CS356: Discussion #10

Dynamic Memory and Cache Lab

Illustrations from CS:APP3e textbook

Goal

• To write a small C simulator of caching strategies.
• Expect about 200-300 lines of code.
• Starting point in your repository.

Traces

• The traces directory contains program traces generated by valgrind
• The format of each line is: <operation> <address>,<size>

For example: “I 0400d7d4,8” “M 0421c7f0,4” “L 04f6b868,8”

• Operations

○ Instruction load: I (ignore these) ○ Data load: ฀L (hit, miss, miss/eviction) ○ Data store: ฀S (hit, miss, miss/eviction) ○ Data modify: ฀M (load+store: hit/hit, miss/hit, miss/eviction/hit) http://bytes.usc.edu/cs356/assignments/cachelab.pdf

Cache Lab

Reference Cache Simulator

./csim-ref [-hv] -S <S> -K <K> -B <B> -p <P> -t <tracefile>

• h Optional help flag that prints usage information
• v Optional verbose flag that displays trace information
• S <S> Number of sets (s=log2(S) is the number of bits used for the set index)
• K <K> Number of lines per set (associativity)
• B <B> Number of block size (i.e., use B = 2b bytes / block)
• p <P> Selects a policy, either LRU or FIFO
• t <tracefile> select a trace

$ ./csim-ref -S 16 -K 1 -B 16 –p LRU -t traces/yi.trace hits:4 misses:5 evictions:3 $ ./csim-ref -S 16 -K 1 -B 16 –p LRU -v -t traces/yi.trace L 10,1 miss M 20,1 miss hit ... ... M 12,1 miss eviction hit hits:4 misses:5 evictions:3 (See https://usc-cs356.github.io/assignments/cachelab.html)

Reference Cache Simulator

$ ./csim-ref -S 2 -K 2 -B 2 -p LRU -v -t traces/simple_policy.trace L 0,1 miss L 1,1 hit L 2,1 miss L 6,1 miss L 2,1 hit L a,1 miss eviction L 2,1 hit hits:3 misses:4 evictions:1 $ ./csim-ref -S 2 -K 2 -B 2 -p FIFO -v -t traces/simple_policy.trace L 0,1 miss L 1,1 hit L 2,1 miss L 6,1 miss L 2,1 hit L a,1 miss eviction L 2,1 miss eviction hits:2 misses:5 evictions:2

LRU and FIFO

Reference Cache Simulator

$ ./csim-ref -S 2 -K 1 -B 4 -p LRU -v -t traces/simple_size.trace L 0,2 miss L 1,2 hit L 3,1 hit L 6,6 miss miss eviction L 3,1 miss eviction hits:2 misses:4 evictions:2

Memory accesses that cross a line boundary

Your Simulator

Metadata Metadata Metadata Metadata Metadata Metadata

?? bits per line to support eviction policy

Not needed in this lab

Your Simulator

struct Line { // include valid bit, tag, and metadata };

Flat array for 𝑇 × 𝐿 struct Line

Example 1 struct Line { // include valid bit, tag, and metadata }; struct Line *cache; cache = (struct Line *)malloc(S * K * sizeof(struct Line));

Your Simulator

Array for 𝑇

struct Line *

Array for 𝐿 struct Line per set

struct Line ** Example 2 struct Line **cache; cache = (struct Line **)malloc(...); for i = 0, 1, ..., S-1 do cache[i] = (struct Line *)malloc(...); struct Line { // include valid bit, tag, and metadata };

Your Simulator

Fill in the csim.c file to:

• Accept the same command-line options.
• Produce identical output.

Rules

• Include name and username in the header.
• Use only C code (must compile with gcc -std=c11)
• Use malloc to allocate data structures for arbitrary S, K, B
• Implement both LRU and FIFO policies.
• Ignore instruction cache accesses (starting with I).
• Memory accesses can cross block boundaries:

⇒ How to deal with this?

• At the end of your main function, call:

printSummary(hit_count, miss_count, eviction_count)

Evaluation

3 test suites:

• Direct Mapped: K = 1; no need to implement an eviction policy
• Policy Tests: check that LRU and FIFO policies work correctly
• Size Tests: include memory accesses that cross a line boundary

You only need to output the correct number of cache hits, misses, evictions.

• You can run csim-ref -v to check the expected behavior.
• Start from small traces such as traces/dave.traces
• Use the getopt library to parse command-line arguments.

○ int s = atoi(arg_str); int S = pow(2, s); You must pass all tests in a test suite to receive its points.

Problems

• How to parse the input traces?

○ fopen (open a file), fgets (read a line), sscanf (parse a line), fclose

• How to represent the cache? How to allocate memory for any s, E, b?

○ Cache = S sets ○ Each set = E cache lines ○ Use malloc and free

• What needs to be stored in a cache line?

○ Valid bit, tag, and what else? ○ How to keep track of statistics for LRU and FIFO policies?

• How to retrieve data at a memory address?

○ How to extract tag / set / block bits from an input address? ○ How to select the correct set? And how to look for a hit? ○ What to update in case of hit (in addition to hit counter)? ○ What to do in case of miss?

• Useful: Print the content of the cache after each request in a trace

Dynamic Memory Allocation in C

Low-level memory allocation in Linux void *mmap(void *addr, size_t length, int prot, int flags, int fd, off_t off) int munmap(void *addr, size_t length) void *sbrk(intptr_t increment) Portable alternatives in stdlib void *malloc(size_t size) void *calloc(size_t nmemb, size_t size) void *realloc(void *ptr, size_t size) void free(void *ptr) Check man pages for these functions! $ man malloc

malloc and free in action

Each square represents 4 bytes. malloc returns addresses at multiples of 8 bytes (64 bit). If there is a problem, malloc returns NULL and sets errno. malloc does not initialize to 0, use calloc instead.

Using malloc and free

#include <stdlib.h> #include <stdio.h> int compare(const void *x, const void *y) { int xval = *(int *)x; int yval = *(int *)y; if (xval < yval) return -1; else if (xval == yval) return 0; else return 1; }

$ gcc sort.c -o sort $ ./sort How many numbers to sort? 4 Please input 4 numbers: 2 3 1 -1 Sorted numbers: -1 1 2 3

int main() { int count = 0; printf("How many numbers to sort? "); if (scanf("%d", &count) != 1) { fprintf(stderr, "Invalid input\n"); return 1; } int *numbers = (int *) malloc(count * sizeof(int)); printf("Please input %d numbers: ", count); for (int i = 0; i < count; i++) { if (scanf("%d", &numbers[i]) != 1) { fprintf(stderr, "Invalid input\n"); return 1; } } qsort(numbers, count, sizeof(int), compare); printf("Sorted numbers:"); for (int i = 0; i < count; i++) { printf(" %d", numbers[i]); } printf("\n"); free(numbers); return 0; }

Memory-Related Bugs

/* Return y = Ax */ int *matvec(int **A, int *x, int n) { int i, j; int *y = (int *)malloc(n * sizeof(int)); /* should set y[i] = 0 (or use calloc) */ for (i = 0; i < n; i++) { for (j = 0; j < n; j++) { y[i] += A[i][j] * x[j]; } } return y; } void buffer_overflow() { char buf[64]; gets(buf); /* use fgets instead */ return; } void bad_pointer() { int val; scanf("%d", val); /* use &val */ } int *stackref() { int val; return &val; /* val is a local variable */ } void leak(int n) { int *x = (int *)malloc(n * sizeof(int)); return; /* x is garbage at this point */ } int *search(int *p, int val) { while (*p && *p != val) p += sizeof(int); /* should be p++ */ return p; }

Memory-Related Bugs

/* Create an nxm array */ int **makeArray1(int n, int m) { int i; /* should be sizeof(int*) */ int **A = (int **)malloc(n * sizeof(int)); for (i = 0; i < n; i++) { A[i] = (int *)malloc(m * sizeof(int)); } return A; } /* Create an nxm array */ int **makeArray2(int n, int m) { int i; int **A = (int **)malloc(n * sizeof(int *)); /* should be .. i < n .. */ for (i = 0; i <= n; i++) { A[i] = (int *)malloc(m * sizeof(int)); } return A; } int *binheapDelete(int **binheap, int *size) { int *packet = binheap[0]; binheap[0] = binheap[*size - 1]; *size--; /* This should be (*size)-- */ heapify(binheap, *size, 0); return(packet); } int *heapref(int n, int m) { int i; int *x, *y; x = (int *)malloc(n * sizeof(int)); /* ... */ /* Other calls to malloc and free here */ free(x); y = (int *)malloc(m * sizeof(int)); for (i = 0; i < m; i++) { y[i] = x[i]++; /* x[i] in freed block */ } return y; }

Explicit Heap Allocators

Explicit allocators like malloc

• Must handle arbitrary sequences of allocate/free requests
• Must respond immediately (no buffering of requests)
• Helper data structures must be stored in the heap itself
• Payloads must be aligned to 8-bytes boundaries
• Allocated blocks cannot be moved/modified

Goal 1. Maximize throughput: (# completed requests) / second

• Simple to implement malloc with running time O(# free blocks)

and free with running time O(1) Goal 2. Maximize peak utilization: max{ allocated(t) : t ⩽ T} / heapsize(T)

• If the heap can shrink, take max{ heapsize(t) : t ⩽ T}
• Problem: fragmentation, internal (e.g., larger block allocated for alignment)
• r external (free space between allocated blocks)
• Severity of external fragmentation depends also on future requests

Implementation: Implicit Free Lists

• Block size includes header/padding, always a multiple of 8 bytes.
• Can scan the list using headers but O(# blocks), not O(# free blocks)
• Special terminating header: zero size, allocated bit set (will not be merged)
• With 1-word header and 2-word alignment, minimum block size is 2 words

Each square represents 4 bytes Header: (block size) / (allocated)

Exercise

Assume:

• 8-byte alignment
• Block sizes multiples of 8 bytes
• Implicit free list with 4-byte header (format from previous slide)

Block size (in bytes) and block header (in hex) for blocks allocated by the following sequence: malloc(1) malloc(5) malloc(12) malloc(13)

• malloc(1): 8 bytes, block header 0x00000009 == 0...01001
• malloc(5): 16 bytes, block header 0x00000011 == 0...10001
• malloc(12): 16 bytes, block header 0x00000011 == 0...10001
• malloc(13): 24 bytes, block header 0x00000019 == 0...11001

Block Placing and Splitting of Free Blocks

• If multiple blocks are available in the list, which one to pick?

○ First Fit: First block with enough space. ⇒ retains large blocks at the end of the list, but must skip many ○ Next Fit: First block with enough space, start from last position. ⇒ no need to skip small blocks at start, but worse memory utilization ○ Best Fit: Smallest block with enough space. ⇒ generally better utilization, but slower (must check all blocks)

• If available space is larger than required, what to do?

○ Assign entire block ⇒ internal fragmentation (ok for good fit) ○ Split the block at 2-word boundary, add another header

Getting additional memory

What to do when no free block is large enough?

• Extend the heap by calling sbrk(intptr_t increment)

○ Returns a pointer to the start of the new area

• Coalesce adjacent free blocks

○ Can coalesce both previous and following block ○ Coalescing when freeing blocks is O(1) but allows thrashing ○ Boundary tag Use a “footer” at the end of each (free) block to fetch previous block

Coalescing Cases

Explicit Free Lists

Allocation time is O(#blocks) for implicit lists...

• Idea. Organize free blocks as a doubly-linked list (pointer inside free blocks)
• LIFO ordering, first-fit placement ⇒ O(1) freeing/coalescing (boundary tags)
• Address order, first-fit placement ⇒ O(#free blocks) freeing

Much faster when memory is full, but lower memory utilization.

Explicit Free Lists: Example

16/0 16/0 24/1 24/1 16/0 ⨯ 16/0 16/0 ⨯ 16/0 0/1

• Still need boundary tags for coalescing
• The next free block can be anywhere in the heap
• Freeing with LIFO policy

○ No coalescing: just add element to list head ○ Coalescing: remove contiguous blocks from free list, merge them, add the new free block to list head

Free List Root

Segregated Free Lists

To reduce allocation time:

• Partition free blocks into size classes, e.g., (2(i), 2(i+1)]
• Keep a list of free blocks for each class
• Add freed blocks to the appropriate class
• Search a block of size n in the appropriate class, then following ones

1-8 9-16 17-32 33-64 65-∞

Segregated Free Lists: Implementation

Simple Segregated

• Allocate maximum class size (e.g., 2(i+1)), never split free blocks
• Can assign first block from list and add freed blocks to front
• If list is empty, extend the heap and add blocks to list
• No header/footer required for allocated blocks, singly-linked free list

Segregated Fits

• First-fit search in appropriate class, split and add remaining to some class
• To free a block, coalesce and place result in appropriate class

Advantages

• Higher throughput: log-time search for power-of-two size classes
• Higher utilization: first-fit with segregated lists is closer to best fit
