Caltrain Electrification Update Palo Alto ARB/HRB January 10, 2019 Project Description Area Project Service 51 miles Electrification: Up to 79 mph Overhead Contact Service Increase San Francisco System (OCS) 6 trains / hour

slide-1
SLIDE 1

Caltrain Electrification Update

Palo Alto ARB/HRB January 10, 2019

slide-2
SLIDE 2

Project Description

Area Project Service 51 miles San Francisco to San Jose (Tamien Station) Electrification:

  • Overhead Contact

System (OCS)

  • Traction Power

Facilities

Electric Trains

  • 75 percent of fleet

Up to 79 mph Service Increase

  • 6 trains / hour / direction
  • More station stops / reduced travel

time

  • Restore Atherton & Broadway

service

Mixed-fleet service (interim period) Continue tenant service

  • ACE, Capital Corridor, Amtrak,

Freight

slide-3
SLIDE 3

Schedule

slide-4
SLIDE 4

Palo Alto Station

Photo simulation from east platform facing north.

slide-5
SLIDE 5

Palo Alto Station

Photo simulation from west platform facing south

slide-6
SLIDE 6

Center Poles Typical

Pole heights range from 30-45.5’

slide-7
SLIDE 7

Side Poles at Platform Typical

Pole heights range from 30-45.5’

slide-8
SLIDE 8

Palo Alto Station

65% Design Drawings. Subject to change.

slide-9
SLIDE 9

Palo Alto Station

65% Design Drawings. Subject to change.

slide-10
SLIDE 10

Palo Alto Station Pole Color Recommendation

  • Seeking ARB/HRB recommendation on

Station Area Pole Color

slide-11
SLIDE 11

Stanford Station

Photo simulation from Alma Street facing north

slide-12
SLIDE 12

Side Poles at Platform Typical

Pole heights range from 30-45.5’

slide-13
SLIDE 13

Stanford Station

65% Design Drawings. Subject to change.

slide-14
SLIDE 14

Stanford Station

65% Design Drawings. Subject to change.

slide-15
SLIDE 15

Stanford Station Pole Color Recommendation

  • Seeking ARB/HRB recommendation on

Station Area Pole Color

slide-16
SLIDE 16

California Avenue Station

Photo simulation from west platform facing south

slide-17
SLIDE 17

Side Poles at Platform Typical

Pole heights range from 30-45.5’

slide-18
SLIDE 18

California Avenue Station

65% Design Drawings. Subject to change.

slide-19
SLIDE 19

California Avenue Station

65% Design Drawings. Subject to change.

slide-20
SLIDE 20

California Avenue Pole Color Recommendation

  • Seeking ARB/HRB recommendation on

Station Area Pole Color

slide-21
SLIDE 21

Additional Pole Types

Two Track Cantilever Portals

Note: Poles outside station areas will be painted Marine Green in Palo Alto

slide-22
SLIDE 22

Traction Power Facilities

  • 10 Traction Power Facilities Installed throughout

Corridor

– 1 Paralleling Station installed in Palo Alto

  • Facility Components

– Transformer – Gantries (up to 50’) – Control House

  • Provides electrical power to trains through the

Overhead Contact System

  • Unmanned, secure, lighted facility
slide-23
SLIDE 23

Paralleling Station 5

  • Located south of Page Mill Road on Caltrain

Property

– Coordination with City on location during EIR

  • Vegetation Screening will be implemented with

review and input from City Staff

  • Control House Color to be selected by City
slide-24
SLIDE 24

Paralleling Station 5 Location

Gantries Transformer Control House

Based on 35% Drawings. Subject to Change.

slide-25
SLIDE 25

Example Parallelling Stations

Examples from Amtrak Northeast Corridor

Control House Transformer Gantries

slide-26
SLIDE 26

Transformer Example

slide-27
SLIDE 27

PS-5 Control House Color Recommendations

  • Seeking ARB/HRB recommendation on

Control House Color

slide-28
SLIDE 28
slide-29
SLIDE 29

Aesthetics Mitigation Measures

  • AES-2b Goal: Help soften visual intrusion of project

elements upon landscape, especially in areas of high use

– Poles:

  • Coordinate with local jurisdiction on poles within station areas
  • No unpainted metal surfaces

– Traction Power Facilities:

  • Coordinate with local jurisdiction on control house color and

vegetation screening at sensitive TPF sites

  • Features to be colored or painted two to three shades darker

than general surrounding area

  • Light or bright colors will be avoided
slide-30
SLIDE 30

Wide Flange Detail

slide-31
SLIDE 31

Taper Tubular Detail

slide-32
SLIDE 32

Two Track Detail

slide-33
SLIDE 33

Additional Pole Types

slide-34
SLIDE 34

Poles Types

TT = Taper Tubular WF = Wide Flange SQ = Square

slide-35
SLIDE 35

Single Side Poles

slide-36
SLIDE 36

Center Poles at Station

Center Taper Tubular Poles at Palo Alto Station
