Autonomous Explorer Group 6 Michael Jun, Scott Hewson, Braedan Jongerius Our Project Build an autonomous robot that will avoid obstacles and build a 2D map of its environment. Robot Platform Rover 5 4 motors with encoders


slide-1
SLIDE 1

Autonomous Explorer

Group 6

Michael Jun, Scott Hewson, Braedan Jongerius

slide-2
SLIDE 2

Our Project

Build an autonomous robot that will avoid

  • bstacles and build a 2D map of its

environment.

slide-3
SLIDE 3

Robot Platform

Rover 5

  • 4 motors with encoders
  • Adjustable ride height
  • Motor rated voltage: 7.2V
  • Motor stall current: 2.5A
  • Output shaft stall torque: 10Kg/cm
  • Gearbox ratio: 86.8:1
  • Speed: 1Km/hr
slide-4
SLIDE 4

Optical Encoders

  • 1000 state changes per 3 wheel rotations
  • A and B XOR-ed together for interrupt
  • 5V dropped to 3.3V with voltage divider
slide-5
SLIDE 5

Ultrasonic Rangefinders

Maxbotix LV-EZ4

  • 42kHz Ultrasonic sensor
  • Low 2mA supply current
  • 20Hz reading rate
  • Analog Output - 10mV/inch
  • 6 to 254 inches (6.45m)
slide-6
SLIDE 6

Digital compass

Honeywell HMC6352

  • Simple I2C interface
  • 1 to 20Hz selectable update rate
  • 0.5 degree heading resolution
  • 1 degree repeatability
slide-7
SLIDE 7

Hardware Diagram

DE0 Nano Range Finders Compass Motor Pairs Voltage Divider 4 4 ADC Optical Encoders PWM I2C 8 XOR 1 1 5 1 4 Counters

slide-8
SLIDE 8

Sensors Layout

slide-9
SLIDE 9

Software

slide-10
SLIDE 10

Scalar to Vector Conversion

if(Command==NOT_TURNING) {

CarPositionX= cos((Angle+90)*PI/180)*DistanceTraveled+CarPositionX; CarPositionY=sin((Angle+90)*PI/180)*DistanceTraveled+CarPostionY; } LeftSensorX=cos((Angle+180)*PI/180)*LeftSensorScalar+CarPositionX; LeftSensorY=sin((Angle+180)*PI/180)*LeftSensorScalar+CarPositionY; RightSensorX=cos((angles)*PI/180)*RightSensorScalar+CarPositionX; RightSensorY=sin((angle)*PI/180)*RightSensorScalar+CarPositionY;

slide-11
SLIDE 11

Test Plans

  • Simulate inputs to test VHDL components
  • Measure outputs from sensors to verify function
  • Measure current draw from components
  • Have robot navigate simple obstacles
slide-12
SLIDE 12

The Future of the Project

  • SD card storage / wireless transmitting
  • Backtracking and/or nodes
  • Improved turning algorithms
slide-13
SLIDE 13
  • Rangefinder can't sense < 6 inches
  • Rangefinder beam pattern
  • Current draw
  • Retrieving and displaying mapped data in a

simple manner

The Current Challenges

slide-14
SLIDE 14

Questions?
