Big Spatial Data Management on Hadoop and Beyond

Ahmed Eldawy Computer Science and Engineering

1

Claudius Ptolemy (AD 90 – AD 168)

Al Idrisi (1099–1165)

Cholera cases in the London epidemic of 1854

Cool computer technology..!! Can I use it in my application? Oh..!! But, it is not made for me. Can’t make use of it as is My pleasure. Here it is. I have BIG data. I need HELP..!!

Kindly let me get the technology you have Kindly let me understand your needs

1969

HELP..!! I have

BIG data. Your

technology is not helping me mmm…Let me check with my good friends there. My pleasure. Here it is. Cool Database technology..!! Can I use it in my application? Oh..!! But, it is not made for me. Can’t make use of it as is

Kindly let me understand your needs Kindly let me get the technology you have

HELP..!! Again, I have BIG data. Your technology is not helping me Sorry, seems like the DBMS technology cannot scale more Let me check with my other good friends there. My pleasure. Here it is. Cool Big Data technology..!! Can I use it in my application? Oh..!! But, it’s not made for me. Can’t make use of it as is

Kindly let me understand your needs Kindly let me get the technology you have

Big Spatial Data Management

Tons of Spatial data out there…

Smart Phones Satellite Images Medical Data Traffic Data Geotagged Microblogs VGI Sensor Networks Geotagged Pictures

26

Spatial Data & Hadoop

Takes 193 seconds Hadoop Spatial Data

points = LOAD ’points’ AS (id:int, x:int, y:int); result = FILTER points BY x < xmax AND x >= xmin AND y < ymax AND y >= ymin;

SpatialHadoop

points = LOAD ’points’ AS (id:int, location:point); result = FILTER points BY Overlap(location, rectangle (xmin, ymin, xmax, ymax));

Finishes in 2 seconds

➔ SpatialHadoop

27

80,000 downloads in one year

Industry Academia

Conducted more than seven

keynotes, tutorials, and invited talks Incubated by Eclipse Foundation and renamed to GeoJinni >500GB public datasets for benchmarking and testing Spatial Language Spatial Indexes Spatial Operations Visualization Students Projects Collaboration

University

• f

Genova

28

The Built-in Approach of SpatialHadoop The On-top Approach

Storage (HDFS) MapReduce Runtime Job Monitoring and Scheduling

Pig Latin Hadoop

Java APIS

User Programs Spatial Modules (Spatial) User Program + MapReduce APIs + Job Monitoring and Scheduling + MapReduce Runtime + Storage +

…

Storage (HDFS) MapReduce Runtime Job Monitoring and Scheduling

Pig Latin Hadoop Java APIS

User Programs

Spatial Indexing Early Pruning Spatial Operators Spatial Language

From Scratch Approach The Built-in Approach (SpatialHadoop)

29

Agenda

The ecosystem of SpatialHadoop

Motivation Internal system design Applications Related work Experiments

Open Research Problems

30

VLDB’13 ICDE’15

SpatialHadoop Architecture

Applications: SHAHED [ICDE’15] – MNTG [SSTD’13, ICDE’14]

TAREEG[SIGMOD’14, SIGSPATIAL’14]

Language

Pigeon [ICDE’14]

Visualization

[VLDB’15, ICDE’16]

ST-Hadoop

Operations

Basic operations – CG_Hadoop [SIGSPATIAL’13]

MapReduce

Spatial File Splitter Spatial Record Reader

Indexing

Grid – R-tree – R+-tree – Quad tree [VLDB’15]

31

Indexing

Applications: SHAHED [ICDE’15] – MNTG [SSTD’13, ICDE’14]

TAREEG[SIGMOD’14, SIGSPATIAL’14]

Visualization

[VLDB’15, ICDE’16]

ST-Hadoop

Operations

Basic operations – CG_Hadoop [SIGSPATIAL’13]

MapReduce

Spatial File Splitter Spatial Record Reader

Language

Pigeon [ICDE’14]

Indexing

Grid – R-tree – R+-tree – Quad tree [VLDB’15]

VLDB’13 ICDE’15

32

Data Loading in Hadoop

Blindly chops down a big file into 128MB chunks Values of records are not considered Relevant records are typically assigned to two different blocks HDFS is too restrictive where files cannot be modified

Input File Data Nodes

128MB 128MB 128MB 128MB

33

Two-layer Index Layout

Global Indexing

Locally Indexed HDFS Bocks Data Nodes Global Index

34

Uniform Grid

Works only for uniformly distributed data

35

R-tree

Read a sample Bulk load the sample into an R-tree

Leaf node capacity C 𝐷 = 𝑙. 𝐶 𝑆 (1 + 𝛽) k: Sample size B: HDFS Block capacity |R|: Input size α: Index overhead

Use MBR of leaf nodes as partition boundaries

36

R-tree

Read a sample Bulk load the sample into an R-tree

Leaf node capacity C 𝐷 = 𝑙. 𝐶 𝑆 (1 + 𝛽) k: Sample size B: HDFS Block capacity |R|: Input size α: Index overhead

Use MBR of leaf nodes as partition boundaries Partition the data

37

R-tree

Read a sample Bulk load the sample into an R-tree

Leaf node capacity C 𝐷 = 𝑙. 𝐶 𝑆 (1 + 𝛽) k: Sample size B: HDFS Block capacity |R|: Input size α: Index overhead

Use MBR of leaf nodes as partition boundaries Partition the data Optional: Build R-tree Local indexes

38

R-tree-based Index of a 400 GB road network

39

Non-indexed Heap File

40

MapReduce Layer

Applications: SHAHED [ICDE’15] – MNTG [SSTD’13, ICDE’14]

TAREEG[SIGMOD’14, SIGSPATIAL’14]

Visualization

[VLDB’15,ICDE’16]

ST-Hadoop [TODS ]

Operations

Basic operations – CG_Hadoop [SIGSPATIAL’13, TSAS]

Indexing

Grid – R-tree – R+-tree – Quad tree [VLDB’15]

Language

Pigeon [ICDE’14]

 Under review Demo paper

MapReduce

Spatial File Splitter Spatial Record Reader

VLDB’13 ICDE’15

41

Map plan – Hadoop

File Splitter Split Number

• f splits

Split Record Reader Record Reader k,v k,v k,v k,v k,v k,v Map Map Map task Map task Input Heap File Spatial File Splitter Filter Function Spatial Record Reader Spatial Record Reader

Map plan – SpatialHadoop

Indexed Input File(s)

…

42

Operations

Applications: SHAHED [ICDE’15] – MNTG [SSTD’13, ICDE’14]

TAREEG[SIGMOD’14, SIGSPATIAL’14]

Visualization

[VLDB’15, ICDE’16]

ST-Hadoop

MapReduce

Spatial File Splitter Spatial Record Reader

Indexing

Grid – R-tree – R+-tree – Quad tree [VLDB’15]

Language

Pigeon [ICDE’14]

Operations

Basic operations – CG_Hadoop [SIGSPATIAL’13]

VLDB’13 ICDE’15

43

Operations Layer

Basic Operations: e.g, Range query and

KNN

Spatial Join Operations Computational geometry operations:

e.g., Polygon Union, Voronoi diagram, Delaunay Triangulation, and Convex Hull

User-defined operations: e.g., kNN join

44

Range Query

Use the global index to prune disjoint partitions Use local indexes to find matching records

45

KNN over Indexed Data

k=3

First iteration runs as before and result is tested for correctness  Answer is incorrect Second iteration processes other blocks that might contain an answer ✓ Answer is correct

46

Spatial Join

Join Directly Partition – Join

47

Spatial Join

Join Directly Partition – Join

Total of 36 overlapping pairs Only 16 overlapping pairs

48

CG_Hadoop

Polygon Union Voronoi Diagram Delaunay Triangulation Skyline Convex Hull Farthest/closest pair

Single Machine Hadoop Spatial Hadoop

29x 260x 1x

• A. Eldawy, Y. Li, M. F. Mokbel, R. Janardan. “CG_Hadoop: Computational Geometry in MapReduce”, ACM SIGSPATIAL’13

49

Convex Hull

Find the minimal convex polygon that contains all points

Input Output

50

Convex Hull in CG_Hadoop

Hadoop SpatialHadoop Partition Pruning Local hull Global hull

51

Visualization

Applications: SHAHED [ICDE’15] – MNTG [SSTD’13, ICDE’14]

TAREEG[SIGMOD’14, SIGSPATIAL’14]

ST-Hadoop

Operations

Basic operations – CG_Hadoop [SIGSPATIAL’13]

MapReduce

Spatial File Splitter Spatial Record Reader

Indexing

Grid – R-tree – R+-tree – Quad tree [VLDB’15]

Language

Pigeon [ICDE’14]

Visualization

[VLDB’15, ICDE’16] VLDB’13 ICDE’15

52

Visualization in HadoopViz

Scatter Plot Road Network Heat Map Satellite Data Vector Map Admin Boundaries The goal of HadoopViz is not to propose new visualization techniques, instead its goal is to scale out existing techniques.

53

Heat Map From 2009 to 2014 Month-by-Month

72 Frames × 14 Billion points per frame Total = 1 Trillion points

Created in 3 hours on 10 nodes instead of 60 hours

54

Abstract Visualization

Input Partition

• 3. plot
• 3. plot
• 3. plot
• 2. Create

canvas

• 2. Create

canvas

• 4. merge
• 4. merge
• 4. merge
• 1. smooth
• 1. smooth
• 1. smooth
• 5. write

Output Image

55

Example: Satellite Data Visualization

• 1. Smooth: Recover holes
• 2. Create Canvas: Initialize a

2D Matrix with zeros

𝟑𝟑 𝟖 𝟐𝟔

• 3. Plot:

Update the matrix

+

• 4. Merge:

Matrix addition

• 5. Write:

Generate the image

56

Example: Road Network Visualization

• 1. Smooth: Merge intersections
• 2. Create Canvas:

Create a blank image

• 3. Plot: Draw

roads as polygons

• 5. Write: Encode as

PNG and write to file

• 4. Merge: Plot an

image on the other

57

Multilevel Images in HadoopViz

Map of California – 2GB Generated in 2 minutes on 10-node cluster instead of one hour

58

Multi-level Visualization

Abstract multi-level visualization algorithm The choice of partitioning technique changes for each zoom level Zoom Level Threshold level 𝑨𝜄 Default Hadoop partitioning Spatial Partitioning 𝒜𝜾 = 𝟐 𝟑 log 𝐶 𝑙 𝑢

B: Block capacity k: Partitioning parameter |t|: Tile size

59

Applications

Visualization

[VLDB’15, ICDE’16]

ST-Hadoop

Operations

Basic operations – CG_Hadoop [SIGSPATIAL’13,]

MapReduce

Spatial File Splitter Spatial Record Reader

Indexing

Grid – R-tree – R+-tree – Quad tree [VLDB’15]

Language

Pigeon [ICDE’14]

Applications: SHAHED [ICDE’15] – MNTG [SSTD’13, ICDE’14]

TAREEG[SIGMOD’14, SIGSPATIAL’14]

VLDB’13 ICDE’15

60

SHAHED – A system for querying and

visualizing spatio-temporal satellite data

http://shahed.cs.umn.edu/

• A. Eldawy et al. “SHAHED: A MapReduce-based System for Querying and Visualizing Spatio-temporal Satellite Data”, IEEE ICDE’15

(Best poster runner-up)

• A. Eldawy et al. “A Demonstration of SHAHED: A MapReduce-based System for Querying and Visualizing Satellite Data”, IEEE

ICDE’15

Visualize animated heat maps

• r still images

Run spatio-temporal selection and aggregate queries

61

TAREEG – Web-based extractor for

OpenStreetMap data using MapReduce

http://tareeg.net/

• L. Alarabi, A. Eldawy, R. Alghamdi, M. F. Mokbel. “TAREEG: A MapReduce-Based System for Extracting Spatial Data from

OpenStreetMap”, ACM SIGSPATIAL’14 ___ “TAREEG: A MapReduce-Based Web Service for Extracting Spatial Data from OpenStreetMap”, SIGMOD’14

62

Agenda

The ecosystem of SpatialHadoop

Motivation Internal system design Applications Related work Experiments

Other research projects Future work

63

Other Big Spatial Data Systems

• A. Eldawy and M. Mokbel. “The Era of Big Spatial Data: A Survey”, Foundations and Trends in Databases 2016

Parallel

ESRI Tools for Hadoop SpatialHadoop is the only extensible system that can be easily expanded by researchers and developers

64

Quad K-d Hilbert 500 1000 1500 2000 2500 RUNNING TIME (SEC)

Experimental Results

Spatial Join Running time with different indexes

0.01 0.1 1 10 100 1 2 4 8 16 64 128

Throughput of Range Query

Hadoop SpatialHadoop

100 200 300

Union Voronoi Skyline Convex Hull Closest Pair Farthest Pair

Speedup of CG_Hadoop

Baseline Hadoop SpatialHadoop

500X 260X

20 40 60

Scatter Plot Roads Heatmap Satellite Vector Map Border Lines

Visualization Speedup

Baseline HadoopViz

48X

65

Agenda

The ecosystem of SpatialHadoop

Motivation System design Applications Related work Experiments

Future directions

66

Future Research Directions

Extend HadoopViz

Interactive visualization Support more case studies

Migrate spatial indexes to Spark to support spatial data mining

• perations

Improve HDFS spatial indexes to support dynamic data

67

Adaptive Multilevel Visualization

Empty tiles Covered by parent data tiles

Data tiles Small data sizes in those areas Not worth of preprocessing Image tiles Big enough to consider preprocessing

Empty tiles No data in there

68

Dynamic Indexes

69

Advanced Analytic Queries

Partitioning Local VD Pruning Vertical Merge Pruning Horizontal Merge Final output

70

Sphinx: Distributed SQL Engine for Big Spatial Data

HDFS

Storage

Spatial Indexes

Query Executor

R-tree Scanner Spatial Join

Query Planner

Range Query Plans Spatial Join Plans

Query Parser

Spatial Data types/ Functions Spatial Indexing Command

Cloudera Impala Sphinx

• A. Eldawy. M. Elganainy, I. Sabek, A. Bakeer, A. Abdelmotaleb, M. F. Mokbel “Sphinx: Distributed Execution of Interactive SQL

Queries on Big Spatial Data”, poster in ACM SIGSPATIAL’15

71

Summary

Indexes Operations Visualization (HadoopViz) Apps

72

Thank You

Questions?

73

A Unified Big Data Interface

Impala Sphinx MLLib

…

HDFS – File System YARN – Resource Manager

Unified Big Data Abstraction

Cost Model Query Optimizer Query Executor

SparkSQL

74

Language

Applications: SHAHED [ICDE’15] – MNTG [SSTD’13, ICDE’14]

TAREEG[SIGMOD’14, SIGSPATIAL’14]

Visualization

[VLDB’15, ICDE’16]

ST-Hadoop [TODS ]

Operations

Basic operations – CG_Hadoop [SIGSPATIAL’13, TSAS]

MapReduce

Spatial File Splitter Spatial Record Reader

Indexing

Grid – R-tree – R+-tree – Quad tree [VLDB’15]

 Under review Demo paper

Language

Pigeon [ICDE’14] VLDB’13 ICDE’15

75

Language (Pigeon)

Hides the complexity of the system with a high level language OGC standard used by Oracle Spatial and PostGIS Extends Pig Latin with OGC-compliant primitives

Spatial data types (e.g., Polygon) Basic operations (e.g., Area) Spatial predicates (e.g., Touches) Spatial analysis (e.g., Union) Spatial aggregate functions (e.g., Convex Hull)

• A. Eldawy and M. F. Mokbel, “Pigeon: A Spatial MapReduce Language”, Demo at IEEE ICDE’14

76

Spatial Data Types

lakes = LOAD ’lakes’ AS (id:int, area:polygon);

Data Loading Range Query

houses_in_range = Filter houses BY Overlap(house_loc, range); nearest_houses = KNN houses WITH_K=100 USING DistanceTo(house_loc, query_loc); lakes_states = Join lakes BY lakes_boundary states BY states_boundary Predicate = Overlap

KNN Spatial Join

77

Spatio-temporal Indexing

Applications: SHAHED [ICDE’15] – MNTG [SSTD’13, ICDE’14]

TAREEG[SIGMOD’14, SIGSPATIAL’14]

Visualization

HadoopViz[VLDB’15]

Operations

Basic operations – CG_Hadoop [SIGSPATIAL’13, TSAS]

MapReduce

Spatial File Splitter Spatial Record Reader

Indexing

Grid – R-tree – R+-tree – Quad tree [VLDB’15]

Language

Pigeon [ICDE’14]

 Under review Demo paper

ST-Hadoop [TODS ]

VLDB’13 ICDE’15

• A. Eldawy, L. Alarabi, M. F. Mokbel. “ST-Hadoop: A MapReduce Framework for Spatial and

Spatio-temporal Data” Submitted to ACM TODS

78

Monthly Indexes

Multiresolution Spatio-temporal Index

2012 2013

jan feb dec jan feb dec jan 366 1 2 365 1 2 31

… … … … …

1

Daily Indexes Yearly Indexes

• A. Eldawy, L. Alarabi, M. F. Mokbel. “ST-Hadoop: A MapReduce Framework for Spatial and

Spatio-temporal Data” Submitted to ACM TODS

2

79

Performance of SHAHED

80

Reference Point

Intersection rectangle Reference point

r s

81

Index building

82

Index Building for NASA Data

83

Related Work

Most techniques for spatial data processing in Hadoop use Hadoop as a blackbox

RQ, KNN and SJMR [Zhang et al’09] R-tree construction [Cary et al’09] KNN Join [Lu et al’12, Zhang et al’12] RNN [Akdogan et al’10] ANN [Wang et al’10]

MD-HBase [Nishimura et al’11]

Framework for multi-dimensional data processing Based on HBase, a key-value store on HDFS Does not support MapReduce programming

84

Map plan – Hadoop

File Splitter Split Number

• f splits

Split Record Reader Record Reader k,v k,v k,v k,v k,v k,v Map Map Map task Map task Input Heap File Spatial File Splitter Filter Function Spatial Record Reader Spatial Record Reader

Map plan – SpatialHadoop

Indexed Input File(s)

…

85

KNN

k=3

SpatialFileSplitter selects the block that contains the query point Map function performs kNN in the selected block Answer is tested for correctness ✓ Answer is correct

86

KNN

k=3

First iteration runs as before and result is tested for correctness  Answer is incorrect Second iteration processes other blocks that might contain an answer

87

Range query

88

K Nearest Neighbor

89

Preliminary Results

90
