Browser Enhancements to Help Improve Page Load Performance Using Delta Delivery W3C Performance Working Group November 8th, 2012 Robert Hundt (rhundt@google.com) Mark Heffernan (meheff@google.com) Ian Flanigan (flan@google.com) Google

slide-1
SLIDE 1

Google Confidential and Proprietary

Browser Enhancements to Help Improve Page Load Performance Using Delta Delivery

W3C Performance Working Group November 8th, 2012 Robert Hundt (rhundt@google.com) Mark Heffernan (meheff@google.com) Ian Flanigan (flan@google.com)

slide-2
SLIDE 2

Google Confidential and Proprietary

Every day Gmail subjects users to a combined 61 years of this...

slide-3
SLIDE 3

Google Confidential and Proprietary

Initial Load

Initial load latency: Time from the user starting to navigating to App to rendering complete. Gmail, Docs, Sheets

  • Median: Low seconds

90%'ile: Low 10's of seconds 99%'ile: Low minutes (in slow geographies) Initial load is by far the slowest action our users commonly perform.

slide-4
SLIDE 4

Google Confidential and Proprietary

Initial Load

Robert's Goals

  • Bring initial load to < 1 sec at median
  • Stretch: Bring initial load to < 1 sec at 90%-tile
slide-5
SLIDE 5

Google Confidential and Proprietary

Initial Load

Robert's Goals

  • Bring initial load to < 1 sec at median
  • Stretch: Bring initial load to < 1 sec at 90%-tile

Ideas in this presentation won't quite get us there, but it'll be a big improvement.

slide-6
SLIDE 6

Google Confidential and Proprietary

Basics of Initial Load (Gmail)

Initial load sequence is complicated!

slide-7
SLIDE 7

Google Confidential and Proprietary

Basics of Initial Load

Three phases: Phase 1 Redirects, establish connection Phase 2 Bootstrap, download resources Phase 3 Execute JS, build view

slide-8
SLIDE 8

Google Confidential and Proprietary

Initial load: Phase 1

Phase 1 Redirects, establish connection Phase 2 Bootstrap, download resources Phase 3 Execute JS, build view

slide-9
SLIDE 9

Google Confidential and Proprietary

Initial load: Phase 1

From navigation start to execution of first byte of JS. Includes redirects, establishing connection(s). Median <2s 90%-tile a few seconds 99%-tile a couple of tens of seconds Measured with W3C Navigation Timing API.

slide-10
SLIDE 10

Google Confidential and Proprietary

Initial load: Phase 2

Phase 1 Redirects, establish connections Phase 2 Bootstrap, download resources Phase 3 Execute JS, build view

slide-11
SLIDE 11

Google Confidential and Proprietary

Initial load: Phase 2

Primarily three components:

  • Main page: bootstrap and userdata (100kB), not cacheable
  • Main Javascript (1.1MB), cacheable
  • Stylesheet (300kB), cacheable
slide-12
SLIDE 12

Google Confidential and Proprietary

Initial load: Phase 2

Main Page

<html> ... <iframe src="..."> <script> ... </script> ... USER DATA ... </html>

Javascript

<html> ... <script> XMLHttpRequest(...) </script> <script> ... </script> </html>

JSON Stylesheet

['6rwewc438gq3', 4, [".G-M5{font-size: 70%;font-family: arial..."], [ ... ] ]

Three resources are downloaded in a cascade:

Files are partitioned into script tags to enable pipelined parsing and execution.

slide-13
SLIDE 13

Google Confidential and Proprietary

Where is the bottleneck?

fast ~1s ~5s ~60s slow

  • Main page dominates faster initial loads.
  • Javascript and stylesheet dominate slower initial loads.
slide-14
SLIDE 14

Google Confidential and Proprietary

Reducing size of Javascript and Stylesheet

  • Server doesn't send the entire resource.
  • Instead, sends only the difference (delta) between what the client

has (in cache or local storage) and the latest version.

  • Delta is encoded with fast, efficient scheme called VCDIFF.
  • Delta can be much smaller than the entire resource

We looked at: RFC3229, SDCH, Bunch of internal implementations, proposals.

slide-15
SLIDE 15

Google Confidential and Proprietary

DeltaJS Basics

Client has Javascript of version X from previous session.

// Version X

function(){var b=null;;function g(){return h.nav

slide-16
SLIDE 16

Google Confidential and Proprietary

DeltaJS Basics

Client starts initial load with request to server.

// Version X

function(){var b=null;;function g(){return h.nav

https://mail.google.com/...

slide-17
SLIDE 17

Google Confidential and Proprietary

DeltaJS Basics

Server response includes the latest version number (Y).

// Version X

function(){var b=null;;function g(){return h.nav

<html> <script> LATEST="Y"; ... </script> </html>

slide-18
SLIDE 18

Google Confidential and Proprietary

DeltaJS Basics

Client requests delta from X to Y.

// Version X

function(){var b=null;;function g(){return h.nav

/mail/u/0/?base=X&ver=Y...

slide-19
SLIDE 19

Google Confidential and Proprietary

DeltaJS Basics

Server computes and returns encoded delta between version X and Y which is much smaller than Y itself.

// Version X

function(){var b=null;;function g(){return h.nav

Delta_X_Y=" cQegGXra9W7L2O PCXp0cQegGXra9 W7L2OPCXp0cQeg GXra9W7L2OPCXp 0..."

slide-20
SLIDE 20

Google Confidential and Proprietary

DeltaJS Basics

Client applies delta updating version X to Y and starts executing version Y.

// Version Y

function(){var c=null;;function f(){return h.nav

slide-21
SLIDE 21

Google Confidential and Proprietary

Or... Speculative All-In-One

Initial server response includes the latest version number (Y), as well as the Delta to Last Used (X).

// Version X

function(){var b=null;;function g(){return h.nav

<html> <script> LATEST="Y"; ... </script> </html> + Delta_X_Y= "...."

slide-22
SLIDE 22

Google Confidential and Proprietary

DeltaJS for Gmail

  • Version-to-versions deltas are ~2% original size (20kB).
  • A whole month's worth of changes is <9% of original size.
slide-23
SLIDE 23

Google Confidential and Proprietary

DeltaJS for Gmail: Impact

Can we estimate the potential benefit? Model:

  • Assume one of the three major

resources (main page, JS, SS) is always on critical path.

  • Simulate reduced download time* of JS

and SS for a large sample of initial loads.

* Time from first byte received to last byte received.

slide-24
SLIDE 24

Google Confidential and Proprietary

DeltaJS for Gmail: Impact

Estimate is conservative: doesn't account for faster main page downloading by no longer sharing bandwidth with JS and SS.

slide-25
SLIDE 25

Google Confidential and Proprietary

DeltaJS for Gmail: Impact

What if JS and SS download times are reduced by 95%?

improvement Median 11% 90%-tile 30% 90%-tile India 48% 99%-tile 42% 99%-tile India 52%

Initial load latency could be reduced by about half for high percentiles!

slide-26
SLIDE 26

Google Confidential and Proprietary

Initial load: Phase 3

Phase 1 Redirects, establish connections Phase 2 Bootstrap, download resources Phase 3 Execute JS, build view

slide-27
SLIDE 27

Google Confidential and Proprietary

Browser Platform Enhancements

Challenge: Avoid regressions on Fast Path We're thinking of 4 key enhancements 1. Sha256, VCDiff in browser 2. Pre-Heat JS engine 3. Protocol Change 4. Streaming VCDiff

slide-28
SLIDE 28

Google Confidential and Proprietary

Browser/Platform Enhancements - 1 / 4

Sha256 in Chrome

  • Hashing 1.1MB JS: ~300ms
  • Hashing 1.1MB C++: ~10ms, 30x faster

Proposal:

  • Expose JS interface to Sha256 (crypto API?)
  • Same thing for VCDIFF
slide-29
SLIDE 29

Google Confidential and Proprietary

Browser/Platform Enhancements - 2 / 4

Pre-Heat Storage / JS engine during connection wait time:

  • Pre-Load - "all" of LocalStorage
  • Pre-Parse - load and pre-parse JS (find function start/end points)
  • Pre-Compile - load, pre-parse, and pre-compile JS

And maybe even:

  • Pre-Run - load, compile, and run. Might introduce fantastically

complicated side-effects.

slide-30
SLIDE 30

Google Confidential and Proprietary

Browser/Platform Enhancements - 3 / 4

Delta-Application via HTTP protocol change (vague idea):

  • Server tells browser to explicitly cache/retain resource, e.g., via

response header X-Delta-Version: 12345abc

  • When requesting (cached) resource, browser adds:

X-Delta-Previous-Version: 12345abc

  • Server returns full resource, or Delta marked as:

Content-Type: delta/x-vcdiff

with additional headers, e.g.: C-Delta-Version: 1ontuhno X-Delta-SHA256: a3498249ebbeec23

  • Big Benefit: Transparent to users (client code)
slide-31
SLIDE 31

Google Confidential and Proprietary

Browser/Platform Enhancements - 4 / 4 Streaming Delta Application

  • Pipeline parallelism between

○ JS download ○ VCDIFF ○ and parsing

  • Modify delta format and add "safe points":

"it is safe to parse/execute up to this point in the

  • riginal/modified resource"
slide-32
SLIDE 32

Google Confidential and Proprietary

  • Thanks. Q / A

4 key proposed enhancements

  • 1. Sha256, VCDiff in browser
  • 2. Pre-Heat JS engine
  • 3. Protocol Change (vague)
  • 4. Streaming VCDiff
