Continuous Delivery of Embedded Software

Mike Long, Partner, Praqma Norway @meekrosoft

@meekrosoft

@meekrosoft

Agenda:

• What is Continuous Delivery?
• What are the challenges in Embedded?
• What techniques can we take advantage
• f?
• How can we test embedded software?
• Who has done this already?

@meekrosoft

https://www.flickr.com/photos/philia17/15601597778/

@meekrosoft

Professional software development

• 1. Take a copy of the codebase for existing product
• 2. Carefully document its current algorithms
• 3. Add changes surrounded by ifdefs
• 4. Test for months
• 5. Commit the code as a new project that will “hopefully”

get merged to the in the future

• 6. Compile on my laptop
• 7. Ship!

@meekrosoft

Airbus engineers employed the latest and greatest formal methods, and provided model checking and formal proofs of all of their avionics code. Meanwhile, according to the story, Boeing performed extensive design review and testing, and made all their software engineers fly on the first test flights. The general upshot of the story was that most of us (it seemed) felt more comfortable flying on Boeing aircraft. (It would be interesting to see if that would still be the majority

• pinion in the software engineering community.)

https://www.cerias.purdue.edu/site/blog/post/short_random_thought_on_testing/#When:16:40:35Z

Eugene H. Spafford, Professor & Executive Director, Purdue University

@meekrosoft

What is Continuous Delivery?

@meekrosoft

Agile Manifesto

• Four doctrines, twelve Principles

# 1 # 7

@meekrosoft

Rejected Fail

Integration

Commit

“Build”

Fail Toll-gate pass

Continuous Integration

@meekrosoft

Analysis & Metrics Deploy Functional test Document Validate

Done done Pipeline Fail Fail Fail Fail Fail Rejected

Continuous Delivery

@meekrosoft

Analysis & Metrics Deploy Functional test Document Validate

Done done Pipeline Fail Fail Fail Fail Fail Rejected Rejected Fail

Integration

Commit

“Build”

Fail Toll-gate pass

@meekrosoft

Release trains

@meekrosoft

Release trains

@meekrosoft

Challenges

@meekrosoft

http://www.lego.com/en-us/minifigures/characters/computer-programmer-0c248844ec9d4245a5c17479a208e45b

Solo work

@meekrosoft

Fire and forget codebases?

@meekrosoft

@meekrosoft

Production-like environment???

@meekrosoft

@meekrosoft

Versioning

@meekrosoft

The red thread of traceability

We want to know: what it is compatible with, what it depends on, where it was built, what its test results were, its source version, and the task that spawned the change

@meekrosoft http://semver.org

@meekrosoft

Examples

myapplication-1.0.0-alpha+001.sha.5114f85

Artifact Name

@meekrosoft

Examples

myapplication-1.0.0-alpha+001.sha.5114f85

Major.minor.patch

@meekrosoft

Examples

myapplication-1.0.0-alpha+001.sha.5114f85

Prerelease version

@meekrosoft

Examples

myapplication-1.0.0-alpha+001.sha.5114f85

Build number

@meekrosoft

Examples

myapplication-1.0.0-alpha+001.sha.5114f85

git short SHA

@meekrosoft

Examples

myapplication-1.0.0-SNAPSHOT+001.sha. 5114f85

SNAPSHOT

@meekrosoft

@meekrosoft

@meekrosoft

Build

@meekrosoft http://blog.codinghorror.com/the-f5-key-is-not-a-build-process/

If your "build process" is the F5 key, you have a problem…..Get your build process out of the IDE and into a build script.

@meekrosoft

What’s missing?

Traceability: Can I find out exactly the environment for this build? Reproducibility: Can I build something from last year with the same results?

@meekrosoft

@meekrosoft

@meekrosoft

@meekrosoft

A Traceability ecosystem

@meekrosoft

Configuration as code

Linux slave Linux slave Linux slave Linux slaves Dockerfile Vagrant file Windows slaves Puppet file Windows slaves Windows slaves Jenkins Jobs JobDSL

@meekrosoft

Build in a box

Jenkins Master Artifactory Docker container Linux slave Linux slave Linux slave Linux slave Linux slave Linux slave Windows slave Vagrant VM Windows slave Windows slave Windows slave Windows slave Puppet Master

@meekrosoft

Testing

@meekrosoft

@meekrosoft

System Tests ✓

@meekrosoft

System Tests

• Control power
• Program devices
• Control Actuators
• Sense results

✓

@meekrosoft

System Tests Component Tests

✓ ✓

@meekrosoft

System Tests Component Tests

✓ ✓ ✓

@meekrosoft

@meekrosoft

Test everywhere

Test on your host for:

• Feedback speed, debugging

But also test on target because:

• Compilers/hardware are different
• Endiness/overflow/underflow behave

differently

• Ship them if you can!

@meekrosoft

@meekrosoft

Pro Tips

@meekrosoft

// #ifdef MY_PROD_V1

Avoid using the preprocessor for variants

• It makes builds slow
• Lowers cohesion
• Also hinders understandability

@meekrosoft

Only build your binaries once

Efficiency - time to feedback Safety - ship what you test

@meekrosoft

Amplify feedback loops

TDD Red Refactor Green

Learn Measure Build

Produ ct Data Ideas

Continuous Integration Continuous Delivery BDD Automated Deployment Customer Feedback

@meekrosoft

Dev Env is competitive advantage

Attrition vs. Late follower vs. Unhappy customers vs. Recruitment First to market Raving fandom

@meekrosoft

Summary

@meekrosoft

https://www.flickr.com/photos/22423670@N08/14260168597

@meekrosoft

@meekrosoft

The researchers praised Tesla for the way the vehicle handled the bogus commands and how the car maker responded to their findings.

@meekrosoft

In late July, Fiat Chrysler issued a recall for more than 1.4 million vehicles after hackers Charlie Miller and Chris Valasek showed how to use bugs in the onboard software of the Jeep Cherokee to shut it down remotely.

@meekrosoft

Agenda:

• What is Continuous Delivery? ✓
• What are the challenges in Embedded? ✓
• What techniques can we take advantage
• f? ✓
• How can we test embedded software? ✓
• Who has done this already? ✓

@meekrosoft

Questions?
