C-2 DRAWER SYSTEMS AND SLIDES Standard Drawer Finishes: Grey, White and Stainless Steel Tool free assembly and removal of drawer Silent system gurantees smooth running Full adjustment (up, down, left, right) Standard

slide-1
SLIDE 1
slide-2
SLIDE 2

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-2

Length Grey White Stainless Steel

270 mm 105-MA270G 105-MA270W 105-MA270SS 300 mm 105-MA300G 105-MA300W 105-MA300SS 350 mm 105-MA350G 105-MA350W 105-MA350SS 400 mm 105-MA400G 105-MA400W 105-MA400SS 450 mm 105-MA450G 105-MA450W 105-MA450SS 500 mm 105-MA500G 105-MA500W 105-MA500SS 550 mm 105-MA550G 105-MA550W 105-MA550SS

Standard Drawer (packaged as a complete set)

Standard Drawer

  • Finishes: Grey, White and Stainless Steel
  • Tool free assembly and removal of drawer
  • Silent system gurantees smooth running
  • Full adjustment (up, down, left, right)
  • Standard 83mm height sides
  • Dynamic load capacity: 40kg

Standard Drawer includes:

1. One pair of Full Extention Soft-Close Slides

  • 2. One pair of Doublewall Drawer Sides (83 mm

height) and Infinity Cover Caps

  • 3. One pair of rear fixing brackets
  • 4. Two universal drawer front connectors
slide-3
SLIDE 3

Installation Dimensions Drilling Pattern Installation Dimensions

Drawer Front, Back and Bottom Dimensions

Space Requirement

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-3

Technical Specifications

Drawer Front NL = Nominal Slide Length LT = Internal Cabinet Depth LT = NL + 3

slide-4
SLIDE 4

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-4

Standard Drawer Production Pack (packaged as a complete set)

Standard Drawer Production Packs

  • Finishes: Grey and White
  • Tool free assembly and removal of drawer
  • Silent system gurantees smooth running
  • Full adjustment (up, down, left, right)
  • Standard 83mm height sides
  • Dynamic load capacity: 40kg

Each production pack includes:

1. One pair of Full Extension Soft-Close Slides

  • 2. One pair of Doublewall Drawer Sides (83mm

height)

To order a complete system, you will need to add:

1. Two universal drawer front connectors

  • 2. One pair of rear fixing brackets
  • 3. One pair of Cover Caps

Production Pack Benefits:

  • Easier to order for large quantity production
  • Green friendly packaging - much less waste

Length Grey White Qty

400 mm 105-MA400G-PD

  • 20

450 mm 105-MA450G-PD

  • 20

500 mm 105-MA500G-PD 105-MA500W-PD 20

Standard Drawer - Production Packs

Finish Mounting Part No. Qty

Zinc Screw-On 105-M01011Z 120 Zinc Press-In Dowel 105-M01016Z 120 Zinc Expansion Dowel 105-M0101B 120

Universal Drawer Front Connectors

Finish Description Part No. Qty

Grey Infinity by Marathon 105-MJS1-INFINITY-G 500 White Infinity by Marathon 105-MJS1-INFINITY-W 500 Grey/White Customer’s Custom Logo *Special Order Only.

  • Min. Quantities Apply.

1000

Cover Caps

Finish Part No. Qty

Grey 105-M01031G 60 White 05-M01031W 60

Standard Rear Fixing Brackets

slide-5
SLIDE 5

Installation Dimensions Drilling Pattern Installation Dimensions

Drawer Front, Back and Bottom Dimensions

Space Requirement

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-5

Technical Specifications

Drawer Front NL = Nominal Slide Length LT = Internal Cabinet Depth LT = NL + 3

slide-6
SLIDE 6

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-6

Length Grey White

270 mm 105-M31-270G 105-M31-270W 300 mm 105-M31-300G 105-M31-300W 350 mm 105-M31-350G 105-M31-350W 400 mm 105-M31-400G 105-M31-400W 450 mm 105-M31-450G 105-M31-450W 500 mm 105-M31-500G 105-M31-500W 550 mm 105-M31-550G 105-M31-550W

Standard Drawer (packaged as a complete set)

Standard Drawer, Push System Slides

  • Finishes: Grey and White
  • Tool free assembly and removal of drawer
  • Silent system gurantees smooth running
  • Full adjustment (up, down, left, right)
  • Installation requires 3mm space between drawer front

and cabinet edge to push drawer in before it rebounds

  • Standard 83mm height sides
  • Dynamic load capacity: 40kg

Standard Drawer includes:

1. One pair of Full Extention Push-to-Open Slides

  • 2. One pair of Doublewall Drawer Sides (83 mm

height) and Infinity Cover Caps

  • 3. One pair of rear fixing brackets
  • 4. Two universal drawer front connectors

These Push-To-Open Drawer Kits are compatible with other components and accessories of the Doublewall Drawer Sys- tem and you can substitute them whenever a standard drawer kit of 83mm height is specified.

slide-7
SLIDE 7

Installation Dimensions Drilling Pattern Installation Dimensions

Drawer Front, Back and Bottom Dimensions

Space Requirement

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-7

Technical Specifications

Drawer Front NL = Nominal Slide Length LT = Internal Cabinet Depth LT = NL + 3

slide-8
SLIDE 8

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-8

Standard Drawer 115mm Height Sides (packaged as a complete set)

Standard Drawer, 115 mm Height Sides

  • Finishes: Grey and White
  • Tool free assembly and removal of drawer
  • Silent system gurantees smooth running
  • Full adjustment (up, down, left, right)
  • Tall 115mm height sides
  • Dynamic load capacity: 40kg

Length Grey White

270 mm 105-MA270G-115 105-MA270W-115 300 mm 105-MA300G-115 105-MA300W-115 350 mm 105-MA350G-115 105-MA350W-115 400 mm 105-MA400G-115 105-MA400W-115 450 mm 105-MA450G-115 105-MA450W-115 500 mm 105-MA500G-115 105-MA500W-115 550 mm 105-MA550G-115 105-MA550W-115

Standard Drawer kit with 115 mm height sides includes:

1. One pair of Full Extention Soft-Close Slides

  • 2. One pair of Doublewall Drawer Sides

(115 mm height) and Infinity cover caps

  • 3. One pair of rear fixing brackets
  • 4. Two universal drawer front connectors
slide-9
SLIDE 9

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-9

Technical Specifications Installation Dimensions Drilling Pattern Space Requirement Installation Dimensions

Drawer Front

Drawer Front, Back and Bottom Dimensions

NL = Nominal Slide Length LT = Internal Cabinet Depth LT = NL + 3

slide-10
SLIDE 10

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-10

To make this unit, order Standard Drawer plus parts listed below

Standard Internal Drawer

  • Finishes: Grey, White and Stainless Steel
  • Tool free assembly and removal of drawer
  • Silent system gurantees smooth running
  • Full adjustment (up, down, left, right)
  • Standard 83mm height sides
  • Dynamic load capacity: 40kg

Order Standard Drawer kit (see Page C-2) plus these parts:

  • 4. Add a pair of internal front fixing brackets
  • 5. Add a metal 1100 mm internal drawer front which

can be cut to match your drawer width Finish Part No.

Grey 105-M01012G White 105-M01012W

Internal Drawer Front Brackets

(Drawer front brackets available in grey & white) Finish Part No.

Grey 105-M01021G White 105-M01021W Polished Chrome 105-M01021PC

Internal Drawer Front, 1100 mm Lengths

slide-11
SLIDE 11

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-11

Technical Specifications Drilling Pattern Installation Dimensions

Drawer Front, Back and Bottom Dimensions

Space Requirement

Drawer Front

Installation Dimensions Space Requirement

NL = Nominal Slide Length LT = Internal Cabinet Depth LT = NL + 3

slide-12
SLIDE 12

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-12 Standard Internal Drawer, 115mm Height Sides

  • Finishes: Grey, White and Stainless Steel
  • Tool free assembly and removal of drawer
  • Silent system gurantees smooth running
  • Full adjustment (up, down, left, right)
  • Tall 115mm height sides
  • Dynamic load capacity: 40kg

Order Standard Drawer kit with 115 mm height sides (see Page C-8) plus these parts:

  • 4. Add a pair of internal front fixing brackets that fits

115mm height sides

  • 5. Add a metal 1100 mm internal drawer front which

can be cut to match your drawer width Finish Part No.

Grey 105-M02010G-115 White 105-M02010W-115

Internal Drawer Front Brackets

(Drawer front brackets available in grey & white) Finish Part No.

Grey 105-M01021G White 105-M01021W

Internal Drawer Front, 1100 mm Lengths

To make this unit, order Standard Drawer plus parts listed below

slide-13
SLIDE 13

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-13

Technical Specifications Drilling Pattern Installation Dimensions

Drawer Front, Back and Bottom Dimensions

Installation Dimensions Space Requirement

NL = Nominal Slide Length LT = Internal Cabinet Depth LT = NL + 3

slide-14
SLIDE 14

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-14 Deep Drawer with Single Round Lateral Rails

  • Finishes: Grey, White and Stainless Steel
  • Tool free assembly and removal of drawer
  • Silent system gurantees smooth running
  • Full adjustment (up, down, left, right)
  • Standard 83mm height sides
  • Dynamic load capacity: 40kg

Order Standard Drawer kit (see Page C-2) plus these parts:

  • 3. Add a pair of rear single rail fixing brackets
  • 6. Add a pair of round lateral rails

Length Grey White Polished Chrome

270 mm 105-M41E270G 105-M41E270W 105-M41E270PC 300 mm 105-M41E300G 105-M41E300W 105-M41E300PC 350 mm 105-M41E350G 105-M41E350W 105-M41E350PC 400 mm 105-M41E400G 105-M41E400W 105-M41E400PC 450 mm 105-M41E450G 105-M41E450W 105-M41E450PC 500 mm 105-M41E500G 105-M41E500W 105-M41E500PC 550 mm 105-M41E550G 105-M41E550W 105-M41E550PC

Finish Part No.

Grey 105-M01032G White 105-M01032W Polished Chrome 105-M01032PC

Rear Fixing Brackets for Single Rail Round Lateral Rails

To make this unit, order Standard Drawer plus parts listed below

slide-15
SLIDE 15

Installation Dimensions Drilling Pattern Installation Dimensions

Drawer Front, Back and Bottom Dimensions

Space Requirement

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-15

Technical Specifications

Drawer Front NL = Nominal Slide Length LT = Internal Cabinet Depth LT = NL + 3

slide-16
SLIDE 16

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-16

Deep Drawer, 115 mm Height, Single Round Lateral Rails

  • Finishes: Grey, White and Stainless Steel
  • Tool free assembly and removal of drawer
  • Silent system gurantees smooth running
  • Full adjustment (up, down, left, right)
  • Tall 115mm height sides
  • Dynamic load capacity: 40kg

Length Grey White

270 mm 105-M41E270G 105-M41E270W 300 mm 105-M41E300G 105-M41E300W 350 mm 105-M41E350G 105-M41E350W 400 mm 105-M41E400G 105-M41E400W 450 mm 105-M41E450G 105-M41E450W 500 mm 105-M41E500G 105-M41E500W 550 mm 105-M41E550G 105-M41E550W

Finish Part No.

Grey 105-M02032G-115 White 105-M02032W-115

Rear Fixing Brackets for Single Rail, 115 mm Order Standard Drawer kit with 115 mm height sides (see Page C-8) plus these parts:

  • 3. Add a pair of rear single rail fixing brackets for

115 mm height sides

  • 6. Add a pair of round lateral rails

To make this unit, order Standard Drawer plus parts listed below

Round Lateral Rails

slide-17
SLIDE 17

Installation Dimensions Drilling Pattern Installation Dimensions

Drawer Front, Back and Bottom Dimensions

Space Requirement

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-17

Technical Specifications

Drawer Front NL = Nominal Slide Length LT = Internal Cabinet Depth LT = NL + 3

slide-18
SLIDE 18

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-18 Deep Internal Drawer, Single Round Lateral Rails

  • Finishes: Grey, White and Stainless Steel
  • Tool free assembly and removal of drawer
  • Silent system gurantees smooth running
  • Full adjustment (up, down, left, right)
  • Standard 83mm height sides
  • Dynamic load capacity: 40kg

Order Standard Drawer kit (see Page C-2) plus these parts:

  • 3. Add a pair of rear single rail fixing

brackets

  • 4. Add a pair of internal front fixing brackets for single

rail

  • 5. Add a metal 1100 mm internal drawer front which

can be cut to match your drawer width

  • 6. Add a pair of round lateral rails (see Page C-14)

Finish Part No.

Grey 105-M01013G White 105-M01013W

Internal Front Brackets, Single Rail

Finish Part No.

Grey 105-M01021G White 105-M01021W Polished Chrome 105-M01021PC

Internal Drawer Front, 1100 mm Lengths

Finish Part No.

Grey 105-M01032G White 105-M01032W Polished Chrome 105-M01032PC

Rear Fixing Brackets for Single Rail

To make this unit, order Standard Drawer plus parts listed below

slide-19
SLIDE 19

Installation Dimensions Drilling Pattern Installation Dimensions

Drawer Front, Back and Bottom Dimensions

Space Requirement

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-19

Technical Specifications

NL = Nominal Slide Length LT = Internal Cabinet Depth LT = NL + 3

slide-20
SLIDE 20

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-20

  • Finishes: Grey, White and Stainless Steel
  • Tool free assembly and removal of drawer
  • Silent system gurantees smooth running
  • Full adjustment (up, down, left, right)
  • Tall 115mm height sides
  • Dynamic load capacity: 40kg

Order Standard Drawer kit with 115 mm height sides (see Page C-8) plus these parts:

  • 3. Add a pair of rear single rail fixing

brackets for 115 mm height sides

  • 4. Add a pair of internal front fixing brackets for single

rail and 115 mm height sides

  • 5. Add a metal 1100 mm internal drawer front which

can be cut to match your internal drawer width

  • 6. Add a pair of round lateral rails (see Page C-14)
  • 7. Add a 1100 mm internal front round cross rail that

can be cut to match your drawer width

Deep Internal Drawer, 115 mm, Single Round Lateral Rails

Finish Part No.

Grey 105-M02011G-115 White 105-M02011W-115

Internal Front Brackets Round 115 mm

Finish Part No.

Grey 105-M01021G White 105-M01021W

Internal Drawer Front, 1100 mm Lengths

Finish Part No.

Grey 105-M01043G White 105-M01043W

Internal Round Cross Rail, 1100 mm Lengths

Finish Part No.

Grey 105-M02032G-115 White 105-M02032W-115

Rear Fixing Brackets for Single Rail 115mm

To make this unit, order Standard Drawer plus parts listed below

slide-21
SLIDE 21

Installation Dimensions Drilling Pattern Installation Dimensions

Drawer Front, Back and Bottom Dimensions

Space Requirement

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-21

Technical Specifications

NL = Nominal Slide Length LT = Internal Cabinet Depth LT = NL + 3

slide-22
SLIDE 22

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-22 Deep Drawer with Single Square Lateral Rails

  • Finishes: Grey, White and Stainless Steel
  • Tool free assembly and removal of drawer
  • Silent system gurantees smooth running
  • Full adjustment (up, down, left, right)
  • Standard 83mm height sides
  • Dynamic load capacity: 40kg

Order Stanadrd Drawer kit (see Page C-2) plus these parts:

  • 3. Add a pair of rear single rail fixiing brackets
  • 6. Add a pair of square lateral rails

Length Grey White

270 mm 105-M41P270G 105-M41P270W 300 mm 105-M41P300G 105-M41P300W 350 mm 105-M41P350G 105-M41P350W 400 mm 105-M41P400G 105-M41P400W 450 mm 105-M41P450G 105-M41P450W 500 mm 105-M41P500G 105-M41P500W 550 mm 105-M41P550G 105-M41P550W

Finish Part No.

Grey 105-M01032G White 105-M01032W

Rear Fixing Brackets for Single Rail Square Lateral Rails

To make this unit, order Standard Drawer plus parts listed below

slide-23
SLIDE 23

Installation Dimensions Drilling Pattern Installation Dimensions

Drawer Front, Back and Bottom Dimensions

Space Requirement

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-23

Technical Specifications

Drawer Front NL = Nominal Slide Length LT = Internal Cabinet Depth LT = NL + 3

slide-24
SLIDE 24

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-24

Deep Drawer, 115 mm Height, Single Square Lateral Rails

  • Finishes: Grey, White and Stainless Steel
  • Tool free assembly and removal of drawer
  • Silent system gurantees smooth running
  • Full adjustment (up, down, left, right)
  • Tall 115mm height sides
  • Dynamic load capacity: 40kg

Order Standard Drawer kit with 115 mm height sides (see Page C-8) plus these parts:

  • 3. Add a pair of rear single rail fixing brackets for

115 mm height sides

  • 6. Add a pair of square lateral rails

Length Grey White

270 mm 105-M41P270G 105-M41P270W 300 mm 105-M41P300G 105-M41P300W 350 mm 105-M41P350G 105-M41P350W 400 mm 105-M41P400G 105-M41P400W 450 mm 105-M41P450G 105-M41P450W 500 mm 105-M41P500G 105-M41P500W 550 mm 105-M41P550G 105-M41P550W

Finish Part No.

Grey 105-M02032G-115 White 105-M02032W-115

Rear Fixing Brackets for Single Rail, 115 mm Square Lateral Rails

To make this unit, order Standard Drawer plus parts listed below

slide-25
SLIDE 25

Installation Dimensions Drilling Pattern Installation Dimensions

Drawer Front, Back and Bottom Dimensions

Space Requirement

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-25

Technical Specifications

Drawer Front NL = Nominal Slide Length LT = Internal Cabinet Depth LT = NL + 3

slide-26
SLIDE 26

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-26 Deep Internal Drawer with Single Lateral Rails

  • Finishes: Grey, White and Stainless Steel
  • Tool free assembly and removal of drawer
  • Silent system gurantees smooth running
  • Full adjustment (up, down, left, right)
  • Standard 83mm height sides
  • Dynamic load capacity: 40kg

Order Standard Drawer kit (see Page C-2) plus these parts:

  • 3. Add a pair of rear single rail fixing brackets
  • 4. Add a pair of internal front fixing brackets for single

rail

  • 5. Add a metal 1100 mm internal drawer front which

can be cut to match your drawer width

  • 6. Add a pair of square lateral rails

Finish Part No.

Grey 105-M01013G White 105-M01013W

Internal Front Brackets, Single Rail

Finish Part No.

Grey 105-M01021G White 105-M01021W Polished Chrome 105-M01021PC

Internal Drawer Front, 1100 mm Lengths

Finish Part No.

Grey 105-M01032G White 105-M01032W

Rear Fixing Brackets for Single Rail

Length Grey White

270 mm 105-M41P270G 105-M41P270W 300 mm 105-M41P300G 105-M41P300W 350 mm 105-M41P350G 105-M41P350W 400 mm 105-M41P400G 105-M41P400W 450 mm 105-M41P450G 105-M41P450W 500 mm 105-M41P500G 105-M41P500W 550 mm 105-M41P550G 105-M41P550W

Square Lateral Rails

To make this unit, order Standard Drawer plus parts listed below

slide-27
SLIDE 27

Installation Dimensions Drilling Pattern Installation Dimensions

Drawer Front, Back and Bottom Dimensions

Space Requirement

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-27

Technical Specifications

NL = Nominal Slide Length LT = Internal Cabinet Depth LT = NL + 3

slide-28
SLIDE 28

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-28

  • Finishes: Grey, White and Stainless Steel
  • Tool free assembly and removal of drawer
  • Silent system gurantees smooth running
  • Full adjustment (up, down, left, right)
  • Tall 115mm height sides
  • Dynamic load capacity: 40kg

Deep Internal Drawer, 115 mm, Single Lateral Rails

Finish Part No.

Grey 105-M02012G-115 White 105-M02012W-115

Internal Front Brackets for Single Square, 115mm

Finish Part No.

Grey 105-M02032G-115 White 105-M02032W-115

Rear Fixing Brackets for Single Rail, 115 mm

Finish Part No.

Grey 105-M01021G White 105-M01021W

Internal Drawer Front, 1100 mm Lengths

Finish Part No.

Grey 105-M01078G White 105-M01078W

Internal Square Cross Rail, 1100 mm Lengths Order Standard Drawer kit with 115 mm height sides (see Page C-8) plus these parts:

  • 3. Add a pair of rear single rail fixing brackets for

115 mm height sides

  • 4. Add a pair of internal front fixing brackets for single

rail with 115 mm height sides

  • 5. Add a metal 1100 mm internal drawer front which

can be cut to match your drawer width

  • 6. Add a pair of square lateral rails (see Page C-26)
  • 7. Add a 1100 mm internal front square cross rail that

can be cut to match your drawer width

To make this unit, order Standard Drawer plus parts listed below

slide-29
SLIDE 29

Installation Dimensions Drilling Pattern Installation Dimensions

Drawer Front, Back and Bottom Dimensions

Space Requirement

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-29

Technical Specifications

NL = Nominal Slide Length LT = Internal Cabinet Depth LT = NL + 3

slide-30
SLIDE 30

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-30 Pots and Pan Drawer, Double Round Laterial Rails

  • Finishes: Grey, White and Stainless Steel
  • Tool free assembly and removal of drawer
  • Silent system gurantees smooth running
  • Full adjustment (up, down, left, right)
  • Standard 83mm height sides
  • Dynamic load capacity: 40kg

Order Standard Drawer kit (see Page C-2) plus these parts:

  • 3. Add a pair of rear doubling rail fixing brackets
  • 6. Add two pairs of round lateral rails

Length Grey White Polished Chrome

270 mm 105-M41E270G 105-M41E270W 105-M41E270PC 300 mm 105-M41E300G 105-M41E300W 105-M41E300PC 350 mm 105-M41E350G 105-M41E350W 105-M41E350PC 400 mm 105-M41E400G 105-M41E400W 105-M41E400PC 450 mm 105-M41E450G 105-M41E450W 105-M41E450PC 500 mm 105-M41E500G 105-M41E500W 105-M41E500PC 550 mm 105-M41E500G 105-M41E550W 105-M41E550PC

Round Lateral Rails

Finish Part No.

Grey 105-M01033G White 105-M01033W Polished Chrome 105-M01033PC

Rear Fixing Brackets for Double Rail

To make this unit, order Standard Drawer plus parts listed below

slide-31
SLIDE 31

Installation Dimensions Drilling Pattern Installation Dimensions

Drawer Front, Back and Bottom Dimensions

Space Requirement

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-31

Technical Specifications

Drawer Front NL = Nominal Slide Length LT = Internal Cabinet Depth LT = NL + 3

slide-32
SLIDE 32

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-32 Pots and Pan Internal Drawer, Double Round Rails

  • Finishes: Grey, White and Stainless Steel
  • Tool free assembly and removal of drawer
  • Silent system gurantees smooth running
  • Full adjustment (up, down, left, right)
  • Standard 83mm height sides
  • Dynamic load capacity: 40kg

Order Standard Drawer kit (see Page C-2) plus these parts:

  • 3. Add a pair of rear double rail fixing brackets

(see Page C-30)

  • 4. Add a pair of internal double front fixing brackets
  • 5. Add a metal 1100 mm internal drawer front cut to

match your drawer width (see Page C-18)

  • 6. Add a pair of round lateral rails (see Page C-14)
  • 7. Add an 1100 mm internal cross rail which can be

cut to match your drawer width

  • 8. Add an internal drawer handle (optional)

Finish Part No. Grey

105-M01043G

White

105-M01043W

Polished Chrome

105-M01043PC

Finish Part No. Grey

105-M01014G

White

105-M01014W

Internal Front Fixing Brackets for Double Round Rails

Finish Part No, Grey

105-M01022G

White

105-M01022W

Internal Round Cross Rail, 1100 mm Lengths Internal Drawer Handles (optional)

To make this unit, order Standard Drawer plus parts listed below

slide-33
SLIDE 33

Installation Dimensions Drilling Pattern Installation Dimensions

Drawer Front, Back and Bottom Dimensions

Space Requirement

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-33

Technical Specifications

NL = Nominal Slide Length LT = Internal Cabinet Depth LT = NL + 3

slide-34
SLIDE 34

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-34 Pots and Pan Drawer, Double Square Lateral Rails

  • Finishes: Grey, White and Stainless Steel
  • Tool free assembly and removal of drawer
  • Silent system gurantees smooth running
  • Full adjustment (up, down, left, right)
  • Standard 83mm height sides
  • Dynamic load capacity: 40kg

Order Standard Drawer kit (see Page C-2) plus these parts:

  • 3. Add a pair of rear double rail fixing brackets
  • 6. Add two pairs of square lateral rails

Length Grey White

270 mm 105-M41P270G 105-M41P270W 300 mm 105-M41P300G 105-M41P300W 350 mm 105-M41P350G 105-M41P350W 400 mm 105-M41P400G 105-M41P400W 450 mm 105-M41P450G 105-M41P450W 500 mm 105-M41P500G 105-M41P500W 550 mm 105-M41P550G 105-M41P550W

Finish Part No.

Grey 105-M01033G White 105-M01033W Polished Chrome 105-M01033PC

Rear Fixing Brackets for Double Rail Square Lateral Rails

To make this unit, order Standard Drawer plus parts listed below

slide-35
SLIDE 35

Installation Dimensions Drilling Pattern Installation Dimensions

Drawer Front, Back and Bottom Dimensions

Space Requirement

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-35

Technical Specifications

Drawer Front NL = Nominal Slide Length LT = Internal Cabinet Depth LT = NL + 3

slide-36
SLIDE 36

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-36 Pots and Pan Drawer with High Metal boxsides

  • Finishes: Grey, White and Stainless Steel
  • Tool free assembly and removal of drawer
  • Silent system gurantees smooth running
  • Full adjustment (up, down, left, right)
  • Standard 83mm height sides
  • Dynamic load capacity: 40kg

Order Standard Drawer kit (see Page C-2) plus these parts:

  • 3. Add a pair of rear double rail fixing brackets
  • 6. Add two pairs of lateral rails (see Page C-14)
  • 13. Add a pair of High Metal Boxsides

Length Grey White Stainless Steel

350 mm 105-M52E350G 105-M52E350W 105-M52E350SS 400 mm 105-M52E400G 105-M52E400W 105-M52E300SS 450 mm 105-M52E450G 105-M52E550W 105-M52E450SS 500 mm 105-M52E500G 105-M52E500W 105-M52E500SS 550 mm 105-M52E550G 105-M52E550W 105-M52E550SS

High Metal Boxsides

Finish Part No.

Grey 105-M01033G White 105-M01033W Polished Chrome 105-M01033PC

Rear Fixing Brackets for Double Rail

To make this unit, order Standard Drawer plus parts listed below

slide-37
SLIDE 37

Installation Dimensions Drilling Pattern Installation Dimensions

Drawer Front, Back and Bottom Dimensions

Space Requirement

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-37

Technical Specifications

Drawer Front NL = Nominal Slide Length LT = Internal Cabinet Depth LT = NL + 3

slide-38
SLIDE 38

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-38

Internal Pots and Pan Drawer, High Metal Boxsides

  • Finishes: Grey, White and Stainless Steel
  • Tool free assembly and removal of drawer
  • Silent system gurantees smooth running
  • Full adjustment (up, down, left, right)
  • Standard 83mm height sides
  • Dynamic load capacity: 40kg

Length Grey White Stainless Steel

350 mm 105-M52E350G 105-M52E350W 105-M52E350SS 400 mm 105-M52E400G 105-M52E400W 105-M52E300SS 450 mm 105-M52E450G 105-M52E550W 105-M52E450SS 500 mm 105-M52E500G 105-M52E500W 105-M52E500SS 550 mm 105-M52E550G 105-M52E550W 105-M52E550SS

High Metal Boxsides

Finish Part No.

Grey 105-M01022G White 105-M01022W

Internal Drawer Handles (optional) Order Standard Drawer kit (see Page C-2) plus these parts:

  • 3. Add two of rear double rail fixing brackets

(see Page C-36)

  • 4. Add a pair of internal double front fixing brackets (C-32)
  • 5. Add a metal 1100 mm internal drawer front cut to

match your drawer width (see Page C-18)

  • 6. Add a pair of round lateral rails (see Page C-14)
  • 7. Add an 1100 mm internal cross rail which can be

cut to match your drawer width (see Page C-32)

  • 8. Add an internal drawer handle (optional)
  • 13. Add a pair of High Metal Boxsides

To make this unit, order Standard Drawer plus parts listed below

slide-39
SLIDE 39

Installation Dimensions Drilling Pattern Installation Dimensions

Drawer Front, Back and Bottom Dimensions

Space Requirement

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-39

Technical Specifications

NL = Nominal Slide Length LT = Internal Cabinet Depth LT = NL + 3

slide-40
SLIDE 40

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-40

Pots and Pan Drawer with Glass Boxsides

  • Finishes: Grey, White and Stainless Steel
  • Tool free assembly and removal of drawer
  • Silent system gurantees smooth running
  • Full adjustment (up, down, left, right)
  • Standard 83mm height sides
  • Dynamic load capacity: 40kg

Order Standard Drawer kit (see Page C-2) plus these parts:

  • 3. Add a pair of rear double rail fixing brackets
  • 6. Add one pair of round lateral rails (see Page C-14)
  • 14. Add pair of front adaptors for glass boxsides
  • 15. Add a pair of tempered glass boxsides
  • 16. Add pair of rear adaptors for glass boxsides

Length Part No.

300 mm 105-M01062-300 350 mm 105-M01062-350 400 mm 105-M01062-400 450 mm 105-M01062-450 500 mm 105-M01062-500 550 mm 105-M01062-550

Tempered Glass Boxsides

Finsh Part No.

Grey 105-M01061G

Front Adaptors for Glass Boxsides

Finish Part No.

Grey 105-M01063G

Rear Adaptors for Glass Boxsides

Finish Part No.

Grey 105-M01033G White 105-M01033W

Rear Fixing Brackets for Double Rail

To make this unit, order Standard Drawer plus parts listed below

slide-41
SLIDE 41

Installation Dimensions Drilling Pattern Installation Dimensions

Drawer Front, Back and Bottom Dimensions

Space Requirement

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-41

Technical Specifications Glass Dimensions

Drawer Front NL = Nominal Slide Length LT = Internal Cabinet Depth LT = NL + 3

slide-42
SLIDE 42

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-42 Internal Pots and Pan Drawer with Glass Boxsides

  • Finishes: Grey, White and Stainless Steel
  • Tool free assembly and removal of drawer
  • Silent system gurantees smooth running
  • Full adjustment (up, down, left, right)
  • Standard 83mm height sides
  • Dynamic load capacity: 40kg

Order Standard Drawer kit (see Page C-2) plus these parts:

  • 3. Add a pair of rear double rail fixing brackets

(see Page C-30)

  • 4. Add pair of internal double front fixing brackets for

glass boxsides

  • 5. Add a metal 1100 mm internal drawer front which

can be cut to match your drawer width (Page C-18)

  • 6. Add one pair of round lateral rails (see Page C-14)
  • 7. Add an 1100 mm internal cross rail which can be

cut to match your drawer width (see Page C-32)

  • 8. Add an internal drawer handle (optional)
  • 14. Add pair of front adaptors for glass boxsides (C-40)
  • 15. Add a pair of tempered glass boxsides (see Pg C-40)
  • 16. Add pair of rear adaptors for glass boxsides (C-40)

Finish Part No.

Grey 105-M01022G White 105-M01022W

Internal Drawer Handles (optional)

To make this unit, order Standard Drawer plus parts listed below

Finish Part No.

Grey 105-M01015G White 105-M01015W

Internal Double Front Brackets for Glass

slide-43
SLIDE 43

Installation Dimensions Drilling Pattern Installation Dimensions

Drawer Front, Back and Bottom Dimensions

Space Requirement

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-43

Technical Specifications Glass Dimensions

NL = Nominal Slide Length LT = Internal Cabinet Depth LT = NL + 3

slide-44
SLIDE 44

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-44

Under Sink Drawer kit (packaged as a complete set)

Under Sink Drawer

  • Finishes: Grey, White and Stainless Steel
  • Tool free assembly and removal of drawer
  • Silent system gurantees smooth running
  • Full adjustment (up, down, left, right)
  • Standard 83mm height sides
  • Dynamic load capacity: 40kg

Under Sink Drawer kit includes:

  • 1. One pair of Full Extension Soft-Close Slides
  • 2. Two pair of Doublewall Drawer Sides

(83 mm height) which includes two pairs of Infinity cover caps

  • 3. Two pairs of rear fixing brackets
  • 4. Four universal drawer front connectors

Length Grey White Stainless Steel

500 mm 105-M01500G-G 105-M01500G-W 105-M01500G-SS 550 mm 105-M01550G-G 105-M01550G-W 105-M01550G-SS

Under SInk Drawer Kits

slide-45
SLIDE 45

Installation Dimensions Drilling Pattern Installation Dimensions

Drawer Front, Back and Bottom Dimensions

Space Requirement

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-45

Technical Specifications

Drawer Front NL = Nominal Slide Length LT = Internal Cabinet Depth LT = NL + 3

slide-46
SLIDE 46

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-46

Standard Corner Drawer 45° kit (packaged as a complete set)

Standard Corner Drawer 45°

  • Finishes: Grey, White and Stainless Steel
  • Tool free assembly and removal of drawer
  • Silent system gurantees smooth running
  • Full adjustment (up, down, left, right)
  • Standard 83mm height sides
  • Dynamic load capacity: 40kg

Standard Corner Drawer 45° kit includes:

  • 1. One pair of Full Extension Soft-Close Slides
  • 2. One pair of Doublewall Drawer Sides

(83 mm height) whidch includes a pair of infinity cover caps

  • 3. One pair of rear fixing brackets
  • 4. One pair front fixing brackets

Length Grey White Stainless Steel

600 mm 105-M01600N-G 105-M01600N-W 105-M01600N-SS 650 mm 105-M01650N-G 105-M01650N-W 105-M01650N-SS

Standard Corner Drawer Kits

slide-47
SLIDE 47

Installation Dimensions Drilling Pattern Installation Dimensions

Drawer Front, Back and Bottom Dimensions

Space Requirement

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-47

Technical Specifications

Drawer Front NL = Nominal Slide Length LT = Internal Cabinet Depth LT = NL + 3

slide-48
SLIDE 48

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-48

Deep Corner Drawer 45° kit (packaged as a complete set)

Deep Corner Drawer 45°

  • Finishes: Grey, White and Stainless Steel
  • Tool free assembly and removal of drawer
  • Silent system gurantees smooth running
  • Full adjustment (up, down, left, right)
  • Standard 83mm height sides
  • Dynamic load capacity: 40kg

Deep Corner Drawer 45° kit includes:

  • 1. One pair of Full Extension Soft-Close Slides
  • 2. One pair of Doublewall Drawer Sides

(83 mm height) which includes a pair of Infinity cover caps

  • 3. One pair of rear fixing brackets
  • 4. One pair front fixing brackets
  • 6. One pair of round lateral rails

Length Grey White Stainless Steel

600 mm 105-M01600P-G 105-M01600P-W 105-M01600P-SS 650 mm 105-M01650P-G 105-M01650P-W 105-M01650P-SS

Deep Corner Drawer Kits

slide-49
SLIDE 49

Installation Dimensions Drilling Pattern Installation Dimensions

Drawer Front, Back and Bottom Dimensions

Space Requirement

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-49

Technical Specifications

Drawer Front NL = Nominal Slide Length LT = Internal Cabinet Depth LT = NL + 3

slide-50
SLIDE 50

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-50

Inside Cabinet Space Requirements

Stabilizer for Wide Drawers

Length Part No.

450 mm 105-M01081-450 500 mm 105-M01081-500 550 mm 105-M01081-550

When combined with wider drawers between 900 to 1200 mm in width, the stabilizer kit will help with the smooth and silent closing action.

Stabilizer Kits

Spacer Blocks

Size Product No. Colour Qty

25 mm 105-M001G Grey 400 25 mm 105-M001W White 400

  • 32mm System compatible
  • 25mm (1”) Depth
  • Matches drawer system/slide mounting holes
slide-51
SLIDE 51

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

Technical Specifications

Assembly Tools for the Front Fixing Bracket

Marking Put the L/H gauge into L/H Drawer side. Put the R/H gauge into R/H Drawer side. Line up the drawer front and marking positions with a light tap on each side. Fix front brackets over the pin hole marks. Type Part No.

Front Bracket 105-M0101A

Assembly Jig for Front Fixing Brackets Assembly Jig for Lateral Rail Drillings

Fix front bracket Mark position of the railings Drill ø 10 hole (depth 12mm) Press the dowel of the railing Mark position of the railings Fix the dowel of the railing with screw into the drawer front Fix front bracket Application for Expansion Dowel Application for Knock-In Dowels into the drawer front Type Part No.

Laterial Rail 105-ML3

C-51

slide-52
SLIDE 52

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-52

Double Cross Rail with Dividers System Single Crossed Rails System

Accessories

Parts Required

  • Pic. No.

Finish Part No.

7 Grey 105-M01043G 7 Chrome 105-M01043PC 7 White 105-M01043W 9 Grey 105-M01044G 10 Grey 105-M01045G

  • Pic. No.

Finish Part No.

7 Grey 105-M01043G 7 Chrome 105-M01043PC 7 White 105-M01043W 8 Grey 105-M01042G 11 Grey 105-M01046G 12 Grey 105-M01047G 12 White 105-M01047W

Double Cross Rails System

  • Pic. No.

Finish Part No.

7 Grey 105-M01043G 7 Chrome 105-M01043PC 7 White 105-M01043W 20 Grey 105-M01048G

Parts Required Parts Required

slide-53
SLIDE 53

Installation Dimensions Space Requirement

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-53

Technical Specifications Solid Sectional Dividers System Anti-Slip Mat for 500 mm Drawers

Accessories

Parts Required

  • Pic. No.

Finish Part No.

17 Grey 105-M01071G 17 White 105-M01071W 18 Grey 105-M01072G 18 White 105-M01072W 19 Grey 105-M01073G 19 Chrome 105-M01073PC

19

White 105-M01073W

Finish Part No.

Clear 105-ANTI-CL

Drawer Handle for Internal Drawers with Round Front Cross Rail

Rolls are 1500 mm in length. Cut to size to match drawer width. Finish Part No.

Grey 105-M01022G White 105-M01022W

slide-54
SLIDE 54

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-54 Cutlery Trays For Doublewall Drawers

  • Dim. (W x D)

Part No.

430 x 490 mm 105-M015001G 480 x 490 mm 105-M015002G 530 x 490 mm 105-M015003G 580 x 490 mm 105-M015004G 780 x 490 mm 105-M015005G 880 x 490 mm 105-M015006G

105-M015001G 105-M015002G 105-M015003G 105-M015004G 105-M015005G 105-M015005G

  • Easy-to-access compartments
  • High impact, durable, grey plastic
  • Can be trimmed-to-fit: 2-1/2” (64mm) in width and 3” (76mm) in depth.
  • Depth: 490mm suitable for 500mm Doublewall Drawers

See page D-55 for specific dimensions

  • f Trimmable Range in mm and inches.
slide-55
SLIDE 55

Installation Dimensions Space Requirement

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-55

Technical Specifications Installation Dimensions

Custom Cover Caps with your Company Name/Logo

Custom Cover Caps can be branded with your Company Logo

1. Choose the colour of the cover cap - available in Grey or White.

  • 2. Provide your logo in Adobe Illustrator or EPS vector file (preferred).
  • 3. If not available, provide the largest resolution JPEG or graphic that you can.

We will attempt to create the needed files and show proof.

  • 4. Final logo file is sent to our supplier who will provide detailed drawings showing proposed logo and

dimensions.

  • 5. Customer will provide approval and place an order for minimum 1000 pairs.
  • 6. Estimated time of arrival is 8-10 weeks into your local branch.
  • Promote your brand inside your cabinet

drawers

  • Full approval over process
  • Your logo appears accurate in colour and

appearance

  • Caps available Grey or White

Program Benefits Example - Proof for Approval Example - Final Cover Cap

slide-56
SLIDE 56

Product Numbers

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-56 Undermount Soft-Close Slides

Standard Duty, Full Extension

  • Soft-Close Undermount slide
  • Includes height adjustable locking clip
  • Drawer height adjustment of 0 - 3 mm
  • Tool Free assembly and removal
  • Silent system guarantees smooth no noise operation
  • Limited Lifetime Warranty
  • Load capacity: 25 kg

Drilling Pattern

Length Product No. Load Capacity (kg) Qty

250 mm 105-S10250H 25 10 270 mm 105-S10270H 25 10 300 mm 105-S10300H 25 10 350 mm 105-S10350H 25 10 400 mm 105-S10400H 25 10 450 mm 105-S10450H 25 10 500 mm 105-S10500H 25 10 550 mm 105-S10550H 25 10 600 mm 105-S10600H 25 10

250 270 300 350 400 450 500 550 600

9 9 9 9 9 9 96

250 L 270 L 300 L 350 L 400 L 450 L 500 L 550 L 600 L

37 32 128 160 192 224 23 78 NL

Cabinet edge

Fo urth hole

slide-57
SLIDE 57

Technical Specifications

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-57

Cabinet Depth Dimensions Cabinet Width Dimensions

LW 37 SKW=LW-42 Max 16 M a x 1 3 Min 6 12 26.5 21 SKW=Internal Drawer Width LW=Internal Cabinet Width

Drawer Size and Boring Dimensions

  • 4. For removal, press the release tab and pull out the drawer.
  • 3. Lay the drawer bottom onto the slides, then push the

drawer into the cabinet.

  • 1. Fix the slide to the cabinet.
  • 2. Fix the locking device to the drawer bottom.

Assembly & Removal

Very careful attention must be made to the rear pinhole. A solid and tight connection must be made between slide and box. A straight or angled sawcut may be used as an alternative to the round drill hole. 7 33 6 11 Max 13

75 Min55 NL=Nominal Slide Length LT = Internal Cabinet Depth NL-10 NL LT 37 4

Cabinet edge

min

Standard Drawer: LT = NL + 3 X NL-10+X 37 20

Cabinet edge

min

Internal drawer: LT = NL + 21

slide-58
SLIDE 58

Product Numbers

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-58 Undermount Soft-Close Slides

Drilling Pattern

250 270 300 350 400 450 500 550 600

9 9 9 9 9 9 96

250 L 270 L 300 L 350 L 400 L 450 L 500 L 550 L 600 L

37 32 128 160 192 224 23 78 NL

Cabinet edge

Fo urth hole

Length Product No. Load Capacity (kg) Qty

250 mm 105-SS10-250H 35 10 270 mm 105-SS10-270H 35 10 300 mm 105-SS10-300H 35 10 350 mm 105-SS10-350H 35 10 400 mm 105-SS10-400H 35 10 450 mm 105-SS10-450H 35 10 500 mm 105-SS10-500H 35 10 550 mm 105-SS10-550H 35 10 600 mm 105-SS10-600H 35 10

Heavy Duty, Full Extension

  • Heavy Duty Soft-Close Undermount slide
  • Includes height adjustable locking clip
  • Drawer height adjustment of 0 - 3 mm
  • Tool Free assembly and removal
  • Silent system guarantees smooth no noise operation
  • Limited Lifetime Warranty
  • Load capacity: 35 kg
slide-59
SLIDE 59

Technical Specifications

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-59

  • 4. For removal, press the release tab and pull out the drawer.
  • 3. Lay the drawer bottom onto the slides, then push the

drawer into the cabinet.

  • 1. Fix the slide to the cabinet.
  • 2. Fix the locking device to the drawer bottom.

Cabinet Depth Dimensions Cabinet Width Dimensions Drawer Size and Boring Dimensions Assembly & Removal

LW 37 SKW=LW-42 Max 16 M a x 1 3 Min 6 12 26.5 21 SKW=Internal Drawer Width LW=Internal Cabinet Width 7 33 6 10 11 Max 13 M i n 5 5 75 NL=Nominal Slide Length LT = Internal Cabinet Depth NL-10 NL LT 37 4

Cabinet edge

min

Standard Drawer: LT = NL + 3 X NL-10+X 37 20

Cabinet edge

min

Internal drawer: LT = NL + 21

Very careful attention must be made to the rear pinhole. A solid and tight connection must be made between slide and box. A straight or angled sawcut may be used as an alternative to the round drill hole.

slide-60
SLIDE 60

Product Numbers

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-60 Undermount Push System Slides

Standard Duty, Full Extension Drilling Pattern

Length Product No. Load Capacity (kg) Qty

250 mm 105-F10-250H 25 10 270 mm 105-F10-270H 25 10 300 mm 105-F10-300H 25 10 350 mm 105-F10-350H 25 10 400 mm 105-F10-400H 25 10 450 mm 105-F10-450H 25 10 500 mm 105-F10-500H 25 10 550 mm 105-F10-550H 25 10 600 mm 105-F10-600H 25 10

250 270 300 350 400 450 500 550 600

9 9 9 9 9 9 96

250 L 270 L 300 L 350 L 400 L 450 L 500 L 550 L 600 L

37 32 128 160 192 224 23 78 NL

Cabinet edge

Fo urth hole

  • Push System Undermount slide
  • Includes height adjustable locking clip
  • Drawer height adjustment of 0 - 3 mm
  • Tool Free assembly and removal
  • Silent system guarantees smooth no noise operation
  • Limited Lifetime Warranty
  • Load capacity: 25 kg
slide-61
SLIDE 61

Technical Specifications

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-61

Cabinet Depth Dimensions Cabinet Width Dimensions Drawer Size and Boring Dimensions

  • 4. For removal, press the release tab and pull out the drawer.
  • 3. Lay the drawer bottom onto the slides, then push the

drawer into the cabinet.

  • 1. Fix the slide to the cabinet.
  • 2. Fix the locking device to the drawer bottom.

Assembly & Removal

LW 37 SKW=LW-42 Max 16 M a x 1 3 Min 6 12 26.5 21 SKW=Internal Drawer Width LW=Internal Cabinet Width

Very careful attention must be made to the rear pinhole. A solid and tight connection must be made between slide and box. A straight or angled sawcut may be used as an alternative to the round drill hole. 7 33 6 11 Max 13

75 Min55

NL=Nominal Slide Length LT = Internal Cabinet Depth

min

Standard Drawer: LT = NL + 3 Standard drawer NL-10 NL LT

Must leave 3mm clearance for Push-to-Open to function.

37 4

Cabinet edge

min

Internal drawer: LT = NL + 21 X NL-10+X Inner drawer 37 20 Cabinet edge

Must leave 3mm clearance for Push-to-Open to function.

slide-62
SLIDE 62

Product Numbers

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-62

Drilling Pattern

Length Product No. Load Capacity (kg) Qty

250 mm 105-FF10-250H 35 10 270 mm 105-FF10-270H 35 10 300 mm 105-FF10-300H 35 10 350 mm 105-FF10-350H 35 10 400 mm 105-FF10-400H 35 10 450 mm 105-FF10-450H 35 10 500 mm 105-FF10-500H 35 10 550 mm 105-FF10-550H 35 10 600 mm 105-FF10-600H 35 10

Heavy Duty, Full Extension

250 270 300 350 400 450 500 550 600

9 9 9 9 9 9 96

250 L 270 L 300 L 350 L 400 L 450 L 500 L 550 L 600 L

37 32 128 160 192 224 23 78 NL

Cabinet edge

Fo urth hole

Undermount Push System Slides

  • Heavy Duty Push System Undermount slide
  • Includes height adjustable locking clip
  • Drawer height adjustment of 0 - 3 mm
  • Tool Free assembly and removal
  • Silent system guarantees smooth no noise operation
  • Limited Lifetime Warranty
  • Load capacity: 35 kg
slide-63
SLIDE 63

Technical Specifications

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-63

  • 4. For removal, press the release tab and pull out the drawer.
  • 3. Lay the drawer bottom onto the slides, then push the

drawer into the cabinet.

  • 1. Fix the slide to the cabinet.
  • 2. Fix the locking device to the drawer bottom.

Cabinet Depth Dimensions Cabinet Width Dimensions Drawer Size and Boring Dimensions Assembly & Removal

LW 37 SKW=LW-42 Max 16 M a x 1 3 Min 6 12 26.5 21 SKW=Internal Drawer Width LW=Internal Cabinet Width 7 33 6 10 11 Max 13 M i n 5 5 75

NL=Nominal Slide Length LT = Internal Cabinet Depth

min

Standard Drawer: LT = NL + 3 Standard drawer NL-10 NL LT

Must leave 3mm clearance for Push-to-Open to function.

37 4

Cabinet edge

min

Internal drawer: LT = NL + 21 X NL-10+X Inner drawer 37 20 Cabinet edge

Must leave 3mm clearance for Push-to-Open to function.

Very careful attention must be made to the rear pinhole. A solid and tight connection must be made between slide and box. A straight or angled sawcut may be used as an alternative to the round drill hole.

slide-64
SLIDE 64

Product Numbers

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-64 Undermount Soft-Close Slides

Heavy Duty, Full Extension - KV MuV Metric Series

  • Soft-close Undermount slide
  • Includes height-adjustable locking clip
  • Tool-free height adjustment
  • Limited Lifetime Warranty
  • Load capacity: 34 kg

Drilling Pattern

Cabinet Depth Interior Depth Slide Length

Setback 4mm [5/32 in.] Mount Position 37mm [1-7/16 in.] 37mm [1-7/16 in.] 25mm [1 in.]

  • Min. Top Gap

6mm [1/4 in.]

  • Max. Drawer Height=

Opening minus 20mm [13/16 in.] Bottom Recess/ 12.7mm [1/2 in.] Bottom Clearance 14mm [9/16 in.]

Drawer Gap

1mm [1/32 in.]

Variable Setback

Interior Depth Range

A B

64mm [2-1/2 in.] 23mm [29/32 in.]

See chart below See chart below

Drawer Length ±1.5mm

slide-65
SLIDE 65

Technical Specifications

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-65

6mm x 10mm DEEP [1/4 in. x 3/8 in. DEEP] 7mm [9/32 in.] mm Max.

  • in. Max.]

33mm Min. [1-5/16 in. Min.] 6 in.]

Installation Dimensions Drawer Notch & Bore

Cabinet Opening Width

CRITICAL CRITICAL

  • Max. Drawer

Bottom Recess 12.7mm [1/2 in.]

  • Min. Top Opening

Clearance 6.3mm [1/4 in.]

  • Min. Bottom

Opening Clearance 14mm [9/16 in.] Cabinet Opening Width Minus 42mm [1-5/8 in.] = Inside Drawer Width MuV Maximum Drawer Side Material Thickness: 16mm [5/8 in.]

Rear Mounting Hole Pattern

Length Product No. A B Qty

250 mm KMUVB-250 96 mm 96 mm 4 300 mm KMUVB-300 96 mm 128 mm 4 350 mm KMUVB-350 96 mm 128 mm 6 400 mm KMUVB-400 96 mm 128 mm 6 450 mm KMUVB-450 96 mm 128 mm 6 500 mm KMUVB-500 96 mm 128 mm 6 550 mm KMUVB-550 96 mm 128 mm 6

Front Mounting Hole Pattern Part Numbers

37mm

[1-7/16 in.] TYP. 25mm [1 in.] TYP. 9mm [11/32 in.] 9mm [11/32 in.] 37.5mm [1-15/32 in.] 32mm [1-1/4 in.] 9mm [11/32 in.] TYP. 6mm [1/4 in.] 25mm [1 in.] 37mm [1-7/16 in.] 33mm [1-5/16 in.]

slide-66
SLIDE 66

Product Numbers

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-66 Undermount Soft-Close Slides

Heavy Duty, Full Extension - Salice Futura 6555 Series

Length Product No. Load Capacity (kg) Qty

300mm SA6555/30 30 6 350mm SA6555/35 30 6 400mm SA6555/40 30 6 450 mm SA6555/45 30 6 500 mm SA6555/50 30 6 550 mm SA6555/55 30 6 600 mm SA6555/60 30 6

Drilling Pattern

Product No.

SA710.610

Pair of Salice locking clips with tool free integrated height adjustment. Product No.

SA750.010

Pair of Salice locking clips with tool free inte- grated 6-way adjust- ment clip (height, depth and side adjustment).

Locking Clips (sold separately)

Accessories

  • Soft-close Undermount slide
  • Safety system that prevents turning over
  • Locking clip sold separately
  • Tool-free height adjustment of ±2.5 mm
  • Made in Italy
  • Limited Lifetime Warranty
  • Load capacity: 30 kg
slide-67
SLIDE 67

Technical Specifications

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-67

Drawer Size

6-Way Adjustable Clip shown in diagram. Position the left and the right clip at the front of the drawer. Fix with the screws on the bottom or on the front of the drawer.

Rear Hook

Cabinet Dimensions Clip Assembly Drawer Drilling

PM LN

Drawer Abbreviations SP = Thickness of drawer LN = Nominal slide length PM = Depth of cabinet X = Internal width of cabinet

X SP

Drawer Dimensions LC = Runner length - 10mm X-41 = Internal width of drawer The drawer length is 10mm shorter than the runner length The internal width of drawer is 41mm less than the internal width of cabinet.

LC X - 41 20 31.5 21 10-15 X 9.5

Max.

16

Min.5

29 12 41 X - 41

  • Min. 60
  • Min. 33

ø7 x 10 7 11 A LN - 10 LN - 10

  • Min. 33

ø7 x 10 7 11 A SP 85.7 40 23 32 23 7 81.4

slide-68
SLIDE 68

Product Numbers

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-68 Undermount Push System Slides

Heavy Duty, Full Extension - Salice Futura 6557 Series

  • Push-to-Open
  • Safety system that prevents turning over
  • Locking clip sold separately
  • Tool-free height adjustment of ±2.5 mm
  • Made in Italy
  • Limited Lifetime Warranty
  • Load capacity: 30 kg

Drilling Pattern

Length Product No. Load Capacity (kg) Qty

300mm SA6557/30 30 6 350mm SA6557/35 30 6 400mm SA6557/40 30 6 450 mm SA6557/45 30 6 500 mm SA6557/50 30 6 550 mm SA6557/55 30 6 600 mm SA6557/60 30 6

Product No.

SA710.610

Pair of Salice locking clips with tool free integrated height adjustment. Product No.

SA750.010

Pair of Salice locking clips with tool free inte- grated 6-way adjust- ment clip (height, depth and side adjustment).

Locking Clips (sold separately)

Accessories

slide-69
SLIDE 69

Technical Specifications

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-69

6-Way Adjustable Clip shown in diagram. Position the left and the right clip at the front of the drawer. Fix with the screws on the bottom or on the front of the drawer.

Rear Hook

Drawer Size Cabinet Dimensions Clip Assembly Drawer Drilling

PM LN

Drawer Abbreviations SP = Thickness of drawer LN = Nominal slide length PM = Depth of cabinet X = Internal width of cabinet

X SP

Drawer Dimensions LC = Runner length - 10mm X-41 = Internal width of drawer The drawer length is 10mm shorter than the runner length The internal width of drawer is 41mm less than the internal width of cabinet.

LC X - 41 20 31.5 21 10-15 X 9.5

Max.

16

Min.5

29 12 41 X - 41

  • Min. 60
  • Min. 33

ø7 x 10 7 11 A LN - 10 LN - 10

  • Min. 33

ø7 x 10 7 11 A SP 85.7 40 23 32 23 7 81.4

slide-70
SLIDE 70

Product Numbers

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-70 Soft-Close Ball Bearing Slide

Full Extension with Integrated Soft-Close - GSlide 4570 Series

  • 38 mm (1.5”) stroke of soft-close
  • Non handed disconnect release
  • Electro-plated Zinc
  • 12.5 mm (1/2”) side spacing
  • 32 mm system compatible
  • Load capacity: 45 kg

Length Product No. Length (mm) Slide Travel (mm) Load Capacity (kg) Qty

10 in 371-GS4570-10 250 175 20 10 12 in 371-GS4570-12 300 213 20 10 14 in 371-GS4570-14 350 303 25 10 16 in 371-GS4570-16 400 404 30 10 18 in 371-GS4570-18 450 455 35 10 20 in 371-GS4570-20 500 505 40 10 22 in 371-GS4570-22 550 555 45 10 24 in 371-GS4570-24 600 605 35 10 26 in 371-GS4570-26 650 655 35 10 28 in 371-GS4570-28 700 705 35 10

Rear Mounting Bracket for Face Frame

Product No. Qty

371-GS4340-RB 100

Accessories

slide-71
SLIDE 71

Technical Specifications

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-71

Length (in) Length (mm) A B C D E F G

10 in 250 124

  • 96
  • 12 in

300 174

  • 128
  • 14 in

350 96 224

  • 96

192

  • 16 in

400 96 235

  • 166
  • 18 in

450 128 285

  • 128

216

  • 20 in

500 96 160 335 128 266

  • 22 in

550 96 160 385 128 224 316

  • 24 in

600 128 192 435 128 224 366

  • 26 in

650 128 224 416 128 224 320 416 28 in 700 128 224 480 128 224 320 466

192 96 128 96 36 36 36 36 36 36 36 36 36 10” (250) 12” (300) 14” (350) 16” (400) 18” (450) 20” (500) 22” (550) 24” (600) 26” (650) 28” (700) 36 166 216 128 128 266 128 128 128 128 224 224 224 224 316 366 320 416 320 466

slide-72
SLIDE 72

Product Numbers

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-72 Soft-Close Ball Bearing Slide

Full Extension with Integrated Soft-Close - DTC 45571 Series

Length Product No. Length (mm) Slide Travel (mm) Qty

12 in 105-45571-12 300 270 10 14 in 105-45571-14 350 341 10 16 in 105-45571-16 400 400 10 18 in 105-45571-18 450 450 10 20 in 105-45571-20 500 500 10 22 in 105-45571-22 550 550 10 24 in 105-45571-24 600 600 10 26 in 105-45571-26 650 650 10 28 in 105-45571-28 700 700 10

  • Integrated soft-close
  • Non handed disconnect release
  • Electro-plated Zinc
  • 12.7 mm (1/2”) side spacing
  • Round profile
  • System 32mm compatible
  • 45 kg load capacity

NL= Nominal Slide Length LT= Internal Cabinet Depth

52.5

Travel

37

Cabinet Edge

2 LT =NL+4

min

Open Position

slide-73
SLIDE 73

Technical Specifications

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-73

45.6 12.7

4.5x9.3 A B 9.4 15.8 4.5 C D E

Nominal Length (NL)

4.5 6.3 4.5x10.3 6.3 16 16 16 50.5 16 35 6 F 16

Length (in) Length (mm) A B C D E F

12 in 300 224 64

  • 96
  • 14 in

350 256 96 64 128

  • 16 in

400 320 128 64 192

  • 18 in

450 352 160 64 224

  • 20 in

500 416 192 64 256

  • 22 in

550 448 224 64 224 320 24 in 600 512 224 64 224 352 26 in 650 512 224 64 224 352 416 28 in 700 608 224 64 224 352 480

slide-74
SLIDE 74

Product Numbers

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-74 Push System Ball Bearing Slide

Full Extension Slide with Integrated Push - GSlide 4260 Series

  • Push-Open function built into slide
  • Rebounds 2” - 5” when drawer is pushed in
  • Only 3-4 mm required for push-rebound gap
  • Non handed disconnect release
  • Zinc-plated with clear epoxy
  • 12.5 mm (1/2”) side spacing
  • Load capacity: 45 kg

Length Product No. Length (mm) Slide Travel (mm) Load Capacity (kg) Qty

12 in

371-GS4260-12

300 305 25 10 14 in

371-GS4260-14

350 356 35 10 16 in

371-GS4260-16

400 406 40 10 18 in

371-GS4260-18

450 457 45 10 20 in

371-GS4260-20

500 508 45 10 22 in

371-GS4260-22

550 559 40 10 24 in

371-GS4260-24

600 610 40 10 26 in

371-GS4260-26

650 660 35 10 28 in

371-GS4260-28

700 711 35 10

Rear Mounting Bracket for Face Frame

Product No. Qty

371-GS4340-RB 100

Accessories

slide-75
SLIDE 75

Technical Specifications

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-75

Length A B C D E F G H I

12 in

  • 200
  • 14 in

96

  • 256

192

  • 16 in

128

  • 294

224

  • 18 in

96 160

  • 344

288

  • 20 in

96 160 352

  • 394

224 352

  • 22 in

128 192 384

  • 444

224 352

  • 24 in

128 224 416

  • 494

224 352 448 26 in 128 224 416 480

  • 544

224 352 480 28 in 128 224 288 480 544 544 224 352 544

192 128 128 36 36 36 36 36 36 36 36 12” (300) 14” (350) 16” (400) 18” (450) 20” (500) 22” (550) 24” (600) 26” (650) 28” (700) 36 224 288 128 128 352 128 128 128 128 224 224 224 224 128 224 352 352 448 352 480 352 544

slide-76
SLIDE 76

Product Numbers

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-76 Ball Bearing Slides

Full Extension with Overtravel, Ball Bearing Slide

  • Full Extension with 7/8” over travel
  • 32 mm hole pattern
  • Easy Release
  • Zinc Plated
  • Non-handed
  • Hold in feature
  • Load Capacity: 45 kg

Length Product No. Qty

10 in 514-4501-10 20 12 in 514-4501-12 20 14 in 514-4501-14 20 16 in 514-4501-16 20 18 in 514-4501-18 15 20 in 514-4501-20 15 22 in 514-4501-22 15 24 in 514-4501-24 15 26 in 514-4501-26 15 28 in 514-4501-28 15

& Specifications

These products have passed where required ANSI/BIFMA/BHMA/KCMA and LGA DIN 68889

Documation available upon request.

slide-77
SLIDE 77

Technical Specifications

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-77

Accessories

Rear Mounting Bracket

Product No. Qty

514-4501-RBRKT 100

Nominal Length Travel Nominal Length (mm) A B C D E

10 in 10-7/8 in 250

  • 12 in

12-7/8 in 300 224

  • 96
  • 14 in

14-7/8 in 350 224

  • 96

256 16 in 16-7/8 in 400 224 320

  • 128

288 18 in 18-7/8 in 450 224 352

  • 128

320 20 in 20-7/8 in 500 224 416

  • 128

320 22 in 22-7/8 in 550 224 352 448 128 224 24 in 24-7/8 in 600 224 352 480 128 224 26 in 26-7/8 in 650 224 352 544 128 224 28 in 28-7/8 in 700 224 352 544 128 224

slide-78
SLIDE 78

Product Numbers

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-78

Part Numbers and Specifications

  • Epoxy Finish: White
  • Self-closing
  • Double stop positions
  • 2-D front panel adjustment
  • Screw-on bottom panel
  • Lengths: 270-550 mm
  • Load capacity: 25 kg

Product No. Mounting Qty

105-L1M Screw-On 100 pairs 105-L1MM 10mm Dowels 100 pairs 105-L2MC 10mm Expansion Dowels 100 pairs

Product No. Length Side Height Colour Qty

105-F12E-270 270 mm 86 mm White 8 sets 105-F12E-300 300 mm 86 mm White 8 sets 105-F12E-350 350 mm 86 mm White 8 sets 105-F12E-400 400 mm 86 mm White 8 sets 105-F12E-450 450 mm 86 mm White 8 sets 105-F12E-500 500 mm 86 mm White 8 sets 105-F12E-550 550 mm 86 mm White 8 sets

Front Fixing Brackets for 86/150mm Sides

Metalbox Drawer System, 86mm Height Sides

slide-79
SLIDE 79

Technical Specifications

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-79

Travel Calculations

Drawer Front Mounting

Slide Mounting Dimensions 86 mm

slide-80
SLIDE 80

Product Numbers

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-80

Part Numbers and Specifications

Metalbox Drawer System, 150mm Height Sides

  • Epoxy Finish: White
  • Self-closing
  • Double stop positions
  • 2-D front panel adjustment
  • Screw-on bottom panel
  • Lengths: 300-550 mm
  • Load capacity: 25 kg

Product No. Mounting Qty

105-L1M Screw-On 100 105-L1MM 10 mm Dowels 100 105-L2MC 10 mm Expansion Dowels 100

Product No. Length Side Height Colour Qty

105-F14K-300 300 mm 150 mm White 8 105-F14K-350 350 mm 150 mm White 8 105-F14K-400 400 mm 150 mm White 8 105-F14K-450 450 mm 150 mm White 8 105-F14K-500 500 mm 150 mm White 8 105-F14K-550 550 mm 150 mm White 8

Front Fixing Brackets for 86/150mm Sides

slide-81
SLIDE 81

Technical Specifications

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-81

Travel Calculation Slide Mounting Dimensions 150 mm Drawer Front Mounting

slide-82
SLIDE 82

Product Numbers

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-82 Soft-Close Mechanism

Add-on for Metalbox Drawers

Product No. Drawer Length Qty

105-WHC1A 250 - 300 mm 200 105-WHC1 350 - 550 mm 200

  • Smooth soft-close motion
  • Simple and easy to install
  • Works with any drawer length
  • Excellent for retrofitting

37 25 15 A1 B1 37 32 B1 A1

15 5

.

0 5 . 1

Internal Cabinet Drawer Width

15 5

.

54 86 150 32 64 128 A1 54 86 150 B1

Side Height

X Y Z

105-WHC1A 105-WHC1 84 102 X 32 96 Y

Part No.

Z 128 96

All measurements are noted in millimetres (mm).

slide-83
SLIDE 83

Technical Specifications

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-83

Product No. Length Colour Qty

105-HY350 350 mm White 50 105-HY400 400 mm White 50 105-HY450 450 mm White 50 105-HY500 500 mm White 50 105-HY550 550 mm White 50

Round Lateral Rails

Add-on for Metalbox Drawers

  • Compatible with any height sides
  • Sized for any drawer length
slide-84
SLIDE 84

Product Numbers

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-84

  • With stablizing washer for smoother rolling
  • Makes less noise
  • Self-Closing, 3/4 Extension
  • White and Brown Colour. Others by Special Order.
  • Load capacity: 25 kg

Bottom Mount Euro Slides

Length Length (mm) White Product No. Brown Product No. Qty

10 in 250 02-7000-W10 25 12 in 300 02-7000-W12 02-7000-B12 25 14 in 350 02-7000-W14 02-7000-B14 25 16 in 400 02-7000-W16 02-7000-B16 25 18 in 450 02-7000-W18 02-7000-B18 25 20 in 500 02-7000-W20 02-7000-B20 25 22 in 550 02-7000-W22 02-7000-B22 25 24 in 600 02-7000-W24

  • 25

Length Length (mm) White Product No. Brown Product No. Qty

12 in 300 02-7000-W12-PD

  • 100

14 in 350 02-7000-W14-PD 02-7000-B14-PD 100 16 in 400 02-7000-W16-PD 02-7000-B16-PD 100 18 in 450 02-7000-W18-PD

  • 100

20 in 500 02-7000-W20-PD

  • 100

22 in 550 02-7000-W22-PD 02-7000-B22-PD 100

These products have passed where required ANSI/BIFMA/BHMA/KCMA and LGA DIN 68889

Documation available upon request.

Regular Packaging (One slide unit is wrapped together and sold per each) Production Packaging (Cabinet Left (CL), Cabinet Right (CR), Drawer Left (DL) and Drawer Right (DR) packaged sep- arately in 4 boxes of 100 pieces each. Cases will not be broken.)

slide-85
SLIDE 85

Technical Specifications

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-85

Product No.

02-7000-PBR

Rear Mounting Bracket

Product No.

105-WHC1-1

Soft-Close Mechanism

  • Add Soft-close to your Drawers
  • Compatible with 350 to 600 mm slides

Accessories

  • For Face Frame Cabinetry
  • Compatible with most manufacturers
slide-86
SLIDE 86

Product Numbers

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-86 Keyboard Slide

Adjustable Height Ball Bearing Keyboard Slide

  • Hold-in design to prevent bounce back
  • Adjustable Height from 2-29/64” to 3-99/128”
  • 4 fixed adjustable heights
  • Hold-out design holds keyboard open
  • Black Zinc Plated
  • Load capacity: 23 kg

Part Numbers & Specifications

Length Part No, Load Capacity/Kg Qty

15 in 039-3515-B-15 23 kg

slide-87
SLIDE 87

Technical Specifications

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-87

  • Geared and Ungeared
  • For Pedestal or 4 Leg Tables
  • Premium construction
  • Smooth running
  • Made in Canada

Wooden Table Slides

Closed Length Product No. Description Opened Length Width Height Qty

26 in 02-1000 Geared 51-1/2 in 2-13/16 in 2-3/8 in 1 36 in 02-1009 Geared 71-1/2 in 2-13/16 in 2-3/8 in 1 38 in 02-1011 Geared 75-1/2 in 2-13/16 in 2-3/8 in 1 40 in 02-1013 Geared 79-1/2 in 2-13/16 in 2-3/8 in 1 48 in 02-1015 Geared 95-1/2 in 3 in 2-3/8 in 1

For Pedestal Tables

Closed Length Product No. Description Opened Length Width Height Qty

26 in 02-1001 Non-Geared 51-1/2 in 2-5/8 in 2-3/8 in 1 40 in 02-1022 Geared 79-1/2 in 2-13/16 in 2-3/8 in 1

For 4 Leg Tables Geared Non-Geared

slide-88
SLIDE 88

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-88 Spacers

Round Spacers Rectangle Spacers Rectangle Spacers Spacer Blocks

Size Product No. Qty

5/8 in 02-9502 100 7/8 in 02-9504 100

Size Product No. Qty

3/4 in 02-9503 1000 1 in 02-9505 1000

Size Product No. Qty

1/2 in 02-9509 100

Size Product No. Colour Qty

25 mm 105-M001G Grey 400 25 mm 105-M001W White 400

  • 32mm System compatible
  • 25mm (1”) Depth
  • Matches drawer system/slide mounting holes
slide-89
SLIDE 89

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-89 Soft-Close Mechanism

Add-on for Bottom Mount Euro Slides

Slide Length Product No. Qty

350 - 600mm 105-WHC1-1 200

  • Smooth soft-close motion
  • Excellent for retrofitting
  • Simple and easy to install
  • Compatible with most manufacturers
  • Intended for 350-600mm length

96 96 32 37 16 64 102 A H 64

12 5

.

0 5 .

12 5

. Internal Cabinet Drawer Width

A(mm) H(mm) 14.5 13 37 35.5

slide-90
SLIDE 90

03-2015

www.marathonhardware.com 1-800-840-1228 1-800-465-8665 info@marathonhardware.com Western Canada Ontario and East

DRAWER SYSTEMS AND SLIDES

C-90 Rear Mounting Brackets for Face Frame

For 371-GS4260 / 371-GS4570 Series Slides For 514-4501 Series Slides

Product No. Qty

371-GS4340-RB 200

Product No. Qty

514-4501-RBRKT 100

3.54 in. [90 mm] 1.08 in. [27.2mm] 1.89 in. [48.1mm]

For Bottom-Mount Euro Slides

Product No. Qty

02-7000-PBR 100
