Avoiding Pitfalls when Using NVIDIA GPUs for Real-Time Tasks in Autonomous Systems Ming Yang, Nathan Otterness , Tanya Amert, Joshua Bakita, James H. Anderson, F. Donelson Smith All image sources and references are provided at the end. 1 2

slide-1
SLIDE 1

Avoiding Pitfalls when Using NVIDIA GPUs for Real-Time Tasks in Autonomous Systems

Ming Yang, Nathan Otterness, Tanya Amert, Joshua Bakita, James H. Anderson, F. Donelson Smith

All image sources and references are provided at the end.

1

slide-2
SLIDE 2

2

slide-3
SLIDE 3

3

Computer Vision & AI Expertise GPU Behavior Expertise Real-time Expertise

slide-4
SLIDE 4

Pitfalls for Real-Time GPU Usage

  • Synchronization and blocking
  • GPU concurrency and performance
  • CUDA programming perils

4

slide-5
SLIDE 5

CUDA Programming Fundamentals

(i) Allocate GPU memory

cudaMalloc(&devicePtr, bufferSize);

(ii) Copy data from CPU to GPU

cudaMemcpy(devicePtr, hostPtr, bufferSize);

(iii) Launch the kernel (kernel = code that runs on GPU)

computeResult<<<numBlocks, threadsPerBlock>>>(devicePtr);

(iv) Copy results from GPU to CPU

cudaMemcpy(hostPtr, devicePtr, bufferSize);

(v) Free GPU memory

cudaFree(devicePtr);

5

slide-6
SLIDE 6

CUDA Programming Fundamentals

(i) Allocate GPU memory

cudaMalloc(&devicePtr, bufferSize);

(ii) Copy data from CPU to GPU

cudaMemcpy(devicePtr, hostPtr, bufferSize);

(iii) Launch the kernel (kernel = code that runs on GPU)

computeResult<<<numBlocks, threadsPerBlock>>>(devicePtr);

(iv) Copy results from GPU to CPU

cudaMemcpy(hostPtr, devicePtr, bufferSize);

(v) Free GPU memory

cudaFree(devicePtr);

6

slide-7
SLIDE 7

CUDA Programming Fundamentals

(i) Allocate GPU memory

cudaMalloc(&devicePtr, bufferSize);

(ii) Copy data from CPU to GPU

cudaMemcpy(devicePtr, hostPtr, bufferSize);

(iii) Launch the kernel (kernel = code that runs on GPU)

computeResult<<<numBlocks, threadsPerBlock>>>(devicePtr);

(iv) Copy results from GPU to CPU

cudaMemcpy(hostPtr, devicePtr, bufferSize);

(v) Free GPU memory

cudaFree(devicePtr);

7

slide-8
SLIDE 8

(i) Allocate GPU memory

cudaMalloc(&devicePtr, bufferSize);

(ii) Copy data from CPU to GPU

cudaMemcpy(devicePtr, hostPtr, bufferSize);

(iii) Launch the kernel (kernel = code that runs on GPU)

computeResult<<<numBlocks, threadsPerBlock>>>(devicePtr);

(iv) Copy results from GPU to CPU

cudaMemcpy(hostPtr, devicePtr, bufferSize);

(v) Free GPU memory

cudaFree(devicePtr);

CUDA Programming Fundamentals

8

slide-9
SLIDE 9

CUDA Programming Fundamentals

(i) Allocate GPU memory

cudaMalloc(&devicePtr, bufferSize);

(ii) Copy data from CPU to GPU

cudaMemcpy(devicePtr, hostPtr, bufferSize);

(iii) Launch the kernel (kernel = code that runs on GPU)

computeResult<<<numBlocks, threadsPerBlock>>>(devicePtr);

(iv) Copy results from GPU to CPU

cudaMemcpy(hostPtr, devicePtr, bufferSize);

(v) Free GPU memory

cudaFree(devicePtr);

9

slide-10
SLIDE 10

CUDA Programming Fundamentals

(i) Allocate GPU memory

cudaMalloc(&devicePtr, bufferSize);

(ii) Copy data from CPU to GPU

cudaMemcpy(devicePtr, hostPtr, bufferSize);

(iii) Launch the kernel (kernel = code that runs on GPU)

computeResult<<<numBlocks, threadsPerBlock>>>(devicePtr);

(iv) Copy results from GPU to CPU

cudaMemcpy(hostPtr, devicePtr, bufferSize);

(v) Free GPU memory

cudaFree(devicePtr);

10

slide-11
SLIDE 11

Pitfalls for Real-Time GPU Usage

  • Synchronization and blocking
  • GPU concurrency and performance
  • CUDA programming perils

11

slide-12
SLIDE 12

Explicit Synchronization

12

slide-13
SLIDE 13

Explicit Synchronization

13

Each CUDA stream is managed by a separate CPU thread in the same address space.

slide-14
SLIDE 14

Explicit Synchronization

14

K1 starts K1 completes

slide-15
SLIDE 15

Explicit Synchronization

15

1024 threads 256 threads

slide-16
SLIDE 16

Explicit Synchronization

16

  • 1. Thread 3 calls cudaDeviceSynchronize

(explicit synchronization). (a)

  • 2. Thread 3 sleeps for 0.2 seconds. (c)
  • 3. Thread 3 launches kernel K3. (d)
slide-17
SLIDE 17

Explicit Synchronization

17

  • 1. Thread 3 calls cudaDeviceSynchronize

(explicit synchronization). (a)

  • 2. Thread 4 launches kernel K4. (b)
  • 3. Thread 3 sleeps for 0.2 seconds. (c)
  • 4. Thread 3 launches kernel K3. (d)
slide-18
SLIDE 18

Explicit Synchronization

18

Pitfall 1. Explicit synchronization does not block future commands issued by other tasks.

slide-19
SLIDE 19

Implicit Synchronization

19

Two commands from different streams cannot run concurrently [if separated by]:

  • 1. A page-locked host memory allocation
  • 2. A device memory allocation
  • 3. A device memory set
  • 4. A memory copy between two addresses to the same

device memory

  • 5. Any CUDA command to the NULL stream

CUDA toolkit 9.2.88 Programming Guide, Section 3.2.5.5.4, "Implicit Synchronization":

slide-20
SLIDE 20

Implicit Synchronization

20

➔ Pitfall 2. Documented sources of implicit synchronization may not occur.

  • 1. A page-locked host memory allocation
  • 2. A device memory allocation
  • 3. A device memory set
  • 4. A memory copy between two addresses to the same

device memory

  • 5. Any CUDA command to the NULL stream
slide-21
SLIDE 21

Implicit Synchronization

21

slide-22
SLIDE 22

Implicit Synchronization

22

  • 1. Thread 3 calls cudaFree. (a)
  • 2. Thread 3 sleeps for 0.2 seconds. (c)
  • 3. Thread 3 launches kernel K3. (d)
slide-23
SLIDE 23

Implicit Synchronization

23

  • 1. Thread 3 calls cudaFree. (a)
  • 2. Thread 4 is blocked on the CPU when

trying to launch kernel 4. (b)

  • 3. Thread 4 finishes launching kernel K4,

thread 3 sleeps for 0.2 seconds. (c)

  • 4. Thread 3 launches kernel K3. (d)
slide-24
SLIDE 24

Implicit Synchronization

24

➔ Pitfall 3. The CUDA documentation neglects to list some functions that cause implicit synchronization. ➔ Pitfall 4. Some CUDA API functions will block future CUDA tasks on the CPU.

slide-25
SLIDE 25

Pitfalls for Real-Time GPU Usage

  • Synchronization and blocking

○ Suggestion: use CUDA Multi-Process Service (MPS).

  • GPU concurrency and performance
  • CUDA programming perils

25

slide-26
SLIDE 26

Pitfalls for Real-Time GPU Usage

  • Synchronization and blocking

○ Suggestion: use CUDA Multi-Process Service (MPS).

  • GPU concurrency and performance
  • CUDA programming perils

26

slide-27
SLIDE 27

27

GPU Concurrency and Performance

  • Implicit synchronization penalty = Processes with MPS
  • vs. Threads
slide-28
SLIDE 28

28

GPU Concurrency and Performance

  • Implicit synchronization penalty = Processes with MPS
  • vs. Threads
  • GPU concurrency benefit = Processes with MPS vs.

Processes without MPS

slide-29
SLIDE 29

29

GPU Concurrency and Performance

  • Implicit synchronization penalty = Processes with MPS
  • vs. Threads
  • GPU concurrency benefit = Processes with MPS vs.

Processes without MPS

  • MPS overhead = Threads vs. Threads with MPS

(not in plots)

slide-30
SLIDE 30

30

GPU Concurrency and Performance

slide-31
SLIDE 31

31

GPU Concurrency and Performance

slide-32
SLIDE 32

GPU Concurrency and Performance

32

70% of the time, a single Hough transform iteration completed in 12 ms or less.

slide-33
SLIDE 33

GPU Concurrency and Performance

33

This occurred when four concurrent instances were running in separate CPU threads.

slide-34
SLIDE 34

GPU Concurrency and Performance

34

The observed WCET using threads was over 4x the WCET using multiple processes.

slide-35
SLIDE 35

GPU Concurrency and Performance

35

slide-36
SLIDE 36

GPU Concurrency and Performance

36

slide-37
SLIDE 37

GPU Concurrency and Performance

37

➔ Pitfall 5. The suggestion from NVIDIA’s documentation to exploit concurrency through user-defined streams may be of limited use.

slide-38
SLIDE 38

Pitfalls for Real-Time GPU Usage

  • Synchronization and blocking

○ Suggestion: use CUDA Multi-Process Service (MPS).

  • GPU concurrency and performance
  • CUDA programming perils

38

slide-39
SLIDE 39

Pitfalls for Real-Time GPU Usage

  • Synchronization and blocking

○ Suggestion: use CUDA Multi-Process Service (MPS).

  • GPU concurrency and performance
  • CUDA programming perils

39

slide-40
SLIDE 40

Pitfalls for Real-Time GPU Usage

  • Synchronization and blocking

○ Suggestion: use CUDA Multi-Process Service (MPS).

  • GPU concurrency and performance
  • CUDA programming perils

40

slide-41
SLIDE 41

Synchronous Defaults

if (!CheckCUDAError( cudaMemsetAsync( state->device_block_smids, 0, data_size))) { return 0; }

41

Why does this cause implicit synchronization?

slide-42
SLIDE 42

Synchronous Defaults

if (!CheckCUDAError( cudaMemsetAsync( state->device_block_smids, 0, data_size))) { return 0; }

42

  • The CUDA docs say that memset

causes implicit synchronization...

slide-43
SLIDE 43

Synchronous Defaults

if (!CheckCUDAError( cudaMemsetAsync( state->device_block_smids, 0, data_size))) { return 0; }

43

  • The CUDA docs say that memset

causes implicit synchronization...

  • But didn't slide 20 say memset

doesn't cause implicit synchronization?

slide-44
SLIDE 44

Synchronous Defaults

if (!CheckCUDAError( cudaMemsetAsync( state->device_block_smids, 0, data_size))) { return 0; }

44

if (!CheckCUDAError( cudaMemsetAsync( state->device_block_smids, 0, data_size, state->stream))) { return 0; }

➔ Pitfall 6. Async CUDA functions use the GPU-synchronous NULL stream by default.

slide-45
SLIDE 45

Other Perils

45

➔ Pitfall 7. Observed CUDA behavior often diverges from what the documentation states or implies.

slide-46
SLIDE 46

Other Perils

46

➔ Pitfall 8. CUDA documentation can be contradictory.

slide-47
SLIDE 47

Other Perils

47

➔ Pitfall 8. CUDA documentation can be contradictory.

CUDA Programming Guide, section 3.2.5.1:

The following device operations are asynchronous with respect to the host: [...] Memory copies performed by functions that are suffixed with Async

CUDA Runtime API Documentation, section 2:

For transfers from device memory to pageable host memory, [cudaMemcpyAsync] will return only once the copy has completed.

slide-48
SLIDE 48

Other Perils

48

➔ Pitfall 9. What we learn about current black-box GPUs may not apply in the future.

slide-49
SLIDE 49

Conclusion

  • The GPU ecosystem needs clarity and openness!
  • Avoid pitfalls when using NVIDIA GPUs for

real-time tasks in autonomous systems

○ GPU synchronization, application performance, and problems with documentation

49

slide-50
SLIDE 50

Thanks! Questions?
