Block-Supply Chain: A New Anti- Counterfeiting Supply Chain Using NFC and Blockchain By: Naif Alzahrani Nirupama Bulusu Portland State University Motivation Products Counterfeiting World Health Organization (WHO) 2008 [1]: 30% of

slide-1

SLIDE 1

Block-Supply Chain: A New Anti- Counterfeiting Supply Chain Using NFC and Blockchain

By: Naif Alzahrani Nirupama Bulusu Portland State University

slide-2

SLIDE 2

World Health Organization (WHO) 2008 [1]: 30% of

medical products are counterfeit in developing countries

MarkMonitor, 2011 [2]: counterfeit sales cost about

$135 billion in online shopping

2017: 40–50% of antimalarials are counterfeit in

countries like SoutheastAsia and Africa [3]

Motivation

Products’ Counterfeiting

slide-3

SLIDE 3

Existing Solutions

Existing Approaches Cryptographic Track &Trace

Challenge Response Protocol

slide-4

SLIDE 4

Challenge Response Protocol

Sever Tag

1. Generates a random Challenge

Challenge

4

slide-5

SLIDE 5

Challenge Response Protocol

Sever Tag

1. Generates a random Challenge

Challenge Response Challenge Sign Private key Response 2.

5

slide-6

SLIDE 6

Challenge Response Protocol

Sever Tag

1. Generates a random Challenge

Challenge Response Challenge Sign Private key Response 2. Verify Public key Response 3. Challenge

6

slide-7

SLIDE 7

7

Existing Solutions

slide-8

SLIDE 8

1. Modification

Genuine Product Legitimate Tag

Expiration Date

Modifies Data

8

Counterfeiting Attacks

slide-9

SLIDE 9

2. Cloning

Genuine Product Counterfeit Product Copies and Writes Data

9

Counterfeiting Attacks

slide-10

SLIDE 10

3. Tag Reapplication

Genuine Product Legitimate Tag Counterfeit Product Removes and Reapplies Tag

10

Counterfeiting Attacks

slide-11

SLIDE 11

Block-Supply Chain: decentralized supply chain to:

Track and trace product
Detect:

Modifiction Cloning Tag reapplication

Contribution

slide-12

SLIDE 12

Block-Supply Chain

Initialization Phase Verification Phase

slide-13

SLIDE 13

Initialization Phase

slide-14

SLIDE 14

B0

Manufacturer

Initialization Phase

slide-15

SLIDE 15

slide-16

SLIDE 16

B0 B0 B0 B0 B0 B0

Initialization Phase

slide-17

SLIDE 17

B0 B0 B0 B0 B0 B0

Initialization Phase

slide-18

SLIDE 18

Initialization Phase

B0 B0 B0 B0 B0 B0

slide-19

SLIDE 19

Block-Supply Chain

Initialization Phase Verification Phase

slide-20

SLIDE 20

Verification Phase

B0 B0 B0 B0 B0 B0

slide-21

SLIDE 21

Verification Phase

B1 B1 B1 B1 B1 B1 B0 B0 B0 B0 B0 B0

slide-22

SLIDE 22

Verification Phase

B1 B1 B1 B1 B1 B1 B0 B0 B0 B0 B0 B0

Local Authentication

slide-23

SLIDE 23

B2

Verification Phase

B1 B1 B1 B1 B1 B1 B0 B0 B0 B0 B0 B0

slide-24

SLIDE 24

B2 B2 B2 B2 B2 B2

Verification Phase

B1 B1 B1 B1 B1 B1 B0 B0 B0 B0 B0 B0

slide-25

SLIDE 25

B2

Verification Phase

B1 B1 B1 B1 B1 B1 B0 B0 B0 B0 B0 B0

Global Authentication Global Authentication Global Authentication Global Authentication Global Authentication

slide-26

SLIDE 26

B2

Verification Phase

B1 B1 B1 B1 B1 B1 B0 B0 B0 B0 B0 B0

Global Authentication Global Authentication Global Authentication Global Authentication

B2 Valid?

Global Authentication

slide-27

SLIDE 27

B2

Verification Phase

B1 B1 B1 B1 B1 B1 B0 B0 B0 B0 B0 B0 B2 B2 B2 B2 B2

slide-28

SLIDE 28

1. Trace-and-track products
2. Detects:
Modification
Cloning
Tag reapplication

Local Authentication Global Authentication

+

Verification Phase

slide-29

SLIDE 29

Consensus Protocol

slide-30

SLIDE 30

Existing Protocols

Proof of Work (PoW)

Solve a challenge: compute a cryptographic

hashes

If succeed, submit the block to the network

slide-31

SLIDE 31

Existing Protocols

Proof of Work (PoW)

Issues:
1. Huge computational effort
2. Energy and computing resources

consumption

3. Relies on a few mining pools (raises

doubts on the decentralization)

4. Frequently fork

slide-32

SLIDE 32

Existing Protocols

Fixed-Validators Decentralization

Small fixed number of nodes chosen to be

validators

Proof of Stake (PoS): e.g. the voting power
Committee size —> Computation and

communication overhead

slide-33

SLIDE 33

Existing Protocols

Fixed-Validators Decentralization

Examples:
1. Tendermint
2. Hyperledger Fabric
1/3 byzantine nodes

slide-34

SLIDE 34

Existing Protocols

Fixed-Validators Decentralization

Issues:
1. Strong trust assumption
2. Fixed committee of validators is

vulnerable to adversarial attacks

DoS attack
Powerful adversary can corrupt or

bribe most of them over time

slide-35

SLIDE 35

Existing Protocols

Fixed-Validators Decentralization

Issues:
3. Fairness of selection
4. Small committee + massive number of

transactions —> performance bottleneck

slide-36

SLIDE 36

Design Goals

1. Efficiency:
Small number of validators
2. Security:
Random rotating-validators’ selection
3. Validators’ selection fairness
Selection with equal probability

slide-37

SLIDE 37

New consensus protocol that:

Utilizes different set of validators
n every block proposal
Maintains security by employing

random validators’ selection

Achieves efficiency by employing

small number of validators

Contribution

slide-38

SLIDE 38

Proposed Protocol

Based on Tendermint
Select different set of validators on every

block proposal

Balances between efficiency and security

slide-39

SLIDE 39

Four types of nodes:
1. Proposer: proposes the new block
2. Validation-leader: selects the validators
3. Validator: validates the proposed block
4. Idle: waits for the consensus on the block

Proposed Protocol

slide-40

SLIDE 40

At the genesis state
Each proposer is randomly mapped to a

validation-leader

The validation-leader is activated upon

receiving the block from its proposer

Proposer to validation-leader mapping

Proposed Protocol

slide-41

SLIDE 41

On proposing a new block
Each validation-leader randomly selects Log

n validators

A validator is activated upon receiving a

‘validate’ message from its validation-leader

Validators Selection

Proposed Protocol

slide-42

SLIDE 42

slide-43

SLIDE 43

Evaluation

Security

0.33% random malicious nodes

slide-44

SLIDE 44

Evaluation

Efficiency

slide-45

SLIDE 45

Limitation 1: the number of validators is static

Future solution: dynamic variable number of validators based on a risk likelihood

Limitation 2: Malicious or lazy validation-

leaders Future solution: a game theoretical model to reward and punish validation-leaders

Limitations

slide-46

SLIDE 46

Future Work

Limitation 1: the number of validators is static

Future solution: dynamic variable number of validators based on a risk likelihood

Limitation 2: Malicious or lazy validation-

leaders Future solution: a game theoretical model to reward and punish validation-leaders

slide-47

SLIDE 47

Limitation 1: the number of validators is static

Future solution: dynamic variable number of validators based on a risk likelihood

Limitation 2: Malicious or lazy validation-

leaders Future solution: a game theoretical model to reward and punish validation-leaders

Limitations

slide-48

SLIDE 48

Future Work

Limitation 1: the number of validators is static

Future solution: dynamic variable number of validators based on a risk likelihood

Limitation 2: Malicious or lazy validation-

leaders Future solution: a game theoretical model to reward and punish validation-leaders

slide-49

SLIDE 49

Limitation 3: always-validation mode

Future solution: a game theoretical model to validate with probability according to the proposing node risk likelihood

Limitation 4: validation-leaders know their

proposers in advance Future solution: blind proposers validation- leaders mapping.

Limitations

slide-50

SLIDE 50

Future Work

Limitation 3: always-validation mode

Future solution: a game theoretical model to validate with probability according to the proposing node risk likelihood

Limitation 4: validation-leaders know their

proposers in advance Future solution: blind proposers validation- leaders mapping.

slide-51

SLIDE 51

Limitation 3: always-validation mode

Future solution: a game theoretical model to validate with probability according to the proposing node risk likelihood

Limitation 4: validation-leaders know their

proposers in advance Future solution: blind proposers validation- leaders mapping.

Limitations

slide-52

SLIDE 52

Future Work

Limitation 3: always-validation mode

Future solution: a game theoretical model to validate with probability according to the proposing node risk likelihood

Limitation 4: validation-leaders know their

proposers in advance Future solution: blind proposers validation- leaders mapping.

slide-53

SLIDE 53

Tianks Questjons
