AVer Surveillance Solution NXU Lite : Free 32CH VMS Software The professional solution for IP cam The professional solution for IP cam free bundle software Darren Lin | 05-Sep-2012 | AVer Information Inc. | www.aver.com 23-Nov-2011 AVer


slide-1
SLIDE 1

AVer Surveillance Solution

NXU Lite : Free 32CH VMS Software

The professional solution for IP cam

23-Nov-2011 AVer Information Inc. | www.aver.com

The professional solution for IP cam free bundle software

Darren Lin | 05-Sep-2012 | AVer Information Inc. | www.aver.com

slide-2
SLIDE 2

Why NXU Lite?

For distributor/ end user

Excellent NVR capability

  • Auto IP camera search in the different subnet domain
  • User friendly network change feature Active IP (without IP cam finder)
  • Intelligent Streaming technology
  • Up to 32ch IP cameras of AVer IPCam

Easy to use

  • User friendly UI style

Stronger alarm system

  • Support 32 alarm
  • Send to multiple CMS and white list

Powerful remote capability

  • Support to connect to 1000 DVR/NVR with CM3000 Gold
  • Support iPhone/ Android phone mobile application
slide-3
SLIDE 3
  • up to 5 megapixels for one camera channel
  • total of 42 megapixels for all channels
  • supports H.264/MPEG4/MJPEG video formats

Excellent IP camera capability Supports up to 32CH IP cameras

Ensures sharper image for critical areas

Analog Camera Megapixel IP Camera

  • Great IP camera integration with the

key IP camera brands on the market

slide-4
SLIDE 4

Display mechanism

  • Compatible system resolution: 1024x768, 1280x1024, 1440x900, 1680x1050,

1920x1200

  • 1, 4, 8, 9, 13, 16, 32-split for live monitoring with full screen mode and compact

mode support

  • Flexible display channel arrangement

– Switch channel image position easily by drag and drop – One click on channel number button to switch display channel

slide-5
SLIDE 5

Camera Tree Display

  • Handy camera tree for intuitive channel selection

– Drag channel to preview split to show the camera image – Double click to switch to single view with selected camera image – Right click on camera icon to switch audio on/off

  • Group function available in camera tree display

– Configure your camera in different group for easier camera management

slide-6
SLIDE 6

Advanced IP and Recording Setting

  • Active IP (user can setup IP cameras without IP cam finder)
  • Always record/Key frame record/Motion record/Smart record
  • Supports mask/shield mechanism
slide-7
SLIDE 7

Advanced alarm notification

  • Allow single event or multiple events as alarm trigger conditions
  • Supports multiple alarm notification mechanisms
  • Supports up to 8 E-maps (.jpg or .bmp) to locate cameras, alarms and

relays easily

slide-8
SLIDE 8

Account Administration

  • Administrator or User level
  • Support up to 256 accounts
  • Expire user account based on specified date
  • Activate user account based on specified date
  • Detail system control right / Remote accessibility / Time Span

setting for user accounts

slide-9
SLIDE 9

Friendly Schedule Interface

  • Two types of schedule setting: One time schedule or weekly schedule
  • Detail schedule could be set on 15 minutes basis
  • Support schedule setting for below functions:

– Record – Backup – Turn On Relay – Turn On Relay – Disable Alarm – Enable Network – Reboot

slide-10
SLIDE 10

Central management System IE browser for remote monitor Main function remote AP for remote live and playback monitor

CM3000/ CM3000 Gold PCViewer Remote Console

Remote Software

2012

iPhone/iPad, Android phone/tablet solution Remote iMatrix, Backup, remote setup, remote ialarm...

Mobile AP Other Remote AP

2011

slide-11
SLIDE 11

Central Management Software

  • iMatrix-

A remote platform that integrates 128 monitor views and displays in a 4- monitor environment to create a TV-wall command center

  • Remote software support
  • Remote setup

A useful function that allows users to set up cameras, recordings, schedules, and alarms from a remote site

CM3000 / CM3000 Gold

Free of charge CMS (free up to 16 DVRs; Max. 1,000 DVRs)

  • iAlarm-

A remote platform that receives and manages all alarm information from a Central Management System and AVer’s DVR/NVR series

slide-12
SLIDE 12

NXU v.s NXU Lite

Category Function NXU NXU Lite System POS v n/a Event Log Attention please v n/a Object counting viewer v n/a Face Finder Viewer v n/a iPOSViewer v n/a Camera Object counting v n/a Face Finder v n/a Alarm Alarm number 64 32 Missing or suspicious object v n/a scene change v n/a Make phone call v n/a Launch program v n/a Network Enable Original Security Protocol v n/a 3GPP v n/a

slide-13
SLIDE 13

H/W Requirement

Windows OS Connecting Channels Suggestion H/W Requirement Suggestion

Windows XP (32bit) 8 channels CPU: Intel Core i3 2120 and above RAM: DDR3-1333 1GB *2 (Dual channel) Windows 7 (32bit) 16 channels CPU: Intel Core i5 3470 and above RAM: DDR3-1333 2GB *2 (Dual channel) Windows 7 (64bit) 32 channels CPU: Intel Core i7 3770 and above RAM: DDR3-1333 2GB *2 (Dual channel)
