30-Percent Engineering Design Services for the

New Mexico Unit of Central Arizona Project

December 6, 2016 Phase 2 – Project Kickoff Meeting

Overview – Phase 1: Scope and Findings Summary – Phase 2: Scope, Schedule, and Deliverables – Gila Diversion Preliminary Findings

30 Percent Engineering Design Services for New Mexico Unit of Central Arizona Project 2

Phase 1: Scope and Findings

Phase 1 – Scope Summary Scope Develop Screening Criteria for Diversion and Storage Concepts along the Gila and Mogollon – Storage: reservoirs and ASR – Diversions: open channel, pipelines, and pumping – Assess environmental impacts

30 Percent Engineering Design Services for New Mexico Unit of Central Arizona Project 4

Phase 1 – Selected Alternative

30 Percent Engineering Design Services for New Mexico Unit of Central Arizona Project 5

Phase 1 – Selected Alternative Alternative 4 (Selected Alternative) Initial Phase – Diversion of 150 cfs – Flood infiltration and storage with additional basins in the Cliff-Gila Valley – Ranney Wells – Construct Winn Reservoir and Diversion to 3,845 AF – Pipeline and pumping to the Upper Gila ditch

30 Percent Engineering Design Services for New Mexico Unit of Central Arizona Project 6

Phase 2 – Scope, Schedule, and Deliverables

Phase 2 – Scope, Schedule, and Deliverables Scope – Diversion – ASR ground water model – ASR geotechnical investigation – ASR down valley sites – Agency requirements – Additional work

30 Percent Engineering Design Services for New Mexico Unit of Central Arizona Project 8

Phase 2 – Schedule

9 30 Percent Engineering Design Services for New Mexico Unit of Central Arizona Project

Project Milestones – Task 6 – Project Management NTP – 11/7/2016 – Task 7 – Diversions NTP – 11/7/2016

– Draft Report Submitted 12/2/2016

– Task 8 – Coordination Meeting NTP - TBD – Task 9 – ASR Ground Water Model NTP – TBD – Task 10 – Geotechnical Investigation NTP - TBD – Task 11 – ASR Down Valley Sites NTP – TBD – Task 12 – Agency Coordination NTP - TBD

Phase 2 – Deliverables Deliverables – Diversion Report – ASR Numerical Model – ASR Geotechnical Report – Down Valley ASR Observations Memorandum – Permitting Summary Memorandum

30 Percent Engineering Design Services for New Mexico Unit of Central Arizona Project 10

Gila Diversion Preliminary Findings

Gila Gage Diversion Site – Gila Stream Gage

• USGS 09430500

– Land Ownership

• US Forest Service (USFS)
• No diversion activities on USFS lands
• TNC & State of New Mexico
• Co-ownership
• National Lands Protection Act (NLPA)

– Access Road Improvements

• Regrade slopes >12%
• Crossing of Mogollon Creek
• Construction & maintenance

30 Percent Engineering Design Services for New Mexico Unit of Central Arizona Project 12

Conceptual Diversion Alternatives Criteria

Site Evaluation Criteria – Available Head

• Highest point below USFS boundary

– All Weather Access

• Except during flooding events

– Structural Stability

• Key diversion to bedrock

– Lateral & Vertical Channel Stability

• Bedrock along both banks
• Observed channel degradation

30 Percent Engineering Design Services for New Mexico Unit of Central Arizona Project 14

Design Alternatives Selection Criteria – Structure Design

• Grouted boulder vs. cast concrete
• Adjustable vs. fixed invert
• At grade vs. surface water intake

– Sediment Transport

• Promote sediment continuity
• Prevent erosion & sedimentation

– Structure Bypass

• Maintain design channel alignment
• Prevent future channel avulsion

– Upstream Fish Passage

• Design to T&E species requirements
• Minimize limiting velocities & depths

– Downstream Navigability

• Minimize recreational hazards

http://www.wildlife.state.nm.us/fishing/game-fish/cold-water/ 30 Percent Engineering Design Services for New Mexico Unit of Central Arizona Project 15

Conceptual Diversion Alternatives 30% Design

Engineered Riffle Diversion

– Invert 4662’ to 4666’ – Grouted Boulder or Concrete – Cast Concrete Walls – Elongated Riffle Rundown – Riprap Bank Protection – Bedload Deflection – Fish & Debris Exclusion – Sediment Sluicing – Surface Conveyance Canal

30 Percent Engineering Design Services for New Mexico Unit of Central Arizona Project 17

Engineered Riffle Diversion – Pros

• Cost to construct
• Fewer mechanical systems
• Reduced power requirements
• Recreational navigation

– Cons

• Non-adjustable invert
• Static sediment management
• No fish passage channel
• Reduced flood flow conveyance

Engineered Riffle: Kremlin, CO 30 Percent Engineering Design Services for New Mexico Unit of Central Arizona Project 18

Obermeyer Pneumatic Gates Diversion

30 Percent Engineering Design Services for New Mexico Unit of Central Arizona Project 19

– Gates Raised 4662’ to 4666’ – Cast Concrete Sill & Walls – Riprap Bank Protection – Mechanical Infrastructure

• Steel gates, pneumatic lines,

bladders, compressors,

• perations controls & housing

– Bedload Deflection – Fish & Debris Exclusion – Sediment Sluicing – Surface Conveyance Canal

Obermeyer Pneumatic Gates Diversion – Pros

• Adjustable invert
• Dynamic sediment flushing
• Fish passage opportunities
• Flood flow conveyance

– Cons

• Cost to construct
• Mechanical systems maintenance
• Additional power requirements

Albuquerque Diversion Dam: http://mapio.net/pic/p-5170793/ 30 Percent Engineering Design Services for New Mexico Unit of Central Arizona Project 20

Combination Coanda Screen & Obermeyer Pneumatic Gate Diversion

30 Percent Engineering Design Services for New Mexico Unit of Central Arizona Project 21

– Gates Raised 4662’ to 4666’ – Cast Concrete Sill & Walls – Riprap Bank Protection – Coanda Screens

• 1 mm opening

– Water Collection Vaults – Mechanical Infrastructure

• Steel gates, pneumatic lines,

bladders, compressors,

• perations controls & housing

– Sediment Sluicing – Subgrade Conveyance Culvert

Combination Coanda Screen & Obermeyer Pneumatic Gate Diversion – Pros

• Partially adjustable invert
• Limited sediment flushing
• Sediment & debris exclusion
• Fish passage opportunities

– Cons

• Cost to construct
• Mechanical systems maintenance
• Sedimentation in vaults
• Reduced head for conveyance
• Additional power requirements

http://www.elginindustries.com/equipment_group/norris_screen/products/product_line/Norri s_Screen/stainless_steel_screening_systems/coanda_screen 30 Percent Engineering Design Services for New Mexico Unit of Central Arizona Project 22

Channel Response to Historic Changes in the River System

River Channel Modifications in the Cliff-Gila Valley – Channelization

• Straightening & leveeing
• Steeper channel slopes

– Disconnection of Floodplain

• Reduced overbank flood storage
• Loss of vegetation & bank stability

30 Percent Engineering Design Services for New Mexico Unit of Central Arizona Project 24

Dynamic Channel Response in Cliff-Gila Valley – Independent of Flood Severity – Vertical Channel Instabilities

• Upstream degradation
• Headcutting
• Downstream aggradation
• Braiding

– Lateral Channel Instability

• Bank erosion & failure
• Channel avulsion

30 Percent Engineering Design Services for New Mexico Unit of Central Arizona Project 25

Observed Channel Response at Gila Gage Site – Ongoing Channel Incision

• Propagation of headcuts

initiated downstream

– Channel Abandonment

• Historically irrigated fields
• Fluvial landforms
• USGS stream gage facility

– Lowered Shallow Water Table

• Perched riparian vegetation
• Expanded upland conditions

30 Percent Engineering Design Services for New Mexico Unit of Central Arizona Project 26

Ecological & Functional Restoration of the Gila River

Intent of Reach-Scale Channel Restoration – Re-elevate Incised Channel – Restore Stable Channel Geometries – Reduce Over-steepened Banks – Reconnect Abandoned Floodplains – Raise Shallow Water Tables – Reestablish Native Riparian Zones

30 Percent Engineering Design Services for New Mexico Unit of Central Arizona Project 28

Pros & Cons of Restoration to Diversion Project – Improve River Function

• Vertical & lateral channel stability
• Sediment continuity of reach

– Raise Diversion Elevations

• Gravity feed ASR infiltration fields

– Restore Aquatic & Riparian Habitats

• T&E species

– Benefit River Based Recreation

• Existing hazards

– Disadvantages of Restoration

• Increased project cost
• Temporary construction impacts

30 Percent Engineering Design Services for New Mexico Unit of Central Arizona Project 29

Next Steps

Recommended Path Forward – Continued Fluvial Geomorphic Analysis – Additional Hydraulic Modeling – Initiate Sediment Transport Modeling – Field Investigations for ASR – Stream Restoration Evaluation

30 Percent Engineering Design Services for New Mexico Unit of Central Arizona Project 31

Questions?

December 6, 2016
