Dean Tuomari Wayne County Department of Public Services Water - - PowerPoint PPT Presentation

Dean Tuomari Wayne County Department of Public Services Water Quality Management Division,

dtuomari@waynecounty.com 734-326-4483

Michigan Water Environment Association Annual Industrial Pretreatment Program Seminar September 26, 2013

Introduction

 Review Elements of the Municipal Separated Storm Sewer

System(MS4) Permit Application

 http://www.michigan.gov/documents/deq/wrd-stormwater-

MS4-Application_402860_7.pdf

 Permit Application Elements

 Storm Water Management Program the eight elements

 Eighty plus procedures required

 Illicit Discharge Elimination Program

 Case Histories  How IPP staff can be the eyes and ears

 Accomplishmnets

Permit Application Elements

 Define the regulated urbanized areas as defined by the

2000 Census

Permit Application Elements

 Identify discharges to waters of the State

 Identify discharge points

 Identify the point where your system discharges to another

jurisdiction

 Agreements between

jurisdictions on follow up is allowable

 Note- open county drains

are considered Waters of the State

Permit Application Elements

 List nested jurisdictions in the application

 E.g. school districts  Community/ies under a county permit

 Provide name and general description of nested

jurisdictions

Permit Element Stormwater Management Program

 Eight Elements - The main objectives of the permit

1.

Enforcement Response Procedure

2.

Public Participation Program

3.

Public Education Program

4.

Construction Stormwater Runoff Program

5.

Post Construction Stormwater Runoff Program

6.

Pollution Prevention and Good Housekeeping Program

7.

Total Maximum Daily Load (TMDL) Implementation Program

8.

Illicit Discharge Elimination Program

Stormwater Management Program

1.

Enforcement Response Procedure

• Response to violation of permitees ordinances
• Contain the ordinance/s
• Method for tracking non-compliance
• Date/location
• Nature of the violation
• Enforcement response used
• Schedule for compliance
• Date violation was resolved

Stormwater Management Program

2.

Public Participation Plan

• If it a collaborative effort with watershed or regional

partners identify, the collaborative activities

• Procedures on how the public participates in the

development of the Stormwater Management Plan

• How is the Plan made available for public review/comment?
• How the public is invited to participate in implementation

and review?

Stormwater Management Program

3.

Public Education Program (PEP)



Provide procedure to assess high priority community issues and target the issues to reduce pollutants in stormwater



Identify /prioritize PEP topics based on assessment of community high priority issues.



Eleven PEP topics in the permit application



For each topic provide



Target audience



Key message



Delivery mechanism and frequency

Stormwater Management Program

3.

Public Education Program (PEP)

• Topics include:
• Promote public stewardship of watersheds
• Educate the public on illicit discharges
• Education on importance of green infrastructure
• Education on the proper maintenance of septic systems
• Promote methods for proper riparian lands to protect water

quality

• Identify /educate commercial, industrial, institutional

entities that may contribute pollutants to stormwater

• Provide a procedure for evaluating effectiveness of the PEP
• Assess changes in public awareness

Stormwater Management Program

• 4. Construction Stormwater Runoff Program
• Is the permittee a Part 91 agency (Soil Erosion)?
• If not list the agency it relies on for Part 91 agency
• Procedure for notifying the Part 91 agency when pollutant from a

construction site enters MS4.

• Procedure to notify MDEQ when pollutant from a construction

site enters MS4.

• Procedure to notify Part 91 agency of construction activity

greater than one acre.

Stormwater Management Program

• 5. Post Construction Stormwater Runoff Program
• Ordinance for post construction runoff
• Water quality performance standard
• Treat first inch of runoff from entire site
• Treat runoff from 90% of all runoff producing storms
• Source of rainfall data
• Channel Protection Performance Standard
• Site runoff does not exceed pre development rate and

volume up to 2 year 24 hour storm

Stormwater Management Program

• 5. Post Construction Stormwater Runoff Program
• Site specific requirements (new and redevelopment)
• Infiltration BMP should not exaberate current groundwater

contamination issues.

• Do BMPs consider potential pollutants from “hotspots”
• (E.g. gas stations, auto recyclers, scrap yards, etc)
• Off-Site Mitigation/Payment in Lieu Programs
• Is off-site mitigation allowed for redevelopment?
• Does ordinance allow Payment in Lieu?
• Fee paid to permitee for stormwater management project
• Same jurisdiction, watershed, sewershed

Stormwater Management Program

• 6. Pollution Prevention and Good Housekeeping



Municipal Facility and Structural Stormwater Control Inventory



Updated inventory of municipal facilities and stormwater structures



Municipal facilities



Police/Fire stations, vehicle yards, public parking lots, animal control building



Structural storm water controls e.g. rain gardens, catch basins, constructed wetlands, pump stations



Up-to-date maps with locations for items above



Procedure for updating the inventory

Stormwater Management Program

• 6. Pollution Prevention and Good Housekeeping



Maintenance Activities for Structural Stormwater Controls



Procedure for prioritizing routine inspection, maintenance and cleaning of catch basins



Revision procedure for updating priority areas.

Stormwater Management Program

• 6. Pollution Prevention and Good Housekeeping



Location of impervious surfaces



E.g. streets, parking lots 

Identify street sweeping methods



Seasonal issues e.g. leaf pickup 

Describe dewatering and disposal of waste material



Management of vegetated properties



Certified pest control applicator 

Employee training



Employee training program for staff that perform pollution prevention and good house keeping

Stormwater Management Program

• 6. Pollution Prevention and Good Housekeeping



Contractor requirements



Comply with pollution prevention and good housekeeping practices

• 7. Total Maximum Daily Load (TMDL) Implementation Plan



A TMDL Implementation Plan will have a waste load allocation to the municipality



Describe current/future Best Management Practices (BMP)that make progress towards meeting waste load allocation in TMDL plan



Monitoring plan to assess effectiveness of BMP to reach load reduction requirement in the TMDL plan.

Stormwater Management Program

• 8. Illicit Discharge Elimination Program (IDEP)
• Definitions
• Illicit Connection- physical connection

to a MS4 that convey non-stormwater discharge or not authorized by local authority

• Illicit Discharge-any discharge or seep

that is not stormwater or uncontaminated ground water

Stormwater Management Program

• 8. Illicit Discharge Elimination Program (IDEP)
• Examples of Illicit Discharges

Grey Water Discharge

Stormwater Management Program

• 8. Illicit Discharge Elimination Program (IDEP)



Up-to date storm sewer system map



Identify location of outfalls



Identify points of discharge



Identify water of the State that receive the discharge



Indicate where the maps can be found

Stormwater Management Program

• 8. Illicit Discharge Elimination Program (IDEP)
• Procedure for prioritize areas with potential of illicit

discharges

• E.g. Areas with:
• History of illicit discharge
• Onsite Sewage Disposal Systems
• Older infrastructure
• Poor dry weather water quality
• Provide geographical location of priority areas

Stormwater Management Program

• 8. Illicit Discharge Elimination Program (IDEP)
• Procedure for prioritizing areas with potential for

illicit discharges

Stormwater Management Program

• 8. Illicit Discharge Elimination Program (IDEP)
• Procedure for field observations of outfalls
• Water color, clarity, floatables, odor
• Structural condition, staining, deposits
• Bacterial sheens, algae, slimes,
• Field screening procedures
• pH
• Ammonia
• Fluoride
• Detergents

Stormwater Management Program

• 8. Illicit Discharge Elimination Program (IDEP)
• Procedure for source investigation
• How will the source be determined?
• Procedures for responding to spills
• Procedure for reporting of polluting material to waters
• f the state from storm system
• Polluting material defined by Part 5 rules.
• Response to illicit discharge
• Corrective action
• Compliance schedule

Stormwater Management Program

• 8. Illicit Discharge Elimination Program (IDEP)
• IDEP Training of staff
• Once during permit cycle
• New staff within the first year of hire
• Evaluation
• How is effectiveness of IDEP program evaluated?
• Wayne County does pollutant load reduction calculations
• Illicit discharge ordinance

Dye Testing

Dropping the dye Liquid Packets Alternate colors Green Fluorescent red Rule 97 file notice of intent

INTENSIVE SAMPLING TECHNIQUE

 To find off-hours or intermittent flows or peak activity

 Automatic samplers  Flow meters  Multiple sampling at specific sites

16:00 11:09 06:18 01:27 20:36 15:45 0.010 0.034 0.058 0.082 0.106 0.130 SpCond(mS/cm) 16:00 11:09 06:18 01:27 20:36 15:45 12.50 13.34 14.18 15.02 15.86 16.70 Temp(C)

DateTime(M/D/Y)

11/22/06 11/23/06 11/24/06 11/25/06 11/25/06 11/26/06

North Mill East

INTENSIVE SAMPLING TECHNIQUE

OTHER TECHNIQUES

 Smoke testing  Televising the storm sewer  Drain walk  Use your imagination

IDEP Case History #1

A Storm Sewer Outfall is discharging a milky white substance into the Lower Rouge River

IDEP Case History #1

IDEP Case History #1

IDEP Case History #2

Livonia case history Case History – Restoring Recreational Use along the Middle Branch Clean Dirty 1996 Newburgh Lake to Nankin Lake meets E. coli standards Downstream of Nankin, lake does not meet E. coli standards

Problem area

• E. Coli

(CFU/100 ML)

IDEP Case History #2

" 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8

300 + manholes in drainage area

• E. Coli

(CFU/100 ML)

Results from May 20, 1997

720

480 84

4 44

# Y # Y # Y # Y # Y

" 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8

3 6 2 2 4 2 4 3 2

R e s u l t s

• f

M a y 2 2 , 1 9 9 7

3 4 1 2

R e s u l t s

• f

M a y 2 1 , 1 9 9 7

• E. Coli

(CFU/100 ML)

IDEP Case History #2

" 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8" 8 " 8" 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8" 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8" 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8 " 8

6560

2960

950

R esults May 23, 1997

• E. Coli

64

IDEP Case History #2

252

5280

105

284

92

64

1840

104

# Y # Y # Y # Y # Y # Y

R esults May 28, 1997

• E. Coli
• E. Coli

(CFU/100 ML)

IDEP Case History #2

124 3040 280 8 304 304

8160 1600

# Y # Y # Y # Y # Y # Y

Results June 6 & 11, 1997

• E. Coli
• E. Coli

(CFU/100 ML)

IDEP Case History #2

9600 12560 24000 >160000

# Y # Y # Y # Y

Results June 13, 1997

• E. Coli
• E. Coli

(CFU/100 ML)

CASE HISTORY – RESTORING RECREATIONAL USE ALONG THE MIDDLE BRANCH

 1997 city planning

 TV’ed sewer – no taps (completed)  Sent letters to residents (not completed)  Dye tested homes (not completed)

 1997 County actions

 Intermittent monitoring  Does problem still exist?

 Evidence of problem disappeared  Continued monitoring

CASE HISTORY – RESTORING RECREATIONAL USE ALONG THE MIDDLE BRANCH

 Memorial Day 1998 – problem back!

 Sent letters out  Dye testing  Educational material sent to homeowners

 Late 1998 – evidence of problem - disappeared  1999 - Clean  2000 - Clean

CASE HISTORY – RESTORING RECREATIONAL USE ALONG THE MIDDLE BRANCH

 Probable cause

 Recreational vehicle/boat dumping sanitary waste  Pet waste

CASE HISTORY – RESTORING RECREATIONAL USE ALONG THE MIDDLE BRANCH WHAT DID WE LEARN?

 Persistence pays  Observable presence in the area had an affect  Public education worked

IPP Staff “Eyes and Ears”

 Be an alert observer  Report suspicious discharges

Rem em em em ber er - ev even en sm sm all d disc scharges es are l e large e pollut ant sources if t hey y pollut e day ay af aft er day ay af aft er day… ay…

IPP Staff “Eyes and Ears”

IPP Staff “Eyes and Ears”

Leaky dumpsters Failing septic system

IPP Staff “Eyes and Ears”

Poorly maintained grease trap leaks

• utside building

No dumpster

IPP Staff “Eyes and Ears”

Leaking emulsion storage

IPP Staff “Eyes and Ears”

Illicit discharge or connection spotted…now what?

Document details Take pictures (if possible) Report it Follow up

What to Report and to Whom?

Details of the illicit discharge incident Address or cross-street information Identify person or agency responding Notify appropriate person or agency

Reporting Illicit Discharges

• Emergency
• 911
• MDEQ Pollution Emergency Alerting

System (PEAS), 24 hour (800) 292- 4706

• Non-Emergencies
• County Health/Environmental

contact

• Local Community IDEP Coordinator
• Local Soil Erosion Control Agency

Wayne County IDEP Accomplishments

Over 259 million gallons per year of polluted water removed Over 1,200 miles of county drains inspected Over $1.8 Million grant funded investigations performed Over 9,700 facilities inspected Over 700 facilities with illicit connections / discharges 2,407 illicit discharge sources identified

Dye Testing

Floor Drains 54% Sinks 19% Toilets 11%

Type of Illicit Discharges Identified

Wayne County

1987-2012

Outdoor Washing Pads Washing Machines Drinking Fountains Sump Pumps Swimming Pool Drains Machinery Process Water Showers Urinals Other (Not specified)

Violations less than 3%

• Over 75 million gallons

per year of pollution removed

• Over 400 county drains

and 5,000 road drains inspected

• Over $1.5 Million grant

funded investigations performed (2001- 2012)

Partners: Environmental Health, Public Works, Department of Roads, Local Governments & Schools

Macomb County IDEP Accomplishments

Success Story Middle 3 Rouge

Success Story Middle 3 Rouge

• E. coli Daily Beach Standard

Success Story Middle 3 Rouge Macroinvertebrate Communities

Middle 3 Storm Water Management Area Macroinvertebtrate Data Trend Spring 2001-2012 All Sites (Wayne County Data)

10 20 30 40 50 2004 2005 2006 2007 2008 2009 2010 2011 2012 2013 Year SQI Score

p =0.027785 Slope=1.5019  - Site Score

USEFUL WEBSITES



http://www.waynecounty.com/doe



http://www.rougeriver.com



http://www.epa.gov



http://www.michigan.gov/deq



http://www.cwp.org On-site Sewage Disposal Ordinances online:



http://www.macombcountymi.gov/publichealth



http://www.wcdoe.org/watershed/regulations



http://www.ewashtenaw.org/government/departments/environmental_health/wells_septic

It takes a partnership for effective pollution prevention

County Executive

Wayne County Department

• f Public Services

This training session was developed as part of the Rouge River National Wet Weather Demonstration Project, which is funded, in part, by the United States Environmental Protection Agency grant #XP995743– 09
