CPR - Construction Products Registration

From 1st July 17 all non-fire performance cables introduced into the EU market which are to be a permanent fixture in a building

• r construction must comply with CPR

• Affects products installed

permanently in building and construction

• Includes Cables
• Looks at how they react

in the event of a fire

CPR

Cables

Medium Voltage Power Cable Low Voltage Power Cable Data and Fibre Cable Twin Cable Flat Cable Control Cable

The Cables Are Assessed For:

Flame Propagation Acidity Flaming Droplets & Particles Smoke Emissions

And are classified:

So What Does Compliance Mean

Conformite Europeanne Or European Conformity Assessment of Verification Of Constancy of Performance Declaration of Performance

DoP

CE

AVCP

CE Marking.

a) Applied to Product or product packaging b) May also be on the cable print markings c) CPR classification and key product information for traceability (DoP)

AVCP System.

Assessment and Verification of Consistency of Performance “1+” Including:

• Initial type-testing and continuous surveillance,
• Audit & testing of samples by 3rd party

certification body

• Factory production control by manufacturer

“3” including:

• initial type-testing by 3rd party laboratory
• factory production control by manufacturer

“4” including:

• initial type-testing and factory production

control by manufacturer

DoP

Cut Ticket replicates details of the CE label in greater detail Cut Ticket when CPR doesn’t apply

DoP

Cleveland Cable holds the manufacturers DoP

• n file

CPR Summary:

(a) Buy from reputable sources, Cleveland cable is CPR compliant (b) Only affects cables introduced to the EU market after the 1st Jul 17, all cables prior to this date can be legally sold and installed without CPR as it was not a requirement (c) CPR helps make informed purchasing decisions ...... But other standards still apply.
