CALGreen CALGreen A brief introduction to the California Green - - PowerPoint PPT Presentation

CALGreen CALGreen

A brief introduction to the California Green Building Code

Presented by: Stuart Tom, P.E., CBO To: Pasadena & Foothill Chapter, AIA

The Pasadena & Foothill Chapter of the AIA is a Registered Provider with the American Institute of Architects Continuing Education Systems. Credit earned on completion of this program will be reported to CES Records for AIA Members. Certificates of Completion for non‐AIA Members are available on request Certificates of Completion for non‐AIA Members are available on request. This program is registered with the AIA/CES for continuing professional

• education. As such, it does not include content that may be deemed or construed

to be an approval or an endorsement by the AIA of any material of construction

• r any method or manner of handling, using, distributing, or dealing in any

material or product . Questions related to specific materials, methods and services will be addressed at the conclusion of the presentation.

August First Friday Forum August First Friday Forum

CAL-Green: A brief introduction to California’s Green Building Code

Learning Objectives:

The following points are identified as Learning Objectives for CES Credit, and are th i th t ill b d i t d ’ t ti among the issues that will be covered in today’s presentation.



The members will be introduced to the new CAL-Green sustainable standards that will take effect throughout California on January 1, 2011



The members will learn the format of the new code



The members will review the way they can identify which part of the code will apply to residential projects versus non-residential



The members will learn about the enforcement of the “Minimum Mandatory Standards” throughout California as well as the potential local additional “Tier 1” and “Tier 2” standards in various communities

CALGreen

Wh i CALG ?

 What … is CALGreen ?  When … was it adopted ?  Who … adopted it ?  When … does it take effect ?  Where … will it be enforced?  What … are the standards that will apply ?  What … are the standards that will apply ?  Who … will enforce it ?  What impact will it have on me ??  What impact will it have on me ??

CALGreen

 CALGreen is the first and only state-wide green

building code in the nation.

D l d ifi ll f C lif i t dd t i bl



Developed specifically for California, to address sustainable construction practices that are of local significance.



Several years in development, with balanced input from: y p , p



Regulatory Agencies (HCD, DWR, Dept. of Public Health, etc.)



Environmental Groups (Sierra Club, etc.)



Ind str (BIA etc )



Industry (BIA, etc.)



Sustainable Development Advocates (USGBC, Build-It-Green, etc.)



Local Government



California Energy Commission

CALGreen

 CALGreen is a code, not a rating system.

 Part of Title-24 of the California Code of

Regulations (C.C.R.)

CA Administrative Code CA Energy Code CA Building Code CA State Historical Building Code CA Residential Code CA Fire Code CA Electrical Code CA Existing Building Code CA Electrical Code CA Existing Building Code CA Mechanical Code CA Green Building Code CA Plumbing Code CA Reference Standards Code

112 l t 112 years later

CALGreen on-line

 www.bsc.ca.gov/CALGreen



2010 (Draft) is available on-line (.pdf format) E t



Errata



Minor editorial/clean-up



Minor changes to Appendix 5



Education & Outreach



Full copy of the July 2010 CBSC-HCD informational seminar is available on-line available on-line  www.iccsafe.org



Available for purchase



Available for purchase

Why do we need a “Green Code”

R i lik LEED d G P i h

 Rating systems like LEED and Green-Point have

been around for years, so why does California need CALGreen? CALGreen?



Voluntary rating systems do not apply to all new projects, and all jurisdictions do not require such programs. C lif i i th d t t ti ll d



California recognizes the need to systematically reduce non-sustainable building construction practices, and use

• f mandatory code compliance will help achieve that

bj ti

• bjective.



Greenhouse gas emissions, energy use, and potable water consumption need to be reduced.

Code vs. Rating System

 A “Code” establishes a minimum standard that has

been deemed desirable for an entire community. Every individual subject to the code must meet the Every individual subject to the code must meet the established standards in order to pass.

 Codes can be “prescriptive based” “performance  Codes can be prescriptive-based , performance-

based”, or both.

 Prescriptive requirements ensure that desirable goals  Prescriptive requirements ensure that desirable goals

are always met, while performance standards allow flexibility in meeting over-all objectives. y g j

Code vs. Rating System

 A “Rating System” is intended to allow a

relative comparison between similar products.

 Rating systems generally award “points” or

“credits” in a manner that will allow a relative ranking of achievement.

 Rating systems can be successful tools in  Rating systems can be successful tools in

fostering competitions among motivated participants. participants.

Code vs. Rating System

C d ll h b bli h

 Codes are generally the best way to establish

compliance with rules.

F ili l

 Familiar examples:

Municipal Code Vehicle Code Health Code Building Code Housing Code Etc.

 Rating systems are generally the best way to

allow for a comparison of similar products.

 Familiar examples:

Credit Rating CPU Speed Index Wine Spectator Score Vehicle Safety Restaurant Cleanliness Etc Vehicle Safety Restaurant Cleanliness Etc.

Purpose



The primar p rpose of CALGreen is to impro e p blic



The primary purpose of CALGreen is to improve public health, safety and general welfare by enhancing the design and construction of buildings through the use of building concepts having a reduced negative impact or positive concepts having a reduced negative impact, or positive environmental impact and encouraging sustainable construction practices in the following categories:



Planning and design. g g



Energy efficiency.



Water efficiency and conservation.



Material conservation and resource efficiency.



Environmental quality.



It is not the intent that CALGreen substitute or be identified as meeting the certification requirements of any green b ildi building program.

Systematic & Comprehensive y p Adoption of CALGreen

 O i i

ll d t d i A t 2009

 Originally adopted in August 2009



No additional mandatory standards beyond existing code requirements.



All other provisions were 100% voluntary.



Considered the first step towards a comprehensive code.

 “CALGreen” adopted on January 12, 2010 

CALGreen adopted on January 12, 2010



California Building Standards Commission



Applicability to state-owned facilities July 1, 2010 A li bilit t ll f iliti J 1 2011



Applicability to all facilities January 1, 2011



Newly constructed facilities submitted for plan check on or after January 1, 2011, except for apartments, hotels, condominiums 4- stories and greater in height. g g



Does not apply to additions, alterations, remodel, or T.I. work, unless a local amendment applies.

Local Adoption



Most local j risdictions that do not ha e an e isting ell



Most local jurisdictions that do not have an existing, well- established green building program appear to be “leaning” toward a basic adoption of the CALGreen minimum mandatory standards mandatory standards.



As CALGreen raises the awareness of sustainable construction benefits throughout the state, designers, builders, and code enforcement officials will gradually become more and code enforcement officials will gradually become more competent and comfortable applying the new standards.



Local jurisdictions that have effective existing programs in place will be able to maintain their higher standards, while p g , the rest of California gradually “catches up”.



As California continues to enhance CALGreen through its systematic & comprehensive 3-year code adoption process, y p y p p , all of California will move in a convergent direction toward an increasingly more sustainable code.

Local Adoption

 California Health and Safety Code 17958 & 18938



Local adoption within 180-days of publication. M d th d if bl j tifi d th b i f



May amend the code if reasonably justified on the basis of a local geologic, topographic, or climatic condition.



Local amendment may not be less protective than the y p minimum state standard.



Justifications for local amendment must be filed with the C lif i B ildi S d d C i i i California Building Standards Commission prior to enforcement.

Code Adoption Timeline

Effective Date

 On January 1, 2011, CALGreen will take effect.  If local amendments are adopted, such amendments

ill k ff h i id d l l will take effect at the same time, provided local adoption is completed sufficiently prior to the effective date effective date.

 If local adoption is delayed, any specific local

amendments may not be legally enforced until local amendments may not be legally enforced until local adoption is completed and the amendments & justifications are filed with the CBSC. j

Who Will Enforce CALGreen?

 CALGreen will be enforced for private

development by local Building Departments.

 CALGreen will be enforced for state-facilities

by the appropriate state agencies.

 Hospitals – OSHPD  Public Schools – DSA  Mixed Authority – combination of state agency

and municipal agency involvement p g y

What are the Standards?



There are three (3) parts to CALGreen



There are three (3) parts to CALGreen



Minimum Mandatory Standards



Tier 1



Tier 2



Tier 2



Tier 1 & Tier 2 are not mandatory, unless they are locally adopted by the jurisdiction



How are the minimum standards and the tiers expected to fit



How are the minimum standards and the tiers expected to fit in with other California Codes?



California has a continuous 3-year code development process which results in ever-improving minimum standards p g



CALGreen construction standards will gradually be absorbed/incorporated into other parts of Title-24, thereby resulting in “greener” building codes



Example: The evolution of water closet flush volumes



Example: The evolution of water closet flush volumes

What are the Standards?

CALG i i d f i ht (8) h t d t (2)



CALGreen is comprised of eight (8) chapters and two (2) appendices:



Chp 1 Administration



Chp 2 Definitions



Chp 3 Green Building



Chp 4 Residential Mandatory Measures



Chp 5 Nonresidential Mandatory Measures



Chp 6 Referenced Organizations and Standards



Chp 7 Installer and Special Inspector Qualifications



Chp 8 Compliance Forms and Worksheets



App 4A Residential Voluntary Measures



App 5A Nonresidential Voluntary Measures pp y

Chapter 1



Administration



Administration



Purpose: To improve public health, safety and general welfare by enhancing the design and construction of buildings through the use of building concepts having a reduced negative impact, or positive environmental impact and encouraging sustainable construction encouraging sustainable construction.



Scope: Newly constructed buildings unless otherwise indicated in the code.



Shall not substitute or be identified as meeting the certification requirements

• f any green building program.

L l d ti f ll t d d HSC l



Local adoption follows standard HSC rules:



Local amendments must be justified



Appendices do not apply unless specifically adopted



If code requirements conflict, specific/more restrictive provisions shall apply



Alternate materials, designs and methods of construction may be considered



Construction documents and information requirements similar to CBC

Chapter 2

 Definitions

 Unless otherwise stated, words and terms shall,

for the purposes of this code, have the meanings shown in Chapter 2. d fi d i Ch 2 h ll h h

 Terms not defined in Chapter 2 shall have the

meanings ascribed to them in the Title 24, C.C.R. E l

 Examples

Chapter 3



Scope:



Scope:



Mandatory provisions shall apply to newly constructed buildings.



Voluntary measures are not required unless adopted by the local jurisdiction. jurisdiction.



Mixed occupancy buildings:



Comply with the specific green building measures applicable to each specific occupancy. p p y



Phased projects:



Building components and systems considered to be new construction (or newly constructed) shall apply.



Shall apply only to the initial tenant or occupant improvements to a project (303.1.1).



Voluntary Tiers:

Ti 1 d Ti 2



Tier 1 and Tier 2

Chapter 4

 Residential Mandatory Standards

 4.1 – Planning and Design  4.2 – Energy Efficiency  4.3 – Water Efficiency and Conservation  4.4 – Material Conservation and Resource Efficiency  4.5 – Environmental Quality

Q y

Planning and Design

 Storm water and surface drainage

management.

 During construction, either retain or filter storm

water (retention basins; straw wattles, etc.)

 Manage surface drainage to keep surface water

from entering buildings (sloped/graded surfaces; t h d i t ) trench drains; etc.)

Energy Efficiency

 The Department of Housing and Community

Development does not regulate mandatory energy efficiency standards in residential buildings For the efficiency standards in residential buildings. For the purposes of mandatory energy efficiency standards in this code, the California Energy Commission will in this code, the California Energy Commission will continue to adopt mandatory building standards.

 Meet or exceed the minimum standards contained

within the California Energy Code for low-rise residential buildings.

Water Efficiency and Conservation



20% ater sa ings



20% water savings



Flow rate method



Table 4.303.2



Calculation method



Calculation method



Table 4.303.1



Two persons for the first bedroom plus one person for each additional bedroom

M lti l h h d



Multiple shower heads



Prescriptive: Combined flow meets standard, or shall be designed to allow only 1-head at a time



Calculation: 2.5gpm max.



Outdoor water use



Landscape irrigation installed at time of final inspection shall have weather- or soil moisture-based controlers

Material Conservation and Resource Efficiency

J i d i i b ildi l h ll b

 Joints and openings in building envelope shall be

• sealed. Openings in exterior wall plates shall be

protected against passage of rodents. protected against passage of rodents.

 Construction waste shall be reduced by at least 50%.



If jurisdiction does not have a construction & demolition waste management ordinance, a waste management plan shall be required for each project.

 Building operation and maintenance manual shall be  Building operation and maintenance manual shall be

placed in the building at the time of final inspection. (4.410.1)

Environmental Quality



Fireplaces



Fireplaces



Gas fireplaces shall be direct-vented.



Solid-fuel fireplaces are regulated by SCAQMD



Covering of Duct Openings/Protection of Mechanical Equipment g p g q p



Duct openings and mechanical equipment used to move air in the building after occupancy shall be protected from construction contamination.



Pollutant Control



VOC limits established for adhesives bonding agents primers and paints



VOC limits established for adhesives, bonding agents, primers and paints (4.504.2, including tables)



Verification of compliance shall be provided at the request of the AHJ



Carpet and resilient flooring VOC compliance determined by verifying li ith t d d li t d i 4 504 3 & 4 504 4 compliance with standards listed in 4.504.3 & 4.504.4



Composite wood products shall meet formaldehyde emissions limits per Table 4.504.5.



Verification of compliance shall be provided at the request of the AHJ p p q

Environmental Quality (cont.)

I t i M i t C t l



Interior Moisture Control



Interior concrete slabs shall be provided with a capillary break in combination with the moisture barrier required under the Building Code Code.



Building materials with visible signs of water damage shall not be installed.



Wall and floor framing shall not be enclosed when framing members



Wall and floor framing shall not be enclosed when framing members exceed 19% moisture content.



Verification of compliance shall be provided at the request of the AHJ



Insulation products which are visibly wet or have a high moisture p y g content shall be replaced or allowed to dry prior to enclosure in wall

• r floor cavities. Wet applied insulation products shall follow the

manufacturers’ drying recommendations prior to enclosure.

Environmental Quality (cont.)



Indoor Air Q alit and E ha st



Indoor Air Quality and Exhaust



Bathroom exhaust fans shall be ENERGY STAR compliant and be ducted to terminate outside the building.



Unless functioning as a component of a whole house ventilation



Unless functioning as a component of a whole house ventilation system, fans must be controlled by a humidistat which shall be readily accessible.



Humidistat controls shall be capable of adjustment between a relative humidity range of 50 to 80 percent humidity range of 50 to 80 percent.



Bathroom is a room which contains a bathtub, shower, or tub/shower combination.



Environmental Comfort



Environmental Comfort



Whole house exhaust fans shall have insulated louvers or covers which close when the fan is off.



Establishes minimum requirements for heating and air conditioning d i (4 507 2)

• design. (4.507.2)

Residential Construction 3-Story Threshold

 Th b

CALG d li it li bilit f

 The base CALGreen code limits applicability of

residential standards to buildings 3-stories and less in height.

 The Los Angeles Basin Green Building Task Force

is contemplating a recommendation that would involve a local amendment to apply the residential involve a local amendment to apply the residential standards to residential buildings up to 6-stories in height, and apply the nonresidential standards to residential buildings over 6-stories in height residential buildings over 6 stories in height.



Generally below high-rise threshold



Likely to be consistent with Type IIIA fully-sprinklered construction construction

Chapter 5

 Non-Residential Mandatory Standards

 5.1 – Planning and Design  5.2 – Energy Efficiency  5.3 – Water Efficiency and Conservation  5.4 – Material Conservation and Resource Efficiency  5.5 – Environmental Quality

Q y

Planning and Design



Storm ater poll tion pre ention plan



Storm water pollution prevention plan



Site-specific plan required for all newly constructed non-residential projects, including those on parcels less than 1-acre in size (5.106.1)



Short-term bicycle parking (5%)



Short-term bicycle parking (5%)



Buildings with visitors



Long-term bicycle parking (5%)



Buildings with over 10 tenant occupants



Buildings with over 10 tenant-occupants



Designated parking (Table 5.106.5.2)



Low-emitting, fuel efficient, and carpool/van pool vehicles



Paint “Clean Air Vehicle” in location designated by (5 106 5 2 1)



Paint Clean Air Vehicle in location designated by (5.106.5.2.1)



Prevent direct-beam stray light from leaving the site



Develop site to prevent surface water from entering a building building.

Energy Efficiency

 For the purposes of mandatory energy

efficiency standards in this code, the California Energy Commission will continue to adopt mandatory building standards.

 Meet or exceed the minimum standards

contained within the California Energy Code for newly constructed non-residential buildings.

Water Efficiency and Conversation

 S

t t t

 Separate water meters



Buildings < 50,000 sqft



Tenant spaces projected to consume more than 100 gal/day

 Excess consumption



Any building within a project or space within a building that is projected to consume more than 1,000 gal/day  20% savings



Schedule of plumbing fixtures and fittings



Each fixture/fitting shall meet the 20% limitation listed in Table



Each fixture/fitting shall meet the 20% limitation listed in Table 5.303.2.3; or



Provide calculations to demonstrate a reduction in water-baseline using Table 5.303.2.2 M lti l h h d i h



Multiple shower heads serving one shower

Water Efficiency and Conversation



Waste ater red ction



Wastewater reduction



All newly constructed buildings shall reduce wastewater by 20% by:



The installation of water-conserving fixtures; or



Utilizing non-potable water systems (A5 304)



Utilizing non potable water systems (A5.304) 

Outdoor water use



Water budget for landscape irrigation which complies with either:



A local water efficient landscape ordinance; or



California Department of Water Resources Model Water Efficient Landscape Ordinance (AB 1881)



http://www.water.ca.gov/wateruseefficiency/docs/MWELO_TbContent_La w.pdf

S t t t f i d / td t bl t i d f



Separate water meter for indoor/outdoor potable water use required for landscaped areas between 1,000sqft & 5,000sqft



For larger areas, see Water Code §535 (DWR)



Irrigation controllers installed at the time of final inspection, which serve landscaped areas between 1 000sqft 2 500sqft shall comply with serve landscaped areas between 1,000sqft – 2,500sqft shall comply with 5.304.3.1 (soil moisture/rain sensor)

Material Conservation and Resource Efficiency



Water resistance and moist re management



Water resistance and moisture management



Adjust irrigation sprinklers to avoid spray on buildings



Design exterior entries and/or openings subject to foot traffic or wind- driven rain to prevent water intrusion into buildings driven rain to prevent water intrusion into buildings



Construction waste reduction, disposal and recycling



Minimum 50% reduction (weight or volume)



Comply with local ordinance (if more restricitve); or



Comply with local ordinance (if more restricitve); or



Submit a construction waste management plan



Identify materials to be diverted, method of sorting (or mixed), location to be taken (5.408.2)

D t ti i d t if li



Documentation required to verify compliance



Isolated job sites



100% diversion of excavated soil and land clearing debris P id b ildi i h dil ibl



Provide building occupants with a readily accessible recycling area

Material Conservation and Resource Efficiency

 B ildi

C i i i

 Building Commissioning



Newly constructed buildings 10,000sqft & larger to verify that the building systems and components meet project i t requirements



Performed by trained personnel with experience on projects of comparable size and complexity C i i i l ( 410 2)



Commissioning elements (5.410.2)



Owner’s project requirements (OPR) (5.410.2.1)



Basis of design (BOD) (5.410.2.2) g ( ) ( )



Commissioning plan (5.410.2.3)



Functional performance testing (5.410.2.4)



Documentation and training (5 410 2 5)



Documentation and training (5.410.2.5)



Commissioning report (5.410.2.6)

Material Conservation and Resource Efficiency

T i d dj i

 Testing and adjusting

 Newly constructed buildings less than 10,000sqft

P f d b i d l i h i

 Performed by trained personnel with experience

• n projects of comparable size and complexity

 Systems (5 410 3 2)  Systems (5.410.3.2)  Procedures (5.410.3.3)



Testing/adjusting, including air-balancing



Testing/adjusting, including air balancing

 Reporting (5.410.3.4)



Signed by the individual performing these services

 Operations and maintenance manual (5.410.3.5)

Environmental Quality



Fireplace VOC limits paints and coatings and carpeting



Fireplace, VOC limits, paints and coatings, and carpeting standards the same as residential standards.



MERV-8 or better filters required for mechanical ventilation equipment equipment



Smoking prohibited within 25-feet of building entrances, air- intakes and openable windows



I d i lit h ll t CBC d CEC t d d



Indoor air quality shall meet CBC and CEC standards, including specification and installation of CO2 sensors



Acoustical control (5.507.4.1 – freeways/airports/ambient)

E t i ll & f h ll i STC 50



Exterior walls & roof shall require STC 50



Exterior windows shall require STC 30



Interior separation from other tenants/public spaces require STC 40



No CFCs or halons for HVAC systems



No CFCs or halons for HVAC systems

Chapters 6, 7 & 8

 Referenced standards  Installer & special inspection qualifications

p p q

 Installer training (702.1)  Special inspection (702.2-702.4)

p p ( )

 Documentation (703.1-703.2)

 Compliance forms and worksheets  Compliance forms and worksheets

Tier 1 & Tier 2

 Appendix A4 & Appendix A5

 General discussion  Explanation of Tier 1 & Tier 2 checklists  How do I know whether any Tier 1 or Tier 2

standards would apply to my project?

Th k ! Thanks! Before you leave today Before you leave today,

be sure to ask any questions you have.
