Center for Evolutionary Medicine and Informatics Sparse Screening for Exact Data Reduction Jieping Ye Arizona State University Joint work with Jie Wang and Jun Liu 1 Center for Evolutionary Medicine and Informatics wide data feature

slide-1
SLIDE 1

Center for Evolutionary Medicine and Informatics

Sparse Screening for Exact Data Reduction

Jieping Ye

Arizona State University

1

Joint work with Jie Wang and Jun Liu

slide-2
SLIDE 2

Center for Evolutionary Medicine and Informatics

2

wide data tall data sample reduction feature reduction

slide-3
SLIDE 3

Center for Evolutionary Medicine and Informatics

The model learnt from the reduced data is identical to the model learnt from the full data. We focus on two models in this talk:

Lasso for wide data (feature reduction) SVM for tall data (sample reduction)

3

Sparse Screening: A New Framework for Exact Data Reduction

slide-4
SLIDE 4

Center for Evolutionary Medicine and Informatics

4

slide-5
SLIDE 5

Center for Evolutionary Medicine and Informatics

Lasso/Basis Pursuit

(Tibshirani, 1996, Chen, Donoho, and Saunders, 1999)

… =

× + y A z n×1 n×p n×1 p×1 x

5

Simultaneous feature selection and regression

slide-6
SLIDE 6

Center for Evolutionary Medicine and Informatics

Imaging Genetics

(Thompson et al. 2013)

6

slide-7
SLIDE 7

Center for Evolutionary Medicine and Informatics

Sparse Reduced-Rank Regression

7

Vounou et al. (2010, 2012)

slide-8
SLIDE 8

Center for Evolutionary Medicine and Informatics

Structured Sparse Models

8

Group Lasso Tree Lasso Fused Lasso Graph Lasso

slide-9
SLIDE 9

Center for Evolutionary Medicine and Informatics

9

Sparsity has become an important modeling tool in genomics, genetics, signal and audio processing, image processing, neuroscience (theory of sparse coding), machine learning, statistics …

slide-10
SLIDE 10

Center for Evolutionary Medicine and Informatics

Optimization Algorithms

  • Coordinate descent
  • Subgradient descent
  • Augmented Lagrangian Method
  • Gradient descent
  • Accelerated gradient descent
  • …

10

min loss(x) + λ×penalty(x)

slide-11
SLIDE 11

Center for Evolutionary Medicine and Informatics

Lasso Fused Lasso Group Lasso Sparse Group Lasso Tree Structured Group Lasso Overlapping Group Lasso Sparse Inverse Covariance Estimation Trace Norm Minimization http://www.public.asu.edu/~jye02/Software/SLEP/

11

slide-12
SLIDE 12

Center for Evolutionary Medicine and Informatics

More Efficiency?

12

Very high dimensional data Non-smooth sparsity-induced norms Multiple runs in model selection A large number of runs in permutation test

slide-13
SLIDE 13

Center for Evolutionary Medicine and Informatics

How to make any existing Lasso solver much more efficient?

13

slide-14
SLIDE 14

Center for Evolutionary Medicine and Informatics

14

1M 1K

Data Reduction/Compression

  • riginal data reduced data
slide-15
SLIDE 15

Center for Evolutionary Medicine and Informatics

Data Reduction

  • Heuristic-based data reduction

– Sure screening, random projection/selection – Resulting model is an approximation of the true model

  • Propose data reduction methods

– Exact data reduction via sparse screening

  • The model based on reduced data is identical to the
  • ne constructed from complete data

15

slide-16
SLIDE 16

Center for Evolutionary Medicine and Informatics

16

with screening same solution 1M 1M 1K without screening

Sparse Screening

slide-17
SLIDE 17

Center for Evolutionary Medicine and Informatics

Large-Scale Sparse Screening

slide-18
SLIDE 18

Center for Evolutionary Medicine and Informatics

Screening Rule: Motivation

Ghaoui, Viallon, and Rabbani.

slide-19
SLIDE 19

Center for Evolutionary Medicine and Informatics

Large-Scale Sparse Screening (Cont’d)

slide-20
SLIDE 20

Center for Evolutionary Medicine and Informatics

More on the Dual Formulation

  • Solving the dual formulation is difficult
  • Providing a good (not exact) estimate of the
  • ptimal dual solution is easier
  • A good estimate of the optimal dual solution is

sufficient for effective feature screening

20

slide-21
SLIDE 21

Center for Evolutionary Medicine and Informatics

Screening Rule

21

slide-22
SLIDE 22

Center for Evolutionary Medicine and Informatics

Sketch of Sparse Screening

22

slide-23
SLIDE 23

Center for Evolutionary Medicine and Informatics

How to Estimate the Region Θ?

  • J. Wang et al. NIPS’13; J. Liu et al. ICML’14

Non-expansiveness:

slide-24
SLIDE 24

Center for Evolutionary Medicine and Informatics

Enhanced DPP

24

Use projections of rays: Define: Enhanced DPP:

slide-25
SLIDE 25

Center for Evolutionary Medicine and Informatics

Firmly Non-expansive Projection

25

Non-expansiveness: Firmly non-expansiveness:

slide-26
SLIDE 26

Center for Evolutionary Medicine and Informatics

26

Results on MNIST along a sequence of 100 parameter values along the λ/λmax scale from 0.05 to 1. The data matrix is of size 784x50,000

slide-27
SLIDE 27

Center for Evolutionary Medicine and Informatics

27

Evaluation on MNIST

solver SAFE DPP EDPP SDPP time (s) 2245.26 685.12 233.85 45.56 9.34

100 200 300

SAFE DPP EDPP SDPP Speedup

slide-28
SLIDE 28

Center for Evolutionary Medicine and Informatics

Evaluation on ADNI

  • Problem: GWAS to MRI ROI prediction (ADNI)

– The size of the data matrix is 747 by 504095

Method ROI3 ROI8 ROI30 ROI69 ROI76 ROI83 Lasso Solver 37975.31 37097.25 38258.72 36926.81 38116.29 37251.03 SR 84.06 84.44 84.70 83.09 82.76 85.39 SR+Lasso 217.08 215.90 223.39 214.36 212.04 211.57 EDDP 43.56 45.75 45.70 45.01 44.31 44.16 EDDP+Lasso 183.64 190.43 182.87 170.71 177.41 178.98 Running time (in seconds) of the Lasso solver, strong rule (Tibshriani et al, 2012), and

  • EDPP. The parameter sequence contains 100 values along the log λ/λmax scale from

100 log 0.95 to log 0.95.

slide-29
SLIDE 29

Center for Evolutionary Medicine and Informatics

Sparse Screening Extensions

  • Group Lasso

– J Wang, J Liu, J Ye. Efficient Mixed-Norm Regularization: Algorithms and Safe Screening Methods. arXiv preprint arXiv:1307.4156.

  • Sparse Logistic Regression

– J Wang, J Zhou, P Wonka, J Ye. A Safe Screening Rule for Sparse Logistic

  • Regression. arXiv preprint arXiv:1307.4145.
  • Sparse Inverse Covariance Estimation

– S Huang, J Li, L Sun, J Liu, T Wu, K Chen, A Fleisher, E Reiman, J Ye. Learning brain connectivity of Alzheimer’s disease by exploratory graphical models. NeuroImage 50, 935-949. – Witten, Friedman and Simon (2011), Mazumder and Hastie (2012)

  • Multiple Graphical Lasso

– S Yang, Z Pan, X Shen, P Wonka, J Ye. Fused Multiple Graphical Lasso. arXiv preprint arXiv:1209.2139.

29

slide-30
SLIDE 30

Center for Evolutionary Medicine and Informatics

Wide versus Tall Data

30

wide data tall data

slide-31
SLIDE 31

Center for Evolutionary Medicine and Informatics

Support Vector Machines

  • SVM is a maximum margin classifier.

31

denotes +1 denotes -1 Margin

slide-32
SLIDE 32

Center for Evolutionary Medicine and Informatics

Support Vectors

  • SVM is determined by the so-called support vectors.

32

Support Vectors are those data points that the margin pushes up against denotes +1 denotes -1

The non-support vectors are irrelevant to the classifier. Can we make use of this

  • bservation?
slide-33
SLIDE 33

Center for Evolutionary Medicine and Informatics

The Idea of Sample Screening

33

Original Problem Screening

Smaller Problem to Solve

slide-34
SLIDE 34

Center for Evolutionary Medicine and Informatics

Guidelines for Sample Screening

34

  • J. Wang, P. Wonka, and J. Ye. ICML’14.
slide-35
SLIDE 35

Center for Evolutionary Medicine and Informatics

Relaxed Guidelines

35

slide-36
SLIDE 36

Center for Evolutionary Medicine and Informatics

Sketch of SVM Screening

36

slide-37
SLIDE 37

Center for Evolutionary Medicine and Informatics

Synthetic Studies

37

  • We use the rejection rates to measure the performance of the screening rules, the ratio of

the number of data instances whose membership can be identified by the rule to the total number of data instances.

slide-38
SLIDE 38

Center for Evolutionary Medicine and Informatics

Performance of DVI for SVM on Real Data Sets

38

Comparison of SSNSV (Ogawa et al., ICML’13), ESSNSV and DVIs for SVM on three real data sets.

IJCNN, , Speedup Solver Total 4669.14 Solver + SSNSV SSNSV 2.08

2.31

Init. 92.45 Total 2018.55 Solver + ESSNS V ESSNSV 2.09

3.01

Init. 91.33 Total 1552.72 Solver + DVI DVI 0.99

5.64

Init. 42.67 Total 828.02 Wine, , Speedup Solver Total 76.52 Solver + SSNSV SSNSV 0.02

3.50

Init. 1.56 Total 21.85 Solver + ESSNS V ESSNSV 0.03

4.47

Init. 1.60 Total 17.17 Solver + DVI DVI 0.01

6.59

Init. 0.67 Total 11.62 Covertype, , Speedup Solver Total 1675.46 Solver + SSNSV SSNSV 2.73

7.60

Init. 35.52 Total 220.58 Solver + ESSNS V ESSNSV 2.89

10.72

Init. 36.13 Total 156.23 Solver + DVI DVI 1.27

79.18

Init. 12.57 Total 21.26

slide-39
SLIDE 39

Center for Evolutionary Medicine and Informatics

Experiments on Real Data Sets

39

Comparison of SSNSV (Ogawa et al., ICML’13), ESSNSV and DVIs for LAD on three real data sets.

Telescope, , Speedup Solver Total 122.34 Solver + DVI DVI 0.28

9.86

Init. 0.12 Total 12.14 Computer, , Speedup Solver Total 5.85 Solver + DVI DVI 0.08

19.21

Init. 0.05 Total 0.28 Telescope, , Speedup Solver Total 21.43 Solver + DVI DVI 0.06

114.91

Init. 0.1 Total 0.19

slide-40
SLIDE 40

Center for Evolutionary Medicine and Informatics

Resource

40

  • Tutorial webpages of our screening rules, which include sample codes,

implementation instructions, illustration materials, etc.

http://www.public.asu.edu/~jwang237/screening.html

Seven lines implementation

  • f EDPP rule

The list is growing quickly

slide-41
SLIDE 41

Center for Evolutionary Medicine and Informatics

Summary

  • Developed exact data reduction approaches

– Exact data reduction via feature screening – Exact data reduction via sample screening

  • The model based on reduced data is identical to the
  • ne constructed from complete data
  • Results show screening leads to a significant speedup.
  • Extend exact data reduction to other sparse learning

formulations

– Sparsity on features, samples, networks etc

41
