2018 CDB Part IB Plant Development Lecture 4. Patterning of indeterminate growth Jim Haselo fg Department of Plant Sciences Auxin triggered outgrowth of shoot primordia PIN1:GFP distribution in the Arabidopsis shoot apical meristem

slide-1
SLIDE 1

2018 CDB Part IB

Plant Development

Jim Haselofg
 Department of Plant Sciences

Lecture 4. Patterning of indeterminate growth

slide-2
SLIDE 2

Auxin triggered outgrowth of shoot primordia

slide-3
SLIDE 3

PIN1:GFP distribution in the Arabidopsis shoot apical meristem

slide-4
SLIDE 4

Primordial outgrowths in the meristem are triggered by local influxes of auxin

slide-5
SLIDE 5

The meristem is self-organising and renews itself.

slide-6
SLIDE 6
slide-7
SLIDE 7

The shoot meristem is divided into central, peripheral and rib zones. Central zone = undifferentiated cells Peripheral zone = formation of new lateral organs Rib zone = formation of new stem

slide-8
SLIDE 8

The meristem contains three different layers

  • f cells, L1, L2 & L3.

These generally maintain distinct lineages

slide-9
SLIDE 9
slide-10
SLIDE 10
slide-11
SLIDE 11
slide-12
SLIDE 12
slide-13
SLIDE 13

wt shootmeristemless (stm) wuschel (wus)

SHOOT MERISTEMLESS (STM) and WUSCHEL (WUS) are homeodomain genes that are required for formation and maintenance of the shoot apical meristem in Arabidopsis.

slide-14
SLIDE 14
slide-15
SLIDE 15

WUSCHEL expression

slide-16
SLIDE 16

Ectopic expression of WUSCHEL induces stem cell proliferation

slide-17
SLIDE 17
slide-18
SLIDE 18

Combined expression of STM and WUS triggers ectopic meristem formation and

  • rganogenesis
slide-19
SLIDE 19

WUS and STM initiate and maintain meristem growth

  • but how is the size of the apical

meristem constrained? the growth of the shoot meristem is negatively regulated by…. the CLAVATA genes

slide-20
SLIDE 20
slide-21
SLIDE 21
slide-22
SLIDE 22
slide-23
SLIDE 23
slide-24
SLIDE 24
slide-25
SLIDE 25
slide-26
SLIDE 26
slide-27
SLIDE 27

Two other membrane proteins Clavata2 and Coryne associate to form a receptor kinase that functions on a parallel path.

slide-28
SLIDE 28
  • 1. Mutations in the genes, clavata1,

clavata2, coryne and clavata3, produce similar phenotypes - enlarged meristems.

  • 2. These genes function in the same

regulatory pathway.

  • 3. CLAVATA3 is a ligand for the CLAVATA1/

CLAVATA2/CORYNE receptors

slide-29
SLIDE 29
slide-30
SLIDE 30

A glycopeptide regulating stem cell fate in Arabidopsis thaliana

Kentaro Ohyama, Hidefumi Shinohara, Mari Ogawa-Ohnishi & Yoshikatsu Matsubayashi

Nature Chemical Biology 5, 578 - 580 (2009) Published online: 7 June 2009 doi:10.1038/nchembio.182

Clavata3 forms a 13 amino acid arabinosylated glycopeptide

slide-31
SLIDE 31
slide-32
SLIDE 32

CLV3 mRNA CLV1 mRNA

slide-33
SLIDE 33

Over expression of CLAVATA3 causes depletion of the central zone of the meristem.

slide-34
SLIDE 34
slide-35
SLIDE 35

OC RZ

L1 L2 L3

(SC) PZ OP OP OP CZ

(a)

slide-36
SLIDE 36
slide-37
SLIDE 37

CLAVATA3 acts as a signal across the meristem, repressing WUSCHEL activity in the central zone of the shoot meristem.

slide-38
SLIDE 38

Auxin regulated feedback initiates shoot

  • utgrowth.

The Clavata and Wus genes form part of a feedback regulated circuit, controlling cell proliferation within each meristem Wus activates a local cytokinin response in the meristem

slide-39
SLIDE 39

Cytokinin
 signalling

slide-40
SLIDE 40

Walls around tumours — why plants do not develop cancer John H. Doonan and Robert Sablowski, Nature Reviews Cancer, 10: 794 (2010)

slide-41
SLIDE 41

Lecture 5: Formation and specification of lateral organs
