Big Data Programming: an Introduction

Spring 2015,

• X. Zhang

Fordham Univ.

Outline

• What the course is about?
• scope
• Introduction to big data programming
• Opportunity and challenge of big data
• Origin of Hadoop
• High-level overview: HDFS, MapReduce,

YARN

Learning Goal

• Understand concepts in distributed

computing for big data

• Able to develop MapReduce programs to

crunch big data

• Able to perform basic management/

administration/troubleshooting of Hadoop cluster

• Able to understand and use tools in Hadoop

ecosystems by self-learning

• final projects/presentations

Prerequisite

• Proficiency in C++, Java or Python

– And being able to pick up a new language quickly

• Familiarity with Unix/Linux systems

– Understanding of Unix file systems, users and permissions… – Basics Unix commands, – Shell scripting: to automate running your programs and collecting results…

What is Big Data

• Data sets that grow so large that they

become awkward to work with using on hand database management tools. (Wikipedia)

Where do they come from?

• New York Stock Exchange: one terabyte of

new trade data per day

• Facebook: 10 billion photos, one petabyte of

storage

• Data generated by machines: logs, sensor

networks, GPS traces, electronic transactions, …

• Have you collected data?

– Network traces projects: Internet measurements…

Multiple of Bytes: decimal prefix

• 1000 kB kilobyte
• 10002 MB megabyte
• 10003 Gb gigabyte
• 10004 TB terabyte
• 10005 PB petabyte
• 10006 EB exabyte
• 10007 ZB zettabyte
• 10008 YB yottabyte

Cost of Storage

• 1991, consumer grade, 1 gigabyte (1/1000 TB) disk

drives, US$2699

• 1995, 1 GB drives, US$849
• 2007: 1 terabyte hard disk, $375
• 2010: 2 terabyte hard disk costs US$200
• 2012: 4 terabyte hard disk US$450, 1 terabyte hard disk

US$100

• 2013: 4 terabyte hard disk US$179, 3 terabyte hard disk

$129, 2 terabyte hard disk $100, 1 terabyte hard disk US $80

• 2014: 4 terabyte hard disk US$150, 3 terabyte hard disk

$129, 2 terabyte hard disk $90, 1 terabyte hard disk US $60

Challenges

• General Problems in Big Data Era:
• How to process very big volume of data in a reasonable amount
• f time?
• It turns out: disk bandwidth has become bottleneck, i.e., hard

disk cannot read data fast enough…

• Solutions: parallel processing
• Google’s problems: to crawl, analyze and rank web pages into giant

inverted index (to support search engine)

• Google engineers went ahead to build their own systems:
• Google File System, “exabyte-scale data management using

commodity hardware”

• Google MapReduce (GMR), “implementation of design pattern

applied to massively parallel processing”

Background: Inverted Index

• Goal: to support search query, where we need to locate

documents containing some given words, and then rank these documents by relevance

• Means: create inverted index, which stores a list of the

documents containing each word

• Example:

Word: Documents where the work appears the Document 1, Document 3, Document 4, Document 5 cow Document 2, Document 3, Document 4 says Document 5 moo Document 7

• 10

Hadoop History

• Originally Yahoo Nutch Project: crawl and index a large number of

web pages

• Idea: a program is distributed, and process part of data stored with

them

• Two Google papers => Hadoop project (an open source

implementation of Distributed File system and MapReduce framework)

• Hadoop: schedule and resource management framework for execute

map and reduce jobs in a cluster environment

• Now an open source project, Apache Hadoop
• Hadoop ecosystem: various tools to make it easier to use
• Hive, Pig: tools that can translate more abstract description of workload

to map-reduce pipelines.

High-level View: HDFS, MapReduce

12

HDFS (Hadoop Distributed File System)

• A file system running on

clusters of commodity hardware

• Capable of storing very large

files

• Optimized for streaming data

access (i.e., sequential reads)

• initial intent of Hadoop for

large parallel, batch processing jobs

• resilient to node failures

through replication

• via replication

HDFS as a file system

• Command line operations:
• hadoop fs -ls (-mkdir, -cd, …)
• hadoop fs -copyFromLocal …
• hadoop fs -copyToLocal …
• Java Programming API:
• open file, close file, read and write

file,… from programs

14

MapReduce

• End-user MapReduce API for programming

MapReduce application.

• MapReduce framework, the runtime

implementation of various phases such as map phase, sort/shuffle/merge aggregation and reduce phase.

• MapReduce system, which is the backend

infrastructure required to run the user’s MapReduce application, manage cluster resources, schedule thousands of concurrent jobs etc.

15

MapReduce Programming Model

16

Input: a set of [key,value] pairs Output: a set of [key,value] pairs

Split

intermediate [key,value] pairs [k1,v11,v12, …] [k2,v21,v22, …] …

Shuffle

Woud Count Example

• Example: Counting number of occurrences of each word in a large collection of

documents.

• pseudo-code:

map(String key, String value): // key: document name // value: document contents for each word w in value: EmitIntermediate(w, "1");

• reduce(String key, Iterator values):

// key: a word // values: a list of counts int result = 0; for each v in values: result += ParseInt(v); Emit(AsString(result));

17

WeatherData Example

• Problem: analyze highest temperature for each year
• Input: a single file contains multiple year weather

data

• Output: [year, highest_temp] pairs

18

Input: [k,v] pairs intermediate: [k,v] pairs Output: [k,v] pairs

Parallel Execution: Scaling Out

A MapReduce job is a unit of work that client/user wants to be performed

• input data
• MapReduce program
• Configuration information

Hadoop system:

* divides job into map and reduce tasks. * divides input into fixed-size pieces called input splits, or splits. * Hadoop creates one map task for each split, which runs the user-defined map function for each record in the split

19

MapReduce and HDFS

Parallism of MapReduce + very high aggregate I/O bandwidth across a large cluster provided by HDFS => economics of the system are extremely compelling – a key factor in the popularity of Hadoop. Keys: lack of data motion i.e. move compute to data, and do not move data to compute node via network. Specifically, MapReduce tasks can be scheduled on the same physical nodes on which data is resident in HDFS, which exposes the underlying storage layout across the cluster. Benefits: reduces network I/O and keeps most of the I/O on local disk or within same rack.

20

Hadoop 1.x

There are two types of nodes that control the job execution process: a jobtracker and a number of tasktrackers.

• jobtracker: coordinates all jobs run on the system by scheduling

tasks to run on tasktrackers.

• Tasktrackers: run tasks and send progress reports to the jobtracker,

which keeps a record of the overall progress of each job. If a task fails, the jobtracker can reschedule it on a different tasktracker.

21

YARN: Yet Another Resource Negotiator

• Resource management => a global ResourceManager
• Per-node resource monitor => NodeManager
• Job scheduling/monitoring => per-application ApplicationMaster

(AM).

22

Hadoop Deamons are Java processes, running in background, talking to other via RPC over SSH protocol.

YARN:

• Master-slave System: ResourceManager and per-node slave,

NodeManager (NM), form the new, and generic, system for managing applications in a distributed manner.

• ResourceManager: ultimate authority that arbitrates resources

among all applications in the system.

• Pluggable Scheduler, allocate resources to various running

applications

• based on the resource requirements of the applications
• based on abstract notion of a Resource Container which

incorporates resource elements such as memory, cpu, disk, network etc.

• Per-application ApplicationMaster: negotiate resources from

ResourceManager and working with NodeManager(s) to execute and monitor component tasks.
