Background: the production of sound for speech

Adam Albright (albright@mit.edu)

LSA 2017 Phonology University of Kentucky

How do humans use sound to communicate?

▶ Speech production

▶ Intended meaning, calculate syntactic form, determine

phonological form, translate into physical instructions ▶ Speech perception

▶ Sound waves enter ear, auditory analysis, parse for linguistically

significant units, determine phonological and syntactic form, reconstruct intended meaning

The nature of speech The production of voicing Vowels Consonants 1/54

Properties of speech sounds

What makes a speech sound speech?

▶ Speech is noise created by air flowing from the lungs, modified as

it exits through the mouth/nose

▶ Speech is just one of many modes of linguistic communication

▶ Hand signs, writing, semaphore, morse code, … ▶ But all except sign language are derivative from spoken speech

▶ Speech is continuous

▶ A fluid stream of sounds, without necessarily any pauses between

individual sounds, words, or even sentences ▶ Speech is segmentable

▶ Composed of smaller units: words, morphemes, syllables, and

individual sounds

The nature of speech The production of voicing Vowels Consonants 2/54

Speech: continuous, yet segmentable

▷

“If you can’t see that, then I don’t know if I can explain it to you”

explain e k s p l ai n Although it’s not obvious from the waveform, the speech stream is composed of smaller units, which we can refer to discretely Phrases, words, phones ( individual speech sounds)

The nature of speech The production of voicing Vowels Consonants 3/54

Speech: continuous, yet segmentable

▷

“If you can’t see that, then I don’t know if I can explain it to you”

explain e k s p l ai n Although it’s not obvious from the waveform, the speech stream is composed of smaller units, which we can refer to discretely Phrases, words, phones ( individual speech sounds)

The nature of speech The production of voicing Vowels Consonants 3/54

Speech: continuous, yet segmentable

▷

“If you can’t see that, then I don’t know if I can explain it to you” ▶ explain = e k s p l ai n

Although it’s not obvious from the waveform, the speech stream is composed of smaller units, which we can refer to discretely Phrases, words, phones ( individual speech sounds)

The nature of speech The production of voicing Vowels Consonants 3/54

Speech: continuous, yet segmentable

▷

“If you can’t see that, then I don’t know if I can explain it to you” ▶ explain = e k s p l ai n

Although it’s not obvious from the waveform, the speech stream is composed of smaller units, which we can refer to discretely

▶ Phrases, words, phones (= individual speech sounds)

The nature of speech The production of voicing Vowels Consonants 3/54

Evidence for discrete phones

▶ Phonemic awareness tasks (typically used for testing

development in children)

▶ What is the first sound in cat? ▶ Which of these words start with the same sound: cat, pat, coat ▶ Say cat without the [k]; say stand without the [t] ▶ Say cat. What word do you get if you change the [k] to [m]?

▶ Language games

▶ pig latin → ig-pay atin-lay

▶ Speech errors

▶ “cad you rean the small print?” ▶ (More common: ‘spoonerisms’ of word-initial consonants)

▶ Alphabetic writing

The nature of speech The production of voicing Vowels Consonants 4/54

Producing speech

T wo components:

▶ Aerodynamic component

▶ Air is forced out of lungs, though throat, mouth, and nose

▶ Articulatory component

▶ Air stream is modified in various ways on its way out

The nature of speech The production of voicing Vowels Consonants 5/54

The vocal tract

nasal passages larynx (glottis) lips teeth alveolar ridge palate velum uvula tongue blade tongue dorsum tongue to the lungs brain

(my vocal tract, for illustrative purposes)

The nature of speech The production of voicing Vowels Consonants 6/54

The vocal tract

The first linguistically significant airstream obstruction: The larynx ( the glottis) From http://www.oto-hns.northwestern.edu/Voice/education.html (broken link)

The nature of speech The production of voicing Vowels Consonants 7/54

The vocal tract

The first linguistically significant airstream obstruction:

☞

The larynx (= the glottis) From http://www.oto-hns.northwestern.edu/Voice/education.html (broken link)

The nature of speech The production of voicing Vowels Consonants 7/54

Manipulations of the vocal folds

Vocal folds are held at varying degrees of stiffness/closure

▶ Completely open: for respiration (= breathing) ▶ Close enough to obstruct airflow: whispering, sighing, [h]

(aspiration)

▶ Close together, intermediate stiffness: normal (modal) voice ▶ Tightly closed: glottal stop (as in [ʔ]uh-[ʔ]oh)

The nature of speech The production of voicing Vowels Consonants 8/54

Voicing

▶ When the vocal folds are held somewhat close together, and with

the right amount of stiffness, air rushing through causes them to “vibrate”

▶ Vocal folds are forced apart and rapidly close again, repeatedly ▶ Periodic vibrations = voicing

▶ Can feel externally as a “buzzing” on your throat; try

[sssszzzzsssszzz]

Voicing is the first major source of noise for speech Creates a complex periodic wave, which resonates in the mouth and nose, and is otherwise modified on its way into the atmosphere

The nature of speech The production of voicing Vowels Consonants 9/54

Voicing

▶ When the vocal folds are held somewhat close together, and with

the right amount of stiffness, air rushing through causes them to “vibrate”

▶ Vocal folds are forced apart and rapidly close again, repeatedly ▶ Periodic vibrations = voicing

▶ Can feel externally as a “buzzing” on your throat; try

[sssszzzzsssszzz]

Voicing is the first major source of noise for speech

▶ Creates a complex periodic wave, which resonates in the mouth

and nose, and is otherwise modified on its way into the atmosphere

The nature of speech The production of voicing Vowels Consonants 9/54

Source properties: voice quality

How would you characterize the difference between these pairs of sounds?

▶ Mpi (Tibeto-Burman, spoken by ≈ 900 people in Thailand)

T

• ne

Word Gloss Word Gloss Low rising

▷

si ‘to be putrid’

▷

si ‘to be dried up’ Low level

▷

si ‘blood’

▷

si ‘seven’ Mid rising

▷

si ‘to roll rope’

▷

si ‘to smoke’ Mid level

▷

si (a color)

▷

si (classifier) High falling

▷

si ‘to die’

▷

si (name) High level

▷

si ‘four’

▷

si (name)

▶ Regular vs. ‘tense’ voice

Hear them here.

The nature of speech The production of voicing Vowels Consonants 10/54

Source properties: voice quality

!Xóõ (Khoisan, Botswana/Namibia) Plain (voiced) Pharyngealized Strident Breathy

▷

kǁáa

▷

qáʕa

▷

k!ào

▷

k!a̤o ‘camelthorn tree’ ‘long ago’ ‘base’ ‘slope’

The nature of speech The production of voicing Vowels Consonants 11/54

Source properties: voice quality

Voice quality contrasts

▶ Bai (Tibeto-Burman, China) (Esling 2002)

▷

tɕi31 ‘field’

▷

tɕi21 ‘flag’ (breathy) (harsh)

▶ English: what determines the voice quality that a word is spoken

with?

Emotive use: frustration, surprise, etc. Individual style: Louis Armstrong, Julie Kavner, etc.

description

The nature of speech The production of voicing Vowels Consonants 12/54

Source properties: voice quality

Voice quality contrasts

▶ Bai (Tibeto-Burman, China) (Esling 2002)

▷

tɕi31 ‘field’

▷

tɕi21 ‘flag’ (breathy) (harsh)

▶ English: what determines the voice quality that a word is spoken

with?

▶ Emotive use: frustration, surprise, etc. ▶ Individual style: Louis Armstrong, Julie Kavner, etc. ▷

description

The nature of speech The production of voicing Vowels Consonants 12/54

The vocal tract as filter

nasal passages larynx (glottis) lips teeth alveolar ridge palate velum uvula tongue blade tongue dorsum tongue to the lungs brain

The nature of speech The production of voicing Vowels Consonants 13/54

The simplest effect

The vocal tract as a tube, closed at one end From: Ladefoged (1996) Elements of Acoustic Phonetics, p. 117

The nature of speech The production of voicing Vowels Consonants 14/54

Resonances

▶ Formants:

Fn = 2n − 1

4 ×

c L

▶ Fn = formant n ▶ c = speed of sound ≈ 35000cm/sec in warm moist air ▶ L = length of the tube

The nature of speech The production of voicing Vowels Consonants 15/54

Calculating tube length

▶ Solving for L

L = 2n − 1

4 ×

c Fn

▶ Example: F1 = 500Hz, F2 = 1500Hz, F3 = 2500Hz

▶ L = 17.5cm

The nature of speech The production of voicing Vowels Consonants 16/54

Possible filtering actions

▶ Can change the size and shape of the oral cavity ▶ Can obstruct the flow of air so much that it must flow through a

very narrow passageway

▶ Can completely block airflow through the mouth ▶ Can open or close velum to allow allow air to flow through nose

The nature of speech The production of voicing Vowels Consonants 17/54

Examining speech sounds

▶ Examining acoustic properties of speech

▶ Praat: http://www.praat.org ▶ Useful for isolating/replaying sounds, and examining acoustic

properties

▶ Waveform vs. spectrogram ▶ Periodic (voicing) vs. aperiod (frication/aspiration) ▶ Both together: [z], [a̤] ▶ Formants

The nature of speech The production of voicing Vowels Consonants 18/54

The simplest filtering action

▶ Vocal tract acts as resonance chamber ▶ T

• ngue acts to control the size of the chamber, and divide into

sub-chambers

▶ Changing size of these chambers alters the sound wave

▶ Boosts amplitude at certain frequencies, dampens others

The nature of speech The production of voicing Vowels Consonants 19/54

What this means, practically speaking

The effect of different tongue positions on the speech signal: Click!

▶ Raising/lowering tongue in different locations results in different

vowel sounds

▶ Height (high, mid, low) and backness (front, central, back)

The nature of speech The production of voicing Vowels Consonants 20/54

A neat demo

Very realistic vowel qualities can be constructed with simple tube models

▶ Exploratorium demo: http: //www.exploratorium.edu/exhibits/vocal_vowels/vocal_vowels.html

The nature of speech The production of voicing Vowels Consonants 21/54

Vowel features

Try this:

▶ Very slowly say the word yeah…, and feel what you are doing ▶ The primary motion is mouth opening/tongue lowering ▶ Along the way, you say a variety of vowels, including:

▶ [i] in heat ▶ [ɛ] in pet ▶ [æ] in cat ▶ (and probably quite a few others…)

The nature of speech The production of voicing Vowels Consonants 22/54

Vowel features

Now try this:

▶ Very slowly say the word how… ▶ Several motions:

▶ T

• ngue body moving back in the mouth

▶ T

• ngue body moving up

▶ T

• ngue “root” (in throat) moving up/become more tense

▶ Mouth closing, lips rounding

The nature of speech The production of voicing Vowels Consonants 23/54

The description of vowels

Vowels can be described along four dimensions:

▶ Backness ▶ Height ▶ T

enseness

▶ Rounding

The nature of speech The production of voicing Vowels Consonants 24/54

Some American English vowels

T ypical American English vowels, in phonetic transcription

(Phonetic transcription indicated with square brackets)

Front Central Back High (tense) i u (lax) ɪ ʊ Mid (tense) eɪ

• ʊ

(lax) ɛ ə, ʌ (ɔ) Low (tense) ɑ (lax) æ Diphthongs: [aɪ] ([aj]) ‘eye’, [aʊ] ([aw]) ‘how’, [ɔɪ] ([ɔj]) ‘boy’ [i] heat [ɪ] hit [u] hoot [ʊ] hook [eɪ] (=[ej]) gate [ɛ] get [oʊ] (=[ow]) goat [ə] attack [ʌ] gut [ɔ]

• ught

[æ] hat [ɑ] father

The nature of speech The production of voicing Vowels Consonants 25/54

Some things to note

☞ Vowel letters (i, e, a, o, u) stand for what are sometimes called

“pure” vowels

▶ Roughly, values used for languages like Spanish, Italian, etc. ▶ These are closest to the English tense vowels, but English vowels

typically also involve an extra off-glide

▶ [eɪ] (= [ej], [e]), and [oʊ] (= [ow], [o])

☞ Special symbols for lax vowels: [ɪ], [ɛ], [æ], [ɔ], [ʊ], [ə], [ʌ]

The nature of speech The production of voicing Vowels Consonants 26/54

A great resource

Demo with sample words, sounds, and animations

▶ http://soundsofspeech.uiowa.edu/english/english.html

The nature of speech The production of voicing Vowels Consonants 27/54

ə and ʌ

▶ [ə], [ʌ] = “neutral vowels” (uh…) ▶ [ʌ] = stressed, [ə] = stressless

▶ abut [əbʌt], amok [əmʌk], Canuck [kənʌk]

▶ Sometimes [ə] is used for both

The nature of speech The production of voicing Vowels Consonants 28/54

ɑ and ɔ

For some American dialects…

▶ [ɑ] = first syllable in father ▶ [ɔ] = walk, caught, all ▶ But many dialects have merged these into an [ɑ]-like vowel

▶ In fact, the U Iowa site mixes together [ɑ] and [ɔ] words, though

the isolated examples are correct

The nature of speech The production of voicing Vowels Consonants 29/54

ɑ and ɔ

For some American dialects…

▶ [ɑ] = first syllable in father ▶ [ɔ] = walk, caught, all ▶ But many dialects have merged these into an [ɑ]-like vowel

▶ In fact, the U Iowa site mixes together [ɑ] and [ɔ] words, though

the isolated examples are correct

The nature of speech The production of voicing Vowels Consonants 29/54

ɑ and ɔ

For some American dialects…

▶ [ɑ] = first syllable in father ▶ [ɔ] = walk, caught, all ▶ But many dialects have merged these into an [ɑ]-like vowel

▶ In fact, the U Iowa site mixes together [ɑ] and [ɔ] words, though

the isolated examples are correct

The nature of speech The production of voicing Vowels Consonants 29/54

ɑ and ɔ

[ɔ]… [a]…

The nature of speech The production of voicing Vowels Consonants 30/54

ɑ and ɔ

[rɔ] [ra]

The nature of speech The production of voicing Vowels Consonants 31/54

Vowel dimensions

Front, central, back

▶ Front = tongue body toward the front of the mouth

▶ [i], [ɪ], [eɪ], [ɛ], [æ]

▶ Central = tongue body neither front nor back

▶ [ə], [ʌ]

▶ Back = tongue body toward the back of the mouth

▶ [u], [ʊ], [oʊ], [ɔ], [a]

The nature of speech The production of voicing Vowels Consonants 32/54

Vowel dimensions

High, mid, low

▶ High: tongue body significantly raised

▶ [i], [ɪ], [u], [ʊ]

▶ Mid: tongue body “neutral”

▶ [eɪ], [ɛ], [ə], [ʌ], [oʊ], [ɔ]

▶ Low: tongue body lowered

▶ [æ], [ɑ]

The nature of speech The production of voicing Vowels Consonants 33/54

Vowel dimensions

T ense, lax:

▶ T

ense: tongue root raised, narrower constriction in back of mouth

▶ [i], [eɪ], [ɑ], [oʊ], [u]

▶ Lax: tongue root lowered/relaxed

▶ [ɪ], [ɛ], [æ], [ɔ], [ʊ], [ə], [ʌ]

The nature of speech The production of voicing Vowels Consonants 34/54

Vowel dimensions

Rounding:

▶ Rounded: lips rounded

▶ [u], [ʊ], [ow], [ɔ]

▶ Unrounded: lips not rounded

▶ In English, everything else…

▶ Some languages have front rounded vowels (German ü, ö; also

French, Swedish, Hungarian, and many others)

▶ The Japanese vowel that is usually written u is actually a back

unrounded vowel

The nature of speech The production of voicing Vowels Consonants 35/54

Vowels: a fuller set

Front Central Back High (tense) i y ɯ u (lax) ɪ ʏ ʊ Mid (tense) e ø ɤ

• (lax)

ɛ ɶ ə, ʌ ɔ Low (tense) a ɑ ɒ (lax) æ

The nature of speech The production of voicing Vowels Consonants 36/54

Rounding and backness

▶ In English, the non-low back vowels are all round ▶ What is the connection between rounding and backness?

“Rounding” lip protrusion

Lengthens vocal tracts Back vowels get ‘backer’

The nature of speech The production of voicing Vowels Consonants 37/54

Rounding and backness

▶ In English, the non-low back vowels are all round ▶ What is the connection between rounding and backness? ▶ “Rounding” = lip protrusion

▶ Lengthens vocal tracts ▶ Back vowels get ‘backer’

The nature of speech The production of voicing Vowels Consonants 37/54

Diphthongs

▶ Vowel and glide combinations

▶ Vowel + glide: aɪ, aʊ, ɔɪ, oʊ, etc. ▶ Glide + vowel: ju, wo, etc.

▶ English: all have glide second

▶ shine, crowd, toy

▶ Spanish: prueba [prweba] ‘test’, viejo [bjexo] ‘old’

The nature of speech The production of voicing Vowels Consonants 38/54

Practice

Describe and give the symbol for the vowels of the following words, as you pronounce them in your speech English: remember to include height, backness, rounding, tenseness

▶ cat, couch, book, feet, neat, lute

(If you are not a native speaker of English, you may want to have a native speaker pronounce them for you.)

The nature of speech The production of voicing Vowels Consonants 39/54

Some useful web resources

▶ IPA chart (including symbols for other languages) https://web.uvic.ca/ling/resources/ipa/charts/IPAlab/IPAlab.htm ▶ Free IPA fonts for your computer http://dejavu-fonts.org/wiki/Main_Page http://sourceforge.net/projects/linuxlibertine/ http: //scripts.sil.org/cms/scripts/page.php?&cat_id=FontDownloadsIPA ▶ T

yping IPA on the web, to copy into another document

http://ipa.typeit.org/ ▶ Drills for describing consonants http://home.cc.umanitoba.ca/∼krussll/phonetics/practice/ consonant/d2intro.htm

The nature of speech The production of voicing Vowels Consonants 40/54

How are consonants different from vowels?

Airflow obstructions

▶ Stopping flow completely ▶ Rerouting through nose ▶ Impeding to varying degrees

Moving tongue, lips, etc., to block air = articulation

The nature of speech The production of voicing Vowels Consonants 41/54

Describing articulation of consonants

Voicing:

▶ Voiced or voiceless

Place of articulation:

▶ Where in the mouth the constriction is created

Manner of articulation:

▶ Degree (and nature) of the constriction

The nature of speech The production of voicing Vowels Consonants 42/54

Place of articulation

nasal passages larynx (glottis) lips teeth alveolar ridge palate velum uvula tongue blade tongue dorsum tongue to the lungs brain

The nature of speech The production of voicing Vowels Consonants 43/54

Place of articulation

Labial (Bilabial) p, b, m (Labiodental) f, v Interdental θ, ð Alveolar t, d, n, l, s, z, Alveopalatal ʃ, ʒ Palatal j Velar k, g, ŋ Uvular (q, ʁ) Glottal ʔ

The nature of speech The production of voicing Vowels Consonants 44/54

Manner of articulation

In increasing amount of obstruction: Stops Obstruents Affricates Fricatives Nasals Sonorants Liquids Glides

The nature of speech The production of voicing Vowels Consonants 45/54

Manner of articulation

In increasing amount of obstruction: Stops Obstruents Affricates Fricatives Nasals Sonorants Liquids Glides

The nature of speech The production of voicing Vowels Consonants 45/54

Manner of articulation

Stops: completely block airflow

▶ Voiceless: [p], [t], [k]

▶ [p] = voiceless bilabial stop

▶ Voiced: [b], [d], [g]

▶ [g] = voiced velar stop

The nature of speech The production of voicing Vowels Consonants 46/54

Aspiration

In English, voiceless stops in some contexts are aspirated

▶ A puff of air after release of closure, and before the beginning of

voicing

▶ Occurs at the beginnings of words

▶ pie [phaɪ], top [thap]

▶ But not after [s]

▶ spy [spaɪ], stop [stap]

The nature of speech The production of voicing Vowels Consonants 47/54

Nasals

▶ It is possible to keep the mouth closed, but open the velum, to

release air through the nose Labial m whim [wɪm] Alveolar n win [wɪn] Velar ŋ wing [wɪŋ] If your nose is blocked, these sounds you can’t make very well; they become the corresponding regular (oral) stops

▶ a stuffy [d]ose

The nature of speech The production of voicing Vowels Consonants 48/54

Fricatives

Flow of air is obstructed, but not completely blocked

▶ Narrow constriction = air escapes quickly and noisily ▶ Characterized by added turbulent noise

Labiodental f, v fan [fæn], van [væn] Interdental θ, ð thin [θɪn], then [ðɛn] Alveolar s, z sin [sɪn], zen [zɛn] Alveopalatal ʃ, ʒ cash [kæʃ], beige [beɪʒ] Velar x Bach [bax]

▶ th in thin = voiceless interdental fricative ▶ th in then = voiced interdental fricative ▶ s in measure = voiced alveopalatal fricative

The nature of speech The production of voicing Vowels Consonants 49/54

Affricates

Air is stopped briefly, but then released slowly, so there is still

• bstruent

▶ Essentially, stop + fricative combinations

Alveopalatal tʃ, dʒ choke [tʃoʊk], joke [dʒoʊk]

▶ ch in church = voiceless alveopalatal affricate ▶ j in judge = voiced alveopalatal affricate

The nature of speech The production of voicing Vowels Consonants 50/54

Stridents

▶ Alveolar and alveopalatal fricatives and affricates are especially

noisy, because they involve very narrow passages for the air to pass through

▶ These are known as stridents, or sibilants ▶ [s], [z], [ʃ], [ʒ], [tʃ], [dʒ]

The nature of speech The production of voicing Vowels Consonants 51/54

Liquids

▶ Relatively less constriction; air escapes freely around tongue ▶ Lateral: [l]

▶ Alveolar constriction, but air escapes around sides of tongue

▶ Rhotic: [r]

▶ T

• ngue curled back or bunched up

▶ Flap: [ɾ]

▶ T

• ngue briefly tapped against alveolar ridge

▶ atom [æɾəm]

The nature of speech The production of voicing Vowels Consonants 52/54

Glides

▶ Consonant versions of [i], [u] ▶ Very similar articulation, but shorter and with narrower

constriction Palatal [j] yes [jɛs] Labiovelar [w] wet [wɛt]

The nature of speech The production of voicing Vowels Consonants 53/54

Consonants

Bilab Lab Inter- Alv Alv- Retr Pal Vel Uvu Phar Glot dent Pal Stop p b t d ʈ ɖ c ɟ k ɡ q ɢ ʔ Fric Non-lat ɸ β f v θ ð s z ʃ ʒ ʂ ʐ ç ʝ x ɣ χ ʁ ħ ʕ h ɦ Lat ɬ ɮ Affric tʃ dʒ Nas m ɱ n ɳ ɲ ŋ ɴ Trill r ʀ T ap/flap ɾ Approx Non-lat ʍ w ɹ̥ ɹ ɻ j (ʍ w) Lat l̥ l

The nature of speech The production of voicing Vowels Consonants 54/54
