By E.M.S KEY FEATURES DUAL REAL-TIME DISPLAYS TWO INDIVIDUAL MACHINES TWINLINE CABLE ASSIST INCREASED SAFTERY FACTOR SAFE SHIFTING AND DISCONNECTING PROCESSES SWIVELLING LOWER BLOCKS CONSTANT TENSION SYSTEM ALLOWING

SLIDE 1

By E.M.S

SLIDE 2

KEY FEATURES

 DUAL REAL-TIME DISPLAYS  TWO INDIVIDUAL MACHINES  TWINLINE CABLE ASSIST – INCREASED SAFTERY FACTOR  SAFE SHIFTING AND DISCONNECTING PROCESSES  SWIVELLING LOWER BLOCKS  CONSTANT TENSION SYSTEM ALLOWING STABILITY FOR WORKING WHEN MACHINE TRACKS AT REST . BRAKES NEVER APPLIED UNLESS SHUTDOWN OR EMERGENCY STOP ACTIVATED BRAKES APPLIED PRGORESSIVELY NOT ON /OFF AVOIDING SHOCK LOADING CERTIFIED TO INTERNATIONAL SAFETY STANDARDS WITH 5:1 SAFETY FACTOR

SLIDE 3

DUAL REAL-TIME IN INTERCHANGEABLE DIS ISPLAYS

 Real-time monitoring

SLIDE 4

The Break‐away system functions by pulling and triggering an on board switch if the winch machine creeps forward while in operation. This is achieved by anchoring one end of the break‐away line to a stump or stake firmly placed in the ground behind the winch machine. In the event the break‐away switch is triggered, an alarm will sound in the SSM machine and park brakes will be dynamically applied.

BREAK-AWAY (M (MOVEMENT) SWITCH

SLIDE 5

Dual shackle attachment to the tethered machine.

DUAL SHACKLE ATTACHMENT

SLIDE 6

By E.M.S - Electrical & Machinery Services Ltd - Rotorua, New Zealand
