SLIDE 1
clolckwork
the bicycle add-on that boosts you forwards, like clockwork
specifications
size < 10 cm protrusion from wheel plane weight < 3 kg added mass acceleration 0-5 mph in <4 sec price < $50
clolckwork the bicycle add-on that boosts you forwards, like - - PowerPoint PPT Presentation
clolckwork the bicycle add-on that boosts you forwards, like - - PowerPoint PPT Presentation
clolckwork the bicycle add-on that boosts you forwards, like clockwork specifications size < 10 cm protrusion from wheel plane weight < 3 kg added mass acceleration 0-5 mph in <4 sec price < $50 energy storage l how can we store
SLIDE 2
SLIDE 3
energy storage l
how can we store enough energy to meet our acceleration and torque specs?
SLIDE 4
clutch mechanism
bike wheel energy storage system
charging acceleratin g Pink arrow gears spin freely. Blue arrow gears spin with shaft.
how can we access the stored energy and switch between states of charging, neutral, releasing, stopping releasing?
SLIDE 5
risks
- gear ratio
- user control of energy output
SLIDE 6
next steps
- energy storage and output methods
- user friendly installation and universality
SLIDE 7
the problem
- vertical and horizontal printing of arbitrary scale
