Crenshaw/LAX Transit Corridor Industry Review September 12, 2011 Crenshaw/LAX Transit Corridor Industry Review Agenda Welcome Program Overview Design Overview Proposed Procurement Schedule Open Discussion Crenshaw/LAX

SLIDE 1

Crenshaw/LAX Transit Corridor Industry Review

September 12, 2011

SLIDE 2

Welcome
Program Overview
Design Overview
Proposed Procurement Schedule
Open Discussion

Crenshaw/LAX Transit Corridor Industry Review Agenda

SLIDE 3

Crenshaw/LAX Transit Corridor Project Status

Federal Register – August 31, 2011
Board Certifies Project – September 22,

2011

Record of Decision – October 24, 2011

(Target Date)

SLIDE 4

Crenshaw/LAX Transit Corridor Project Overview

8.5 mile Light Rail Line
Includes Maintenance & Storage Facility
Project Budget: $1.715 billion (YOE)
Extends from Exposition at Crenshaw Blvd to MGL
Offers major connections with LAX, links to Metro

Green Line and Exposition Line

Station Locations: Exposition Bl, Vernon (optional),

Martin Luther King Jr., Slauson Ave, West Bl, La Brea Ave, Manchester Ave (optional), Century Bl

Aerial Grade Separations: La Cienega/I-405,

Manchester, Century Bl

Below Grade: Exposition to 48th St., 59th to Victoria

Ave, La Brea, adjacent to LAX South runways

Balance of project at grade

SLIDE 5

Crenshaw/LAX Transit Corridor Environmental Constraints

Environmental Mitigation Requirements
Station Locations
Grade Separations
Park and Ride Facilities
General Configuration

SLIDE 6

Crenshaw/LAX Transit Corridor Base Project - Alignment

SLIDE 7

Crenshaw/LAX Transit Corridor Base Project – Vertical Profile

SLIDE 8

Crenshaw/LAX Transit Corridor Design Revisions

1. Partially Covered LAX Trench with provisions for extended cover 2. BNSF Abandonment 3. Vernon (Leimert Park) Station Contract Option

SLIDE 9

Crenshaw/LAX Transit Corridor Green Line to Century Blvd

SLIDE 10

At-Grade Freight Rail ROW Aviation Blvd Open Trench Three fence lines + guard rail Runway 7R Localizer Antenna Array Airport Service Road

Crenshaw/LAX Transit Corridor LAX Existing Conditions

SLIDE 11

Crenshaw/LAX Transit Corridor LAX Segment – Hybrid Option

SLIDE 12

Crenshaw/LAX Transit Corridor LAX Segment – Fully Covered (Future)

SLIDE 13

Crenshaw/LAX Transit Corridor Century Boulevard to Manchester

SLIDE 14

Crenshaw/LAX Transit Corridor Manchester to Centinela

SLIDE 15

Crenshaw/LAX Transit Corridor Centinela to W 59th

SLIDE 16

Crenshaw/LAX Transit Corridor W 59th to Martin Luther King Blvd

SLIDE 17

Crenshaw/LAX Transit Corridor Martin Luther King Blvd to Exposition Blvd

SLIDE 18

Crenshaw/LAX Transit Corridor Exposition Station Proposed Construction Zone

SLIDE 19

Crenshaw/MLK Station Construction Proposed Station Construction Staging

Staging area Proposed station entrance Approximate station footprint Create new Mall access Existing access closed off

NORTH

SLIDE 20

Crenshaw/LAX Transit Corridor Proposed Procurement Schedule

1. Alignment Contract(s)

Industry Review – August 15, 2011
Step 1 (RFQ – Quals) – November 2011
Step 2 (RFP – Technical/Price Proposal) – January 2012
Award – 4th Quarter 2012
NTP – 4th Quarter 2012

2. Southwestern Yard Contract

Issue Invitation for Bid – Fall 2012
Award – Winter 2013

3. Advanced Utility Relocations

Issue Invitation for Bid – Fall 2011
Award – Spring 2012

SLIDE 21
