D AY 2 D EFINITION OF CIRCLES AND LINE SEGMENTS I NTRODUCTION We encounter circular objects in real life such as: pizzas, wheels, tires, rings, cakes, coins, buttons, clocks and rims. On the other hand, line segments abound in real life.

slide-1
SLIDE 1

DAY 2 – DEFINITION OF CIRCLES

AND LINE SEGMENTS

slide-2
SLIDE 2

INTRODUCTION

We encounter circular objects in real life such as: pizzas, wheels, tires, rings, cakes, coins, buttons, clocks and rims. On the other hand, line segments abound in real

  • life. The edge of a book and the vertical corner of a

wall form line segments. We are going to define circles and identify various parts of a circle.

slide-3
SLIDE 3

VOCABULARY

Circle A two dimensional shape made up points, all having the same distance from a given point called the center of the circle. Subtended angle The angle formed by an arc or a line at a given point. Line segment A portion of a line between two endpoints. Line segment AB, written as 𝐡𝐢 is shown below.

A B

slide-4
SLIDE 4

Center of a circle A fixed point inside a circle that is the same distance from every point on the circle. Circles are named basing on their center. In circle O, the center is shown.

Center O

slide-5
SLIDE 5

Example 1 Draw and label GH. Solution GH is a line segment by definition.

G H

slide-6
SLIDE 6

Example 2 From the figure below, list all the line segments.

A B C F D E

slide-7
SLIDE 7

Solution 𝐸𝐹, 𝐸𝐢, 𝐢𝐹, 𝐺𝐢, 𝐡𝐢, 𝐢𝐷, 𝐡𝐷

slide-8
SLIDE 8

PARTS OF A CIRCLE

ο‚’ Radius

The distance from the center of a circle to any point

  • n the circle.

Radius O

slide-9
SLIDE 9

Chord A straight line that joins any two points on the circle, or simply a line segment whose endpoints lie

  • n the circle. PQ and RS are chords.

Q S R P

slide-10
SLIDE 10

Diameter A line segment which goes through the center

  • f the circle and whose both endpoints lie on the

circle, or simply a chord which passes through the center of the circle. The diameter is the longest chord in a circle. 𝐡𝐢 is the diameter.

A B O

slide-11
SLIDE 11

Circumference The distance around the edge of a circle, or simply the perimeter of a circle. Arc Part of the circumference of a circle. An arc is named according to its endpoints. AB is an arc.

Minor arc Major arc

slide-12
SLIDE 12

Semi circle A half circle formed when we cut a circle along its diameter. Minor arc An arc whose length is less than the length of the arc of the semicircle. Major arc An arc whose length is more than the length of the arc of the semi circle.

slide-13
SLIDE 13

In the figure below, AB is the minor arc and ACB is the major arc.

Minor arc Major arc

slide-14
SLIDE 14

Segment The region of a circle bounded by a chord and an arc. A chord divides a circle into two parts called segments. (a) Major segment Region bounded by the chord and the major arc. (b) Minor segment Region bounded by the chord and minor arc.

slide-15
SLIDE 15

Major and minor segments are shown below. Major segment

Minor segment

slide-16
SLIDE 16

Central angle An angle whose vertex is the center of a circle.

Central angle

slide-17
SLIDE 17

Sector The region of a circle enclosed by two radii and an arc.

O A B Major sector Minor sector Radius

slide-18
SLIDE 18

Secant A straight line that intersects a circle twice.

Secant

slide-19
SLIDE 19

Tangent to a circle A straight line in the plane of a circle that touches the circle at only one point without crossing it. The point at which the tangent touches the circle is called the point of tangency.

Tangent line Point of tangency

slide-20
SLIDE 20

Concentric circles Two or more circles with different radii but having a common center. The diagram below shows two concentric circles. Congruent circles These are equal circles because they have the equal radii.

slide-21
SLIDE 21

Eccentric circles Two or more circles are said to be eccentric if they have different centers though located within one or more of the circles.

C D

slide-22
SLIDE 22

Example 3 Identify whether the lines or line segments are chords, secants, tangents, diameters or radii of the circle below. (a) 𝑄𝑅 (b) π‘ˆπ‘‰ (c) π‘‹π‘Œ (d) 𝑆𝑇 (e) 𝑃𝑅

E A F O C D G B H

slide-23
SLIDE 23

Solution (a) 𝐡𝐢 is a diameter. (b) 𝐷𝐸 is a chord. (c) 𝐻𝐼 is a tangent. (d) 𝐹𝐺 is a secant. (e) 𝑃𝐢 is the radius.

slide-24
SLIDE 24

Example 4 The diameter of circle is given as 7.4 in. Find the radius. Solution The diameter of a circle is twice its radius, therefore, the radius is

7.4 2 = 3.5 π‘—π‘œ.

Example 5 If the radius of a circle is 15.4 ft. what is its diameter? Solution Diameter = 2 Γ— 𝑠𝑏𝑒𝑗𝑣𝑑 = 2 Γ— 15.4 = 30.8 𝑔𝑒

slide-25
SLIDE 25

HOMEWORK

Identify whether the lines or line segments are chords, secants, tangents, diameters or radii of the circle below. (a) 𝐡𝐸 (b) 𝐡𝐢 (c) 𝐹𝐺 (d) 𝐻𝐼 (e) 𝐷𝐸 (f) 𝐡𝐷

A B C D H G F E

slide-26
SLIDE 26

ANSWERS TO HOMEWORK

(a) 𝐡𝐸 is the diameter (b) 𝐡𝐢 is a chord (c) 𝐹𝐺 is a tangent (d) 𝐻𝐼 is a secant (e) 𝐷𝐸 is a radius (f) 𝐡𝐷 is a radius

slide-27
SLIDE 27

THE END
