COMP4076 / GV07 - Virtual Environments: Tracking and Interaction

Wole Oyekoya Department of Computer Science University College London w.oyekoya@cs.ucl.ac.uk http://www.cs.ucl.ac.uk/teaching/VE

Outline

• Introduction
• Models of Interaction
• Interaction Methods

Introduction

• Introduction
• Models of Interaction
• Interaction Methods

Tracking and Interaction

User Input Devices Computer User Synthetic Environment Real Environment Tracking and interaction happens here

Basic Components of an Interface

• The input devices captures user actions
• Transfer functions / control-display mappings /

interaction techniques

– Map the movement of the device into the movement of the controlled elements – Isomorphic: one-to-one mapping between motions in the physical and virtual worlds – Non-isomorphic: input is shifted, scaled, integrated, …

• The display devices present the effects of the

input to the user

What Are the Basic Interaction Tasks?

• Locomotion or Travel

– How to move through the space

• Selection

– How to indicate an object of interest

• Manipulation

– How to change properties of an object of interest

• Symbolic

– How to enter text and other parameters

• System control

– How to change the way the system is behaving

Won’t be covered in this lecture

Challenges in Designing Metaphors?

• Designing interaction metaphors for virtual

environments is hard:

– Six degrees of freedom

• Lack of appropriate input devices

– Isolated parts of body tracked – Boxing glove or fishing rod style of interaction metaphors

• Divide and conquer the problem by identifying

basic models of interaction

Models of Interaction

• Introduction
• Models of Interaction
• Interaction Methods

Models of Interaction

• Extended Desktop Model

– The computer generates a 3D version of the familiar desktop – The user needs tools to do 3D tasks

• Virtual Reality Model

– The user’s body is an interface to the world – The system responds to everything they do or say

Extended Desktop Model

• The desktop is now in 3D
• It can extend beyond the

boundaries of the computer screen itself

• However, the user:

– is not part of the scene – has a “God’s eye view”

Interaction in the Extended Desktop

• Focus on analysing a task and creating devices

that fit the task

• Study ergonomics of the device and

applicability/suitability for the role

• Special-purpose devices can be developed to

support interaction

2D Interaction in a 3D World: Google Earth

Modelling Package (3D Studio Max)

Types of Device to Enable 3D Interaction

Ascension Wanda 3DConnexion Spaceball Polhemus Isotrak 3-Ball Logitech 3D Mouse 3DConnexion Spacemouse Inition 3DiStick Nintendo Wii Remote

GlobeFish and GlobeMouse

Limitations of the Extended Desktop Model

• 3D tasks can be quite

complicated to perform

• Tasks can become very

specialised

– Counterintuitive – Requires a lot of user training

Fakespace Cubic Mouse

Virtual Reality Model

• Track the user as they

move through a genuine 3D space

• Need to track the user

precisely and interpret what they do

• Focus is on users

exploring the environment

Interaction in the Virtual Reality Model

• Tension between isomorphic and non-isomorphic

movements

– Isomorphic: one-to-one mapping between motions in the physical and virtual worlds – Non-isomorphic: input is shifted, scaled, integrated, …

• Tension between mundane and magical responses of the

environment

– Mundane are where the dynamics are governed by the familiar laws of physics (Newtonian mechanics) – Magical are everything else (casting spells, automatic doors, etc…)

Body-Relative Interaction

Technique based on Proprioception

• Provides

– Physical frame of reference in which to work – More direct and precise sense of control – “Eyes off” interaction

• Enables

– Direct object manipulation (for sense of position of object) – Physical Mnemonics (objects fixed relative to body) – Gestural Actions (invoking commands)

Hand-Held Widgets

• Hold controls in hands,

rather than on objects

• User relative motion of

hands to effect widget changes

Mine, Brooks Jr, Sequin

Gestural Actions

• Head – butt zoom
• Look – at Menus
• Two – handed flying
• Over – the – shoulder

deletion

Mine, Brooks Jr, Sequin

Limitations of the Virtual Reality Model

• Can’t track user over very large

areas

– E.g. Some form of locomotion metaphor will be required for long distance travel (see later)

• Physical constraints of systems
• Limited precision and tracking

points

• Lack of physical force feedback

Overcoming Lack of Force Feedback

• One way to overcome lack
• f force feedback is to use

a haptic device

– Will be discussed in another lecture

• Another approach is to

exploit visual dominance in the interpretation of cues

• CyberForce CyberGrasp

Visual Dominance

• The real hand is not

constrained in space

• The virtual hand can be

constrained in virtual space

• Can the user detect the

difference?

“The Hand is Slower than the Eye: A quantitative exploration of visual dominance over proprioception Burns, Whitton, Razzaque, McCallus, Panter, Brooks

Visual Dominance

Task: playing Simon game Drift between virtual and real hand gradually introduced over time

Summary of Interaction Methods

• The extended desktop model:

– Desktop extends beyond physical screen – Interactions and devices on a case-by-case basis – Potentially more accurate, but counterintuitive and specialised interaction

• The virtual reality model:

– User’s body input to system – Potentially more intuitive but more general – Greater reliance on ability to have natural movement and ability to track – Partially resolved using visual dominance for HMDs

Interaction Methods

• Introduction
• Models of Interaction
• Interaction Methods

Basic Interaction Tasks

• Locomotion or Travel

– How to effect movement through the space

• Selection

– How to indicate an object of interest

• Manipulation

– How to move an object of interest

• Symbolic

– How to enter text and other parameters

• System control

– Change mode of interaction or system state

Won’t be covered in this lecture Logically grouped together

Locomotion

• Introduction
• Models of Interaction
• Interaction Methods

– Locomotion or Travel Techniques – Selection and Manipulation

Purpose of Locomotion

• Change the pose of the viewpoint (both position

and attitude) from some start location A to some end location B

• This is the most fundamental task for a virtual

environment

– Arguably if the user can’t change the pose of the viewpoint, it’s not really a virtual environment at all

Types of Travel Techniques

• There are two fundamentally different types:
• Virtual techniques:

– The user’s body remains stationary even through the viewpoint moves

• Physical techniques:

– The user’s physical motion is used to transport the user through the virtual world

Virtual Locomotion Techniques

• The user remains

stationary even though the viewpoint moves

• Techniques must be used

to specify

– Direction – Speed

Taxonomy of Virtual Locomotion Techniques

Bowman, Koller and Hodges

Taxonomy of Virtual Locomotion Techniques

Bowman, Koller and Hodges

Controlling Direction by Steering

• Continuous specification
• f direction of motion
• Direction can be specified

by many means:

– Gaze-directed – Pointing – Physical device (steering wheel, flight stick)

Steering Techniques

• Gaze-based:

– Actually uses head orientation – Cognitively simple – Cannot look around whilst travelling

• Pointing-based:

– Actually uses on hand orientation – Cognitively more complicated – Makes it possible to look in one direction whilst travelling in another – However, you can’t hold other

• bjects or manipulate them whilst

travelling

Target-Based Steering

• Specify discrete target or goal
• Multiple ways to specify the

goal:

– Point at object – Choose from list – Enter coordinates

• Once specified, travel to the

target is passive

• Convenient way to get from A

to B, but inflexible

Route-Based Steering

• Generalisation of the

target-based metaphor

• User specifies multiple

waypoints on a map

• The system generates a

path and passively moves the user along the path

• Placement of waypoints

controls granularity of movement

Taxonomy of Virtual Locomotion Techniques

Bowman, Koller and Hodges

Two-Handed Velocity / Acceleration Selection

• Line between hands defines

direction of travel

• Distance between hands

specifies constant speed

• Pinch glove gestures provide

“nudges”

Mine, Brooks Jr, Sequin

“Grabbing the Air”

• Use hand gestures to move

through the world

• Metaphor is pulling a rope
• Often implemented using

pinch gloves

• Physically occupies hands
• Slow
• Fatiguing

Camera-in-Hand

• A tracker is held in the hand and the camera viewpoint is

slaved to it using an appropriate set of transformations

• This defines a small “workspace” on a table top
• Travel simply involves movement of the hand through the

workspace

How Good Are These Techniques?

• Unfortunately there have been no thorough

comparison of all the different techniques which have been developed

• One of the first rigorous studies of some of the

trade-offs between different travel techniques

– Travel in Immersive Virtual Environments: An Evaluation of Viewpoint Motion Control Techniques, Bowman, Koller and Hodges

Quality Factors

• 1. Speed (appropriate velocity)
• 2. Accuracy (proximity to the desired target)
• 3. Spatial Awareness (the user’s implicit knowledge of his position and
• rientation within the environment during and after travel)
• 4. Ease of Learning (the ability of a novice user to use the technique)
• 5. Ease of Use (the complexity or cognitive load of the technique from the

user’s point of view)

• 6. Information Gathering (the user’s ability to actively obtain information

from the environment during travel)

• 7. Presence (the user’s sense of immersion or “being within” the

environment)

Experiment 1: Absolute Motion Task

• Absolute motion task

– Move until you are inside a virtual sphere – Gaze v. Point AND constrained v. unconstrained

• Constrained disallowed movement in z direction

– Hypothesis - gaze expected to be better

• Neck muscles are more stable
• More immediate feedback
• Eight subjects, each doing four times 80 trials (five times 4

distances to target, four target sizes)

Experiment 1

Bowman, Koller and Hodges

• Results
• No difference between techniques
• Significant factors were target distance and size

Experiment 2: Relative Motion Task

• Relative motion task
• Move to a position

defined relative to a virtual object

• Need forward and

reverse direction

• Nine subjects, four sets
• f 20 trials

Bowman, Koller and Hodges

Experiment 2

• Obvious difference
• Can’t point at target and look at departure

point simultaneously

Bowman, Koller and Hodges

Summary of First Two Experiments

Bowman, Koller and Hodges

Experiment 3: Spatial Awareness Task

• Environment consists
• f cubes of contrasting

colours

• User asked to identify

cube and push L or R

• n mouse button
• User travels to a

different location and repeats the trial

Bowman, Koller and Hodges

Experiment 3

• Testing spatial awareness based on four travel

variations

– Constant speed (slow) – Constant speed (fast) – Variable speed (smooth acceleration) – Jump (instant translation)

• Concern is that jumps and other fast transitions

will confuse users

Experiment 3

• Slow and fast velocity

made no difference to task time

• However, jumping from

point to point lead to significant disorientation and increased task execution time

Virtual Locomotion Summary

• Virtual locomotion or travel occurs when the

viewpoint changes but there is minimal physical interaction from the user

• The interaction metaphors have to specify the

direction, velocity and input conditions

• Many metaphors have been proposed
• Few have been analysed:

– Pointing is better for relative tasks – Jumping from location to location is disorienting

• An alternative is to have physical locomotion

Physical Locomotion

• Map locomotion “as naturally as possible” to

human movement

Direct Locomotion

• There is an isomorphic

mapping between the real- world and the virtual environment

• The user physically walks

from point A to point B

• Intuitive and easy to use
• Requires a suitably large

environment

• Requires a wide area

tracking system

Walking-in-Place

• User “walks in place”
• Movement detected by

gait analysis

– Trackers just on feet – Trackers over entire body

• No perceptual mismatch

– Deep down, user knows that their gait won’t make them move

Which Works Best?

• Despite the huge number of different approaches

which have been developed, relatively few studies have compared the strengths and weaknesses of different approaches

• Travel techniques studied by Bowman et al.
• Comparison of real walking, virtual walking and

flying by Usoh et al.

Walking, Virtual Walking and Flying

• Comparison of real walking, walking in place and

gaze-based flying

• Test scenario was the pit

– Get around the edge to the chair

• 33 naïve subjects and 11 expert subjects recruited

Walking > Walking-in-Place > Flying, in Virtual Environments, Usoh, Arthur, Whitton, Basto, Steed, Slater, Brooks

Results of the Study

Real vs. Virtual Walking vs. Flying

• Real walking

– Best for human-scale spaces – Expensive to implement

• Virtual walking

– Better than flying – Inexpensive to implement

• Limitations of study:

– Walking-in-place implementation was poor – Avatar realism – Scenario incongruity

Redirected Walking

Fire drill scenario

Redirected Walking, Razzaque, Kohn, Whitton

Based on the premise that rotating the virtual scene around a user makes the user turn themself and navigate a much larger area without the user’s awareness

Redirected Walking

Plan view of scenario Plan view of lab area

Redirected Walking

Redirected Walking

• Apply an angular

distortion:

– Small constant offset causes viewpoint to slowly rotate – Increase distortion rate proportionally with user’s walking speed – Increase distortion rate proportionally with user’s angular velocity of head

Redirected Walking in the CAVE

• Problems with walking in

the CAVE:

– You eventually hit the walls – You can turn and see the missing back wall

• One means of countering

this is to rotate the environment

– The user is directed back to the front wall

Redirected Walking in Place, Razzaque, Swapp,Slater, Whitton, Steed

Redirected Walking in the CAVE

• Apply a small rotation to the scene to

cause user to turn towards centre

– Sufficiently small that not consciously noticed – Subject responds to maintain balance

• Increase rate when user is navigating or

rapidly turning head

• Results:

– Variance in number of times user saw back wall decreased – Rates of simulator sickness were not increased – Some users did not notice the rotation

Constrained Walking

• User walks but motion is

constrained

– VirtuSphere – Treadmills

• However, most forms can

be very difficult to use

– Mismatch in perceptual cues – Dynamics / inertia of device make it hard to navigate effectively

VirtuSphere

Summary of Experimental Results

• There is no single best virtual locomotion

technique

– Context dependent – Graceful transitional motions should be used if subjects should understand context of environment

• Physical location provides greatest presence

– Only works for human-sized spaces – Needs lots of room!

Manipulation

• Introduction
• Models of Interaction
• Interaction Methods

– Locomotion – Manipulation

Manipulation

• Manipulation of the environment consists of

changing the contents of the virtual environment

• The term is extremely broad:

– Complex manipulation of an object’s structure, such as moulding or sculpting – Changing abstract properties of an object such as its

• wnership
• We consider rigid body manipulation tasks only

– Operations such as scaling or distorting are frequently implemented as rigid body manipulations of widgets

Canonical Manipulation Tasks

• Selection

– Task of acquiring or identifying a particular object from the set of objects available

• Positioning

– Change the real-world position of an object

• Rotation

– Change the attitude of an object

• This has a direct analogy with 2D GUIs

Taxonomy of Manipulation

Direct Interaction Techniques

• User selects and

manipulates an object using a virtual hand

• A 3D cursor visualises the

current locus of user input

• The user intersects the

cursor with an object and uses a trigger technique

• The object is rigidly

attached to the user’s hand

Simple Virtual Hand

• There is a direct mapping from the user’s hand to the movement
• f the virtual hand

– Linear displacement often scaled – Orientation is not

• Mapping from inputs to hand movement is achieved through a

transfer function

• However, if users have to manipulate an object out of arm’s

reach, they have to travel to get it

Go-Go Interaction

• Nonlinear mapping

between the user’s hand and the virtual hand

• Close in, the hand behaves

like a simple virtual arm

• Further out, it becomes

nonlinear scaled

• Users generally found it

easy to understand and use for manipulation

Poupyrev et al. / Egocentric Object Manipulation in VEs: Empirical Evaluation of Interaction Techniques

World in Miniature Technique

• Rather than scale the user’s

hand, scale the world

• Smaller version of the world

created and superimposed on the real world

• User controls WIM using

hanheld ball

• Can interact with environment by

selecting 1:1 scale or same

• bject on WIM

World in Miniature, Stoakley and Pausch

Indirect Interaction Techniques

• User works with objects

beyond arms reach

• Points at object with their

hand

• Selects by pressing a

button or some other discrete action

• Object then becomes tied

to the user in some way for manipulation

Ray-Based Interaction

• Ray-Based

– Ray is centred on user’s hand – All manipulations are relative to hand motion

• Translation in beam direction is

hard

• Rotation in local object

coordinates is nearly impossible

• Picking small objects in the far

distance is hard because a very high degree of angular accuracy is required

Mark Mine, http://www.cs.unc.edu/~mine/isaac.html

Aperture Technique

• The angle subtended by the

selection cone can be changed by the user

– Head and hand tracked – Line through head and hands defines cone direction – Distance between head and hands defines angle of the cone

• The rotation of the hand sensor

can be used to perform further disambiguation

– User orients hand held wand to align with orientation of object to be picked up

Image-Plane Technique

• User selects 3D
• bjects by

manipulating their 2D projection on a virtual image plane

• If single hand tracked,

aperture technique

• If multiple hands

tracked, head crusher technique

Flashlight Technique

• Rather than use a

single ray for selection, selection occurs over a selection cone

• Disambiguation

strategies include:

– Object closest to centre line selected – Object closest to user selected

Hybrid Techniques

• All manipulation events are based on a repeated

task sequence of selection followed by manipulation

• Therefore, different tasks can use different

interaction metaphors

• Each metaphor can be optimised for the particular

task in the sequence it’s been assigned to do

Scaled World Grab

• The user selects an object using an appropriate image

plane-based technique

• Once selected, the whole world is scaled down to the bring

the object in the user’s reach

• The scaling is carried about a point midway between the

user’s eyes

– The user does not notice the scaling operation because the world does not change visually

• Near and far objects easily moved
• However, slight head movements can massively change

the view of the model

• Problems taking a small, close model and moving it further

away

“Over-generalized findings from other designer’s experiences are more apt to be right than the designer’s uniformed intuition” (Brooks, 1988)

What’s Best?

• Only a few studies of different interaction

techniques have been completed

• Confounding factors:

– Internal validity: the experiment actually tests the property you want to test – External validity: the results of the experiment can be generalised to other scenarios where experiments have not been conducted

Evaluating Selection

• Ray-casting and image-plane are generally more effective

than Go-Go

– Exception: high precision selection, e.g. small or far away objects, can be easier with Go-Go

• Different studies get significant differences in performance:

– Poupyrev: the difference between Go-Go and pointing was not large (10 to 20 percent) – Bowman: the difference between Go-Go and pointing was significant (20 to 60 percent) – Probably due to differences in implementation

• Ray-casting techniques can be approximated as 2D

techniques

Evaluating Manipulation

• Very difficult to do:

– Large amount of variables affecting user performance: direction of movement, distance,accuracy

• Preliminary positioning experiments indicate that:

– Ray is effective for repositioning at a constant distance and within the user reach – Go-Go and scaled world grab have been reported effective in some positioning tasks

• Mine independently studied effects of proprioception on

manipulation

Docking Cube Experiment

• Align docking cube with target cube as quickly as

possible

• Comparing three manipulation techniques:

– Object in hand – Object at fixed distance – Object at variable distance (scaled by arm extension)

• In hand significantly faster

Shaping 3D Boxes Experiment

• Study of two handed selection of volumetric data

for box creation using 3D tracking equipment:

– Hand-on-Corner (HOC): User’s non-dominant hand holds one corner of the box while the dominant hand controls the position of the opposite corner. – Hand-in-Middle (HIM): Similar to HOC except that non-dominant hand is positioned in the middle. – Two Corners (TC): User shapes a box by dragging apart two diagonally opposite corners of the box.

• TC outperforms others with respect to both

accuracy and completion times.

• A. C. Ulinski. Taxonomy and experimental evaluation of two-handed selection techniques for volumetric
• data. PhD thesis, University of North Carolina at Charlotte, Charlotte, NC, USA, 2008.

Summarising Studies

• Direct interaction

– Tasks for close range interaction seem to be most effective

• Ray-based interaction

– Best when all objects stay at the same distance from the user

• Go-go

– Usually less effective – However, supports uniform interaction within the manipulation area

Summary

• Introduction to Interaction
• Models of Interaction

– Extended Desktop Model – Virtual Reality Model

• Interaction Methods

– Locomotion or Travel Techniques – Selection and Manipulation
