ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment ANALYSIS OF DIFFERENT URBAN SPACES ON THERMAL COMFORT IN COLD REGIONS: A CASE FROM ERZURUM/TURKEY Mehmet Akif IRMAK, Sevgi YILMAZ, Emral MUTLU, Hasan

slide-1
SLIDE 1

ANALYSIS OF DIFFERENT URBAN SPACES ON THERMAL COMFORT IN COLD REGIONS: A CASE FROM ERZURUM/TURKEY

Mehmet Akif IRMAK, Sevgi YILMAZ, Emral MUTLU, Hasan YILMAZ

Ataturk University, Faculty of Architecture and Design, Department of Landscape Architecture, 25240 Erzurum, Turkey

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-2
SLIDE 2

Sevgi YILMAZ

  • Prof. Dr.

Ataturk Univ., Architecture and Design, Dept. of Landscape Architecture, 25240, Erzurum/ Turkey sevgiy@atauni.edu.tr; syilmaz_68@hotmail.com

Mehmet Akif IRMAK

  • Assoc. Prof. Dr.

Ataturk Univ., Architecture and Design, Dept. of Landscape Architecture, 25240, Erzurum/ Turkey mairmak@atauni.edu.tr

OUR TEAM

Hasan YILMAZ

  • Prof. Dr.
  • Dept. of Landscape Architecture,

Architecture and Design Fac., Ataturk University Erzurum, TURKEY hyilmaz@atauni.edu.tr

Emral MUTLU

  • Res. Ass. Emral MUTLU
  • Dept. of Landscape Architecture, Architecture

and Design Fac., Ataturk University Erzurum, TURKEY emral.mutlu@atauni.edu.tr

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-3
SLIDE 3

Along with the increase in urban areas across the globe, studies in the field

  • f

climatic comfort improvement have also increased. In particular, efforts to reduce urban heat island have been great in number. Also, studies

  • n

providing thermal comfort in urban areas have garnered attention.

3

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-4
SLIDE 4

The aim of this study within its scope was to evaluate the effects of ➢ Green areas ➢ Seasonal wetlands ➢ City center

  • n microclimate and on the thermal comfort

in the spring and summer periods.

ANALYSIS OF DIFFERENT URBAN SPACES ON THERMAL COMFORT IN COLD REGIONS: A CASE FROM ERZURUM

4

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-5
SLIDE 5

Urban green spaces contribute to the city's microclimate with wind control, shading, reflection, and transpiration while contributing to the balancing of temperature in winters as well.

ANALYSIS OF DIFFERENT URBAN SPACES ON THERMAL COMFORT IN COLD REGIONS: A CASE FROM ERZURUM

5

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-6
SLIDE 6

The effects

  • f

wetlands

  • n

urban microclimate are generally evapotranspiration and heat storage characteristics. Big bodies

  • f

water can slow down temperature changes by absorbing the excess heat, and wetlands, therefore, can control the climate around them.

ANALYSIS OF DIFFERENT URBAN SPACES ON THERMAL COMFORT IN COLD REGIONS: A CASE FROM ERZURUM

6

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-7
SLIDE 7

Urban areas has big effects on urban climate by producing extra heat with their built areas, paved surfaces, dense population, lack of green areas etc. Also, built environment in the city center absorb sunlight and keep them to long time and contribute urban heat island.

ANALYSIS OF DIFFERENT URBAN SPACES ON THERMAL COMFORT IN COLD REGIONS: A CASE FROM ERZURUM 7

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-8
SLIDE 8

This study was conducted in the city

  • f Erzurum in the

northeastern part of

  • Turkey. Erzurum is the

city which has ‘humid continental climate’ according to the most widely used Köppen climate classification systems.

ANALYSIS OF DIFFERENT URBAN SPACES ON THERMAL COMFORT IN COLD REGIONS: A CASE FROM ERZURUM

8

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-9
SLIDE 9

The city has also severe winters, warm summers, and strong seasonality. The prevailing weather conditions of the area change through the year. ➢ The mean annual air temperature is 5.6 °C, ➢ Annual rainfall is measured as 400 mm, ➢ It rains a lot between April and June, ➢ Dry periods are observed as 100–150 days in January, February, August, September, and December. ➢ The warmest month of the area is August, with an average temperature of 27.1 °C.

ANALYSIS OF DIFFERENT URBAN SPACES ON THERMAL COMFORT IN COLD REGIONS: A CASE FROM ERZURUM

9

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-10
SLIDE 10

➢ Winter conditions are prevailing for 5 months (in November, December, January, February, and March) with minimum temperatures between; -4.1 °C / -14.2 °C

➢ The coldest month is measured as January with an average temperature of − 9.3 °C ➢ The prevalent wind direction is southwest with a mean annual speed of 2.7 m/s, and the annual sunshine duration is 2500 h ➢ The city is built at an altitude of 1900 m and has the population of about 500,000.

ANALYSIS OF DIFFERENT URBAN SPACES ON THERMAL COMFORT IN COLD REGIONS: A CASE FROM ERZURUM

10

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-11
SLIDE 11

As the development of winter tourism, the city sprawled toward the Palandoken Skiing Center adjacent to it. Both in the old part of the city, (which contains the historical texture) and in the new settlement areas, there is lack of water-based landscapes and massive green spaces.

ANALYSIS OF DIFFERENT URBAN SPACES ON THERMAL COMFORT IN COLD REGIONS: A CASE FROM ERZURUM

11

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-12
SLIDE 12

ANALYSIS OF DIFFERENT URBAN SPACES ON THERMAL COMFORT IN COLD REGIONS: A CASE FROM ERZURUM

12

The city of Erzurum and case areas: Ata Botanical Park (Station 1), Seasonal Wetland (Station 2), Erzurum City Center (Station 3).

slide-13
SLIDE 13

13

May, 2016; images from the station's installation phase Green Area Seasonal Wetland City Center

slide-14
SLIDE 14

With the help of these weather stations, hourly measurements were taken in March and April (when the wetlands are active) and in the warmest months for the city, July and August. The data taken in 2017 consists of: ➢ hourly mean temperature (°C) ➢ hourly mean relative humidity (%) ➢ hourly mean wind (m/sec) ➢ hourly mean cloudiness

ANALYSIS OF DIFFERENT URBAN SPACES ON THERMAL COMFORT IN COLD REGIONS: A CASE FROM ERZURUM

14

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-15
SLIDE 15

PET (physiological equivalent temperature) values were calculated by using Rayman Software with the climate data obtained from these three meteorological stations. PET was introduced by Höppe and Mayer. PET is defined as the physiological equivalent temperature at any given place and is equivalent to the air temperature at which, in a typical indoor setting, the heat balance of the human body is maintained with core and skin temperatures equal to those under the conditions being assessed.

ANALYSIS OF DIFFERENT URBAN SPACES ON THERMAL COMFORT IN COLD REGIONS: A CASE FROM ERZURUM

15

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-16
SLIDE 16

PET are climate conditions under which

  • ne

adapts to the environment using minimal energy, feeling extremely healthy and dynamic. The PET index is an index derived from the human heat energy equation. That is why the PET index is an ideal tool to calculate the bioclimatic comfort

  • f

people in different climates.

ANALYSIS OF DIFFERENT URBAN SPACES ON THERMAL COMFORT IN COLD REGIONS: A CASE FROM ERZURUM

16

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-17
SLIDE 17

17

RayMan Pro Interface

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-18
SLIDE 18

ANALYSIS OF DIFFERENT URBAN SPACES ON THERMAL COMFORT IN COLD REGIONS: A CASE FROM ERZURUM

18

PET is a universal index for characterising the thermal bioclimate. Standart subject for PET;

  • 35 years old
  • Male
  • 175 cm height
  • 75 kg weight
  • Wear a jacket

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-19
SLIDE 19

ANALYSIS OF DIFFERENT URBAN SPACES ON THERMAL COMFORT IN COLD REGIONS: A CASE FROM ERZURUM

19

PET (°C) Thermal perception Grade of physiological stress < 4 Very cold Extreme cold stress 4.1 – 8.0 Cold Strong cold stress 8.1 – 13.0 Cool Moderate cold stress 13.1 – 18.0 Slightly cool Slight cold stress 18.1 – 23.0 Comfortable No thermal stress 23.1 – 29.0 Slightly warm Slight heat stress 29.1 – 35.0 Warm Moderate heat stress 35.1 – 41.0 Hot Strong heat stress > 41.0 Very hot Extreme heat stress The thermal stress categories of the PET index (Matzarakis et al., 1999)

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-20
SLIDE 20

Ata Botanic Park, named Station 1 in the study which lies adjacent to the city center of Erzurum, was founded in 2006 and covers an area

  • f approximately 35

hectares.

ANALYSIS OF DIFFERENT URBAN SPACES ON THERMAL COMFORT IN COLD REGIONS: A CASE FROM ERZURUM

20

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-21
SLIDE 21

21

Green areas

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-22
SLIDE 22

22

Green areas

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-23
SLIDE 23

The Seasonal Wetland, named as Station 2. It is located in the northern part of the city center of

  • Erzurum. It is

approximately 14.000 hectares and being home to about 220 different types of bird. The area is filled completely with water in March and April. In summer, it becomes wet meadows.

ANALYSIS OF DIFFERENT URBAN SPACES ON THERMAL COMFORT IN COLD REGIONS: A CASE FROM ERZURUM

23

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-24
SLIDE 24

24

Seasonal Wetland

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-25
SLIDE 25

25

Seasonal Wetland

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-26
SLIDE 26

The city center of Erzurum (Station 3) is the third case study area. While it covered an area

  • f 10 km² in 1980s, it

sprawled in the following

  • period. Now, it nearly

covers an area of 36 km². The city center has highly dense historical buildings dating from The Seljuk and Ottoman periods.

ANALYSIS OF DIFFERENT URBAN SPACES ON THERMAL COMFORT IN COLD REGIONS: A CASE FROM ERZURUM

26

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-27
SLIDE 27

Adjacent buildings and narrow streets are the characteristics of physical environment in this area. They decrease the heat loss in hard and long winters.

ANALYSIS OF DIFFERENT URBAN SPACES ON THERMAL COMFORT IN COLD REGIONS: A CASE FROM ERZURUM

27

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-28
SLIDE 28

28

City Center

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-29
SLIDE 29

ANALYSIS OF DIFFERENT URBAN SPACES ON THERMAL COMFORT IN COLD REGIONS: A CASE FROM ERZURUM

29

AREAS March Mean Temperature (°C) April Mean Temperature (°C) July Mean Temperature (°C) August Mean Temperature (°C) Mean Temperature (°C) Dense Green Area

  • 0,2

5,8 20,2 20,2 11,5 Temporary Wetland Area 0,1 5,9 21,2 21,4 12,2 City Centre 1,2 6,7 23,1 23,6 13,7 Temperature Averages and Distributions From Work Stations For March-April and July- August

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-30
SLIDE 30

ANALYSIS OF DIFFERENT URBAN SPACES ON THERMAL COMFORT IN COLD REGIONS: A CASE FROM ERZURUM

30

  • 5

5 10 15 20 25 March Mean Temperature (°C) April Mean Temperature (°C) July Mean Temperature (°C) August Mean Temperature (°C) Mean Temperature (°C) Dense Green Area Temporary Wetland Area City Centre Mean Temperature (°C)

Temperature Averages and Distributions From Work Stations For March-April and July-August

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-31
SLIDE 31

ANALYSIS OF DIFFERENT URBAN SPACES ON THERMAL COMFORT IN COLD REGIONS: A CASE FROM ERZURUM

31

AREAS March Mean Relative Humidity (%) April Mean Relative Humidity (%) July Mean Relative Humidity (%) August Mean Relative Humidity (%) Mean Relative Humidity (%) Dense Green Area 77 66 52 49 61 Temporary Wetland Area 80 66 47 38 58 City Centre 71 60 39 33 51 Humidity Averages and Distributions From Workstations For March-April and July-August

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-32
SLIDE 32

ANALYSIS OF DIFFERENT URBAN SPACES ON THERMAL COMFORT IN COLD REGIONS: A CASE FROM ERZURUM

32

Humidity Level Distributions From Work Stations For March-April and July-August

10 20 30 40 50 60 70 80 90 March Mean Relative Humidity (%) April Mean Relative Humidity (%) July Mean Relative Humidity (%) August Mean Relative Humidity (%) Mean Relative Humidity (%) Dense Green Area Temporary Wetland Area City Centre Mean Relative Humidity (%)

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-33
SLIDE 33

ANALYSIS OF DIFFERENT URBAN SPACES ON THERMAL COMFORT IN COLD REGIONS: A CASE FROM ERZURUM

33

Wind Averages and Distributions From Work Stations For March-April and July-August AREAS March Mean Wind Welocity (m/s) April Mean Wind Welocity (m/s) July Mean Wind Welocity (m/s) August Mean Wind Welocity (m/s) Mean Wind Welocity (m/s) Dense Green Area 0,3 0,5 0,3 0,3 0,35

Temporary Wetland Area 3,1 2,3 2,1 2,2 2,43 City Centre 0,4 0,6 0,6 0,5 0,53

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-34
SLIDE 34

ANALYSIS OF DIFFERENT URBAN SPACES ON THERMAL COMFORT IN COLD REGIONS: A CASE FROM ERZURUM

34

Wind Level Distributions From Work Stations For March-April and July-August

0,5 1 1,5 2 2,5 3 3,5 March Mean Wind Welocity (m/s) April Mean Wind Welocity (m/s) July Mean Wind Welocity (m/s) August Mean Wind Welocity (m/s) Mean Wind Welocity (m/s) Dense Green Area Temporary Wetland Area City Centre Mean Wind Welocity (m/s)

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-35
SLIDE 35

ANALYSIS OF DIFFERENT URBAN SPACES ON THERMAL COMFORT IN COLD REGIONS: A CASE FROM ERZURUM

35

Cloudiness Averages From Work Stations For March-April and July-August March Mean Cloudiness (Octas) April Mean Cloudiness (Octas) July Mean Cloudiness (Octas) August Mean Cloudiness (Octas) Mean Cloudiness 4,4 4,7 1,6 2,8

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-36
SLIDE 36

ANALYSIS OF DIFFERENT URBAN SPACES ON THERMAL COMFORT IN COLD REGIONS: A CASE FROM ERZURUM

36

PET (Physiologically Equivalent Temperature) Averages and Distributions From Work Stations For March-April and July-August AREAS March Mean PET (°C) April Mean PET (°C) July Mean PET (°C) August Mean PET (°C) Mean PET (°C) Dense Green Area

  • 0,2

5,8 23,3 22,7 12,9 Temporary Wetland Area

  • 4,6

4,1 21,4 20,9 10,5 City Centre 0,4 6,5 24,7 25 14,2

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-37
SLIDE 37

ANALYSIS OF DIFFERENT URBAN SPACES ON THERMAL COMFORT IN COLD REGIONS: A CASE FROM ERZURUM

37

PET (Physiologically Equivalent Temperature) Levels Distributions From Work Stations For March-April and July-August

  • 10
  • 5

5 10 15 20 25 30 March Mean PET (°C) April Mean PET (°C) July Mean PET (°C) August Mean PET (°C) Mean PET (°C) Dense Green Area Temporary Wetland Area City Centre Mean PET (°C)

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-38
SLIDE 38

It can be seen that all three areas have extreme cold stress. This extreme conditions are dominant in March-April periods, while comfortable intervals are dominant in July and August periods. On the other hand, strong heat stress is felt intensely in summer period.

ANALYSIS OF DIFFERENT URBAN SPACES ON THERMAL COMFORT IN COLD REGIONS: A CASE FROM ERZURUM

38

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-39
SLIDE 39

0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100% 10 20 30 10 20 30 10 20 30 10 20 30 March April July August

Dense Green Area

0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100% 10 20 30 10 20 30 10 20 30 10 20 30 March April July August

Temporary Wetland Area

39 PET Levels Chronological Distributions From Work Stations of Dense Green Area, Seasonal Wetland Area and City Centre For 2017, March-April and July- August 0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100% 10 20 30 10 20 30 10 20 30 10 20 30 March April July August

City Centre

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

PET (°C) Thermal perception Grade of physiological stress < 4 Very cold Extreme cold stress 4.1 – 8.0 Cold Strong cold stress 8.1 – 13.0 Cool Moderate cold stress 13.1 – 18.0 Slightly cool Slight cold stress 18.1 – 23.0 Comfortable No thermal stress 23.1 – 29.0 Slightly warm Slight heat stress 29.1 – 35.0 Warm Moderate heat stress 35.1 – 41.0 Hot Strong heat stress > 41.0 Very hot Extreme heat stress

slide-40
SLIDE 40

After the measurements it has been found that the Dense Green Area has the lowest temperature values both in spring (2,8 °C) and summer period measurements (20,2°C). It has been observed that in green spaces humidity values reached the highest levels in the summer period measurements. But in spring time when the wetlands are active, it has been found that the humidity values of green areas are lower than wetland areas.

ANALYSIS OF DIFFERENT URBAN SPACES ON THERMAL COMFORT IN COLD REGIONS: A CASE FROM ERZURUM

40

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-41
SLIDE 41

When wind values are examined, it has been

  • bserved that the green spaces have lower

wind levels than the wetlands and the city center both in the spring (0,4 m/s) and in the summer (0,3 m/s). When the PET values are examined, the Dense Green Station, in which lower values are obtained in terms of temperature data, had 2,8°C value higher than that of Wetland Station and positive PET values.

ANALYSIS OF DIFFERENT URBAN SPACES ON THERMAL COMFORT IN COLD REGIONS: A CASE FROM ERZURUM

41

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-42
SLIDE 42

But, these values remained lower than those

  • f

the City Centre Station. Measurements made during the summer showed that the green station had PET values of 23.0°C , between the value of the Wetland Station (21.2°C) and of City Centre (24.9°C).

ANALYSIS OF DIFFERENT URBAN SPACES ON THERMAL COMFORT IN COLD REGIONS: A CASE FROM ERZURUM

42

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-43
SLIDE 43

In the light of all the data obtained during the study, it has been

  • bserved

that wetlands affect the PET values negatively in cold climate, but during hot summer periods, this turns into an advantage by affecting the PET values positively. The warmer urban areas, forming an urban heat island due to the solid surfaces they contain, affected the PET values positively in cold periods. However, this situation has changed in the hot summer period as negative and temperature may cause stress.

ANALYSIS OF DIFFERENT URBAN SPACES ON THERMAL COMFORT IN COLD REGIONS: A CASE FROM ERZURUM

43

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-44
SLIDE 44

As a result of this study, it is seen that the balancing and regulatory effect of green areas in especially hot periods are important. This effect is created by ecological activities such as shading, mirroring, humidity by

  • transpiration. All these activities yielded quite

positive results in summer periods. In addition to summer season, the green areas had positive effects PET values in cold season due to the low winds and the temperature kept on the surface of the trees.

ANALYSIS OF DIFFERENT URBAN SPACES ON THERMAL COMFORT IN COLD REGIONS: A CASE FROM ERZURUM

44

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment

slide-45
SLIDE 45

ANALYSIS OF DIFFERENT URBAN SPACES ON THERMAL COMFORT IN COLD REGIONS: A CASE FROM ERZURUM

45

ICUC 10 10th International Conference on Urban Climate/14th Symposium on the Urban Environment
