If you use a PC at home or at work I f yo u use a PC at ho me o r at Wo rk Co ng ratulatio ns Yo ur life just g o t a who le lo t e asie r 1 1 Media T ec hnology Univer sal Ser ial Bus Sr eenu 1 2 Univer sal Ser ial Bus

SLIDE 1

1 1

Co ng ratulatio ns

Yo ur life just g o t

a who le lo t

e asie r

If you use a PC at home or at work

I f yo u use a PC at ho me o r at Wo rk

SLIDE 2

1 2

Univer sal Ser ial Bus

Sr eenu Media T ec hnology

SLIDE 3

1 3

Basic Info What is USB?

Sr eenu

Media T ec h Univer sal Ser ial Bus

„must have“ feature in today‘s PCs

„Plug and Play“ peripheral connection

„One plug fits all“ Universal – all peripherals share same connector Serial – devices can daisy chain together

SLIDE 4

1 4

Basic Info Why is USB?

no hassel way to connect peripherals pc evolves into a simpler, easier to use appliance. _makes adding peripheral devices so easy _novice user can use it.

Sr eenu

Media T ec h Univer sal Ser ial Bus

SLIDE 5

1 5

Sr eenu

Media T ec h Univer sal Ser ial Bus

Keyboard Mouse Serial Port Parallel Port SCSI Port Sound/Game Ports Graphics Port LAN Modem

Graphics Port

LAN USB USB USB

Telephony, Modem, Keyboard, Mouse,Game ports, Serial ports Device,Digital Audio, Printer, Scanner

Basic Info

SLIDE 6

1 6

Sr eenu

Media T ec h Univer sal Ser ial Bus Basic Info USB‘s Stor y

SLIDE 7

1 7

Sr eenu

Media T ec h Univer sal Ser ial Bus Behind the Sc enes How USB wor ks? Device _ID - information about the device _plugged and unplugged – drivers automatically loaded and unloaded. Software _no special software is required _OS has necessary drivers

SLIDE 8

1 8

Sr eenu

Media T ec h Univer sal Ser ial Bus Behind the Sc enes USB Cable _2 wires for power : +5 volts (red) and ground (brown) _twisted pair : to carry data (yellow and blue) Devices connected to a USB port rely on the USB cable to carry power and data Low power devices – draw thier power - bus High power devices – their own power supplies

SLIDE 9

1 9

Sr eenu

Media T ec h Univer sal Ser ial Bus How fast is USB? Behind the Sc enes High speed USB products have a design rate of 480 Mb/s Full speed USB devices signal at 12 Mb/s Low speed devices use 1.5 Mb/s subchannel

SLIDE 10

1 10

Sr eenu

Media T ec h Univer sal Ser ial Bus Applic ations USB is not designed for heavy multimedia usage; however, it is very capable handling low-end and mid-level devices.

USB can apply to

SLIDE 11

1 11

Sr eenu

Media T ec h Univer sal Ser ial Bus Advantages Hot Pluggable _no need to turn off or restart the computer _connect USB peripherals when ever u need Simple Installation _simple installer applications _supports dynamically loading drivers

SLIDE 12

1 12

Sr eenu

Media T ec h Univer sal Ser ial Bus Advantages Easy Connections _require no terminators or memory addresses _cable – small, simple, inexpensive and easy to atttach Greater Expandability _simultaneous connection upto 127 devices _attach peripherals through interconnected external hubs

SLIDE 13

1 13

Sr eenu

Media T ec h Univer sal Ser ial Bus Pr

duc ts

USB products offer high performance solutions for PC and peripheral applications _Bali USB PVR (Personal Video Recorder) Enables PVR functionality on a PC Conversion of analog videotapes into VCD/DVD _USB Pendrive read, write, copy, delete and move data play MP3 files, run applications, view videos storage capacity: from 16MB – 1GB

SLIDE 14

1 14

Sr eenu

Media T ec h Univer sal Ser ial Bus Pr

duc ts

_USB Bluetooth Adapter data trasfer among devices such as PDA‘s, printers, cellular phones, pc‘s and other emerging devices _ability to share information _obtain network access _take full advantage of wireless connected environment

SLIDE 15

1 15

Sr eenu

Media T ec h Univer sal Ser ial Bus USB OT G (On-T he-Go)

Past is history Future is mystery

Present is omnipresent

new supplement to the USB 2.0 specification augments the capability of existing mobile devices handsets, mobiles, digicams, can be directly connected to USB devices defined especially for portable devices first products expected to ship during this year

SLIDE 16

1 16

Sr eenu

Media T ec h Univer sal Ser ial Bus Summar y

highlights of USB technology _one standard connector type – one-size-fits-all _hot insertion and removal _chain devices together _automatic installation _separate power cord not required _faster

SLIDE 17

1 17

Sr eenu

Media T ec h Univer sal Ser ial Bus R efer enc es

For information regarding USB in general http://www.usb.org/home http://www.everythingusb.com http://www.usbman.com/index.htm http://www.ti.com/sc/usb For Products http://www.mrusb.co.uk/ http://www.dlink.com/products/?pid=34#

SLIDE 18

1 18

Sr eenu

Media T ec h Univer sal Ser ial Bus Questions
