SLIDE 1

DBMS Data Loading: An Analysis on Modern Hardware

Adam Dziedzic, Manos Karpathiotakis*, Ioannis Alagiannis, Raja Appuswamy, Anastasia Ailamaki

SLIDE 2

Data loading: A necessary evil

2

Data loading is a persistent analysis bottleneck

 Top query performance  ACID guarantees  Volume => Expensive 40 zettabytes by 2020*  Velocity => Continuous Fresh data = Interesting data₸

₸ Abad [IISWC12]

* [IDC12]

SLIDE 3

Loading a DBMS

3

Read Load Convert

How does hardware affect loading?

SLIDE 4

Loading a DBMS

3

Read Load Convert

How does hardware affect loading?

SLIDE 5

Experimental setup

Hardware

– Dual socket 8 cores Intel(R) Xeon(R) CPU E5-2640 – 64 GB RAM – HDD: 4 x 500 GB 7.5k RPM SATA disks – SSD: 3 x 200GB SSD disks – DAS: 24 x 500 GB 7.5k RPM SATA disks

Software

– PostgreSQL, DBMS-R – MonetDB, DBMS-C – PostgreSQL parallel external loader (“PCOPY”)

Benchmarks & Real-world Datasets

4

SLIDE 6

1500 3000 4500 6000 7500 25 50 75 100

Loading Time (sec) File size (GB) Symantec Loading Time

Single-threaded data loading

5

Effect of compression

1500 3000 4500 6000 7500 25 50 75 100

Loading Time (sec) File size (GB) TPC-H Loading Time

DBMS-C PostgreSQL MonetDB DBMS-R

[Input storage: HDD Destination storage: DAS]

Dataset characteristics matter

SLIDE 7

1000 2000 3000 25 50 75 100

Loading Time (sec) File size (GB) Symantec Loading Time

Parallel data loading

6

Sublinear speedup for 16 threads

1000 2000 3000 25 50 75 100

Loading Time (sec) File size (GB) TPC-H Loading Time

DBMS-C MonetDB DBMS-R PCOPY

Input storage: HDD - Destination storage: DAS 16 threads Speedup – 16 threads DBMS-R PCOPY MonetDB DBMS-C TPC-H 100GB 1.25 2.77 1.72 2.84 Symantec 100GB 0.87 1.9 2.1

SLIDE 8

20 40 60 80 100 25 50 75 100 Utilzation (%)

Time (sec) DBMS-R, TPC-H SF10 In: HDD - Out: DAS

Write BW

7

Resource Utilization

Unable to saturate resources

SLIDE 9

20 40 60 80 100 25 50 75 100 Utilzation (%)

Time (sec) DBMS-R, TPC-H SF10 In: HDD - Out: DAS

Write BW

7

Resource Utilization

Unable to saturate resources

SLIDE 10

20 40 60 80 100 25 50 75 100 Utilzation (%)

Time (sec) DBMS-R, TPC-H SF10 In: HDD - Out: DAS

Read BW Write BW

7

Resource Utilization

Unable to saturate resources

SLIDE 11

20 40 60 80 100 25 50 75 100 Utilzation (%)

Time (sec) DBMS-R, TPC-H SF10 In: HDD - Out: DAS

CPU Read BW Write BW

7

Resource Utilization

Unable to saturate resources

SLIDE 12

5 10 15 20 25 30 25 50 75 100 I/O Wait (%) DBMS-R MonetDB 20 40 60 80 100 25 50 75 100 Utilzation (%)

Time (sec) DBMS-R, TPC-H SF10 In: HDD - Out: DAS

CPU Read BW Write BW

7

Resource Utilization

Unable to saturate resources

SLIDE 13

Read patterns

8

Block Address Elapsed Time

MonetDB

Block Address Elapsed Time

DBMS-R

Random I/O causes underutilization

[TPC-H SF10 Input storage: HDD Destination storage: DAS]

SLIDE 14

Serial reader vs. Parallel readers

9

# readers depends on input device speed Serial reader improves read utilization

20 40 60 80 100 10 20 30 40 50 60 70 80 90 100 Read Utilzation (%)

Time (sec) PCOPY read utilization

Serial Reader Parallel Readers [TPC-H SF10 Input storage: HDD Destination storage: DAS]

SLIDE 15

Impact of storage

10

SLIDE 16

Impact of storage

11

100 200 300 400 PCOPY DBMS-R DBMS-C

Loading Time (sec)

HDD Source Storage

HDD to DAS HDD to SSD HDD to ramfs

[TPC-H SF10]

100 200 300 400 PCOPY DBMS-R DBMS-C

Loading Time (sec)

DAS Destination Storage

HDD to DAS SSD to DAS ramfs to DAS

Write bottleneck when source storage is fast Slow source storage bottlenecks all systems

Slow input storage Varying input storage

SLIDE 17

Best-case storage scenario

12

100% CPU utilization, yet B/W still underutilized

100 200 300 400

PCOPY DBMS-R DBMS-C Loading Time (sec)

ramfs Source Storage

ramfs to HDD ramfs to DAS ramfs to SSD ramfs to ramfs

[TPC-H SF10] 20 40 60 80 100 5 10 15 20 25 30 CPU Utilization (%)

Time (sec) DBMS-R In: ramfs – Out: ramfs

Device Bandwidth: 12.8 GB/sec Read Rate: 250 MB/sec

SLIDE 18

Data loading: Where does time go?

13

0% 20% 40% 60% 80% 100% PostgreSQL MonetDB

CPU breakdown (%)

Other Write data Logging Tuple creation Conversion Tokenizing Parsing

Parsing, conversion, tokenization hotspots

[10 int columns; 10GB]

SLIDE 19

Reducing data loading overheads

14

NoDB Data Vaults Instant Loading RAW FPGAs GPUs

HW

Reduced Accesses

Optimized Code Path

SDS/Q

SLIDE 20

Bulk loading on modern hardware

General case: Resource under-utilization
Slow destination storage matters
Complex code paths bound max speed

15

SLIDE 21

Bulk loading on modern hardware

General case: Resource under-utilization
Slow destination storage matters
Complex code paths bound max speed

15

Thank You! Questions?

SLIDE 22

Backup Slides

16

SLIDE 23

50x data growth from 2010 to 2020

23

Can DBMS keep up with data growth?

[IDC2012]

SLIDE 24

Storage Characteristics

Name Capacity Configuration Read Speed Write Speed RPM HDD 2TB 4 x HDD (RAID-0) 170 MB/s 160 MB/s 7.5K DAS 12TB 24 x HDD (RAID-0) 1100 MB/s 330 MB/s 7.5K SSD 600GB 3 x SSD (RAID-0) 565 MB/s 268 MB/s n/a

24

SLIDE 25

Parallel data loading – 16 threads

7

Sublinear speedup for 16x DoP

4 8 12 16 25 50 75 100

Speedup File size (GB) TPC-H

PCOPY MonetDB DBMS-R DBMS-C

[Input storage: HDD Destination storage: DAS]

1 2 3 4 25 50 75 100

Speedup File size (GB) Symantec

SLIDE 26

Single-threaded loading – Extra datasets

26

Column stores invest in compression

1500 3000 4500 6000 7500 25 50 75 100

Loading Time (sec) File size (GB) TPC-C Loading Time

PostgreSQL MonetDB DBMS-R DBMS-C

Input storage: HDD Destination storage: DAS

1500 3000 4500 6000 7500 25 50 75 100

Loading Time (sec) File size (GB) SDSS Loading Time

SLIDE 27

Parallel data loading – Extra datasets

27

1000 2000 3000 4000 25 50 75 100

Loading Time (sec) File size (GB) TPC-C Loading Time

PCOPY MonetDB DBMS-R DBMS-C

Input storage: HDD Destination storage: DAS

1000 2000 3000 25 50 75 100

Loading Time (sec) File size (GB) SDSS Loading Time

SLIDE 28

4 8 12 16 25 50 75 100

Speedup File size (GB) SDSS

Parallel data loading – Extra datasets

28

1 2 3 4 25 50 75 100

Speedup File size (GB) TPC-C

PostgreSQL MonetDB DBMS-R DBMS-C

Input storage: HDD Destination storage: DAS

SLIDE 29

The effect of compression

Name TPC-H TPC-C SDSS Symantec DBMS-R 1.5 1.3 1.5 1.5 PostgreSQL 1.4 1.4 1.4 1.1 DBMS-C 0.27 0.82 0.18 0.25 MonetDB 1.1 1.4 1.0 0.92

29

Column stores: Reduced footprint favors OLAP

[10GB] DB size / input file

SLIDE 30

5 10 15 20 25 30 25 50 75 100 I/O Wait (%) PCOPY DBMS-R MonetDB DBMS-C 20 40 60 80 100 25 50 75 100 Utilzation (%)

Time (sec) DBMS-R, TPC-H SF10 In: HDD - Out: DAS

CPU Read BW Write BW

8

Resource Utilization

Unable to saturate resources

SLIDE 31

MonetDB utilization

31

20 40 60 80 100 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150

Utilzation (%) Time (sec)

[Data: TPCH – SF10 Input storage: HDD Destination storage: DAS]

SLIDE 32

PCOPY utilization

32

[Data: TPCH – SF10 Input storage: HDD Destination storage: DAS] 20 40 60 80 100 10 20 30 40 50 60 70 80 90 100 110 Utilzation (%)

Time (sec)

CPU Read BW

SLIDE 33

DBMS-C utilization

33

[Data: TPCH – SF10 Input storage: HDD Destination storage: DAS] 20 40 60 80 100 25 50 75 100 125 150 175 200 225 Utilzation (%)

Time (sec)

SLIDE 34

DBMS-C read patterns

34

SLIDE 35

Reducing data loading overheads

In situ querying [SIGMOD12, VLDB14]
Data Vaults: Exploit metadata [Ivanova12,Kargin15]
Instant Loading: SIMD & Code gen. [Muehlbauer13]
Accelerators (FPGAs, GPUs)

35
