CENG 4480 L09 Memory 2 Bei Yu Reference : Chapter 11 Memories CMOS VLSI DesignA Circuits and Systems Perspective by H.E.Weste and D.M.Harris 1 CENG4480 v.s. CENG3420 CENG3420: architecture perspective memory coherent

slide-1
SLIDE 1

1

Reference:

  • Chapter 11 Memories
  • CMOS VLSI Design—A Circuits and Systems Perspective
  • by H.E.Weste and D.M.Harris

CENG 4480 L09 Memory 2

Bei Yu

slide-2
SLIDE 2
  • L09. Memory-2

CENG4480

CENG4480 v.s. CENG3420

  • CENG3420:

✦ architecture perspective ✦ memory coherent ✦ data address

  • CENG4480: more details on how data is stored

2

slide-3
SLIDE 3
  • L09. Memory-2

CENG4480

Memory Arrays

Random Access Memory Serial Access Memory Content Addressable Memory (CAM) Read/Write Memory (RAM) (Volatile) Read Only Memory (ROM) (Nonvolatile) Static RAM (SRAM) Dynamic RAM (DRAM) Shift Registers Queues First In First Out (FIFO) Last In First Out (LIFO) Serial In Parallel Out (SIPO) Parallel In Serial Out (PISO) Mask ROM Programmable ROM (PROM) Erasable Programmable ROM (EPROM) Electrically Erasable Programmable ROM (EEPROM) Flash ROM

Memory Arrays

3

slide-4
SLIDE 4
  • L09. Memory-2

CENG4480

Storage based on Feedback

  • What if we add feedback to a pair of inverters?
  • Usually drawn as a ring of cross-coupled inverters
  • Stable way to store one bit of information (w. power)

4

1 1 1

slide-5
SLIDE 5
  • L09. Memory-2

CENG4480

How to change the value stored?

  • Replace inverter with NAND gate
  • RS Latch

5

A B A nand B 1 1 1 1 1 1 1

S R Q ¯ Q 1 1

slide-6
SLIDE 6
  • L09. Memory-2

CENG4480

12T SRAM Cell

  • Basic building block: SRAM Cell

✦ Holds one bit of information, like a latch ✦ Must be read and written

  • 12-transistor (12T) SRAM cell

✦ Use a simple latch connected to bitline ✦ 46 x 75 λ unit cell 6

bit write write_b read read_b

slide-7
SLIDE 7
  • L09. Memory-2

CENG4480

nMOS, pMOS, Inverter

7

  • nMOS:

✦ Gate = 1, transistor is ON ✦ Then electric current path

  • pMOS:

✦ Gate = 0, transistor is ON ✦ Then electric current path

  • Inverter:

✦ Q = NOT (A)

slide-8
SLIDE 8
  • L09. Memory-2

CENG4480

6T SRAM Cell

  • Used in most commercial chips
  • A pair of weak cross-coupled inverters
  • Data stored in cross-coupled inverters
  • Compared with 12T SRAM, 6T SRAM:

✦ (+) reduce area ✦ (-) much more complex control 8

bit bit_b word

slide-9
SLIDE 9
  • L09. Memory-2

CENG4480

6T SRAM Read

  • Precharge both bitlines high
  • Then turn on wordline
  • One of the two bitlines

will be pulled down by the cell

  • Read stability

– A must not flip – N1 >> N2 9

bit bit_b N1 N2 P1 A P2 N3 N4 A_b word

0.0 0.5 1.0 1.5 100 200 300 400 500 600 time (ps)

word bit A A_b bit_b

slide-10
SLIDE 10
  • L09. Memory-2

CENG4480

EX: 6T SRAM Read

  • Question 1: A = 0, A_b = 1, discuss the behavior:
  • Question 2: At least how many bit lines to finish read?

– 10

bit bit_b N1 N2 P1 A P2 N3 N4 A_b word

slide-11
SLIDE 11
  • L09. Memory-2

CENG4480

6T SRAM Write

  • Drive one bitline high, the other low
  • Then turn on wordline
  • Bitlines overpower cell with new value
  • Writability

– Must overpower

feedback inverter

– N4 >> P2 – N2 >> P1 (symmetry) 11

time (ps)

word A A_b bit_b

0.0 0.5 1.0 1.5 100 200 300 400 500 600 700

bit bit_b N1 N2 P1 A P2 N3 N4 A_b word

slide-12
SLIDE 12
  • L09. Memory-2

CENG4480

EX: 6T SRAM Write

  • Question 1: A = 0, A_b = 1, discuss the behavior:
  • Question 2: At least how many bit lines to finish write?

– 12

bit bit_b N1 N2 P1 A P2 N3 N4 A_b word

slide-13
SLIDE 13
  • L09. Memory-2

CENG4480

6T SRAM Sizing

  • High bitlines must not overpower inverters during reads
  • But low bitlines must write new value into cell

13

bit bit_b med A weak strong med A_b word

slide-14
SLIDE 14
  • L09. Memory-2

CENG4480

Memory Arrays

Random Access Memory Serial Access Memory Content Addressable Memory (CAM) Read/Write Memory (RAM) (Volatile) Read Only Memory (ROM) (Nonvolatile) Static RAM (SRAM) Dynamic RAM (DRAM) Shift Registers Queues First In First Out (FIFO) Last In First Out (LIFO) Serial In Parallel Out (SIPO) Parallel In Serial Out (PISO) Mask ROM Programmable ROM (PROM) Erasable Programmable ROM (EPROM) Electrically Erasable Programmable ROM (EEPROM) Flash ROM

Memory Arrays

14

slide-15
SLIDE 15
  • L09. Memory-2

CENG4480

Dynamic RAM (DRAM)

  • Basic Principle: Storage of information on capacitors
  • Charge & discharge of capacitor to change stored value
  • Use of transistor as “switch” to:

✦ Store charge ✦ Charge or discharge 15

slide-16
SLIDE 16
  • L09. Memory-2

CENG4480

4T DRAM Cell

16

Data must be refreshed regularly Dynamic cells must be designed very carefully Data stored as charge on gate capacitors (complementary nodes)

Remove the two p-MOS transistors from static RAM cell, to get a four-transistor dynamic RAM cell.

slide-17
SLIDE 17
  • L09. Memory-2

CENG4480

3T DRAM Cell

No constraints on device ratios Reads are non-destructive Value stored at node X when writing a “1” = VDD-VT

17

VDD-VT

slide-18
SLIDE 18
  • L09. Memory-2

CENG4480

3T DRAM Layout

  • 576 λ 3T DRAM v.s. 1092 λ 6T SRAM
  • Further simplified

18

[1970: Intel 1003]

slide-19
SLIDE 19
  • L09. Memory-2

CENG4480

1T DRAM Cell

19

(a) (c) (f) (g) Select B T C DRAM cell To Pump (b) (d) (e)

Stored 1 Stored 0 Write 1 Write 0 Read 1 Read 0

  • Need sense amp helping reading
slide-20
SLIDE 20
  • L09. Memory-2

CENG4480

  • Read:

✦ Pre-charge large tank to VDD/2 ✦ If Ts = 0, for large tank : VDD/2 - V1 ✦ If Ts = 1, for large tank: VDD/2 + V1 ✦ V1 is very insignificant ✦ Need sense amp 20

(a) (c) (f) (g) Select B T C DRAM cell To Pump (b) (d) (e)

Stored 1 Stored 0 Write 1 Write 0 Read 1 Read 0

slide-21
SLIDE 21
  • L09. Memory-2

CENG4480

1T DRAM Cell

Write: Cs is charged or discharged by asserting WL and BL Read: Charge redistribution takes place between bit line and storage capacitance Voltage swing is small; typically around 250 mV

21

Trench-capacitor cell [Mano87]

slide-22
SLIDE 22
  • L09. Memory-2

CENG4480

  • EX. 1T DRAM Cell
  • Question: VDD=4V, CS=100pF, CBL=1000pF. What’s

the voltage swing value?

  • Note:

22

∆V = VDD

2

·

CS CS+CBL

slide-23
SLIDE 23
  • L09. Memory-2

CENG4480

SRAM v.s. DRAM

Static (SRAM)

  • Data stored as long as supply is applied
  • Large (6 transistors/cell)
  • Fast
  • Compatible with current CMOS manufacturing

Dynamic (DRAM)

  • Periodic refresh required
  • Small (1-3 transistors/cell)
  • Slower
  • Require additional process for trench capacitance

23

slide-24
SLIDE 24
  • L09. Memory-2

CENG4480

Array Architecture

  • 2^n words of 2^m bits each
  • Good regularity – easy to design

24

  • k ="2n

locations m bits

slide-25
SLIDE 25
  • L09. Memory-2

CENG4480

SRAM Memory Structure

25

n

D D D

.$.$.

D D D

.$.$.

D D D

.$.$. .$.$.

m

Memory$Data$Out

m

Memory$Data$In Read$Address$Decoder Memory$Read$Address

n

Write$Address$Decoder Memory$WriteAddress

Gated D8latch

D Q WE

Read$bitlines Write$bitlines Write$word$line Read$word$line

.$.$. .$.$.

WE

  • Latch based memory
slide-26
SLIDE 26
  • L09. Memory-2

CENG4480

Array Architecture

  • 2^n words of 2^m bits each
  • How to design if n >> m?
  • Fold by 2k into fewer rows of more columns

26

row decoder column decoder n n-k k 2m bits column circuitry bitline conditioning memory cells: 2n-k rows x 2m+k columns bitlines wordlines

slide-27
SLIDE 27
  • L09. Memory-2

CENG4480

Decoders

  • n:2n decoder consists of 2n n-input AND gates

– One needed for each row of memory – Build AND with NAND or NOR gates

Static CMOS Using NOR gates

27

word0 word1 word2 word3 A0 A1

word0 word1 word2 word3

slide-28
SLIDE 28
  • L09. Memory-2

CENG4480

  • EX. Decoder
  • Question: AND gates => NAND gate structure

28

word0 word1 word2 word3 A0 A1

slide-29
SLIDE 29
  • L09. Memory-2

CENG4480

Large Decoders

  • For n > 4, NAND gates become slow

– Break large gates into multiple smaller gates

29

word0 word1 word2 word3 word15 A0 A1 A2 A3

slide-30
SLIDE 30
  • L09. Memory-2

CENG4480

Predecoding

  • Many of these gates are redundant

– Factor out common gates – => Predecoder – Saves area – Same path effort

  • Question: How many NANDs can be saved?

30

A0 A1 A2 A3 word1 word2 word3 word15 word0 1 of 4 hot predecoded lines predecoders

slide-31
SLIDE 31
  • L09. Memory-2

CENG4480

*Decoder Layout

  • Decoders must be pitch-matched to SRAM cell

– Requires very skinny gates

31

GND VDD word buffer inverter NAND gate A0 A0 A1 A2 A3 A2 A3 A1

slide-32
SLIDE 32
  • L09. Memory-2

CENG4480

*Column Circuitry

  • Some circuitry is required for each column

– Bitline conditioning – Column multiplexing – *Sense amplifiers (DRAM) 32

row decoder column decoder n n-k k 2m bits column circuitry bitline conditioning memory cells: 2n-k rows x 2m+k columns bitlines wordlines

slide-33
SLIDE 33
  • L09. Memory-2

CENG4480

*Bitline Conditioning

  • Precharge bitlines high before reads
  • Equalize bitlines to minimize voltage difference when

using sense amplifiers

33

φ bit bit_b

φ bit bit_b

slide-34
SLIDE 34
  • L09. Memory-2

CENG4480

*Twisted Bitlines

  • Sense amplifiers also amplify noise

– Coupling noise is severe in modern processes – Try to couple equally onto bit and bit_b – Done by twisting bitlines 34

b0 b0_b b1 b1_b b2 b2_b b3 b3_b

slide-35
SLIDE 35
  • L09. Memory-2

CENG4480

*SRAM Column Example

Read Write

35

H H SRAM Cell word_q1 bit_v1f bit_b_v1f

  • ut_v1r
  • ut_b_v1r

φ1 φ2 word_q1 bit_v1f

  • ut_v1r

φ2 More Cells Bitline Conditioning

φ2 More Cells SRAM Cell word_q1 bit_v1f bit_b_v1f data_s1 write_q1 Bitline Conditioning

slide-36
SLIDE 36
  • L09. Memory-2

CENG4480

*Column Multiplexing

  • Recall that array may be folded for good aspect ratio
  • Ex: 2 kword x 16 folded into 256 rows x 128 columns

– Must select 16 output bits from the 128

columns

– Requires 16 8:1 column multiplexers

36

slide-37
SLIDE 37
  • L09. Memory-2

CENG4480

*Ex: 2-way Muxed SRAM

37

More Cells word_q1 write0_q1 φ2 More Cells A0 A0 φ2 data_v1 write1_q1

slide-38
SLIDE 38
  • L09. Memory-2

CENG4480

*Tree Decoder Mux

  • Column mux can use pass transistors

– Use nMOS only, precharge outputs

  • One design is to use k series transistors for 2k:1 mux

– No external decoder logic needed 38

B0 B1 B2 B3 B4 B5 B6 B7 B0 B1 B2 B3 B4 B5 B6 B7 A0 A0 A1 A1 A2 A2 Y Y to sense amps and write circuits

slide-39
SLIDE 39
  • L09. Memory-2

CENG4480

*SRAM from ARM

39

slide-40
SLIDE 40
  • L09. Memory-2

CENG4480

*Sense Amp Operation for 1T DRAM

  • 1T DRAM read is destructive
  • Read and refresh for 1T DRAM

40

slide-41
SLIDE 41
  • L09. Memory-2

CENG4480

*Sense Amplifiers (DRAM)

  • Bitlines have many cells attached

– Ex: 32-kbit SRAM has 256 rows x 128 cols – 256 cells on each bitline

  • tpd ∝ (C/I) ΔV

– Even with shared diffusion contacts, 64C of diffusion

capacitance (big C)

– Discharged slowly through small transistors (small I)

  • Sense amplifiers are triggered on small voltage swing

(reduce ΔV)

41

slide-42
SLIDE 42
  • L09. Memory-2

CENG4480

*Differential Pair Amp

  • Differential pair requires no clock
  • But always dissipates static power

42

bit bit_b sense_b sense N1 N2 N3 P1 P2

slide-43
SLIDE 43
  • L09. Memory-2

CENG4480

*Clocked Sense Amp

  • Clocked sense amp saves power
  • Requires sense_clk after enough bitline swing
  • Isolation transistors cut off large bitline capacitance

43

bit_b bit sense sense_b sense_clk isolation transistors regenerative feedback

slide-44
SLIDE 44
  • L09. Memory-2

CENG4480

Thank You :-)

44
