CHORIST project 5th Standards Development Organizations (SDO) Emergency Services Workshop Wien, 21-23/10/08 Patrice SIMON EADS Secure Networks, FRANCE CHORIST project coordinator CHORIST @ 5th SDO Emergency Services Workshop - Wien, Oct.

slide-1
SLIDE 1

CHORIST @ 5th SDO Emergency Services Workshop - Wien, Oct. 08 - P. SIMON page: 1

CHORIST project

5th Standards Development Organizations (SDO) Emergency Services Workshop

Wien, 21-23/10/08

Patrice SIMON – EADS Secure Networks, FRANCE CHORIST project coordinator

slide-2
SLIDE 2

CHORIST @ 5th SDO Emergency Services Workshop - Wien, Oct. 08 - P. SIMON page: 2

Scope

Present the solutions proposed by the CHORIST project in the domain of the early warning of natural hazards and industrial accidents.

slide-3
SLIDE 3

CHORIST @ 5th SDO Emergency Services Workshop - Wien, Oct. 08 - P. SIMON page: 3

  • 1. Context of the project

What is this all about ?

slide-4
SLIDE 4

CHORIST @ 5th SDO Emergency Services Workshop - Wien, Oct. 08 - P. SIMON page: 4

Industrial accidents Natural hazards

Information flow

CITIZENS AUTHORITIES

Information

  • n the situation

Information

  • n the events

Warnings Alerts sent to call centres Information

  • n the situation

WORLD

slide-5
SLIDE 5

CHORIST @ 5th SDO Emergency Services Workshop - Wien, Oct. 08 - P. SIMON page: 5

The early warning

Natural hazards Industrial accidents event Disaster preparedness and prevention Disaster response Disaster recovery

Scope of CHORIST =

EARLY WARNING

  • 1. Authorities have to be aware of what’s going on.
  • 2. Citizens shall be informed of the situation and

they shall QUICKLY told what to do by the Authorities.

slide-6
SLIDE 6

CHORIST @ 5th SDO Emergency Services Workshop - Wien, Oct. 08 - P. SIMON page: 6

The acronym

CHORIST = integrating Communications for enHanced envirOnmental RISk management and citizens safeTy

slide-7
SLIDE 7

CHORIST @ 5th SDO Emergency Services Workshop - Wien, Oct. 08 - P. SIMON page: 7

The project

  • 3 years (Jun. 06 / May 09)
  • European Commission Framework Programme 6 (FP6)
  • 12.8 M€ (incl. 7.1 M€ EC funding)
  • Cooperation by 17 partners, from 8 European countries

INDUSTRY USERS EURECOM RESEARCH

slide-8
SLIDE 8

CHORIST @ 5th SDO Emergency Services Workshop - Wien, Oct. 08 - P. SIMON page: 8

  • 2. The whole system

A system made of 3 subsystems

slide-9
SLIDE 9

CHORIST @ 5th SDO Emergency Services Workshop - Wien, Oct. 08 - P. SIMON page: 9

CRISIS AREA

Events & Situation (current+forecast)

  • Common Operational Picture

(real-time situation picture)

  • Alerts

Risk assessment report system

Legacy monitoring and warning agencies

Citizens calls Alerts & Situation description

112 call centers

Authorities

(local, national…)

Sensors (raw data) Command and control of rescue teams Situation description

Rapidly deployable systems

  • WiMAX techno.
  • TETRA TEDS
  • n-field

rescue teams

Warning messages to citizens Warning message distribution through:

  • Digital Audio Broadcasting
  • Digital Video Broadcasting
  • GSM cell broadcast
  • Sirens
  • . . .

Communication to citizens

Citizens The three The three CHORIST subsystems HORIST subsystems

slide-10
SLIDE 10

CHORIST @ 5th SDO Emergency Services Workshop - Wien, Oct. 08 - P. SIMON page: 10

  • 3. The CHORIST subsystems
  • a. The risk assessment report subsystem
  • b. The warning subsystem
  • c. The rapidly deployable communication subsystems:
  • i. Wideband subsystem
  • ii. Broadband subsystem
slide-11
SLIDE 11

CHORIST @ 5th SDO Emergency Services Workshop - Wien, Oct. 08 - P. SIMON page: 11

The risk assessment report subsystem: Actors, functions & flows

CHORIST risk assessment report subsystem

Alerts Common Operational Picture Sensors networks Industry and environment monitoring agencies Authorities (local, regional, national)

& Risk Awareness module Risk Assessment module

C orre zi on e de l l e p rev i si on i co n i d at i i d rome t ri c i t e mpo p ort at e val or i cor ret t i val or i cal col at i val or i m i su r a t i

Models for forecast (meterological, hydrological...) Alert data merger and correlation Alert data archiving Message dispatch for alert trigger Situation analysis Threat assessment and risk definition Alert elaboration

112 call centers

slide-12
SLIDE 12

CHORIST @ 5th SDO Emergency Services Workshop - Wien, Oct. 08 - P. SIMON page: 12

The risk assessment report subsystem: Main features

  • Assists authorities by providing a Common Operational

Picture and Alerts:

– to assess natural hazards and industrial accidents – to take decisions

  • Useable at different levels (Local/Regional/National),

depending on the scale of the disaster and according to different roles (e.g. Civil Protection Organisations, police, fire brigades…)

  • ne information system with different views on it.
  • Built on top of existing monitoring agencies. Merges

information from different sources.

slide-13
SLIDE 13

CHORIST @ 5th SDO Emergency Services Workshop - Wien, Oct. 08 - P. SIMON page: 13

  • 3. The CHORIST subsystems
  • a. The risk assessment report subsystem
  • b. The warning subsystem
  • c. The rapidly deployable communication subsystems:
  • i. Wideband subsystem
  • ii. Broadband subsystem
slide-14
SLIDE 14

CHORIST @ 5th SDO Emergency Services Workshop - Wien, Oct. 08 - P. SIMON page: 14

The warning subsystem: Actors, functions & flows

TV Radios Sirens / Loudspeakers Mobile phone

"Chemical plant leakage - Stay home"

Warning messages to broadcast: Area where to broadcast the message:

National, Regional

  • r Local authorities

Natural hazard / industrial accident area

Decide Broadcast Population

CHORIST warning subsystem

Many other means:

  • fixed phones
  • satellites
  • road signs , etc.

1 3

Select

2

Receive

4

Warning messages dispatcher

Schedule of the broadcast

Act as needed

5

slide-15
SLIDE 15

CHORIST @ 5th SDO Emergency Services Workshop - Wien, Oct. 08 - P. SIMON page: 15

The warning subsystem: Main features

  • Allows authorities to send warning message to the

maximum number of people in a given area in the minimum of time.

  • Useable at different levels (Local/Regional/National)
  • Message design (through templates):

– Alarm level ('alarm', 'warning', or 'information') – Location (polygon on a map) – Information (e.g. 'Fire in …') – Action (e.g. 'Go…', 'Gather at…') several languages – More info (e.g. 'Turn radio to 108.3 MHz for more info') – Timestamp

slide-16
SLIDE 16

CHORIST @ 5th SDO Emergency Services Workshop - Wien, Oct. 08 - P. SIMON page: 16

  • 3. The CHORIST subsystems
  • a. The risk assessment report subsystem
  • b. The warning subsystem
  • c. The rapidly deployable communication subsystems:
  • i. Wideband subsystem
  • ii. Broadband subsystem
slide-17
SLIDE 17

CHORIST @ 5th SDO Emergency Services Workshop - Wien, Oct. 08 - P. SIMON page: 17

The rapidly deployable communication WIDEBAND subsystem: Actors, functions & flows

CHORIST rapidly deployable WIDEBAND system

Field rescue teams Video maps . . . Data & Application Servers

IP backbone

TETRA TEDS cell TETRA narrowband cell Voice OPTIONAL

slide-18
SLIDE 18

CHORIST @ 5th SDO Emergency Services Workshop - Wien, Oct. 08 - P. SIMON page: 18

The rapidly deployable communication WIDEBAND subsystem: Main features

  • Overlay of TEDS (standard: TETRA Enhanced Data

Service) with TETRA narrowband

  • Data services only
  • 100 kbps per TRX
  • Standalone or connected to external networks
slide-19
SLIDE 19

CHORIST @ 5th SDO Emergency Services Workshop - Wien, Oct. 08 - P. SIMON page: 19

The rapidly deployable communication BROADBAND subsystem: Actors, functions & flows

Fixed (regional / national) narrowband PMR infrastructure CHORIST rapidly deployable BROADBAND subsystem

Dispatch Positions Narrowband terminals Broadband terminals

WiMAX local cell

WiMAX ad-hoc router WiMAX ad-hoc router + base station WiMAX ad-hoc router + backhaul end-point

WiMAX ad-hoc network IP backbone WiMAX local cell WiMAX backhaul

WiMAX ad-hoc router + backhaul end-point WiMAX ad-hoc router

CRISIS AREA

slide-20
SLIDE 20

CHORIST @ 5th SDO Emergency Services Workshop - Wien, Oct. 08 - P. SIMON page: 20

The rapidly deployable communication BROADBAND subsystem: Main features

  • Innovative self-forming inter-vehicular IPv6 mobile

broadband wireless core network

  • Voice and data services
  • VoIP group communication application developed.
  • Several Mbps in the network
  • Standalone or connected to external networks
slide-21
SLIDE 21

CHORIST @ 5th SDO Emergency Services Workshop - Wien, Oct. 08 - P. SIMON page: 21

For more information:

Visit CHORIST web site at: http://www.chorist.eu/ Contact project coordinator: Patrice SIMON EADS Secure Networks patrice.simon@eads.com
