SLIDE 1
Counting Convex k-gons in an Arrangement of Line Segments
Martin Fink, Neeraj Kumar and Subhash Suri
University of California, Santa Barbara
Motivation
Consider the following problem from computer vision:
Counting Convex k -gons in an Arrangement of Line Segments Martin - - PowerPoint PPT Presentation
Counting Convex k -gons in an Arrangement of Line Segments Martin - - PowerPoint PPT Presentation
Counting Convex k -gons in an Arrangement of Line Segments Martin Fink, Neeraj Kumar and Subhash Suri University of California, Santa Barbara Motivation Consider the following problem from computer vision: Motivation Consider the following
SLIDE 2
SLIDE 3
Motivation
Consider the following problem from computer vision: Given a camera image I representing object boundaries, estimate the number of rectangular objects in the scene.
SLIDE 4
Motivation
Consider the following problem from computer vision: Given a camera image I representing object boundaries, estimate the number of rectangular objects in the scene.
◮ Camera image I ⇒ Arrangement A of line segments
SLIDE 5
Motivation
Consider the following problem from computer vision: Given a camera image I representing object boundaries, estimate the number of rectangular objects in the scene.
◮ Camera image I ⇒ Arrangement A of line segments ◮ Perspective transformation:
Rectangles in scene ⇒ quadilaterals in image
SLIDE 6
Motivation
Consider the following problem from computer vision: Given a camera image I representing object boundaries, estimate the number of rectangular objects in the scene.
◮ Camera image I ⇒ Arrangement A of line segments ◮ Perspective transformation:
Rectangles in scene ⇒ quadilaterals in image
◮ Count all convex quadilaterals (4-gon) in an arrangement
SLIDE 7
Motivation
Consider the following problem from computer vision: Given a camera image I representing object boundaries, estimate the number of rectangular objects in the scene.
◮ Camera image I ⇒ Arrangement A of line segments ◮ Perspective transformation:
Rectangles in scene ⇒ quadilaterals in image
◮ Count all convex quadilaterals (4-gon) in an arrangement
Natural generalization to convex k-gons
SLIDE 8
Problem Definition
Given: An arrangement A(S) of line segments S in 2-D
a b c d e
SLIDE 9
Problem Definition
Given: An arrangement A(S) of line segments S in 2-D
a b c d e
A convex k-gon of A(S) is a convex polygon with k sides if:
SLIDE 10
Problem Definition
Given: An arrangement A(S) of line segments S in 2-D
1 2 3 4 5 6 7 a b c d e
A convex k-gon of A(S) is a convex polygon with k sides if:
◮ vertices are a subset of arrangement vertices.
SLIDE 11
Problem Definition
Given: An arrangement A(S) of line segments S in 2-D
1 2 3 4 5 6 7 a b c d e
A convex k-gon of A(S) is a convex polygon with k sides if:
◮ vertices are a subset of arrangement vertices. ◮ sides are part of input segments.
SLIDE 12
Problem Definition
Given: An arrangement A(S) of line segments S in 2-D
1 2 3 4 5 6 7 a b c d e k = 4
A convex k-gon of A(S) is a convex polygon with k sides if:
◮ vertices are a subset of arrangement vertices. ◮ sides are part of input segments.
SLIDE 13
Problem Definition
Given: An arrangement A(S) of line segments S in 2-D
1 2 3 4 5 6 7 a b c d e k = 4
A convex k-gon of A(S) is a convex polygon with k sides if:
◮ vertices are a subset of arrangement vertices. ◮ sides are part of input segments.
Goal: count and report all such k-gons.
SLIDE 14
Our Results
◮ Count all k-gons in O(n log n + mn) time and O(n2) space
(for constant k)
SLIDE 15
Our Results
◮ Count all k-gons in O(n log n + mn) time and O(n2) space
(for constant k)
◮ Report set of all k-gons K in O(|K|) additional time and
O(mn) additional space
SLIDE 16
Our Results
◮ Count all k-gons in O(n log n + mn) time and O(n2) space
(for constant k)
◮ Report set of all k-gons K in O(|K|) additional time and
O(mn) additional space Count in time much faster than the number of k-gons :
SLIDE 17
Our Results
◮ Count all k-gons in O(n log n + mn) time and O(n2) space
(for constant k)
◮ Report set of all k-gons K in O(|K|) additional time and
O(mn) additional space Count in time much faster than the number of k-gons : Θ(nk)
⌊ n
k ⌋
SLIDE 18
Our Results
◮ Count all k-gons in O(n log n + mn) time and O(n2) space
(for constant k)
◮ Report set of all k-gons K in O(|K|) additional time and
O(mn) additional space Count in time much faster than the number of k-gons : Θ(nk)
⌊ n
k ⌋
◮ Counting k-gons is as hard as the 3SUM problem, for k = 3, 4
SLIDE 19
Counting k-gons
A vertical line L intersects at most two sides of a k-gon P.
L span(P, L) = (a, b)
SLIDE 20
Counting k-gons
A vertical line L intersects at most two sides of a k-gon P.
a b L P span(P, L) = (a, b)
SLIDE 21
Counting k-gons
A vertical line L intersects at most two sides of a k-gon P.
a b L span(P, L) = (a, b) P
SLIDE 22
Counting k-gons
A vertical line L intersects at most two sides of a k-gon P.
a b L span(P, L) = (a, b) P
◮ O(n2) distinct spans (w.r.t. L) among all k-gons
SLIDE 23
Counting k-gons
A vertical line L intersects at most two sides of a k-gon P.
a b L span(P, L) = (a, b) P
◮ O(n2) distinct spans (w.r.t. L) among all k-gons ◮ Suggests a plane sweep based algorithm, key idea:
SLIDE 24
Counting k-gons
A vertical line L intersects at most two sides of a k-gon P.
a b L span(P, L) = (a, b) P
◮ O(n2) distinct spans (w.r.t. L) among all k-gons ◮ Suggests a plane sweep based algorithm, key idea:
◮ Assign a k-gon intersecting L to its span
SLIDE 25
Counting k-gons
A vertical line L intersects at most two sides of a k-gon P.
a b L span(P, L) = (a, b) P
◮ O(n2) distinct spans (w.r.t. L) among all k-gons ◮ Suggests a plane sweep based algorithm, key idea:
◮ Assign a k-gon intersecting L to its span ◮ Update count as we sweep L across the plane
SLIDE 26
Notation
L a b
◮ Open j-gons: All j ≤ k sides start left of L
SLIDE 27
Notation
L a b
◮ Open j-gons: All j ≤ k sides start left of L
SLIDE 28
Notation
L a b
◮ Open j-gons: All j ≤ k sides start left of L
◮ σ(a, b, j) : Number of open j-gons with span (a, b)
SLIDE 29
Notation
L a b σ(a, b, 5) = 2
◮ Open j-gons: All j ≤ k sides start left of L
◮ σ(a, b, j) : Number of open j-gons with span (a, b)
SLIDE 30
Notation
L a b
◮ Open j-gons: All j ≤ k sides start left of L
◮ σ(a, b, j) : Number of open j-gons with span (a, b)
◮ Closed k-gons: All k sides end left of L
SLIDE 31
Notation
L a b count = 2
◮ Open j-gons: All j ≤ k sides start left of L
◮ σ(a, b, j) : Number of open j-gons with span (a, b)
◮ Closed k-gons: All k sides end left of L
◮ count: number of k-gons left of L
SLIDE 32
Algorithm Steps
◮ Set count = 0 and σ(a, b, j) = 0, for all a, b, j
SLIDE 33
Algorithm Steps
◮ Set count = 0 and σ(a, b, j) = 0, for all a, b, j ◮ Compute all intersections (Event points)
SLIDE 34
Algorithm Steps
◮ Set count = 0 and σ(a, b, j) = 0, for all a, b, j ◮ Compute all intersections (Event points) ◮ For each event from left to right: Perform Updates
SLIDE 35
Algorithm Steps
◮ Set count = 0 and σ(a, b, j) = 0, for all a, b, j ◮ Compute all intersections (Event points) ◮ For each event from left to right: Perform Updates ◮ Return count
SLIDE 36
Updates at intersection (a, b)
a b pi L c d
SLIDE 37
Updates at intersection (a, b)
a b pi L c d
◮ Some k-gons complete
SLIDE 38
Updates at intersection (a, b)
a b pi L c d
◮ Some k-gons complete
◮ count += σ(a, b, k)
SLIDE 39
Updates at intersection (a, b)
a b pi L c d
◮ Some k-gons complete
◮ count += σ(a, b, k)
◮ A 2-gon begins
SLIDE 40
Updates at intersection (a, b)
a b pi L c d
◮ Some k-gons complete
◮ count += σ(a, b, k)
◮ A 2-gon begins
◮ σ(b, a, 2) = 1
SLIDE 41
Updates at intersection (a, b)
a b pi c d L
◮ Some k-gons complete
◮ count += σ(a, b, k)
◮ A 2-gon begins
◮ σ(b, a, 2) = 1
◮ Some j-gons grow into j + 1-gons
SLIDE 42
Updates at intersection (a, b)
a b pi c L d
◮ Some k-gons complete
◮ count += σ(a, b, k)
◮ A 2-gon begins
◮ σ(b, a, 2) = 1
◮ Some j-gons grow into j + 1-gons
◮ For all segments c above a
SLIDE 43
Updates at intersection (a, b)
a b pi c L d
◮ Some k-gons complete
◮ count += σ(a, b, k)
◮ A 2-gon begins
◮ σ(b, a, 2) = 1
◮ Some j-gons grow into j + 1-gons
◮ For all segments c above a
SLIDE 44
Updates at intersection (a, b)
a b pi c L d
◮ Some k-gons complete
◮ count += σ(a, b, k)
◮ A 2-gon begins
◮ σ(b, a, 2) = 1
◮ Some j-gons grow into j + 1-gons
◮ For all segments c above a
σ(c, b, j + 1) += σ(c, a, j)
SLIDE 45
Updates at intersection (a, b)
a b pi d L c
◮ Some k-gons complete
◮ count += σ(a, b, k)
◮ A 2-gon begins
◮ σ(b, a, 2) = 1
◮ Some j-gons grow into j + 1-gons
◮ For all segments c above a
σ(c, b, j + 1) += σ(c, a, j)
◮ For all segments d below b
SLIDE 46
Updates at intersection (a, b)
a b pi c d L
◮ Some k-gons complete
◮ count += σ(a, b, k)
◮ A 2-gon begins
◮ σ(b, a, 2) = 1
◮ Some j-gons grow into j + 1-gons
◮ For all segments c above a
σ(c, b, j + 1) += σ(c, a, j)
◮ For all segments d below b
SLIDE 47
Updates at intersection (a, b)
a b pi d L c
◮ Some k-gons complete
◮ count += σ(a, b, k)
◮ A 2-gon begins
◮ σ(b, a, 2) = 1
◮ Some j-gons grow into j + 1-gons
◮ For all segments c above a
σ(c, b, j + 1) += σ(c, a, j)
◮ For all segments d below b
σ(a, d, j + 1) += σ(b, d, j)
SLIDE 48
Updates at intersection (a, b)
a b pi c d L
◮ Some k-gons complete
◮ count += σ(a, b, k)
◮ A 2-gon begins
◮ σ(b, a, 2) = 1
◮ Some j-gons grow into j + 1-gons
◮ For all segments c above a
σ(c, b, j + 1) += σ(c, a, j)
◮ For all segments d below b
σ(a, d, j + 1) += σ(b, d, j)
Total O(n) time per intersection
SLIDE 49
Updates at intersection (a, b)
a b pi c d L
◮ Some k-gons complete
◮ count += σ(a, b, k)
◮ A 2-gon begins
◮ σ(b, a, 2) = 1
◮ Some j-gons grow into j + 1-gons
◮ For all segments c above a
σ(c, b, j + 1) += σ(c, a, j)
◮ For all segments d below b
σ(a, d, j + 1) += σ(b, d, j)
Total O(n) time per intersection Handles degenerate cases: apply pairwise updates collectively
SLIDE 50
Reporting Problem
Goal: Report all k-gons of the output set K.
SLIDE 51
Reporting Problem
Goal: Report all k-gons of the output set K. Keep track of updates using acyclic digraph G = (V , E, L)
1 2 3 4 5 6 7 a b c d e
SLIDE 52
Reporting Problem
Goal: Report all k-gons of the output set K. Keep track of updates using acyclic digraph G = (V , E, L)
1 2 3 4 5 6 7 a b c d e (c, a, 2)
Create a vertex for the new open 2-gon
SLIDE 53
Reporting Problem
Goal: Report all k-gons of the output set K. Keep track of updates using acyclic digraph G = (V , E, L)
1 2 3 4 5 6 7 a b c d e (c, a, 2) (b, a, 3)
2
Add an edge for a j-gon growing into j + 1-gon
SLIDE 54
Reporting Problem
Goal: Report all k-gons of the output set K. Keep track of updates using acyclic digraph G = (V , E, L)
1 2 3 4 5 6 7 a b c d e (c, a, 2) (b, a, 3) (b, d, 4)
2 3
Add an edge for a j-gon growing into j + 1-gon
SLIDE 55
Reporting Problem
Goal: Report all k-gons of the output set K. Keep track of updates using acyclic digraph G = (V , E, L)
1 2 3 4 5 6 7 a b c d e (c, a, 2) (b, a, 3) (b, d, 4) (d, a, 2) (e, a, 4)
2 3 4
Add an edge for a j-gon growing into j + 1-gon
SLIDE 56
Reporting Problem
Goal: Report all k-gons of the output set K. Keep track of updates using acyclic digraph G = (V , E, L)
1 2 3 4 5 6 7 a b c d e (c, a, 2) (b, a, 3) (b, d, 4) (d, a, 2) (e, a, 4) Q = { }
2 3 4
Append vertices for completed k-gons to Q
SLIDE 57
Reporting Problem
Goal: Report all k-gons of the output set K. Keep track of updates using acyclic digraph G = (V , E, L)
1 2 3 4 5 6 7 a b c d e (c, a, 2) (b, a, 3) (b, d, 4) (d, a, 2) (e, a, 4) Q = { }
2 3 7 4
Append vertices for completed k-gons to Q
SLIDE 58
Reporting Problem
Goal: Report all k-gons of the output set K. Keep track of updates using acyclic digraph G = (V , E, L)
1 2 3 4 5 6 7 a b c d e (c, a, 2) (d, a, 2) (b, a, 3) (e, a, 4) (b, d, 4)
2 7 4
Q = { }
3
Recursively enumerate all k-gons
SLIDE 59
Reporting Problem
Goal: Report all k-gons of the output set K. Keep track of updates using acyclic digraph G = (V , E, L)
1 2 3 4 5 6 7 a b c d e (c, a, 2) (d, a, 2) (b, a, 3) (e, a, 4) (b, d, 4)
2 7 4
Q = { }
3
Recursively enumerate all k-gons
SLIDE 60
Reporting Problem
Goal: Report all k-gons of the output set K. Keep track of updates using acyclic digraph G = (V , E, L)
1 2 3 4 5 6 7 a b c d e (c, a, 2) (d, a, 2) (b, a, 3) (e, a, 4) (b, d, 4)
2 7 4 3
Q = { }
Recursively enumerate all k-gons
SLIDE 61
Reporting Problem
Goal: Report all k-gons of the output set K. Keep track of updates using acyclic digraph G = (V , E, L)
1 2 3 4 5 6 7 a b c d e (c, a, 2) (d, a, 2) (b, a, 3) (e, a, 4) (b, d, 4)
2 7 4 3
Q = { }
Recursively enumerate all k-gons
SLIDE 62
Reporting Problem
Goal: Report all k-gons of the output set K. Keep track of updates using acyclic digraph G = (V , E, L)
1 2 3 4 5 6 7 a b c d e (c, a, 2) (d, a, 2) (b, a, 3) (e, a, 4) (b, d, 4)
2 7 4 3
Q = { } ×
Only time respecting paths are valid k-gons
SLIDE 63
Reporting Problem
Goal: Report all k-gons of the output set K. Keep track of updates using acyclic digraph G = (V , E, L)
1 2 3 4 5 6 7 a b c d e K = {(1, 2, 4, 6), (1, 2, 3, 7)}
Report all k-gons in O(|K|) additional time
SLIDE 64
3SUM Hardness
Reduction from Point-on-3-lines problem
SLIDE 65
3SUM Hardness
Reduction from Point-on-3-lines problem Given a set of lines L in plane, is there a point that lies on 3 lines?
SLIDE 66
3SUM Hardness
Reduction from Point-on-3-lines problem Given a set of lines L in plane, is there a point that lies on 3 lines? 3SUM − → 3-Points-on-line
dual
− − − − → Point-on-3-lines
SLIDE 67
3SUM Hardness
Reduction from Point-on-3-lines problem Given a set of lines L in plane, is there a point that lies on 3 lines? 3SUM − → 3-Points-on-line
dual
− − − − → Point-on-3-lines
◮ Reduction ensures that no two lines in L are parallel
SLIDE 68
3SUM Hardness
Reduction from Point-on-3-lines problem Given a set of lines L in plane, is there a point that lies on 3 lines? 3SUM − → 3-Points-on-line
dual
− − − − → Point-on-3-lines
◮ Reduction ensures that no two lines in L are parallel ◮ Compute bounding box B of the arrangement
SLIDE 69
3SUM Hardness
Reduction from Point-on-3-lines problem Given a set of lines L in plane, is there a point that lies on 3 lines? 3SUM − → 3-Points-on-line
dual
− − − − → Point-on-3-lines
◮ Reduction ensures that no two lines in L are parallel ◮ Compute bounding box B of the arrangement ◮ Clip the lines around B to obtain an arrangement of segments
SLIDE 70
3SUM Hardness
Reduction from Point-on-3-lines problem Given a set of lines L in plane, is there a point that lies on 3 lines? 3SUM − → 3-Points-on-line
dual
− − − − → Point-on-3-lines
◮ Reduction ensures that no two lines in L are parallel ◮ Compute bounding box B of the arrangement ◮ Clip the lines around B to obtain an arrangement of segments
n
3
- triangles ⇔ no Point-on-3-lines
SLIDE 71
3SUM Hardness
Reduction from Point-on-3-lines problem Given a set of lines L in plane, is there a point that lies on 3 lines? 3SUM − → 3-Points-on-line
dual
− − − − → Point-on-3-lines
◮ Reduction ensures that no two lines in L are parallel ◮ Compute bounding box B of the arrangement ◮ Clip the lines around B to obtain an arrangement of segments
n
3
- triangles ⇔ no Point-on-3-lines
SLIDE 72
3SUM Hardness
Reduction from Point-on-3-lines problem Given a set of lines L in plane, is there a point that lies on 3 lines? 3SUM − → 3-Points-on-line
dual
− − − − → Point-on-3-lines
◮ Reduction ensures that no two lines in L are parallel ◮ Compute bounding box B of the arrangement ◮ Clip the lines around B to obtain an arrangement of segments
n
3
- triangles ⇔ no Point-on-3-lines
n
4
- quadilaterals ⇔ no Point-on-3-lines
SLIDE 73
3SUM Hardness
Reduction from Point-on-3-lines problem Given a set of lines L in plane, is there a point that lies on 3 lines? 3SUM − → 3-Points-on-line
dual
− − − − → Point-on-3-lines
◮ Reduction ensures that no two lines in L are parallel ◮ Compute bounding box B of the arrangement ◮ Clip the lines around B to obtain an arrangement of segments
n
3
- triangles ⇔ no Point-on-3-lines
n
4
- quadilaterals ⇔ no Point-on-3-lines
Does not extend to k ≥ 5
SLIDE 74
Concluding Remarks
SLIDE 75
Concluding Remarks
◮ Introduced the k-gon counting problem
SLIDE 76
Concluding Remarks
◮ Introduced the k-gon counting problem ◮ Algorithm for k-gon counting in O(mn) ∈ O(n3) time
SLIDE 77
Concluding Remarks
◮ Introduced the k-gon counting problem ◮ Algorithm for k-gon counting in O(mn) ∈ O(n3) time ◮ Reporting in additional O(|K|) time
SLIDE 78
Concluding Remarks
◮ Introduced the k-gon counting problem ◮ Algorithm for k-gon counting in O(mn) ∈ O(n3) time ◮ Reporting in additional O(|K|) time ◮ 3SUM hardness for k = 3, 4 ⇒ Significantly better than
O(n2) unlikely
SLIDE 79
Concluding Remarks
◮ Introduced the k-gon counting problem ◮ Algorithm for k-gon counting in O(mn) ∈ O(n3) time ◮ Reporting in additional O(|K|) time ◮ 3SUM hardness for k = 3, 4 ⇒ Significantly better than
O(n2) unlikely
◮ Open question: faster algorithms?
SLIDE 80
