Carnatic Sustainable Housing Village

Design Presentation - Masterplan Estate Strategy

Student ID: 201273699

View of the scheme’s key community open space: The Campiello

The site location & its relation with the green infrastructure network

The Green Web strategy plan

The Strategic Green and Open Spaces Review Board Report from 2016 identifies the ‘‘Green Web’’, a network

• f green corridors that covers large areas of the city and links them.

The analysis convers three layers of information collected. The strategic position of the site can allow to re- establish immediate connection with the river and it can help extend the green corridors network as a future long term plan. Making the site a public green area will contribute to create a higher quality and more attractive environment for the local communities to enjoy.

Key issues in Mossley Hill area

Low number of key community gathering centres marks further social isolation across Mossley Hill Key centres causing traffic congestion due to their location along the outskirt of Mossley Hill perimeter The site strategic and central location is the most affected by traffic congestion as it is located on secondary roads

Reference: Number of residents accomodated in high density terraced houses adjacent to the site, which were taken into consideration.

Analysed area: 5625 sq.m Average number

• f residents:

204 users

Density in Mossley Hill area The Brief

Selected site area for housing development Datas In housing schemes, the Planning Standards and Guidelines for Open Space and Recreational Area have clearly stated that at least 10 percent of the developed area should be allocated for the provision of open spaces. Considering that 1 hectare should accomodate a maximum number

• f 500 habitants.

Chosen site area 13000 sqm Housing scheme typology High density Estimated number of residents 198 users Developable area 85% 11050 sqm Open space area 10% 1300 sqm Shared community facilities 5% 650 sqm

LOW DENSITY MANSIONS MEDIUM DENSITY DE-TACHED HOUSES HIGH DENSITY TERRACED HOUSES

The site urban context: A patchwork of distinct & enclosed neighbourhoods

The derelict state of the existing buildings on site

8 7 5 4 3 1 2 6

1 2 3 4 6 5 7 8

To be retained for future Community Centre To be demolished

The design ambition: Conceptual mapping

THE CAMPO Retained building Community Centre with flexible use spaces

to supplment the church’s community activities and amplify them

Mid - rise + Mixed use housing

this part of the site is the most exposed and trafficated, therefore it rapresents the most suitable to introduce this type of programme with small shops at ground floor.

Main public green area

to achieve social cohesion and collectivity across the whole urban context, especially between the current isolated suburbs surrounding the site.

Low - rise + Residential housing (Garden Village)

to match urban context

S t . M a t t h e w a n d S t . J a m e s C h u r c h Scale: 1:1000 on A2 LEGEND 1 2 ELMSWOOD ROAD

Pedestrian access Existing boundary walls to be retained

Masterplan : Zoning strategy

Masterplan zoning strategy for the whole site

Selected area for development

1:2000 SCALE

CURRENT ROUTING PROPOSED PRIMARY ROUTING - IMPROVED CONNECTIVITY

Primary Vehicular routes Primary Vehicular routes Secondary Vehicular routes Secondary Vehicular routes Retained Sandstone Boundary walls Existing Sandstone Boundary walls

Carnatic Dining Hall New Community Centre

• St. Matthew’s

&

• St. James

Church

Design aim: Improved connectivity & walkability within the urban context

Using the site’s strategic & central location to improve the routing within the area

1960, Manchester 1966, Manchester 1925, London 1950, Leicester 1935, Camberwell 1940, Conventry

The design goal: Re-establish the community identity

Paved car free open communal spaces

THE CAMPO, THE HEART OF THE DISTRICT THE CAMPIELLO, THE HEART OF EACH NEIGHBOURHOOD

THE SITE THE SITE VENICE VENICE THE CAMPO, 1960 THE CAMPIELLO, 1960

VENICE’S URBAN CONDITION: THE CAMPO & CAMPIELLO PUBLIC DOMESTICITY

CAMPO CAMPIELLO

CAMPO: The name derives from the fact that in ancient times these spaces were real meadows for grazing or cultivated as a vegetable garden. Later in the years, the fields were

• paved. The campo was the Venetians’ social epicentre for several activities such as commercial markets, playgrounds and community gathering events like religious cerimonies

CAMPIELLO: A smaller version of a Campo. It often possess a well located in the centre as the main source of the city’s water supply, through the filtering of rainwater. The campiello defines a micro-community neighbour which stimulates interaction and intimacy among the residents.

The Campo & The Campiello (paved & unpaved community open spaces)

Precedent Study: The Venetian urban condition & community identity

Studies of the Campiello layout to generate high quality open community spaces

Circulation and built environment

I have analysed the typical Dutch Canal housing as it was developed in the 18th century and still remains intact, thanks to the hierarchy that establishes between private, semi-public units access and public paths & traffic. It is intriguing how it deals very carefully with privacy and defines a clear distinction between public and private. The stairs are part of the dwelling but also become a communal semi-public space. Therefore, they can be introduced into the scheme’s design. The main feature of this type of housing provides the access entrance through an elevated ground floor, the souterrain/basement is reachable from the street level and the unit possess flexible open plan layout.

Semi underground Cellar plan (Elevated) Ground floor plan First floor plan The typical Dutch canal house

Precedent study: From public to private & street interface

View of the living areas from the Master Bedroom View from the kitchen Apartment Floor Plan The use of bright colours creates a patterning of spaces that balance and define the differents spaces in the open plan layout whilst providing freeedom to the user to re arrange the spaces based on future needs. Flexible spaces for the users: how to divide the units without using traditional partitions

Precedent study: Open plan layout

Project name: Vivid Colours Architect: Waterfrom Design Area: 100 sq. m Year: 2016 Location: Taiwan

09.00 am - February 12.30 pm - March 04.00 pm - September

Strongest and weakest areas

Natural lighting conditions studies on site development area

The study demonstrates that North/South aligned blocks can benefit more from daylight coming from East and West. The blocks open up in circle towards South in order to create green courtyards that profit from Southern daylight. . The scheme’s aim is to build around the existing landscape to avoid any damage to it and it can be built on the existing buildings footprint in order to maximise daylight use. Since the trees vary in heights, types and are mutable with aging, they cause

• vershading in particular areas which are not ideal

to build on. Secondly, in order to preserve the existing woodland, the design is intended to touch the ground lightly. Therefore, a great opportunity is to build on the existing buildings’ footprint and to use green roofs in order to give back to the site the footprint which has been taken off. Thanks to the study below it has been possible to identify the strongest and weakest points of the selected buildable area, in order to plan better the buildings’ position, orientation and seasonal vegetable gardens locations to maximise daylight use. Areas which profit the most from natural daylight Areas most affected by stark shadows

Current buildings’ footprint & selected site area for development

BUILDINGS ORIENTATION: 45 DEGREES - 70% solar gain (BEST OPTION)

• 1. Evening sun to be avoided as it can cause glare and overheating during

summer time. But ventilation needs to be maximised as prevaling winds come from West.

• 2. Mid-day Sun entry is maximised as it is the strongest during winter times.

Solar shading devices needed against direct summer sun.

• 3. Morning sun maximised as it offers pleasant teperature during summer but

it is cold during winter. BUILDINGS ORIENTATION: 90 DEGREES - 50% solar gain

• 1. Morning sun can enter it offers pleasant teperature during summer but it is

cold during winter as it arises late.

• 2. The most advantageous mid-day Sun entry is blocked as the units are

arranged in line.

• 3. Elevation exposed to evening sun which provides high temperatures during

summer time and can cause overheating.

Maximised solar orientation of the units Define a hierarchy of spaces

Central semi-public communal open space in plan Distinct appearance can define different ownership of spaces, whist community collectivity is being kept thanks to the visual relation with the common central

• pen space

The dwelling’s back garden acts as a transition space between private & semi-public space Visual connection to be kept between the semi-private unit garden & the common open space Change of levels at the front of the units can ensure privacy whilst define distinction between public and private

Private Semi- Private Semi- Public

Orientation studies to maximise daylight use

OPTION 1 - 90 Degrees North/South units OPTION 2 - 45 Degrees angled units 17:00 pm - March 17:00 pm - March 09:00 am - March 09:00 am - March 13:00 pm - March 13:00 pm - March

The model testing demonstrates that a layout that proposes North/South aligned blocks with 45 degrees angled orientated units can help maximise the daylight use in the buildings. The blocks are supposed to profit from West and East sunlight, instead they just profit from Southern sun and overshade on each

• ther’s. Careful considerations should be made on choosing the right distance between the blocks in order to avoid this.

Masterplan proposal in context

Retained Building New community centre 1:700 SCALE 5m 10m 20m

The scheme concept

Design in response to the landscape & tree preservation Building following the existing blocks’ footprint 45 Degrees angled dwellings orientation to maximise solar entry Communal community open spaces to anable social interaction: The Campiello & the seasonal vegetable gardens Routing & walkability

Primary routes Secondary routes

The Campiello Community Allotments Community Allotments

Transparency & views

The scheme lighting conditions

09:30 am - February 13:30 pm - July 11:00 am - March 14:00 pm - September 11:10 pm - April 15:00 pm - October 13:00 pm - June 13:00 pm - December

Following the existing buildings’ footprint and predominantely using North/South aligned blocks with 45 degrees angled units towards South, the scheme allows all buildings to profit from daylight, views and communal open community spaces. The landscape and trees are totally preserved, not damaged and the existing open green spaces can become cultivable seasonal farming as they profit from daylight all day.

Housing Typologies & Accomodation schedule

92 DWELLINGS 54 19 19 64 sq. m 102 sq. m 153 sq. m TYPE 1 TYPE 2 TYPE 3 56 BUILDINGS 202 ESTIMATED INHABITANTS TYPOLOGY DISTRIBUTION TARGET GROUPS

YOUNG COUPLES YOUNG FAMILY ELDERLY TRADITIONAL FAMILY LONE PARENT/ YOUNG PROFESSIONAL DIFFERENTLY ABLE

LEGEND

TYPE 01 TYPE 02 TYPE 03

Floor plans per typology

1:100 SCALE

PROSPECTIVE USERS

LONE PARENT/ YOUNG PROFESSIONAL DIFFERENTLY ABLE ELDERLY

YOUNG COUPLES YOUNG FAMILY

Floor plans per typology

• PROSPECTIVE USERS

1:100 SCALE

Floor plans per typology

PROSPECTIVE USERS

TRADITIONAL FAMILY

• 1:100 SCALE

Environmental strategy: Passive Houses

1:50 SCALE

1 Light shelf to reflect daylight deep into the unit. Main windows apartures facing the prevaling wind direction whilst placed at opposite pressure zones to allow warm air to escape and cool air to enter. Extensive green roof to provide passive cooling. Low maintance needed as it will use sedum plant species which can resist to very hot summers and can maintain itself. Roof overhang to provide solar shading during summer.

Windows placed on opposite walls to stimulate cross-ventilation.

2 3 4

HOT AIR RISES SUMMER SUN Prevaling Wind Direction Indirect sunlight direct sunlight WINTER SUN

LEGEND 1. 2. 3. 4.

Hemp Fiber - Batt Insulation

• it is a sustainable innovative bio material
• high Insulation performance values
• it possess great thermal mass proprieties.
• it allows air exchange and allows the

building to ‘‘breathe’’, avoiding capturing moisture.

• it absorbs CO2 and generates better air

quality. Natural Slate - Roofing

• it can be locally sourced and lower carbon

emissions.

• it is durable.
• It is sustainable and natural.
• it is fire resistant and can resist to extreme

temperatures by also

• ffering

waterproofing. Vertical Timber Cladding

• it blends well with the contextual site’s

woodland.

• it is sustainable and recyclable.

Natural VOC Free Paint

• It is plant based and it can contribute

to higher indoor air quality as it does not release any toxic substances when in contact with moisture. STRUCTURAL MATERIALS EXTERNAL FINISH INTERNAL FINISH Lightweight Timber structure

• Chosen for its lightweight to speed u

construction process.

• It is demountable and recyclable.

Low impact bio breathable building materials palette

Exploded view: Temporary demountable structural strategy

1:200 SCALE

Wall construction Timber lightweight studs structure with hemp insulation, OSB board and Waterproofing layer. Horizontal timber cladding screwed to pre-treated vertical and horizontal timber battens to create a ventilated air cavity behind the cladding system. Fiber cement board on façade to be screwed on vertical battens and cover the blockwork. Floor construction Steel screw foundation piles have been chosen to avoid the foundations to remain permanently in the ground. This system allows the structure to be totally demoutable as the screw piles can later be unscrewed, if needed. Perimetric blockwork to sit on top of the supporting steel grade beams grid in contact with the ground, to create a ventilated void. Suspended floor system (Floor joists with hemp insulation) to sit on top of blockwork via a floor plate. This will be followed by the OSB board, vapour control layer and finished interior flooring. From an exploration of bio materials, the construcion system is intended to be 100% diassamblable and recyclable

Aerial view of the scheme from North West - The Western Community allotment

Site North/South section A - Proposed development in context

Carnatic Road Elmswood Road A Retained Dining Hall New Community Centre 1:700 SCALE 5m 10m 20m

1:200 SCALE

Site East/West section B - looking from Carnatic Road

B

Elevation A Elevation A

Detailed site Plan of the Campiello

1:200 SCALE

Typical Internal view of the units
