordia

slide-1
SLIDE 1

CPAIOR 2019

Deep Inverse Optimization

Yingcong Tan 1, Andrew Delong 2, Daria Terekhov 1

1Department of Mechanical, Industrial and Aerospace Engineering

Concordia University

2Department of Computer Science and Software Engineering

Concordia University

Thursday, June 6th, 2019

slide-2
SLIDE 2

Agenda

i. Motivation ii. Methodology iii. Experiments iv. Summary

Yingcong Tan, Andrew Delong, Daria Terekhov Deep Inverse Optimization 2/35

slide-3
SLIDE 3

What is Inverse Optimization (IO)?

Forward Optimization Problem c minx c′x s.t. Ax ≤ b

Target

c

Target

minc Target, x s.t. x ∈ arg minx{c′x|Ax ≤ b}

Yingcong Tan, Andrew Delong, Daria Terekhov Deep Inverse Optimization 3/35

slide-4
SLIDE 4

What is Inverse Optimization (IO)?

Forward Optimization Problem c x∗ minx c′x s.t. Ax ≤ b c

Target

minc Target, x s.t. x ∈ arg minx{c′x|Ax ≤ b}

Yingcong Tan, Andrew Delong, Daria Terekhov Deep Inverse Optimization 4/35

slide-5
SLIDE 5

What is Inverse Optimization (IO)?

Forward Optimization Problem Inverse Optimization Problem c x∗ minx c′x s.t. Ax ≤ b c

Target

minc Target, x s.t. x ∈ arg minx{c′x|Ax ≤ b}

Yingcong Tan, Andrew Delong, Daria Terekhov Deep Inverse Optimization 5/35

slide-6
SLIDE 6

What is Inverse Optimization (IO)?

Forward Optimization Problem Inverse Optimization Problem c x∗ minx c′x s.t. Ax ≤ b c

Target

x minc Target, x s.t. x ∈ arg minx{c′x|Ax ≤ b}

Yingcong Tan, Andrew Delong, Daria Terekhov Deep Inverse Optimization 6/35

slide-7
SLIDE 7

Motivation

Routing Problem (i.e., Least Cost Path) Objective Learn the arc cost Production Planning Problem Objective Estimate backorder cost Customer Behavior Objective Estimate customer utility function

Yingcong Tan, Andrew Delong, Daria Terekhov Deep Inverse Optimization 7/35

slide-8
SLIDE 8

Contribution

Existing algorithms

Highlights Optimization formulations based on optimality conditions Guarantee optimal solution Limitation Algorithms are tailored to solve special cases of IO problems

*Chan et al. [2–4], Troutt et al.[6, 7], Aswani et al. [1], Saez-Gallego and Morales [5]

Yingcong Tan, Andrew Delong, Daria Terekhov Deep Inverse Optimization 8/35

slide-9
SLIDE 9

Contribution

Existing algorithms

Highlights Optimization formulations based on optimality conditions Guarantee optimal solution Limitation Algorithms are tailored to solve special cases of IO problems

*Chan et al. [2–4], Troutt et al.[6, 7], Aswani et al. [1], Saez-Gallego and Morales [5]

Deep Inverse Optimization

Highlights First deep-learning based approach Learn parameters through backpropogation Generally applicable to different IO problems Limitation Doesn’t guarantee optimal solution

Yingcong Tan, Andrew Delong, Daria Terekhov Deep Inverse Optimization 9/35

slide-10
SLIDE 10

Agenda

i. Motivation ii. Methodology iii. Experiments iv. Summary

Yingcong Tan, Andrew Delong, Daria Terekhov Deep Inverse Optimization 10/35

slide-11
SLIDE 11

Methodology

(IO): Find a Cost Vector Consistent With Target

Target

c

Discrepancy ∆c

Yingcong Tan, Andrew Delong, Daria Terekhov Deep Inverse Optimization 11/35

slide-12
SLIDE 12

Methodology

Solve FOP using Interior-Point Method (IPM)

Target

c x∗

Discrepancy ∆c

Yingcong Tan, Andrew Delong, Daria Terekhov Deep Inverse Optimization 12/35

slide-13
SLIDE 13

Methodology

Observe Discrepancy and Compute Gradients

Target

c x∗

Discrepancy ∆c

Yingcong Tan, Andrew Delong, Daria Terekhov Deep Inverse Optimization 13/35

slide-14
SLIDE 14

Methodology

Observe Discrepancy and Compute Gradients

Target

c x∗

Discrepancy ∆c

Yingcong Tan, Andrew Delong, Daria Terekhov Deep Inverse Optimization 14/35

slide-15
SLIDE 15

Methodology

Termination

Target

c x∗

Yingcong Tan, Andrew Delong, Daria Terekhov Deep Inverse Optimization 15/35

slide-16
SLIDE 16

Methodology

Deep Inverse Optimization Unroll the IPM Unroll a Deep RNN

x(0) = features x(1) = RNN(x(0), weights) x(2) = RNN(x(1), weights) x(n) = RNN(x(n−1), weights)

minweights Loss(Target, x(n)) Dynamic Num. of Steps Backpropogation

∂ Loss ∂ weights

Yingcong Tan, Andrew Delong, Daria Terekhov Deep Inverse Optimization 16/35

slide-17
SLIDE 17

Methodology

Deep Inverse Optimization Unroll the IPM

c, A, b = DefineLP(features, weights) x(0) = FindFeasible(c, A, b) x(1) = Newton(x(0), c, A, b) x(2) = Newton(x(1), c, A, b) x(n) = Newton(x(n−1), c, A, b)

Dynamic Num. of Steps minweights Loss(Target, x(n)) Unroll a Deep RNN

x(0) = features x(1) = RNN(x(0), weights) x(2) = RNN(x(1), weights) x(n) = RNN(x(n−1), weights)

minweights Loss(Target, x(n))

Yingcong Tan, Andrew Delong, Daria Terekhov Deep Inverse Optimization 17/35

slide-18
SLIDE 18

Agenda

i. Motivation ii. Methodology iii. Experiments iv. Summary

Yingcong Tan, Andrew Delong, Daria Terekhov Deep Inverse Optimization 18/35

slide-19
SLIDE 19

Experiments on Three Learning Tasks

Task 1 Single-point non-parametric LP Goal Learn cost vector – Closed-form solution proposed by Chan et al. [2, 4]

Yingcong Tan, Andrew Delong, Daria Terekhov Deep Inverse Optimization 19/35

slide-20
SLIDE 20

Experiments on Three Learning Tasks

Task 1 Single-point non-parametric LP Goal Learn cost vector – Closed-form solution proposed by Chan et al. [2, 4] Task 2 Single-point non-parametric LP Goal Learn cost vector and constraints jointly – Maximum likelihood estimation approach proposed by Troutt et al. [6]

Yingcong Tan, Andrew Delong, Daria Terekhov Deep Inverse Optimization 20/35

slide-21
SLIDE 21

Experiments on Three Learning Tasks

Task 1 Single-point non-parametric LP Goal Learn cost vector – Closed-form solution proposed by Chan et al. [2, 4] Task 2 Single-point non-parametric LP Goal Learn cost vector and constraints jointly – Maximum likelihood estimation apprach proposed by Troutt et al. [6] Task 3 Multi-point parametric LP, i.e., c, A, b = f (features, weights) Goal Learn weights – Not addressed in literature

Yingcong Tan, Andrew Delong, Daria Terekhov Deep Inverse Optimization 21/35

slide-22
SLIDE 22

Experiment on Task 1

Goal Learn cost vector consistent with a single observed target X ∗ Target c

Yingcong Tan, Andrew Delong, Daria Terekhov Deep Inverse Optimization 22/35

slide-23
SLIDE 23

Experiment on Task 1

Goal Learn cost vector consistent with a single observed target X ∗ Target X ∗ c c Test on 300 random LP instances

Yingcong Tan, Andrew Delong, Daria Terekhov Deep Inverse Optimization 23/35

slide-24
SLIDE 24

Experiment on Task 1

N = 10 Variables M = 20 Constraints Before Learning After Learning

X ∗ Target X ∗ c c

Yingcong Tan, Andrew Delong, Daria Terekhov Deep Inverse Optimization 24/35

slide-25
SLIDE 25

Squared Error (Learned vs Target)

N = 2 , M = 4 N = 2 , M = 8 N = 2 , M = 1 6 N = 1 , M = 2 N = 1 , M = 3 6 N = 1 , M = 8 10

11

10

9

10

7

10

5

10

3

10

1

101

loss (squared error) Yingcong Tan, Andrew Delong, Daria Terekhov Deep Inverse Optimization 25/35

slide-26
SLIDE 26

Experiment on Task 2

Goal Learn cost vector and constraints consistent with a single

  • bserved target

X Target c

Yingcong Tan, Andrew Delong, Daria Terekhov Deep Inverse Optimization 26/35

slide-27
SLIDE 27

Experiment on Task 2

Goal Learn cost vector and constraints consistent with a single

  • bserved target

X Target X c c Test on 300 random LP instances

Yingcong Tan, Andrew Delong, Daria Terekhov Deep Inverse Optimization 27/35

slide-28
SLIDE 28

Squared Error (Learned vs Target)

N = 2 , M = 4 N = 2 , M = 8 N = 2 , M = 1 6 N = 1 , M = 2 N = 1 , M = 3 6 N = 1 , M = 8 10

11

10

9

10

7

10

5

10

3

10

1

101

loss (squared error) Yingcong Tan, Andrew Delong, Daria Terekhov Deep Inverse Optimization 28/35

slide-29
SLIDE 29

Experiment on Task 3

Goal Learn weights such that decisions are consistent with observed targets across multiple conditions

TARGET DISCREPANCY

Yingcong Tan, Andrew Delong, Daria Terekhov Deep Inverse Optimization 29/35

slide-30
SLIDE 30

Experiment on Task 3

Goal Learn weights such that decisions are consistent with observed targets across multiple conditions

Yingcong Tan, Andrew Delong, Daria Terekhov Deep Inverse Optimization 30/35

slide-31
SLIDE 31

Squared Error (Learned vs Target)

TARGET Yingcong Tan, Andrew Delong, Daria Terekhov Deep Inverse Optimization 31/35

slide-32
SLIDE 32

Squared Error (Learned vs Target)

Yingcong Tan, Andrew Delong, Daria Terekhov Deep Inverse Optimization 32/35

slide-33
SLIDE 33

Agenda

i. Motivation ii. Methodology iii. Experiments iv. Summary

Yingcong Tan, Andrew Delong, Daria Terekhov Deep Inverse Optimization 33/35

slide-34
SLIDE 34

Summary

General-purpose framework for solving IO problems

Solves parametric or non-parametric problems Learns all parameters individually or jointly Easily extends to non-linear problems

Deep-Inv-Opt package is now available on https://github.com/tankconcordia/deep inv opt

Yingcong Tan, Andrew Delong, Daria Terekhov Deep Inverse Optimization 34/35

slide-35
SLIDE 35

Thank you !

Yingcong Tan, Andrew Delong, Daria Terekhov Deep Inverse Optimization 35/35
