Distribution Transformers | Power Transformers | Structures Corporate Presentation ABOUT US ISO 9001, 14001 & 18001 Rajasthan Powergen Transformer Pvt. Ltd., is an Indian OEM established in 2012 at Rajasthan, India. We offer wide

slide-1
SLIDE 1

Corporate Presentation

Distribution Transformers | Power Transformers | Structures

slide-2
SLIDE 2

ABOUT US

  • Rajasthan Powergen Transformer Pvt. Ltd., is an Indian OEM established in 2012 at Rajasthan,

India.

  • We offer wide range of quality transformers that conforms to international quality standards.
  • Our fully-integrated factory is equipped with state of the art machinery for core laminations,

coil-winding, ovening, oil filtration, tank fabrication, testing & packing of transformers. We take pride for our highly skilled and committed professionals having rich experience in the industry, who consistently strive for quality & customer satisfaction

ISO 9001, 14001 & 18001

slide-3
SLIDE 3

FACTORY LAYOUT

ISO 9001, 14001 & 18001

slide-4
SLIDE 4

QUALITY POLICY

  • Committed to design, manufacture, repair & timely supply of all

type of fabrication, distribution and power transformers with professionalism & dedication to the complete satisfaction of our clients.

  • Committed to continual improvement in performance ensuring

quality through precise planning, quality reports, testing, reasonable price & timely delivery by effective implementation

  • f quality management system

ISO 9001, 14001 & 18001

  • Lic. No. CM/L 8400030105
slide-5
SLIDE 5

ISO CERTIFICATIONS

ISO 9001, 14001 & 18001

slide-6
SLIDE 6

STRATERGY

Quality product catering to diversified sector in energy sector Commitments to quality, timely delivery, performance & customer service Assurance of timely delivery & services. follow best safety practice in industry One stop shop for all need of tomorrow's power at lowest

  • wnership cost.

ISO 9001, 14001 & 18001

slide-7
SLIDE 7

ORGANIZATION STRUCTURE

Director Marketing Director Technical Director Operations GM Marketing Purchase Manager

  • Asst. Marketing

manager Marketing Engineer GM Operations Quality assurance engineer Accounts Manager Testing Engineer Production Supervisor Store’s Manager

  • Asst. Accounts

Manager

CEO

ISO 9001, 14001 & 18001

slide-8
SLIDE 8

PRODUCTS

STRUCTURE POWER TRANSFORMER DISTRIBUTION TRANSFORMER

ISO 9001, 14001 & 18001

slide-9
SLIDE 9

POWER TRANSFORMER

  • Rating: 5 MVA to 20MVA upto 33kV line
  • Frequency: 50/60Hz
  • Standards: IS/IEC Standards
  • Winding: Copper
  • Insulating Fluid: Mineral Oil as per IS/IEC Standard
  • Cooling : ONAN/ONAF
  • Tap Changer : OLTC/OCTC as per customer requirement

ISO 9001, 14001 & 18001

slide-10
SLIDE 10

DISTRIBUTION TRANSFORMER

  • Rating: 5 KVA 1-phase to 5000 KVA 3-phase
  • Frequency: 50/60Hz
  • Standards: IS/IEC Standards
  • Core: CRGO/Amorphous
  • Winding: Copper/Aluminum
  • Insulating Fluid: Mineral Oil as per IS/IEC Standard
  • Tap Changer: OLTC/OCTC as per customer requirement

ISO 9001, 14001 & 18001

slide-11
SLIDE 11

STRUCTURES

  • Transmission & Substation Structure as per

design for voltage class up to 66 kV

  • V Cross arms, Clamps, Top Hampers, Stay

Clamps.

ISO 9001, 14001 & 18001

slide-12
SLIDE 12

MANUFACTURING PROCESS

Tank fabrication

Oil filling Inspection

Insulation Conductor

Paper covered strip/wire

Core Assembly

Dispatch Fabrication Tank Tanking Filtration Testing Press board, Insulating paper, Permawood Slit paper, blocks, spacers, supports, strips Coil winding HV & LV Core coil assembly Ratio Check Drying

ISO 9001, 14001 & 18001

slide-13
SLIDE 13

INFRASTRUCTURE

  • Total area of the facility : 33,400 Sq. Meters
  • Manufacturing facility : 5,000 Sq. Meters
  • Fabrication Facility : 1,500 Sq. Meters
  • Shot Blasting facility : 10,000 Sq. Feet
  • Stores : 1,000 Sq. Feet
  • Testing Room : 300 Sq. Feet
  • Lamination Cutting Area : 1,500 Sq. Feet
  • Winding Area : 500 Sq. Feet
  • Final Assembly Area : 5,000 Sq. Feet

ISO 9001, 14001 & 18001

slide-14
SLIDE 14

INFRASTRUCTURE

  • Turns Ratio Meter
  • Insulation Testing Meter
  • Winding Resistance Meter
  • Double Voltage Double Frequency Meter
  • High Voltage Testing Kit
  • Power Analyser
  • PD Measurement System
  • Capacitor Bank of 50 MVAr
  • Temperature Rise Testing Meter

ISO 9001, 14001 & 18001

slide-15
SLIDE 15

INFRASTRUCTURE

  • In-house transformer designing.
  • In-house transformer tank fabrication

with latest machinery and skilled work force.

  • Sand-Blasting & Paint Shop.
  • Finishing, Packaging & Dispatch facility.

ISO 9001, 14001 & 18001

slide-16
SLIDE 16

MAJOR CLIENTS

ISO 9001, 14001 & 18001

slide-17
SLIDE 17

CERTIFICATION

ISO 9001, 14001 & 18001

slide-18
SLIDE 18

GROWTH STORY : REVENUE & MVA

1.69 11.55 22.14 6.44 38 50

10 20 30 40 50 60 2012-132013-142014-152015-162016-172017-18

Turnover (Indian Rs. Cr.) Financial Year

10.24 29.9 55.6 20.01 134.4 190

40 80 120 160 200 2012-132013-142014-152015-162016-172017-18

Production (MVA) Financial Year Revenue Growth MVA Growth

ISO 9001, 14001 & 18001

slide-19
SLIDE 19

CORPORATE SOCIAL RESPONSIBILITY

Animal Welfare Humanity Environmental Humanity Social

ISO 9001, 14001 & 18001

slide-20
SLIDE 20

CONTACT US

Registered Office: Khasra No. 911-914, Karola-Bhinmal Road, Karola, Dist: Jalore, Sanchore, RJ – 343041 (INDIA) Mobile: +91 9983308843 Email : power@rajasthanpower.in

  • Mktg. & Sales Office:

9,Harihar Lifescapes,1st Floor,3rd Khetwadi Girgaon, Mumbai,MH - 400004 (INDIA) Mobile: +91 7230085705 Email : anand.selvaraj@rajasthanpower.in

ISO 9001, 14001 & 18001
