Continuous MySQL Restores Divij Rajkumar (divij@fb.com) Production - - PowerPoint PPT Presentation

Divij Rajkumar (divij@fb.com)

Production Engineer, MySQL Infrastructure, Facebook

Continuous MySQL Restores

• Verify backup integrity
• Haven’t tested your backups? You don’t have them
• Understand resource requirements for restores
• Time, server capacity, network capacity
• Test restore orchestration
• Don’t panic during a disaster event

Continuous Restores – Why?

Backups

• Everything, every day

Backups

server

shar d shar d shar d shar d shar d shar d

mysq l

shar d shar d shar d shar d shar d shar d

mysq l

Shard 86 User 1 User 2 . . User 1000

• Everything, every day
• Tens of thousands of servers, many, many shards
• Stored in HDFS
• 3 types:
• Full dumps
• Differential backups
• Binary Logs

Backups

• mysqldump
• --single-transaction
• --set-gtid-purged=COMMENTED, stored in metadata
• github.com/facebook/mysql-5.6
• Per shard, not per instance
• Shards aren’t pinned to an instance
• Easier to locate

Backups – Full dumps

• Logical, not physical
• Easy single-table restore
• No indexes backed up, reduced size
• Easy to debug
• Better compression
• Every 5 days

Backups – Full dumps

• Diff between 2 full dumps
• 2 files generated - Rows deleted, Rows inserted
• Based off of existing dump in HDFS
• Take full dump -> compute diff -> upload diff

Backups – Differential backups

Backups – Differential backups

• Diff between 2 full dumps
• 2 files generated - Rows deleted, Rows inserted
• Based off of existing dump in HDFS
• Take full dump -> compute diff -> upload diff
• Possible because of logical full dumps

Backups – Differential backups

• Raw binlogs from mysql
• Record Previous-GTIDs in metadata
• Using mysqlbinlog:
• --start-position=4
• --stop-position=121
• Continuously uploaded
• Binlog Server to interface

Backups – Binary Logs

• Everything, every day
• Tens of thousands of servers, many, many shards
• Stored in HDFS
• 3 types:
• Full dumps
• Differential backups
• Binary Logs

Backups

Restore Infrastructure

Warchief

OR C

ORC DB Peon

MySQ L

Syn c Schedul e

CRT

Reque st

Restore Infrastructure

Peon

MySQ L

Peon

MySQ L

ORC - Peons

Restore Infrastructure - Peons

server

restored db restored db restored db

mysq l

restored db restored db restored db restored db

mysq l

peo n peo n

• Python process
• Exposes Thrift

interface

• Manages MySQL

Instance

• Multiple peons per host
• Work on restore jobs
• 1 database == 1 job

Restore Jobs – State Machine

• 1. SELECT – Select backup to restore
• 2. DOWNLOAD – Download backup to disk
• 3. LOAD – Load tables in parallel
• 4. VERIFY – Verify loaded full/diff dump
• 5. REPLAY – Replay binlogs

+ FAILED states

Restore Jobs – mysqldump index

• Custom index added to mysqldump output
• Locate tables using per-table byte offsets
• Preserved across diff backups

Restore Jobs – SELECT

• Pre-defined search range per job
• 1 day == restore most recent backup only
• Use metadata to ignore “bad” backups
• Only full/diff backups selected here

Restore Jobs – DOWNLOAD

• For full dumps:
• Download mysqldump from HDFS to disk
• For diff backups:
• Stream diffs + full dump to perform 3-way merge
• Store recreated mysqldump to disk
• Single mysqldump output at the end

Restore Jobs – LOAD

• Split backup into per-table streams using index
• Load tables in parallel

Restore Jobs – VERIFY

• Perform sanity checks on loaded data
• Possible verification methods:
• Compare checksums
• Compare number of tables loaded
• Best verification: replay binlogs

Restore Jobs – REPLAY

• Replay X seconds/minutes/hours worth of binlogs
• Enables point in time restores
• Verify loaded data can be written to

Restore Jobs – State Machine

SELECT DOWNLOAD LOAD TABLE LOAD TABLE LOAD TABLE VERIFY REPLAY LOAD TABLE LOAD TABLE

Restore Jobs – Pipeline

• Allow processing many jobs concurrently
• Peon has 1 handler per job state
• Limit per-state concurrency

Restore Jobs – Pipeline

DOWNLOA D LOA D LOAD TABLE VERIF Y REPLA Y SELEC T

SLOT 1 SLOT 2 SLOT 3 SLOT 4 SLOT 5

db1340 db2362 db142 db7 – t1 db7 – t2 db982 – t3 db982 – t9 db7 – t5 db7 db982

DOWNLOA D LOA D LOAD TABLE VERIF Y REPLA Y

db1963

SELEC T

db3794 db165 SLOT 1 SLOT 2 SLOT 3 SLOT 4 SLOT 5 db651 db1000

Restore Jobs – Pipeline

Restore Jobs – Pipeline

• Allow processing many jobs concurrently
• Peon has 1 handler per job state
• LOAD -> LOAD + LOAD_TABLE
• Limit per-state concurrency
• Slot capacity can be tuned

Restore Jobs – Selecting Binlogs

• Full/diff backups can be taken from slaves
• Binlogs always taken from master
• Need to uniquely identify transactions…
• GTIDs!

Restore Jobs – Selecting Binlogs

• Use GTIDs purged from mysqldump:
• --set-gtid-purged=COMMENTED
• Use GTIDs purged from mysqlbinlog:
• --start-position=4
• --stop-position=121
• These are GTIDs purged, not GTIDs contained

Restore Jobs – Selecting Binlogs

• GTIDs purged from LOAD state (dump_gtids):
• GTIDs purged in binlogs (binlog_gtids):

Contains 451-529 Contains 530-774 Contains 775-?

First superset First binlog to replay

Restore Jobs – Replaying Binlogs

• Filter binlog events with mysqlbinlog:
• --database
• --skip-gtids
• --skip-empty-trans
• github.com/facebook/mysql-5.6
• Last transaction to replay:
• --stop-datetime

db100 – t1 db100 – t2 db100 –t3

Restore Job – Lifecycle

DOWNLOA D LOA D LOAD TABLE VERIF Y REPLA Y SELEC T

SLOT 1 SLOT 2 SLOT 3 SLOT 4 SLOT 5 db100

CRT

Warchief

OR C

ORC DB Peon

MySQ L

Syn c Schedul e

CRT

Reque st

Restore Infrastructure

Peon

MySQ L

Peon

MySQ L

CRT – Continuous Restore Tier

• Create restore jobs for shards
• Periodically poll backup metadata to find backups
• Thrift call to Warchief to issue restore job
• Monitor restore progress
• Peons expose job and health stats via Thrift
• Detailed stats written to Scuba

CRT – Continuous Restore Tier

• Failure handling
• Retry on transient errors
• Mark “unstable”
• Notify oncall
• Orchestration component
• Resolve dependency graph
• Request restores in order of dependency

On-demand Restores

“oops, I accidentally ran UPDATE without WHERE”

“oops, I thought I was on my dev database”

“oops”

Warchief

OR C

ORC DB Peon

MySQ L

Syn c Schedul e

CRT

Reque st

Restore Infrastructure

Peon

MySQ L

Peon

MySQ L

UI/CLI

Reque st

Discover Edge Cases

War Stories

War Stories – Collation Change

• COLLATE=latin1_bin
• Required for MyRocks
• Schema change deployed
• Most diff backup restores fail overnight
• Thanks CRT Monitoring!

200x increase in DOWNLOAD_FAILED !

War Stories – Collation Change

• DifferentialBackup used default collation
• Sorting order broken in diff files
• Consistent sorting is required for 3-way merge
• 3-way merges failed for affected backups
• Wouldn’t have been caught without continuous

restores

• DifferentialBackup fixed to understand table collation

War Stories – RBR Binlogs

• Row-based replication deployed
• Lots of REPLAY failures overnight

“The database used for the current transaction

has changed since BEGIN. This is not supported!”

• 2 common patterns:
• Shards belonged to same database tier
• Failure only happened after master promotion

War Stories – RBR Binlogs

• SBR binlogs:
• Each BEGIN contains session database
• RBR binlogs:
• On master, each BEGIN contains session database
• On slave, BEGIN has no session database

War Stories – RBR Binlogs

• With mysqlbinlog --skip-gtids --skip-empty-trans
• Expected: session databases don’t change across events
• Binlogs not rotated after master promotion
• For some part of binlog, instance is a slave
• For some part of binlog, session database is empty
• For some part of binlog, session databases don’t match

“The database used for the current transaction has changed since BEGIN. This is not supported!”

War Stories – RBR Binlogs

• Possible solutions:
• Rotate binlogs during promotion
• Fix MySQL server behaviour
• Patch mysqlbinlog
• ???

Divij Rajkumar (divij@fb.com)

Thank s!
