S TA N D A R D S A S D R I V E RS O F I N N O VAT I O N

BUILDING DESIGN, INNOVATION AND TECHNOLOGY IN HOUSING

• AR. MARIA BENITA O. REGALA, FUAP, ASEAN ARCHITECT

DEPARTMENT MANAGER NATIONAL HOUSING AUTHORITY

WHAT IS INNOVATION

• Innovation refers to an idea, embodied in a technology, product, or

process, which is new and creates value. To be impactful, innovations must also be scalable, not merely one-off novelties. The Strategy for American Innovation” focuses on two broad categories

• f innovation:
• Innovation to drive economic growth and address national priorities
• Institutional and public sector innovation
• ( Kent Shigetomi, Office of the U.S. Trade Representative to Apec, Lima,

Peru )

STANDARDS DRIVE INNOVATION

• Performance Based
• Facilitate Market Access
• Improve quality and Market Reputation
• Intellectual Property Rights
• Minimum Quality
• Safety Requirements
• Interoperability
• ( Standards Council of Canada)

AITECH Accreditation Certificate

compliance to codes

Physical properties are

environmentally sound

lower cost of construction

Structurally sound

Materials are Locally available

Faster construction time

BENEFITS OF THE ACCREDITATION SYSTEM /CERTIFICATION

• Government Recognition/ Requirement for government

financing

• Helps provide access to market
• Helps increase public confidence
• Reduces uncertainties on the product
• Creates opportunities for improvement through monitoring and

feedback from the market/industry

• A. Materials
• B. Complete Building System
• C. Wall System
• C. Floor / Roof Framing System
• A. Roofing Sheets
• B. Septic Tanks

NEW MATERIALS AND TECHNOLOGIES

INTERIOR WALL

LIGHTWEIGHT PARTITION PANEL

LIGHT METAL CEILING FRAMES

METAL FRAMING

DRYWALL PARTITION

METAL FURRING

FLOOR AND ROOF DECK SYSTEM

T-JOIST AND ROOF DECK SLAB

ROOF

BITUMINOUS ROOFING SHEET

AITECH ACCREDITED TECHNOLOGIES FOR BUILDINGS

USED IN NHA LOW RISE BUILDING PROJECTS AND OFFICES

SUMMARY OF LRB PROJECTS USED AS REFERENCE

PROJECT/ LOCATION TOTAL NO. OF UNITS NO OF UNITS WITH TECHNOLOGY

• NO. OF UNITS

USING CONVENTIONAL SYSTEM Caloocan City 3,720 2,400 1,320 Quezon City 1,680 960 720 Valenzuela City 2,474 2,474 Malabon 180 180 Mandaluyong 68 68 San Jose Del MOnte 1,788 600 1,188 Manila 240 240 PASIG 780 420 360 TOTAL 10,930 4,380 6,550

• No. of Bldgs. : 10
• No. of Units : 1,200

11

• No. of Bldgs. : 10
• No. of Units : 600

12

HOUSING TECHNOLOGY RESOURCE AND EXHIBIT CENTER BUILDING ROOFING BY ONDULINE WALLS BY SRC PANEL SYSTEM

SRC WALL PANEL HOUSING TECHNOLOGY RESOURCE AND EXHIBIT CENTER BUILDING

ONDULINE ROOFING

NHA STAFF HOUSE

HOUSING TECHNOLOGY RESOURCE AND EXHIBIT CENTER BUILDING USING AITECH ACCREDITED PPST

In the aftermath of Typhoon Yolanda, many new technologies were submitted to the Aitech Committee for accreditation. To date there are 66 accredited technologies. List of accredited

technologies can be found in our website : nha.gov.ph

Likewise in view of the new climatic conditions, structural standards must comply with the new parameters for

• construction. A technical working group on disaster resiiency was

formed by the NHA to arrive at new design parameters for housing.

DESIGN PARAMETER ONE-STOREY TWO- STOREY 3-STOREYS OR MORE WIND LOAD 250 KPH 250 KPH 250 KPH STRENGTH OF WALL AND SUPERSTRUCTURE 3,000 PSI 3,000 PSI 3,000 PSI SOIL BEARING CAPACITY 95 KPA 95 KPA 95 KPA SEISMIC LOAD ZONE 4 ZONE 4 ZONE 4 LOADINGS 50 PSF 50 PSF 50 PSF FIRE RESISTANCE 2 HOURS 2 HOURS 2 HOURS

MODEL PROPONENT/ AGENCY COST PER UNIT

• 1. 22 sq.m. with Loft

Rowhouse for Typhoon Yolanda Victims NHA Php219,723.63

• 2. 2 Storey LRB

Architectural Design by NHA Structural Design by DPWH For Estimate

• 3. 3 Storey LRB

Architectural Design by NHA Structural Design by DPWH For Estimate

• 4. 28.40 sq.m. Rowhouse for

Typhoon Yolanda Victims Goldenville Realty Dev’t. Corp. Php194,790.96

• 5. 27 sq. m. Single Detached

(Bamboo House) - Palawan Habitat for Humanity Philippines Php 225,121.95

22.00 SQM LOFTABLE ROWHOUSE

22.00 sq.m. LOFTABLE ROWHOUSE FOR TYPHOON YOLANDA VICTIMS

Proposed Lot Size: 40.00 sq.m. (4.00 m x 10.00 m) Floor Area: 22.00 sq.m. (4.00 m x 5.50 m)

FLOOR PLAN

26.00 SQM ROWHOUSE

26.00 sq.m. ROWHOUSE (AITECH)

Proposed Lot Size: 40.00 sq.m. (4.00 m x 10.00 m) Floor Area: 26.00 sq.m. (4.00 m x 6.50 m)

FLOOR PLAN

28.40 SQM ROWHOUSE WITHOUT LOFT

28.40 sq.m. ROWHOUSE (AITECH)

Proposed Lot Size: 40.00 sq.m. (4.00 m x 10.00 m) Floor Area: 26.00 sq.m. (4.00 m x 6.50 m) Provision for T&B: 2.40 sq.m (1.20 m x 2.00 m) TOTAL FLOOR AREA: 28.40 sq.m

FLOOR PLAN

25

MODEL PROPONENT/ AGENCY COST PER UNIT

• 1. Proposed Duplex

Housing Plan for Yolanda Rehabilitation – Philippine Red Cross Lot Area = 50 sq.m. House Area = 21 sq.m. Jose Cris Builders Php150,127.98

• 2. Proposed 22 sq.m.

Lofted Rowhouse for Typhoon Yolanda Victims Jose Cris Builders 200,000.00

• 3. Proposed 28.60 sq.m.

Bungalow Design as Another Option for Permanent Housing – Yolanda Project PermaForms Inc. / Realm Homebuilders Incorporated Php196,244.32

• 4. 22 sq.m. Rowhouse

with Loft Provision PermaForms Inc. / Realm Homebuilders Incorporated Php195,000.09

26

MODEL PROPONENT/ AGENCY COST PER UNIT

• 5. 22 sq.m. Loftable

Rowhouse Nedsteel Construction and Development Corporation (NCDC) End Unit = Php158,439.47 Regular Unit = Php136,038.17

• 6. 26 sq.m. Single Storey

Row House Nedsteel Construction and Development Corporation (NCDC) Php 194,999.31

• 7. 22 sq.m. Loftable Row

House for Typhoon Yolanda Victims Ecostrong Builders Corporation Regular Unit = Php 170,501.92 End Unit (Stand alone) = Php 214,419.28

• 8. 22 sq.m. Loftable Row

House

• E. Florentino3 +

Associates Php 187,716.30

• 9. 26 sq.m. Single Storey

Row House With Bedroom SKS Construction and Development Corporation Regular Unit = Php 194,999.88

• 10. 26 sq.m. Single Storey

Row House Without Bedroom SKS Construction and Development Corporation Regular Unit = Php 192,363.82

27 TECHNOLOGY NAME OF PROPONENT STATUS

• 1. FENA Roof Anchor

System (Alternative to J-Bolt) ARCHITECT FRANCISCO J. NAKPIL Technology is found technically appropriate to make roofing structures resilient; DPWH interposes no objection to its use as an alternative material

• 2. Rib-type galvanized

iron roofing and Hook- type bolt ROBIG BUILDERS AND DEVELOPMENT CORPORATION Approved by the DPWH

• 3. Onduline Roofing

Material OFIC PHILIPPINES, INC. Approved by the DPWH for use as alternative to G.I. Roofing

CHALLENGES ENCOUNTERED IN USING NEW TECHNOLOGIES

• not yet so widely accepted by the public; not attuned to culture
• warranties sometimes are not assured and even the capability to do it
• n a mass scale
• builders are not well trained on the construction methodology

especially so if the don’t own the technology

• results to material wastage instead of savings
• delays in construction
• substandard or poor quality of construction
• closed systems do not allow for future expansion or use in combination

with other materials

Memorandum Circular 2016-020 : Guidelines Using AITECH Accredited and New Technologies approved on 27 January 2016. Construction Checklist/Guidelines for the following technologies, completed by January 2016

• The conduct of the Hands-On Training Seminar was created

to educate NHA technical staff and

• ther

developers/contractors

• n

the proper construction methodologies of DPWH-approved housing models with AITECH accredited technologies/systems/building materials for typhoon reconstruction projects and other NHA projects.

Hands On Training for 186 Technical personnel completed as of EO June 2016, including Iloilo for 33 personnel conducted on 29 June to 01 July 2016 done in coordination with technology proponents, to ensure proper installation and methodology Construction Checklist/Guidelines for New Technologies being applied in Typhoon Yolanda Rowhouse projects completed by EO January 2016.( defined what items should be prepared prior to, during and after construction) Continuous monitoring of performances by contractors using such technologies as a regular part of due diligence ( CPES and AITECH Monitoring Team )

TECHNOLOGY USED

• NO. OF HOUSING

UNITS

IN % PERMAFORMS

19,043 46%

NEDSTEEL

19,715 47%

SKS/TAC SYSTEM

3,000 7%

• NO. OF UNITS USING AITECH

ACCREDITED TECHNOLOGY

41,758

100%

BREAKDOWN OF UNITS

OUT OF THE 133,000 HOUSING PRODUCTION TARGET FOR YOLANDA, 31.40% OF THE TOTAL UTILIZED NEW TECHNOLOGIES,

Day 1 : Lecture Day 2 : Actual Demo

• n Site

Day 3 : Wrap Up and Graduation

34

Phase 2: Held at the NHA Samar- Leyte Project Office, Sagkahan, Tacloban City Partner technical providers:

• Permaforms Inc.
• Nedsteel

Construction & Dev’t. Corp.

• United Steel Technology

International Corp.

35

Phase 3: Held at the NHA Bacolod Project Office, Bacolod City Partner technical providers:

• Permaforms Inc.
• Central Lumber Corporation
• United Steel Technology

International Corp.

36

Phase 4: Held at the NHA Main Office, Elliptical Road, Diliman, Quezon City, for Eco-Key System Partner technical providers:

• Paligid Development Corporation

37

Phase 5 :Held at Iloilo City for the NHA Iloilo and Cebu Yolanda Projects Partner technical providers:

• Permaforms Inc.
• Nedsteel Construction and

Development Corporation

• United Steel Technology

International Corp.

• Proponents of new technologies must ensure that their products are

properly used by builders to protect their reputation and the interest of the public in general

• The proponents must allocate funds for the transfer of the technology

to end users as part of their marketing cost, and also to promote them and enable the use on a mass scale to speed up constructioN.

• Developers/Contractors must ensure that they are well versed with the

technology prior to their application to avoid construction errors/ bad construction

• Government testing centers must likewise be improved for better

quality control and calibration and must allocate funds for such improvements and conduct researches towards this end.

• APPROPRIATEFUNDS / BUDGET MUST BE ALLOCATED FOR R&D

• Integration of the resiliency principles/ guidelines on design and

construction in our building code which is presently being reviewed by the DPWH Board of Consultants and its various referral codes ( architectural, engineering/structural, sanitary, electrical and mechanical, fire, etc.)

• Review of local laws pertaining to settlements and recommend

proposals for a typhoon/earthquake code on specific areas that are disaster prone/or are in extreme environments

• Review of processes and procedures to ensure compliance to

resiliency guidelines: who will check ? Are they technically competent? Training for regulators and implementors alike is critical

• Resiliency is not just about strength of buildings but also
• n the location/choice of sites and on the way they are

planned.

• It is also about building the resiliency of communities

who are directly affected by calamities and the effects of climate change. Therefore community/housing development programs must always be geared towards this direction.

• Multi-stakeholder

participation is indeed and truly a must in any endeavor both by government and the private sector, even with the use

• f

new technologies to achieve resiliency in our buildings and communities (direction setting, program

• wnership

issues, end- user education, experts advise, policy related matters, etc.)

Government as policy maker Local government units as frontliners

Communities/en d users

Manufacturers/su ppliers Private sector/developers /contractors
