Blowfish Wesley Wigham, Stephen Yingling, Chad Zawistowski Blowfish Block size of 64 bits Key size of 64 bits Feistel Network Complex P-array and S-box initialization Encrypts two entries to replace the next two 16

slide-1
SLIDE 1

Blowfish

Wesley Wigham, Stephen Yingling, Chad Zawistowski

slide-2
SLIDE 2

Blowfish

  • Block size of 64 bits
  • Key size of 64 bits
  • Feistel Network
  • Complex P-array and S-box

initialization

○ Encrypts two entries to replace the next two

  • 16 rounds
slide-3
SLIDE 3

Blowfish (cont.)

  • The function f splits
  • ne of the 32-bit

halves into 4 bytes

  • Each byte is run

through an S-box and then combined through addition/XOR

slide-4
SLIDE 4

Original Implementation

  • Used a for-loop to iterate through the rounds
  • The feistel function was not inlined, and was

called extremely often

  • Generating S-boxes was slow, but was only

performed once

  • Python’s pack and unpack methods were

used for converting between integers and byte arrays

slide-5
SLIDE 5

Original Call Stack

encrypt encrypt_block feistel pack unpack 1x 2x 16x 2x pack 1x

slide-6
SLIDE 6

Timetrial: Original

Encrypting the all-0 bytestring 2.5 million times (3 trials)

  • Average Running Time: 197.279 seconds
  • Total times spent in a selection of functions:

○ feistel = 82.666 secs ○ encrypt_block = 58.479 secs ○ pack = 31.230 secs ○ encrypt = 6.572 secs ○ unpack = 3.892 secs ○ generate S box = 0.002 secs

slide-7
SLIDE 7

Analysis

  • Spends a long time in encrypt_block

○ Mostly in ‘feistel’ ■ The ‘feistel’ function incurs quite a bit of

  • verhead, but is where most processing takes

place ○ Secondarily in ‘pack’ ■ python library call, converts bytearray to integer ■ ‘feistel’ also calls ‘pack’

slide-8
SLIDE 8

Optimized Implementation

  • Did in-place calculations of 2 rounds at once

to avoid left-right swapping overhead

  • Unrolled the rounds’ for-loop
  • Inlined the feistel function to remove calling
  • verhead
  • Within ‘encrypt_block’, replaced calls to

‘pack’ with inline bit operations

slide-9
SLIDE 9

Optimized Call Stack

encrypt encrypt_block 1x 1x 1x inline feistel 16x inline bitshift 2x pack inline pack

slide-10
SLIDE 10

Timetrial: Optimized

Encrypting the all-0 bytestring 2.5 million times (3 trials)

  • Average Running Time: 68.125 seconds
  • Total times spent in a selection of functions:

○ encrypt_block = 46.119 secs ○ encrypt = 6.561 secs ○ pack = 2.249 secs ○ generate S box = 0.012 secs ○ unpack = 0.001 secs

slide-11
SLIDE 11

Results of Changes

  • 2.94x faster overall

○ Switching to manual bitshift operations reduced time in pack by 29 seconds and in unpack by 3 seconds ○ Eliminated significant calling overhead by inlining the feistel function ○ Unrolled the for loop in encrypt_block and saved approximately 12 seconds

slide-12
SLIDE 12

Optimization Lessons

  • Python’s overhead for function calls

becomes significant over billions of calls

  • Python’s struct library is fairly inefficient for

combining bytearrays of known size into integers

slide-13
SLIDE 13

Future Work

  • Replace the remaining pack and unpack

functions with our own conversions

  • Unroll loops within the S box generation

function

slide-14
SLIDE 14

Questions?

?
