Census Geographies Introduction to Fundamentals of Census Geographies GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc Introduction to Census Geographies Fundamentals of Census Geographies Census Geographic

slide-1
SLIDE 1

Introduction to

Census Geographies

slide-2
SLIDE 2

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

Fundamentals of

Census Geographies

slide-3
SLIDE 3

Legal/Administrative Areas

  • Existence and boundaries officially prescribed through

legal means to manage various programs

  • Census Bureau generally accepts boundaries provided by
  • fficial local entities

Statistical Entities

  • Created based on the programmatic and analytical needs
  • f data users for situations when geographic coverage of

legal entities is inadequate

  • Census Bureau cooperates with local entities to establish

standards and boundaries

Census Geographic Entity Types

Introduction to Census Geographies Fundamentals of Census Geographies

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

slide-4
SLIDE 4

Census Geographic Entities

Introduction to Census Geographies Fundamentals of Census Geographies

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

Geographic Area Type Number Nation Legal 1 Regions Statistical 4 Divisions Statistical 9 States and Equivalent Legal 57 Metropolitan Areas Statistical 362 Urbanized Areas Statistical 405 Counties and Equivalent Legal 3248 County Subdivisions and Places Mixed 60,228 Census Tracts Statistical 62,276 Block Groups Statistical 229,192 Blocks Statistical 7,017,427 Special-Purpose Entities Legal/Administrative 404,583

slide-5
SLIDE 5

Federal Information Processing Standards (FIPS)

  • Issued by the National Institute of Standards and

Technology (NIST) American National Standards Institute Codes (ANSI)

  • Issued by the InterNational Committee for

Information Technology Standards (INCITS)

Unique Geographic Entity Codes

Introduction to Census Geographies Fundamentals of Census Geographies

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

slide-6
SLIDE 6

Census Geographic Entities

Introduction to Census Geographies Fundamentals of Census Geographies

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

Nation Regions Divisions States Counties Census Tracts Block Groups Blocks Statistical Legal

slide-7
SLIDE 7

Regions and Divisions

Introduction to Census Geographies Fundamentals of Census Geographies

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

slide-8
SLIDE 8
  • Assigned a unique 2-digit code in alphabetical order

(Texas = 48) Statistical Equivalent Entities

  • District of Columbia
  • Puerto Rico
  • American Samoa
  • Commonwealth of the Northern Mariana Islands
  • Guam
  • U.S. Virgin Islands

States and Equivalents

Introduction to Census Geographies Fundamentals of Census Geographies

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

slide-9
SLIDE 9
  • Assigned a unique 3-digit code in alphabetical order

within each state (Harris County = 201)

Counties and Equivalents

Introduction to Census Geographies Fundamentals of Census Geographies

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

Geographic Entity Type Counties 48 states Parishes Louisiana Cities, Boroughs, Municipalities, and Census Areas Alaska Incorporated Places MD, MO, NV, VA District of Columbia and Guam No subdivisions Municipios Puerto Rico Islands and Districts American Samoa Municipalities Northern Marianas Islands U.S. Virgin Islands

slide-10
SLIDE 10

Counties in Texas

Introduction to Census Geographies Fundamentals of Census Geographies

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

slide-11
SLIDE 11

Counties in Washington, DC Region

Introduction to Census Geographies Fundamentals of Census Geographies

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

slide-12
SLIDE 12

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

Census Tracts

slide-13
SLIDE 13
  • Small, relatively permanent statistical subdivisions of a

county

  • Uniquely numbered in each county with a 6-digit

numeric code XXXX.XX Target Population

  • Optimum population = 4,000
  • Minimum population = 1,200
  • Maximum population = 8,000

Census Tracts

Introduction to Census Geographies Census Tracts

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

slide-14
SLIDE 14

Census Tracts in Texas

Introduction to Census Geographies Census Tracts

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

slide-15
SLIDE 15

Census Tracts in Harris County

Introduction to Census Geographies Census Tracts

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

slide-16
SLIDE 16

Census Tracts Inside the Loop

Introduction to Census Geographies Census Tracts

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

slide-17
SLIDE 17
  • Updated decennially through the Participant

Statistical Areas Program (PSAP)

  • Census tracts > 8,000 are split
  • Census tracts < 1,200 are merged
  • Small boundary revisions allowed as long as a

large amount of the population in the tracts is not affected.

  • All changes documented in Census Tract

Relationship Files so data can be compared between decades.

Updating Census Tracts

Introduction to Census Geographies Census Tracts

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

slide-18
SLIDE 18

1970 Census Tracts

Introduction to Census Geographies Census Tracts

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

slide-19
SLIDE 19

1980 Census Tracts

Introduction to Census Geographies Census Tracts

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

slide-20
SLIDE 20

1990 Census Tracts

Introduction to Census Geographies Census Tracts

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

slide-21
SLIDE 21

2000 Census Tracts

Introduction to Census Geographies Census Tracts

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

slide-22
SLIDE 22

Montrose Census Tracts

Introduction to Census Geographies Census Tracts

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

slide-23
SLIDE 23

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

Census Block Groups

slide-24
SLIDE 24
  • Statistical subdivisions of a census tract
  • Uniquely numbered 0-9 in each census tract

Target Population

  • Optimum population = 1,500
  • Minimum population = 600
  • Maximum population = 3,000

Census Block Groups

Introduction to Census Geographies Census Block Groups

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

slide-25
SLIDE 25

Montrose Census Block Groups

Introduction to Census Geographies Census Block Groups

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

slide-26
SLIDE 26

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

Census Blocks

slide-27
SLIDE 27
  • Smallest statistical subdivision
  • Bounded by visible features and non-visible

boundaries

  • Uniquely numbered 0000-9999 in each census tract
  • No population requirements

Census Blocks

Introduction to Census Geographies Census Blocks

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

slide-28
SLIDE 28

Montrose Census Blocks

Introduction to Census Geographies Census Blocks

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

slide-29
SLIDE 29

GEOID 482014106001018

  • State 48 = Texas
  • County 201 = Harris
  • Census Tract 4106.00
  • Block Group 1
  • Block 1018

Example FIPS Codes

Introduction to Census Geographies Census Blocks

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

slide-30
SLIDE 30

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

Nation Subdivisions

slide-31
SLIDE 31

Census Geographic Entities

Introduction to Census Geographies Nation Subdivisions

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

Urban Areas Core-Based Statistical Areas Nation Regions Divisions States Counties Census Tracts Block Groups Blocks

slide-32
SLIDE 32

Urbanized Areas (UAs)

  • Densely developed territory with 50,000 people
  • r more

Urban Clusters

  • Densely developed territory with 2,500 to 50,000

people Titles may contain up to 3 place names

Urban Areas (UAs)

Introduction to Census Geographies Nation Subdivisions

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

slide-33
SLIDE 33

Core Based Statistical Areas

Introduction to Census Geographies Nation Subdivisions

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

2010 Geographic Entities Type Core Based Statistical Areas (CBSAs) Administrative Metropolitan Statistical Areas Administrative Micropolitan Statistical Areas Administrative Combined Statistical Area (CSAs) Administrative Metropolitan Division Administrative Historic Geographic Entities Type Primary Metropolitan Statistical Areas (PMSAs) Administrative Consolidated Metropolitan Statistical Areas (CMSAs) Administrative

slide-34
SLIDE 34

Metropolitan Statistical Area

  • Contains at least one UA and > 50,000 people

Micropolitan Statistical Area

  • Contains at least one UC and > 10,000 people

Core-Based Statistical Areas (CBSAs)

Introduction to Census Geographies Nation Subdivisions

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

slide-35
SLIDE 35

Core-Based Statistical Areas

Introduction to Census Geographies Nation Subdivisions

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

slide-36
SLIDE 36
  • Two or more adjacent CBSAs with substantial

employment interchange

Combined Statistical Areas (CSAs)

Introduction to Census Geographies Nation Subdivisions

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

slide-37
SLIDE 37

Combined Statistical Areas

Introduction to Census Geographies Nation Subdivisions

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

slide-38
SLIDE 38
  • Subdivisions of metropolitan statistical areas
  • Population greater than 2.5 million

Metropolitan Divisions

Introduction to Census Geographies Nation Subdivisions

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

slide-39
SLIDE 39

Metropolitan Divsions

Introduction to Census Geographies Nation Subdivisions

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

slide-40
SLIDE 40

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

State Subdivisions

slide-41
SLIDE 41

Census Geographic Entities

Introduction to Census Geographies State Subdivisions

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

Core-Based Statistical Areas Nation Regions Divisions States Counties Census Tracts Block Groups Blocks Places Urban Areas

slide-42
SLIDE 42

Incorporated Places

  • Legally bounded entities established to provide

governmental functions for a concentration of people

  • Usually city, town, village, or borough

Census Designated Places (CDPs)

  • Statistical entities derived by the Census Bureau
  • Not legal boundaries
  • Usually coincide with visible feature or adjacent legal

boundaries

Places

Introduction to Census Geographies State Subdivisions

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

slide-43
SLIDE 43

Places

Introduction to Census Geographies State Subdivisions

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

slide-44
SLIDE 44

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

County Subdivisions

slide-45
SLIDE 45

Census Geographic Entities

Introduction to Census Geographies County Subdivisions

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

Core-Based Statistical Areas Nation Regions Divisions States Counties Census Tracts Block Groups Blocks Places County Subdivision Urban Areas

slide-46
SLIDE 46

Minor Civil Divisions (MCDs)

  • Legally bounded entities
  • In 29 states
  • May have a formal government with elected
  • fficials

Census County Divisions (CCDs)

  • Statistical entities derived by the Census Bureau
  • Not legal boundaries

County Subdivisions

Introduction to Census Geographies County Subdivisions

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

slide-47
SLIDE 47

County Subdivision Classification

Introduction to Census Geographies County Subdivisions

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

slide-48
SLIDE 48

County Subdivisions in Harris County

Introduction to Census Geographies County Subdivisions

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

slide-49
SLIDE 49

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

Special-Purpose Entities

slide-50
SLIDE 50

Special-Purpose Entities

Introduction to Census Geographies Special-Purpose Entities

GIS/Data Center | Email gisdata@rice.edu | Lab (713) 348-2599 | library.rice.edu/gdc

Geographic Area Type Number Congressional Districts Legal 435 Voting Districts (VTDs) Legal 148,872 School Districts Administrative 15,274 Traffic Analysis Zones (TAZs) Administrative 200,000 ZIP Code Tabulation Areas (ZCTAs) Administrative 40,000
