VISION WIDE TECH CO., LTD HHO Automation Co., Ltd.

Compan pany profile ile & Pr Produc duct t ap application lication

VISION WIDE

Product range

7

Multi-Angle Application SE/SF/NF/HF/FA series Composites Material 5 axes Application /ADM series Heavy Duty Application VB/VF series 5 axes Cylinder Machining ASM series Huge loading Application BM /MM/XM series Hi Speed 5-axes Machining GS/GF/GM series

VISION WIDE

X Travel (m) VB / SF

1 5 40 1 5 2 3

NF VF

2 3 4 4

XBM/XM HF BM

10 6

FA

6 7 8 9

Double column machining center High performance 5-axes M/C Column & Bridge- Moving M/C Heavy duty M/C

Heavy duty bridge M/C

Y Travel (m) Complex Indexing Attachment

Rigidity Accuracy Application

VISION WIDE

GF /GM X travel,m

1 5 100 1 5 2 3 2 3 4 4 10 6 Speed Accuracy Application 6 7 8 9

GS

Complex Indexing Attachment High performance 5-axes M/C

Y Travel (m)

Bridge- Moving 5-axes M/C

High speed & accuracy 5-axes M/C

ADM ASM Milling &Turning 5-axes M/C

VISION WIDE

10

Over 20 models of attachment milling head for various multi-angle machining AHC Device AAC device for whole angle-position Machining……

Product range

TCPM control ATC Device

VISION WIDE

11

Friendly and intelligent Operation system

IEM Intelligent Efficiency Management IAM Intelligent Accuracy Management

• TCPM management
• Path accuracy optimization
• Thermal compensation
• Auto measuring system

IFM Intelligent Factory Management

• Auto maintenance notify…
• Immediate notification alert
• Remote real-time monitoring
• Machine utilization management

IOM Intelligent Operation Management

• Tool compensation management
• Workpiece coordinate data management
• Trouble diagnosis…
• Parameter/program management
• Tool life management
• Feed-rate optimization
• Spindle overloading monitoring
• Vibration monitoring
• Loading setting…

More intelligent application

VISION WIDE

12

H800/H1200

 Quickly setup in different machine  Easily process definition  Auto material feed  Visual process management  Manufacture report  Producing status monitoring  Alert notification

Automation feed system

For lathe and machining center

Plug-in

VISION WIDE

13

Manufacturing execution systems (MES) Automation Transfer Devices (ATD) HMI Control System (HCS)

Station status Producing schedule Producing capacity Production command machining data Machine Status

Automatic Producing Program

VISION WIDE

14

Auto loading device PC-Based/PLC+HMI

• 1. Automated device
• 2. Device sequence control
• 3. Producing monitoring
• 4. Manufacture data record
• 5. Manufacturing statistics

Control kernel Function offer Customized device Robot, Machining tool, Feed device Measurement ,CCD Motoring Integrited equipment

Intelligent automation control

Automation manufacture

Intelligent factory

Cloud

Pre-maintenance alert， Producing record, Real time monitoring, Producing data analysis

VISION WIDE

15

Product Application in various Industry

VISION WIDE

16

Aluminum machining application

Features:

• 12,000rpm/75kW spindle
• 750ipm cutting feed rate
• Thinner plate cutting force analysis
• Over 5,000cu-cc/min of chip removal from machine

VISION WIDE

17

Hard steel alloy machining application

Features:

• 1,000~2,500Nm spindle torque
• Hydraulic static guide way on Z travel
• 100,000N of axial thrust force.
• Machine model :BM / XM / MM series

Hydraulic static guide way

VISION WIDE

18

CFRP cut around application

Features :

• Twin-pallet auto change
• 5axes motion with 24,000rpm spindle
• 2300ipm rapid feedrate
• Full-closed cover with dust vacuum device

VISION WIDE

19

High precision machining of automobile sheet metal

Feature:

• 10,000rpm spindle speed
• 0.02mm thermal compensation,
• 6000 real cutting feed rate,
• 0.1mm profile error.

VISION WIDE

20

Sunroof glass mold machining application

Feature:

• 18,000rpm spindle speed
• 0.02mm thermal compensation,
• 6000 real cutting feed rate,
• 0.1mm profile error.

VISION WIDE

21

Prototype of sunroof mold machining application

• Feature:
• 18,000rpm spindle speed
• 0.02mm thermal compensation,
• 6000 real cutting feed rate,
• 0.1mm profile error.

VISION WIDE

22

Transportation industrial application

Features:

• The 4th and 5th axis integrated.
• 22kw 4000 rpm spindle

VISION WIDE

23

Casting and machine tool structure machining

Features:

• Straightness accuracy 0.01mm/2m
• Squareness accuracy 0.01mm/m
• TCPM 0.02mm of attachment heads
• Over 1,000Nm spindle cutting torque
• 10m/min cutting feedrate
• Various indexing angle attachment

Horizontal M/C base Lathe M/C base

VISION WIDE

24

Train & railway industrial application

Features:

• Hard steel material cutting
• High cutting power required
• High rigidity of machine
• AC 90 degree head for cutting

VISION WIDE

25

Features:

• Hard steel material cutting
• 26kw gear type 6000rpm
• AC 90 degree head for cutting

Construction engineering Machine

VISION WIDE

26

Oil & Gas component machining

Solid Valve

Features:

• Coolant through spindle 20/70bar with

high flow capacity,

• Full-closed machine splash cover,
• Stable machine rigidity,
• 6000rpm with over 600Nm spindle torque,
• 24m/min rapid feedrate.

VISION WIDE

27

Agriculture machinery application

Features:

• Fixture planning,
• Various attachment heads
• for automation producing.

VISION WIDE

28

LCD chamber machining

Stainless steel Aluminum alloy Features:

• 12,000rpm/75kW spindle
• 750ipm cutting feed rate
• Thinner plate cutting force analysis
• Over 5,000cu-cc/min of chip removal from machine
• 5 axes or multi-angle attachmnet heads

VISION WIDE

29

Features:

• Fixture planning,
• Various attachment heads.

Wind power equipment application

VISION WIDE

30

Hydroelectric equipment application

Features:

• Curve surface with 4+1 axes

synchronously interpolation,

• Twin rotary table with auto

workpiece clamping,

• 4mx4mx1.4m cutting traveling.

Large-scale blade Middle-scale blade

VISION WIDE

31

Turbine body machining application

Large-scale turbine Small-scale turbine Feature:

• 2,500Nm spindle torque,75 kW
• Various attachment heads
• Machine loading over 30tons,
• Hydrostatic bearing on Z axis.

VISION WIDE

32

Drilling device

User Interface Producing status monitoring Dia. 0.5mm Machining monitoring Machining parameter control

Intelligent control

+

VISION WIDE

Part magazine Status Visual Process UI Machining Monitoring

Auto-loading device + Intelligent visual UI For CNC machining center

VISION WIDE

34

Bicycle ratchet assembling machine

Before by manual manufacture After by automation manufacture

VISION WIDE

35

Auto-drilling & chambering machine + Part auto-feeding
