Autonomous driving made safe

tm

Founder, Bio

Celite Milbrandt

• Austin, Texas since 1998
• Founder of Slacker Radio

○ In dash for Tesla, GM, and Ford. ○ 35M active users 2008

• Chief Product Officer of RideScout

○ Acquired by MBUSA/Daimler 2014

Mission statement: Making autonomous vehicle travel safe

Current scenario verification challenges

• Large vehicle fleets
• Driver to manage in the event of system

error

• Expensive/ad hoc and incomplete.
• Many simple scenarios are missed
• Scenario generation and verification

happens in real time, and is not easily repeatable

Solution

• Automate scenario test generation for

planning testing

• Deep learning system for automated

scenario modification and re-generation.

• Leverages existing gaming systems to

enable multiphysics simulation

• Generation of realistic Lidar, Radar,

Camera, and IMU sensor information for perceptions system testing

• Enable automated vehicle control

performance metrics

• Fast error case regeneration, with

derivative regeneration

Testing Perception and Planning

Lidar Radar Inertial Measurement Unit (IMU) Camera Stereo Vision Simulation Engine Control System Under Test Ground Truth w/ Scene Labeling

Training Realistic Traffic Behavior

• Each agent/driver must have separate

behaviors

• Behaviors must be learned based on

different reward structures during training

• Examples of learned behaviors

○ Speeder ○ Brake Happy ○ Cell Phone Driver ○ Drunk Driver

• Behaviors are distributed based on the type
• f scenarios we want to test against
• Accidents result based on distribution of

agents with various learned behaviors

Reinforcement Trained Neural Network

• Input layer is an image in our case
• Output layers are log probability to apply

throttle or turn right.

• More negative log probabilities represent

apply brake or turn left, respectively

• Number of layers and number of neurons for

each layer are selected based on the convergence characteristic given your desired value function and or policy.

• Reward function is chosen based on desired

behavior you are trying to emulate

• Comment: control belongs in CPU,

computation lives in GPU

Neuron Updater rewards

Reinforcement Learning

• Simulator Interface

○ Socket-based ○ Python, C++ ○ Single simulator instance

• Per Agent Reward Modifiers

○ Library of reward modifiers

• Agent Hyperparameters

○ Continuous action space ○ Multiple concurrent agents

• Downsampling

○ Full resolution -> 80x80 ○ Top down view or perspective Agent Downsampler ↓N

nxm

Reward Modifier

P(throttle|s) P(turnRight|s)

Learning to Drive

Example of basic reward system

• Stay in lane
• Don’t hit other vehicles
• Maintain safe distance from leading vehicle
• Change lanes only to avoid collision

Basic System Details:

• Examples of our reward functions for different

types of drivers ○ Modulate reward with speed ○ Generate negative/positive rewards based

• n different collision boundaries

○ Generate reward for cause opposing cars to move, swerve, or change direction

Scalable multi-agent training and testing for A3C...

Example monoDrive Reinforcement Agent

Continuous action space Up to 20 agents (200 future) Reward based on agent reward function/modifier

Andrej Karpathy

# agent based on karpathy http://karpathy.github.io/2016/05/31/rl/

Try it out!

www.monodrive.io

• Download simulator at www.monodrive.io

○ Coming soon! ○ Early version available with request to info@monodrive.io

• Download sample agent and sample reward at:

www.github.com/celite/agent_cm.py

• System Requirements:

○ Windows, Mac, Ubuntu ○ Tensorflow-GPU ○ Or Tensorflow if you have more time than money ○ 32 Gb memory (64GB recommended)

• Example Agent is python based but can be

anything.

• Control Interface based on IP sockets

Agent Downsampler ↓N nxm Reward Modifier P(throttle|s) P(turnRight|s)

Contact Information

info@monodrive.io
