BUCKROE BOARDWALK Repairs, Renovation, & Extension 11 September 2019 OVERVIEW Current conditions + scope Design options + costs Overall plan + common design features 3 Options for existing boardwalk 3 Options for southern

slide-1
SLIDE 1

BUCKROE BOARDWALK

Repairs, Renovation, & Extension

11 September 2019

slide-2
SLIDE 2

OVERVIEW

  • Current conditions + scope
  • Design options + costs
  • Overall plan + common design features
  • 3 Options for existing boardwalk
  • 3 Options for southern section/extension
  • Recommendations
  • Next Steps
  • Questions
slide-3
SLIDE 3

current CONDITIONS

slide-4
SLIDE 4

current CONDITIONS

slide-5
SLIDE 5

SCOPE

  • Repair items identified by Hampton Public Works
  • Evaluate structural integrity of seawall
  • Repairs to seawall, boardwalk, and masonry planters
  • Extend boardwalk south to James T. Wilson Fishing Pier
  • Provide ADA accessible design improvements
  • Provide increased seating options along boardwalk
  • Evaluate lighting
  • Design to reduce sand buildup on boardwalk
  • Identify planting opportunities & low-maintenance plantings
  • Evaluate option for removing existing seawall and building

raised boardwalk

slide-6
SLIDE 6

DESIGN: overall plan

slide-7
SLIDE 7

DESIGN: amenities

Proposed Boardwalk Bench Proposed Boardwalk Garbage Bin Proposed LED Lighting

slide-8
SLIDE 8

DESIGN: plantings

Shade Tree Live Oak Evergreen Tree Japanese Black Pine Flowering Tree Crepe Myrtle Ornamental Grass Salt Meadow Hay Ornamental Grass Blue Switchgrass Ornamental Grass Coastal Panic Grass

slide-9
SLIDE 9

DESIGN: seawall

Decorative Seawall Option 1 Decorative Seawall Option 2 Decorative Seawall Option 3

slide-10
SLIDE 10

DESIGN: pedestrian beach access

Proposed Pedestrian Access Ramp Placement = every 200’ Existing Steps

slide-11
SLIDE 11

DESIGN: options

Existing boardwalk

  • Repair
  • Reconstruction
  • Raised*

Southern section/extension

  • Streetscape
  • Composite
  • Seawall + streetscape
slide-12
SLIDE 12

DESIGN: northern section

Repair Option Reconstruction Option

slide-13
SLIDE 13

DESIGN: buckroe park section

Repair & Reconstruction Option

slide-14
SLIDE 14

COSTS

northern & buckroe park sections Repair Reconstruction $3,675,000 $6,000,000

Includes improvements to concrete seawall (+ seating), boardwalk surface, planters, ADA accessibility, replacement of lighting, plantings Major cost difference between ‘Repair’ & ‘Reconstruction” is the concrete seawall cap & the boardwalk surface reconstruction

30 yrs 50 yrs

slide-15
SLIDE 15

DESIGN: southern section/extension

Streetscape Concept Composite Concept

slide-16
SLIDE 16

COSTS

southern section/extension Streetscape Composite Seawall + Streetscape $400,000 $525,000

Realignment of seawall will take approx. 6’ – 8’ of beach

$1,100,000

slide-17
SLIDE 17

DESIGN: raised boardwalk

Northern Section (below) Southern Section (above) Buckroe Park Section (above)

slide-18
SLIDE 18

COSTS: raised boardwalk

Raised $18,400,000

  • Raised approx. 5’6” above ground level, with additional 3’

railing on top

  • Width ranges from 12’ – 41’ dependent upon section
  • Access onto and off of is more challenging
  • Creates visual barrier between park and beach

75 yrs

slide-19
SLIDE 19

planned FUNDING

Capital Funding for ‘Enhanced Park Maintenance & Buckroe Boardwalk’

FY 20 FY 21 FY 22 $1,000,000 $3,000,000 $2,000,000 $6,000,000

for total project

  • Can shift funding to necessary fiscal year
  • Can supplement with PRLS capital funding
slide-20
SLIDE 20

COSTS

northern & buckroe park sections Repair Reconstruction Raised $3,675,000 $6,000,000 $18,400,000

Includes improvements to concrete seawall (+ seating), boardwalk surface, planters, ADA accessibility, replacement of lighting, plantings Major cost difference between ‘Repair’ & ‘Reconstruction” is the concrete seawall cap & the boardwalk surface reconstruction

30 yrs 50 yrs 75 yrs

slide-21
SLIDE 21

COSTS

southern section/extension Streetscape Composite Seawall + Streetscape $400,000 $525,000

Realignment of seawall will take approx. 6’ – 8’ of beach

$1,100,000

slide-22
SLIDE 22

RECOMMENDATION

Reconstruction Seawall + Streetscape $6,000,000 $1,100,000 50 yrs 75 yrs $7,100,000

for total project

  • Structural, aesthetic, and accessibility improvements
  • Consistent with character of neighborhood, uniform look and

enhanced durability

  • Divvied out into 2 components for permitting purposes if

choosing to realign seawall

  • $1.1 million over the allotted funding/augment with PRLS

maintenance funds

slide-23
SLIDE 23

NEXT STEPS

Meet with Community Phasing Plan for Construction Phase 1: Buckroe Park Future Phases: Construction Document Prep & Permitting ITB for Construction Contract Complete Phase 2: Construction begins

Tentative September 2019 November 2019 June 2020 August 2020 December 2019 – May 2020 September 2020 Complete Pre Summer 2020

slide-24
SLIDE 24

Questions?
