Common Findings from Life Safety Surveys CMS 2012 Edition of NFPA 101 and NFPA 99 Supported by editions of other NFPA Codes 2011 Edition of NFPA 25 Fire Sprinklers 2011 Edition of NFPA 70 National Electric Code 2010

slide-1
SLIDE 1

Common Findings from Life Safety Surveys

slide-2
SLIDE 2

2

CMS

  • 2012 Edition of NFPA 101 and NFPA 99
  • Supported by editions of other NFPA Codes
  • 2011 Edition of NFPA 25 – Fire Sprinklers
  • 2011 Edition of NFPA 70 – National Electric Code
  • 2010 Edition of NFPA 72 – Fire Alarms
  • 2010 Edition of NFPA 110 – Generators
  • 2010 Edition of NFPA 111 – UPS (battery backup systems)
slide-3
SLIDE 3

3

Application for Accreditation

  • Floorplan – Would prefer a life safety plan
  • Good life safety drawing vs. a bad life safety drawing
  • Type of Construction
  • Protected vs. Unprotected
slide-4
SLIDE 4

4

Good Life Safety Plan

slide-5
SLIDE 5

5

Poor Life Safety Plan

slide-6
SLIDE 6

6

Protected vs. Unprotected Construction

slide-7
SLIDE 7

7

Risk Assessments

  • NFPA 99, Sec. 4. Need to conduct a risk assessment,

approved by the operating board, to determine which of Category 1 thru 4 building systems your facility should be designed as, or has been designed as.

  • Defines Type of Electrical System and Med Gas System.
  • Used to be you could be Category 1, 2 or 3.
  • Today, only Category 1 or 2.
slide-8
SLIDE 8

8

Other Assessments and Policies

  • Operating rooms: wet vs. dry procedures
  • Testing of patient care related equipment, i.e., Bio-Med
  • Policy on loss of medical gas and vacuum systems
  • Policy for fire sprinkler system out of service
  • Policy for fire alarm system out of service
slide-9
SLIDE 9

9

Emergency Lighting Systems

  • Egress Lighting
  • EXIT Signs
  • Battery Powered Lighting
  • Anesthetizing locations
  • At the transfer switch
slide-10
SLIDE 10

10

Emergency Lighting Systems

slide-11
SLIDE 11

11

Emergency Lighting Systems

  • NFPA 101, Section 7.9.3 Requirement is for testing for 30

seconds monthly.

  • NFPA 101, Section 7.9.3.1.1 (3) If battery powered, must

test for 30 seconds monthly and 90 minutes annually.

  • Locations for battery powered emergency lighting include

anesthetizing locations and at the generator transfer

  • switch. If battery backup, at the UPS.
slide-12
SLIDE 12

12

Circuit Panels

slide-13
SLIDE 13

13

Generators – NFPA 110

  • Section 8.3.8 – A fuel quality test shall be performed at

least annually using tests approved by ASTM standards.

  • ASTM D975 standards include 13 different tests for

diesel fuel:

  • Flash Point , Water and Sediment, Distillation, Viscosity, Ash

Content, Sulfur, Copper Corrosion, Cetane Index, Cloud Point, Carbon Residue, Lubricity, Conductivity, Density

  • Testing methods include pulling fuel from the bottom of the

tank.

slide-14
SLIDE 14

14

Generator Battery Conductance Test

  • NFPA 110, Sec. 8.3.7.1. – A monthly conductance test of

the generator starting battery may be conducted in lieu

  • f a specific gravity test.
slide-15
SLIDE 15

15

Photo of Conductance Meter

slide-16
SLIDE 16

16

Generators

  • 2010 Edition of NFPA 110, Standard for Emergency and

Standby Power Systems, Section 8.4 Operational Inspection and Testing

  • Section 8.4.2. Diesel generators shall be exercised at least
  • nce monthly, for a minimum of 30 minutes, using one of

the following methods:

slide-17
SLIDE 17

17

Generators

  • Loading that maintains the minimum exhaust gas

temperature per the manufacturer.

  • An operating load of not less than 30% of the generator’s

nameplate rating.

  • Section 8.4.2.3 states: If not tested as above, see section

8.4.2.3 for annual load bank testing requirements.

slide-18
SLIDE 18

18

Generators

  • Section 8.4.2.3 load bank testing: annually for 90

minutes, the first 30 minutes at not less than 50% of the nameplate rating, then next 60 minutes at not less than 75% of the nameplate rating.

  • Level 1 generators shall be tested at least once within

every 36 months, i.e., this is a 4-hour load bank test.

slide-19
SLIDE 19

19

Remote Generator Shut Off

slide-20
SLIDE 20

20

Fire Door Inspections

  • NFPA 80, Section 5.2.3.1 Functional testing of fire door

and window assemblies shall be performed by individuals with knowledge and understanding of the

  • perating components of the type of door being subject

to the testing.

  • Clearances of undercut and space between door edge

and frame.

slide-21
SLIDE 21

21

Fire Door Inspection

  • Match the rating to the wall, or room.
  • Ensure labels on door are in place.
  • Doors opening to egress corridors are self-latching.
  • Hazardous rooms are self-latching and self-closing.
  • No more than 1/8” space between the door and frame

for wood doors. NFPA 80, Section 6.3.1.7

slide-22
SLIDE 22

22

Fire Door Inspections

slide-23
SLIDE 23

23

Fire Barriers – Fire Door Inspections

  • Go to the website below to find local fire door inspectors

that you can contact for quotes.

  • http://www.dhi.org/ Choose “Find a Pro” on the right side
  • f the page
  • Choose Only your state, e.g. “Tennessee” from the state

drop down and choose Only “Fire Door Assembly Inspector” from the DHI Certification(s) drop down.

slide-24
SLIDE 24

24

Fire Barriers – Fire Door Inspections

  • Do not fill out any other fields or drop downs.
  • Hit the find button and resources will be displayed.
  • If no success, contact a local locksmith.
  • National companies will travel to you, but are more

expensive.

slide-25
SLIDE 25

25

Fire and Smoke Dampers

  • 2012 Edition of NFPA 105, Section 6.5
  • Inspected and tested one year after installation and every

4-years thereafter.

slide-26
SLIDE 26

26

Fire Dampers

slide-27
SLIDE 27

27

Smoke Damper

slide-28
SLIDE 28

28

Damper Access Panels

slide-29
SLIDE 29

29

Fire Sprinkler System

  • 2011 Edition of NFPA 25
  • Section 5, Table 5.1.1.2 – Summary of Sprinkler System,

Inspection, Testing and Maintenance

  • Summary of inspection, testing and maintenance of fire

sprinkler valves and valve components, Table 13.1.1.2.

slide-30
SLIDE 30

30

Fire Sprinkler System

  • Inspections:
  • Weekly, monthly, quarterly, semi-annual, annual and 5th

year.

  • Testing:
  • Quarterly, semi-annually, annually, 3rd year, 5th year, 10th,

20th, 50th and 75th year after installation

  • 5th year internal inspection for obstructions
slide-31
SLIDE 31

31

Valves, tamper & flow switches, gauges

slide-32
SLIDE 32

32

slide-33
SLIDE 33

33

Fire Sprinkler System

  • Impairment Coordinator: Section 15.5.2
  • Where a required protection system is out of service for

more than 10 hours in a 24-hour period, the impairment coordinator shall arrange for one of the following:

 Evacuation of the building  An approved fire watch  Establishment of a temporary water supply  Establishment of a program to eliminate potential ignition

sources

slide-34
SLIDE 34

34

Fire Alarm System

  • 2010 Edition of NFPA 72
  • Testing frequencies, see Table 14.4.5
  • Battery voltage, supervisory signals: semi-annually
  • Fire drills not being conducted
slide-35
SLIDE 35

35

Fire Alarm – Out of Service

  • Policy when the fire alarm system is out of service for

more than 4-hours in a 24 hour period.

  • Notify the local fire authority and do one of the following:

 Evacuate the building  Establish a fire watch

slide-36
SLIDE 36

36

Fire Alarm

slide-37
SLIDE 37

37

Electrical Systems

  • 2012 Edition of NFPA 99, Maintenance and Testing of

Circuitry

  • Section 6.4.4.1.2.1* Main and feeder circuit breakers shall

be inspected annually and a program for periodic exercising of the components shall be established per the manufacturer’s recommendation.

slide-38
SLIDE 38

38

Electrical Systems

  • NFPA 99, Sec. 6.3.3.2, and 6.3.4.1. Testing of electrical

receptacles.

  • Hospital grade vs. non-hospital grade determine frequency
  • f testing.
slide-39
SLIDE 39

39

Hospital Grade Receptacles

slide-40
SLIDE 40

40

Electrical Polarity & Tension Tester

slide-41
SLIDE 41

41

Take Aways

  • Have good contracts
  • Tell the vendor you have a contract with they have to

follow the inspection, testing, maintenance tables per the NFPA edition CMS follows

  • Contact an electrician to help you identify the circuit

breakers controlling your emergency lighting systems and inspection of the circuit breakers

slide-42
SLIDE 42

42

Take Aways

  • Fire Sprinklers: 2011 Edition NFPA 25, Section 5, Table

5.1.1.2 and Table 13.1.1.2.

  • Fire Alarm System: 2010 Edition NFPA 72, Testing

frequencies, Table 14.4.5

  • Fire Door Inspection: follow the instructions exactly as

shown

slide-43
SLIDE 43

43

Take Aways

  • Generators: 2010 Edition NFPA 110, Section 8.4.2 for

inspection, testing and maintenance requirements

  • Do your risk assessments
  • Write your policies
slide-44
SLIDE 44

44

The End

  • Questions?
